PIPISTREL d'o'o' AJDOVSCINA

1
PIPISTREL d.o.o. AJDOVSCINA GORISKA CESTA 50
A SI-5270 AJDOVSCINA SLOVENIA e-mail
pipistrel_at_siol.net tel [phone] fax
386 5 36 61 263
2
OPTIONAL FEATURES EQUIPMENT 2
AVIONICS CATALOGUE 2009
3

• autopilot Trutrak Digitrak
• (directional - ailerons only)

• autopilot Trutrak Digiflight II G
• (directional, altitude hold, GPS steering)

4

• air speed indicator
• (diameter 80mm,
• 0-250 km/h, 0-140 kts)
• air speed indicator
• (diameter 58 mm,
• 0-250 km/h, 0-140 kts)

5

• altimeter
• (diameter 80mm, 0-10.000 m, 0-20.000 ft)
• altimeter
• (diameter 58 mm, 0-3000 m, 0-10.000 ft)

6

• variometer
• diameter 80mm, -5 m/sec
• (-10 kts, -1000 fpm)
• variometer
• diameter 58 mm, -5 m/sec
• (-10 kts, -1000 fpm)

7
Electronic variometer LXsi 160 electronic with
acoustic vario
Electronic variometer ILEC SC-7 (diameter 80 mm)
with acoustic vario
8
Variometer tail static probe with installation
9
fuel pressure gauge
10
manifold pressure gauge
11
water temperature indicator
12
(photo coming soon)
outside temperature indicator
13
(photo coming soon)
oil thermostat
14
Dynon Avionics EFIS-D100
Dynon Avionics EFIS-180 - Single Screen (without
Brauniger)
Dynon Avionics EFIS-100 and EMS Dynon 120 -
Double Screen (without Brauniger)
15
artificial horizon (Trutrak ADI)
16
transponder Microair C mode with pitostatic
encoder, aerial, wiring and installation
17
transponder Filser TRT800 S-mode with pitostatic
encoder, aerial, wiring and installation
18
Radio

• including
• aerial
• two headsets HD-1000
• intercom

Following models available (see next slide)
19
radio Filser ATR 500
radio Microair VHF 760
radio XCOM 760
radio Icom IC-A200
radio Filser ATR 833
20
overhead installation
GPS Garmin 496 incl. installation and connection
to the autopilot (if applicable)
dashboard installation
21
ELT AmeriKing AK 450 121.5 MHz with installation
22
(picture coming soon)
ELT Kannad 406 XS.3 Personal locator beacon, 406
MHz
23
Radio wirings with antenna/Radio wirings with
antenna integrated into the rudder fin
24
(picture coming soon)
Transponder wirings with pitostatic encoder and
aerial
25
Additional holes for the instruments
26
PIPISTREL d.o.o. AJDOVSCINA GORISKA CESTA 50
A SI-5270 AJDOVSCINA SLOVENIA e-mail
pipistrel_at_siol.net tel. [phone] fax.
386 5 36 61 263
