Title: Specifications Continued


1
Specifications- Continued
  • Francis Suraweera
  • School of CIT
  • Griffith University
  • Nathan 4111
  • These notes are derived from the book Program
    Derivation by Geoff Dromey

2
Role of the Specification
  • What do we mean by
  • A program is correct?
  • It can be only correct wrt some separate
  • entity its specification.

3
Specification cont.
  • Consider the following

Q
R
FINAL STATES Output data
INITIAL STATES Input data
Program
The state-model for a program specification
4
Specifications Cont.
  • The two sets of interest are
  • One describing the allowable initial states or
    inputs, or data supplied to the program
  • Another describing the corresponding final
    states, or required output or data produced by
    the program.

5
Specification cont.
  • Most problems we are concerned with can be
    specified by two predicates
  • A precondition, Q characterizing the allowable
    initial states
  • A postcondition, R characterizing the allowable
    final states.

6
Specification Cont.
  • The pair (Q, R) define a specification
  • To satisfy a specification
  • the input must make Q true, and
  • the output must make R true.

7
Specification Cont.
  • A predicate is a condition that is either true or
    false depending on the values of its variables.
  • Example
  • N gt 0
  • The above (predicate) is true for N 1, 2, 3,
  • and false for N 0, -1, -2, -3 .etc.

8
Example of a Specification
  • Sorting of N integers
  • Precondition, Q
  • there is at least one integer to be sorted
  • Postcondition, R
  • Rearrange the input data so that the integers
  • form a sequence from the smallest to the
  • largest.

9
Sorting of N integers cont.
  • Q N ? 1
  • R (?j 1 lt j ? N aj-1 ? aj ) ? perm(a, A)

10
The Design Process
  • Design involves two essential things
  • Decomposition of a problem into simpler
    sub-problems
  • Refinement of strategy for solving a problem
  • (or sub-problem) by introducing additional
  • detail i.e., make the strategy more explicit

11
Example Building a house
  • The process starts with client visiting an
    architect.
  • The requirements are as follows
  • 3 bedrooms, (all to be in one area) and 2
    bathrooms,
  • A large lounge,
  • A kitchen with large bench space,
  • A dinning room

12
Example Building a house
  • Architects proposed floor plan

Bath
Lounge
Bedroom
Bedroom
Kitchen
Bedroom
Dinning room
Bath
13
Building the house contd.
  • The architect then consults the client
  • This is to check clients satisfaction with the
  • plan
  • If the client is not happy then refine the
  • plan.

14
Example Building a house
  • Architects refined floor plan

Bath
Lounge
Bedroom
Bedroom
Kitchen
Bedroom
Dinning room
Bath
15
Lessons for the program designers
  • L1 have a detailed plan and design document
    before building the house
  • L2 the process of creating a plan and developing
    a design from the plan is separated from the
    process of building and
  • L3 the detailed design is arrived at by a
    process of refinement.

16
Problem1
  • We have a group of people scattered among several
    threatened locations A, B, and C each of which is
    progressively further from some safe destination,
    D.
  • To save the people, they must be transported from
    where they are (i.e., A, B, or C) to the safe
    destination, D.
  • Assume that in order to transport the people to
    D, it is necessary to build a makeshift road
    network through to D.

17
Problem1 continued.
  • Consider the following

D
C
B
A
Possible starting locations
Destination location
18
Problem1 Refinement1.
  • Precondition Q1
  • 1(a) Build a road from A to D, the destination
  • 1(b) Transport the people from A to D

A
D
19
Problem1 continued.
  • Precondition Q1
  • This mechanism will solve the problem in a
    restricted circumstance
  • the whole population lives at location A
  • Note the above refinement will contribute to the
    general solution to the problem.

A
D
20
Problem1 continued.
  • NOTE
  • A refinement such as
  • build a road from C to B
  • is rejected at this stage because it could not
    establish the postcondition.

A
C
B
21
Problem1 Refinement 2.
  • Precondition Q2
  • 2(a) Build a road from B to A
  • 2(b) Transport the population from B to A,
  • and then to D.

B
A
22
Problem1 Refinement 2.
  • Precondition Q2
  • Again, this mechanism will solve the problem in a
    restricted circumstance that
  • the whole population lives either at A or B

B
A
D
23
Problem1 Refinement 3.
  • Precondition Q3
  • 3(a) Build a road from C to B
  • 3(b) Transport the population from C to B,
  • and then on to A, and subsequently D.

