Systems-of-Systems Analysis of Ballistic Missile
Defense Architecture Effectiveness through
Surrogate Modeling and Simulation
SysCon 2008 IEEE International Systems
Conference Montreal, Canada April 710, 2008
Paul Miceli, W. Dale Blair, Phil West Georgia
Tech Research Institute Georgia Institute of
Technology Atlanta, Georgia 30332-0801

• Tommer Ender, Ryan Leurck,
• Brian Weaver, Dimitri Mavris
• Aerospace Systems Design Laboratory
• School of Aerospace Engineering
• Georgia Institute of Technology
• Atlanta, GA 30332-0150

2
Introduction

• Realizing an effective BMD system has been a goal
  of U.S. military planners since the first German
  V-2 rockets began falling on London during WWII
• Emergence of new nuclear threats
• North Korean ballistic missile tests in summer of
  2006
• Suspected ongoing nuclear weapons development
  program in Iran

An integrated, layered Ballistic Missile Defense
System to defend the United States, its deployed
forces, allies and friends from ballistic
missiles of all ranges and in all phases of
flight. -MDA
3
Challenges

• No historical database of working BMD systems
  from which designers can generate trends or
  rules of thumb to help reduce design cycle time
• Scope of the problem limits physical testing
• Full-scale test of realistic threat scenario
  expensive
• Modeling and simulation (MS) required
• Modeling of entire BMD scenario too
  computationally expensive to be useful in
  earliest stages of design

Emerging techniques for quickly evaluating the
performance of complex systems-of-systems can be
used to study BMD
4
Architecture Diagram
Analysis codes for each component are extremely
complex
Even if all tools could be successfully
integrated, runtime would be prohibitive
www.mda.mil
5
Systems-of-Systems Architecture Analysis

• Systems-of-Systems
• Elements that are operationally and managerially
  independent 2
• Collaborating only through information exchange
• Capability of the integrated whole to produce
  results greater than sum of the individual
  components

BMD is an SoS problem targets, interceptors,
radars, and launch platforms evolve independent
of one another

• Architecture Analysis
• SoS architecture acts as a framework that directs
  the interaction of components with their
  environment, data management, communication, and
  resource allocation 3
• The system-of-systems architecture defines the
  interfaces and composition which guides its
  implementation and evolution ?4

Allocation of functionality to components and
inter-component interaction, rather than the
internal workings of individual components
6
Current Approaches for BMD Architecture Analysis

• Wilkening BMD effectiveness determined by
  modeling the integrated system as a series of
  Bernoulli trials 5
• Required numbers of interceptors needed as a
  function of key parameters, target properties and
  rules of engagement
• Ben-Asher applying SoS design principles when
  defining architecture enhances the probability of
  creating successful BMD systems 6
• Limited to defining responsibility sharing rules
  and interfaces between system level components
• Parnell methods should enable interaction
  between decision makers, operators, and
  developers, through real-time what-if scenarios
  7

Common Issue Rapid architecture analysis of the
entire BMD problem sacrifices MS accuracy
7
Functional Decomposition
Search/Scan

• A series of battle management elements that
  execute in a serial process
• Comparable to standard kill chain
• Execution of any element is conditional on the
  success of the previous element

Detect
Report
Locate
Track
Develop track
Report
Associate
Sensor Fusion
Fuse
BMD Battle Management
Report
Prioritize Threats
Fire Control
Identify Candidate Platforms
Develop Fire Control Solution
Launch
Update target/track
Engage
Fly to intercept
Activate seeker
Discriminate target
Endgame
Kill Assessment
NOTE No claim is made that the complete BMD
problem is represented in this study
Determine Kill
Report
8
Proof-of-Concept Scenario

• Used to scope the elements of the problem
  decomposition that are necessary to be studied in
  detail

• 4 Threats
• Launched near simultaneously
• 2 Ships
• Stationed within an operational area
• Sensor/shooter platforms
• 1 Land Based Interceptor
• Fixed location
• Sensor/shooter platform

Four near-simultaneous Threat Launches
Operational Area for two battleships
Land Based Interceptor
9
Surrogate Models

• Surrogate models enable rapid manipulation of
  any modeling and simulation tools
• Equation based regressions of complex codes
• Negligible loss in accuracy of original tools
• Can be executed in fractions of a second instead
  of hours or days
• On-the-fly tradeoffs yield results that otherwise
  may not have been discovered
• Enables decision making across a
  systems-of-systems hierarchy

Bringing Modeling Simulation Forward in the
Decision Making Process
10
Neural Network Surrogate Models

• Any regression model must make assumptions as to
  the behavior of a measured response and accept a
  certain amount of error
• i.e. Response Y roughly varies linearly with
  variables X1 and X2
• Polynomial based Response Surface methods are
  proven
• How does one create regressions in which a
  functional form behavior assumption is not
  possible?

