CS285

1
CS285

• Designing Viae Globi
• (Roads on a Sphere)
• Carlo H. Séquin
• University of California, Berkeley
• Inspired by
• Brent Collins
• Gower, Missouri

2
Hyperbolic Hexagon by B. Collins

• 6 saddles in a ring
• 6 holes passing through symmetry plane at 45º
• wound up 6-story
  Scherk tower
• Discussion What if
• we added more stories ?
• or introduced a twist before closing the ring ?

3
Closing the Loop
straight or twisted
4
Sculpture Generator I, GUI
5
Base Geometry One Scherk Story

• Hyperbolic Slices gt Triangle Strips
• Pre-computed -- then warped into toroid

6
Brent Collins
Hyperbolic Hexagon II
7
Hyper-Sculpture Family of 12 Trefoils
W2
W1
B1 B2 B3
B4
8
Brent Collins Pax Mundi1997 wood, 30diam.
2006 Commission from HR Block, Kansas
City to make a 70diameter version in
bronze. My task to define the master
geometry. CAD tools played important role.
9
How to Model Pax Mundi ...

• Already addressed that question in 1998
• Pax Mundi could not be done with Sculpture
  Generator I
• Needed a more general program !
• Used the Berkeley SLIDE environment.
• First Needed to find the basic paradigm ? ? ?

10
Sculptures by Naum Gabo

• Pathway on a sphere
• Edge of surface is like seam of tennis- or
  base-ball
• ? 2-period Gabo curve.

11
2-period Gabo Curve

• Approximation with quartic B-splinewith 8
  control points per period,but only 3 DOF are
  used (symmetry!).

12
4-period Gabo Curve

• Same construction as for as for 2-period curve

13
Pax Mundi Revisited

• Can be seen as Amplitude modulated, 4-period
  Gabo curve

14
SLIDE

• SLIDE Scene Language for Interactive Dynamic
  Environments
• Developed as a modular rendering pipelinefor our
  introductory graphics course.
• Primary Author Jordan Smith
• Based on OpenGL and Tcl/tk.
• Good combination of interactive 3D graphicsand
  parameterizable procedural constructs.

15
SLIDE Example Klein Bottle

• Final Project CS 184, Nerius Landys Shad
  Roundy

16
SLIDE Example Bugs Life

• Final Project CS 184, David Cheng and James Chow

17
SLIDE as a Design Tool

• SLIDE originally a modular rendering tool.
• Later enhanced to serve as a CAD tool
• Spline curves and surfaces
• Morphing sweeps along such curves
• 3D warping module (Sederberg, Rockwood)
• Many types of subdivision surfaces
• These are key elements for a 2nd Generation
  Sculpture Generator

18
SLIDE-UI for Knot Generation
19
SLIDE-GUI for Pax Mundi Shapes
Good combination of interactive 3D graphicsand
parameterizable procedural constructs.
20
2-period Gabo sculpture
Tennis ball or baseball seam used as sweep
curve.
21
Viae Globi Family (Roads on a Sphere)
2 3 4
5 periods
22
Via Globi 5 (Virtual Wood)
Wilmin Martono
23
Modularity of Gabo Curve Generator

• Sweep Curve Generator
• Gabo Curves as B-splines
• Cross Section Fine Tuner
• Paramererized shapes
• Sweep / Twist Controller

24
Sweep / Twist Control

• How do we orient, move, morph ...the cross
  section along the sweep path ?

Natural orientationwith Frenet frame
Torsion MinimizationAzimuth tangential /
normal
900 of twistadded.
25
Extension Free-form Curve on a Sphere
Spherical Spline Path Editor (Jane Yen)
Nice smooth interpolating curves through sparse
data points
26
Many Different Viae Globi Models
27
Maloja
28
Extending the Paradigm Aurora-M

• Simple path on sphere,
• but more play with the swept cross section.
• This is a Moebius band.
• It is morphed from a concave shape at the bottom
  to a flat ribbon at the top of the flower.

29
Paradigm Extension Sweep Path is no longer
confined to a sphere!

• Music of the Spheres (Brent Collins)

30
Allows Knotted Sweep Paths

• Chinese Button Knot

31
Really Free-form 3D Space Curves

• Figure-8 knot

32
Using Another Cross Section

• Galapagos 6

33
Target Geometry

• Constraints
• Bronze, 70 diameter
• Less than 1500 pounds
• Less than 50000
• Maintain beauty, strength
• Minimize master geometry

34
Emulation

• Use smoother quintic spline
• Make 4 identical parts(needs extra control
  point)
• Add a few warp parameters

35
Emulation Define Master Pattern

• Master to make a mold from.

Alignment tab

• Use 4 copies.

36
Model of Master Part Made with FDM

• 4 pieces make the whole sculpture

37
Joe Valaseks CNC Milling Machine

• Styrofoam milling machine

38
Design of Two-Part Master

• Alignment tabs for easy assembly

39
Subdivide into Two Master Segments
40
Machined Master Pattern 2
41
(Cut) Master ? Silicone Rubber Mold
42
Mold ? Several (4) Wax Copies
43
Spruing the Wax Parts for Casting
44
Ceramic Slurry Shell Around Wax Part
45
Shell Ready for Casting
46
Casting with Liquid Bronze
47
The Freed Bronze Cast
48
Assembling the Segments
49
The Growing Ribbon
50
The Single Support Point
51
Grinding the Welded Seams,Polishing the Surface
52
Applying Patina
53
Ready for Shipping
54
The Move Around the Building (Jan.18)
55
Front Door

• HR Block Building

56
Steve Tightening the Bolts
57
Brent Polishing Our Baby
58
(No Transcript)
59
(No Transcript)
