Title: Determination of 1'5m fluorescence lifetime in erbiumdoped glass using laserexcited fluorescence


1
Determination of 1.5??m fluorescence lifetime in
erbium-doped glass using laser-excited
fluorescence
  • Peter Bowyer
  • School of Physics and Astronomy
  • University of Southampton
  • Highfield
  • SO17 3JH

2
Outline
  • Introduction
  • Why laser-excited fluorescence
  • Introduction to the theory
  • Experimental setup
  • Experimental results
  • Analysis
  • Errors Conclusion

3
Introduction
  • Why laser-excited fluorescence?
  • Widely used in telecommunications industry for
    amplification of optical signals
  • When a weak optical signal passes through
    erbium-doped glass it stimulates the excited Er3
    ions to emit radiation of the same wavelength,
    amplifying the input signal
  • Why Erbium?
  • 4f shell incomplete and screening by outer 5s and
    5p shells
  • Leads to some metastable states which emit at
    correct wavelength
  • Why measure the decay time?
  • The longer the lifetime, the more efficient the
    device more suited for use in an amplifier

4
How fluorescence occurs
4F9/2
Excited states decay radiatively or vibrationally
to metastable state
4I9/2
4I11/2
4I13/2
Electrons in Er3 ions excited using input laser
Decays to ground state, fluorescing (1.55 ?m)
4I15/2
5
Glass samples
Sample A Erbium-doped fluorozirconate glass
(ZBLAN) Soft glass, ionically bonded 2 erbium
fluoride
Peter Bowyer Sample A has more radiative decay
as loads of metastable states Sample B is with
tougher bonds more vibrational decay possible
Sample B Lead germanate glass relatively hard
oxide glass, covalent bonding 0.1 Er2O3
6
Experimental setup
  • Schematic diagram of equipment

Peter Bowyer Laser is square-wave
pulsedcharges crystal, which decays when laser
not on
Final measurements performed in darkroom
7
Experimental Results
Sample B
Sample A
1 vertical square 500mV
1 vertical square 200mV
Horizontal time scale is identical (10ms per
square)
8
Analysed Results
Decay occurs exponentially
Lifetime of sample A
Lifetime of sample B
The uncertainty was calculated using a stepwise
approach, taking pairs of points
9
Errors Conclusion
  • Darkroom did not cut out all light
  • Method of calculating errors not best suited to
    data
  • Alignment of laser through centre of crystal
    proved impossible

Conclusion Sample A (soft glass with 2 Er3) is
more suitable for use as an amplifier