Design Space Behavior
Regression Functional Form
How do we fit this?
Equation Form
Solve for
Y mxb
m, b
Y ax2bxc
a, b, c
Y ax3 bx2 cx d
a, b, c, d
Neural Network
Linear Fit
Quadratic Fit
Cubic Fit
Neural Networks are emerging as a useful way of
creating highly nonlinear regression models
11
Neural Network Surrogate Models
Neural Network Structure

• A Neural Network is a computational
  architecture based on the design of the
  interconnections of neurons in our brains
• The elements of Neural Networks were inspired by
  biological nervous systems, in which the
  connections between elements determines the
  network function
• It is a set of nonlinear equations that predict
  output variables from a set of given input
  variables using layers of linear regressions and
  S-shaped logistic functions

Input Layer
Hidden Layer
Output Layer
H1
X1
H2
X2
H3
Y1
H4
X3
Single Response

H5

Xn
Pattern of Connections Found by Training
Hn
of Hidden Nodes Defined by Optimization
12
Modeling and Simulation (MS)

• Goal of BMD simulation is to model protection of
  some area from incoming targets by engaging them
  with interceptors
• Consider MS of all elements within the kill
  chain

Interceptors
Scenarios
Sensors
Tracking
Sensor Fusion
Battle Management
Sensor 1
T 1
Sensor 2
T 2
EVALUATE Intercept. Success
.
.
.
.
.
.
Sensor n
T n
Performance Metrics

• Defended Area
• Leakers / Interceptors . .

13
Computational Complexity of BMD Modeling and
Simulation
Due to computational complexity BMD simulation is
very computationally intensive and time consuming

• Run Time Example
• Consider 9 TBM Threats, 16 Sensors all in fixed
  locations 1 set of Monte Carlo (MC) runs 10
  Hours
• Parameter Variation
• Hold launch points constant, vary impact among 5
  different locations
• Move each radar though 6 locations
• Corresponding Run Time
• 10hrs 59 166 3.3x1015 hrs gt 37,000,000
  years
• (if run on 1,000 parallel machines)
• Many other system parameters of interest remain


14
Target Detection and Tracking

• Due to computational complexity most tools for
  studying BMD system performance are either
• Truth Based
• Any target in a systems field of view (FOV) if
  presumed to be under track
• Ignores reality, since the BMD system performance
  is highly dependent on ability of system to
  detect and track targets
• Performance Prediction Based
• Based on sensor and tracking parameters, however
• Do not require Monte Carlo Simulations
• Have fast run times
• Typically make many assumptions

Performance Prediction Target Detection
Tracking Techniques are Used for this Study
15
Sensor Model

• Two Phased Array Radars
• Notional ground based X-band radar
• Notional ship based S-band radar with four array
  faces
• Assumptions
• Perfect resolution so that merged measurements
  not an issue
• No false alarms
• Probability of detection is 1 given a sufficient
  signal-to-noise ratio

• Sensor Parameters
• Sensor / Target Geometry

• Monopulse Parameters
• Sensor / Target Geometry
• Off bore-sight steer angle

Local Tracker Performance Prediction
Compute Measurement Covariance
Compute SNR
16
Local Tracker Performance Prediction

• Based on a measurement covariance and track
  filter parameters, tracker performance is
  expressed as a noise only covariance and maneuver
  lag
• Assumptions
• Perfect measurement to track association
• Steady State
• Constant update rate
• Critical in the future to relax assumption of
  perfect measurement to track association
• Closely spaced objects a BIG deal in BMD

17
System Track Performance Prediction

• Centralized Multi-Sensor Track Fusion
• Fuse all local tracks at a centralized location
• Performance prediction techniques used to assess
  the quality of the fused tracks
• Reporting Responsibility
• System track selected as the best of all local
  tracks for a given object under tracks
• Used in Link-16
• Architecture level effects?