C
B
24
Problem1 continued.
  • With refinements 1, 2, and 3 - (Q1, Q2, Q3)
  • We have a mechanism to solve the problem in
  • the circumstance that
  • - the whole population lives at either A, or B,
    or C.

D
C
B
A
25
Problem1 continued.
Q3
refinement3
refinement2
Q2
refinement1
Q1
Goal
Distance from the Goal
26
Pre- and Postconditions
  • Definition
  • A condition (precondition or postcondition) is
    said to be stronger if it is true for fewer
    cases.

27
Pre- and Postconditions
  • For example, the condition
  • N gt 0 which is true for N 1, 2, 3,
  • but excludes N 0
  • is stronger than the condition
  • N ? 0 which is true for N 0, 1, 2, 3,
  • NOTE N ? 0 is weaker than N gt 0.

28
Weakest Precondition Calculations
  • Example
  • Consider the problem of computing the quotient,
    q, and the remainder, r, when a natural number X
    is divided by a divisor D.
  • This problem can be solved by assigning to r the
    value of X and then repeatedly subtracting
    multiples of D from r until r is less than D.

29
Weakest Precondition Calculations - continued
  • Suppose X 27 and D 6

r q X D
27 0 27 6
21 1 27 6
15 2 27 6
9 3 27 6
3 4 27 6
The remainder is 3 and the quotient is 4
30
Weakest Precondition Calculations - continued
The relation between q, r, X and D is given by
X q.D r .(1) this is called an
invariant. A simple program for this is r X
q 0 While r ? D do r r
D q q 1 End
31
Commands by calculation
  • If q and r represent different values of the
  • q and r variables, then the following holds
  • X q.D r (2)
  • Now suppose we also know that the equation
  • r r D (3)
  • holds. (corresponds to the program command).
  • Show how to obtain q q 1

32
Notation for substitution
  • If P is a formula, x is a variable, and a is a
    term then is the formula that results in when
    each free occurrence of x in P is replaced by a.
  • Example Given that P is (?y)(y gtx)
  • P(x/2) (?y)(y gt 2)
  • P(x/xz) (?y)(y gt xz)

x
P
a
33
Assignment statement
  • assigment identifier expression
  • Example
  • s s i
  • i i 1

34
If statement
  • An IF statement allows the selection and
    execution of just one of a number of possible
    commands S1, S2, , SN.
  • To define an IF statement we need the concept of
    a guarded command.
  • A guarded command is of the form
  • Guard ? statement

35
If statement
  • The guard is a predicate which evaluates to
    either true or false. The statement to the right
    of the arrow is executed only if the guard
    evaluates to true.

36
If statement
  • For a set of guards B1, B2, , BN and a set of
    statements S1, S2, , SN we have
  • If B1 ? S1
  • B2 ? S2
  • B3 ? S3
  • ....
  • BN ? SN
  • fi

37
DO statement
  • For a set of guards B1, B2, , BN and a set of
    statements S1, S2, , SN we have
  • Do B1 ? S1
  • B2 ? S2
  • B3 ? S3
  • ....
  • BN ? SN
  • oD

38
Weakest Precondition and the state model
  • What, for a given initial state, will be the
  • corresponding final state produced by the
  • program?
  • Given some set of final states what corresponding
    initial states would produce those final states
    when transformed by a given program?

39
Weakest Precondition
  • For a terminating program statement, S,
  • and a required postcondition R,
  • wp(S, R)
  • symbolizes the weakest precondition such
  • that execution of S is certain to establish
  • the postcondition.

40
Properties of Weakest Precondition
  • Law of the excluded miracle (1)
  • There are no states in which the execution of a
  • mechanism S can begin and guarantee to
  • terminate in a state satisfying FALSE.
  • NO proofs are given. (For proofs please refer to
  • Program Derivation by Geoff Dromey.

41
Properties of Weakest Precondition
  • Law of conjunction (2)
  • For a mechanism S and a postconditions R1 and
  • R2 the following equivalence holds
  • wp(S, R1) ? wp(S, R2) ? wp(S, R1 ? R2)

42
Properties of Weakest Precondition
  • Law of disjunction (3)
  • For a mechanism S and a postconditions R1 and
  • R2
  • wp(S, R1) ? wp(S, R2) ? wp(S, R1 ? R2)

43
Properties of Weakest Precondition
  • Law of monotonicity (4)
  • For a mechanism S and a postconditions R1 and
  • R2 the following relation applies
  • (R1 ? R2) ? (wp(S, R1) ? wp(S, R2))

44
The Weakest Precondition Concept
  • Given the operation
  • add 4 marbles to the existing number of
    marbles
  • and that after the operation there are exactly 6
    marbles how many marbles must there have been
    before execution of the operation?

45
The Weakest Precondition Concept - Continued
  • The answer is 2.
  • Let x number of marbles to start with
  • Then
  • x ???
  • S x x 4
  • x 6

46
The Weakest Precondition Concept
  • The precondition calculation
  • x ???
  • S x x 4
  • x 6
  • ----------------------------------
  • wp( x x 4, x 6)
  • ? x 4 6
  • ? x 2 (note ? means equivalent)

47
Weakest Precondition Examples
  • Complete the following weakest precondition
    calculations.
  • wp( i 3, i 3)
  • wp( i i 1, i 3)
  • wp( i j 1, i 3)

48
Weakest Precondition Examples
  • Complete the following weakest precondition
    calculations.
  • wp( i 3, i 3)
  • ? 3 3
  • ? true

49
Weakest Precondition Examples
  • Complete the following weakest precondition
    calculations.
  • wp( i i 1, i 3)
  • ? i 1 3
  • ? i 2

50
Weakest Precondition Examples
  • Complete the following weakest precondition
    calculations.
  • wp( i j 1, i 3)
  • ? j 1 3
  • ? j 2

51
Weakest Precondition Examples
  • Determine the weakest precondition wp(S, R) for
    the following commands S and postconditions R.
  • S R
  • i i 2 i gt 1
  • i i 2 j j 2 i j 0
  • ai 1 ai aj

52
Weakest Precondition Examples
  • Solution to Problem
  • S R
  • i i 2 i gt 1
  • ---------------------------------------------
  • wp(i i 2, i gt 1)
  • i2 gt 1
  • ? i gt -1

53
Weakest Precondition Examples
  • Solution to problem
  • i i 2 j j 2 i j 0
  • --------------------------------------------------
    -
  • wp(ii 2 jj 2, i j 0)
  • For these problems, apply wp(S1 S2, R)
  • ? wp(S1, wp(S2, R))

54
Weakest Precondition Examples
  • Solution
  • wp(S1, wp(S2, R))
  • ? wp(i i 2, wp(j j 2, i j 0)
  • ? wp(i i 2, i j 2 0)
  • ? (i 2 j 2 0)
  • i j 0
  • NOTE this method can be generalized to
  • handle wp calculations for S1 S2 S3 etc.

55
Weakest Precondition Examples
  • Given
  • S ai 1 R ai aj
  • ----------------------------------------------
  • wp(ai 1, ai aj)
  • ? 1 aj

56
Weakest Precondition Examples
  • Try this problem
  • ???
  • a BC (S1)
  • b a D (S2)
  • Postcondition 2b gt X

57
Weakest Precondition Examples
  • Step1
  • wp(b a D, 2b gt X)
  • corresponds to calculation of wp(S2, R)
  • ? 2(a D) gt X
  • Step2
  • wp(a BC, 2(a D) gt X)
  • ? 2(BC D) gt X

58
Strongest Postcondition Calculations
  • Notation
  • sp(P, S) ? reasoning forwards
  • Useful in doing verification of programs
  • wp(S,R)gtreasoning backwards

59
Strongest Postcondition Calculations
  • Suppose we have
  •
  • P x gt 3
  •
  • x x 2
  •
  • R ????

60
Strongest Postcondition Calculations
  • R must be expressed in terms of the new x
    (eliminate old x)
  •
  • x x 2 and so we get
  •
  • xold x -2
  •
  • Substituting for xold in P we get
  •
  • R x - 2 gt 3 x gt 5

61
Strongest Postcondition Calculations
  • Strongest Postcondition
  •   sp( x gt 3, x x 2) x gt 5
  • P xold gt 3
  •
  • x xold 2
  •
  • R x gt 5

62
Strongest Postcondition Calculations
  • P Precondition
  • S1
  • S2
  • sp(P, S1 S2) ? ???
  • To do this apply
  • sp(P, S1 S2) ? sp(sp(P, S1), S2)

63
Strongest Postcondition Calculations Example
  • Pre p xi
  • p p x
  • i i 1
  • Post ???
  • ------------------------------------
  • sp(P, S1 S2) ? sp(sp(P, S1), S2)
  • Step1
  • sp(p xi, p p x)

64
Strongest Postcondition Calculations Example
  • Step1
  • sp(p xi, p p x)
  • ? p xi x
  • Step2
  • sp(p (i 1)x, i i 1 )
  • ? i (p/x 1) 1
  • ? i p/x
  • ? p xi
Write a Comment
User Comments (0)
About PowerShow.com