Two network level tracking schemes considered
18
Engagement Planner Analysis

• Define the battle space as the set of all
  possible launch solutions
• Computed for each interceptor and target pair for
  all times at which, target is presumed to be in
  coast phase

Predicted Intercept Point 1
Predict target trajectory using ballistic
extrapolation
X
Predicted Intercept Point N
X
Fly-out fan trajectory
19
Engagement Planner Analysis

• For each possible intercept as determined by
  fly-out fans
• Compare the maneuverability of the interceptor to
  a critical threshold
• Threshold a function of predicted system track
  accuracy
• Compare at three key decision points
• Interceptor Launch Time
• Interceptor Burnout Time
• Interceptor Seeker Activation
• A launch solution is possible if key decision
  points pass
• Compute Probability of Kill (PK)

20
Probability of Kill
Pib
PK is a function of track covariance and
interceptor seeker field of view (FOV)
Align track covariance with interceptor body frame
Pecef
U
V
W
21
Probability of Kill
Pib
Compute distance in each cross range coordinate
DcrV
V
Area under curve is Gaussian CDF
f Seeker Field of View
W
22
Fire Control

• Single engagement manager supervising
  interceptor-target assignments over all platforms
• Utilized a shoot early strategy
• Threats were engaged when a shot was available
  with a Pk exceeded a threshold
• Time dependent threshold used to instill
  confidence in each chosen shot while being more
  accepting of low Pk as the threat nears
• Shots constrained by
• Availability of platforms
• Interceptors currently engaging threat
• Pk for a given shot

23
Results Placement Trade

• Surrogate models of MS used for Monte Carlo
  system performance assessment of ship operational
  area
• 10,000 Ship/Sensor2 (S2) locations are considered
  for a given single Ship/Sensor 1 (S1) location
• Ground Based Interceptor/Sensor (S3) fixed all
  times
• System performance, probability of zero leakers
  (P0L), provides operational contours

Expanded Operational Area
New S1 Location
24
Results Tracking Method Trade

• With the current Reporting Responsibility
  architecture, it is not possible to get a high
  confidence of success
• Holding the interceptor and fire control systems
  constant, surrogates are used to explore
  different sensor architectures

Reporting Responsibility
Track Fusion
P0L Results Min 0.00 Max 0.60 Avg 0.11
P0L Results Min 0.53 Max 0.87 Avg 0.79
Track fusion vastly improves P0L in terms of
capability and robustness
25
Results Number of Sensors Trade

• Track fusion results show the system performance
  is not sensitive to S2 location
• Surrogates are used to explore the number of
  sensors used

• Models were generated with the forward deployed
  land based sensor removed

• Two ship track fusion architecture yields
• Sizeable operational area
• Improved confidence over three platform reporting
  responsibility
• Note Two ship track fusion requires more
  communications bandwidth and different processing

Probability of Zero Leakers (P0L)
2 Platform Track Fusion 0.00 0.83 0.20
3 Platform Report. Responsibility 0.00 0.60 0.11
Min Max Avg
26
Conclusions

• Surrogate models used to greatly improve runtime
  of large system-of-systems simulation with
  negligible loss in fidelity
• Enabled real-time system-of-systems level
  architectural trade studies utilizing accuracy of
  high-fidelity MS tools
• Asset placement trade
• Tracking method trade
• Number of sensors trade
• Plan to increase fidelity of various modeling and
  simulation of current BMD elements

27

• Supporting Slides

28
Engagement Planner Analysis
Condition 1 for launch
Position Covariance
Track covariance extrapolated to predicted
intercept
Track covariance at interceptor launch
29
Engagement Planner Analysis
Condition 2 for launch
Position Covariance
Track covariance at interceptor burnout
Track covariance extrapolated to predicted
intercept
30
Engagement Planner Analysis
Condition 3 for launch
Position Covariance
Track covariance extrapolated to predicted
intercept
31
References

• Myers, R. H. and Montgomery, D. C., Response
  Surface Methodology Process and Product
  Optimization Using Designed Experiments. New
  York John Wiley Sons, Inc, 1995.
• Maier, M. W., Architecting Principles for
  Systems of Systems, in Proceedings of the Sixth
  Annual International Symposium, International
  Council on Systems Engineering, Boston, MA, 1996.
• Clements, P., Krut, R., Morris, E., and Wallnau,
  K., The Gadfly An Approach to
  Architectural-Level System Comprehension, Fourth
  IEEE Workshop on Program Comprehension, Berlin,
  March, 1996.
• Chen, P., Gori, R., and Pozgay, A., Systems and
  Capability Relation Management in Defense
  Systems-of-System Context, , Proceedings of The
  Ninth International Command and Control Research
  and Technology Symposium, Copenhagen, Denmark,
  2004.
• Wilkening, D.A., A Simple Model for Calculating
  Ballistic Missile Defense Effectiveness, Science
  Global Security, Volume 82, 1999, pp183-215.
• Ben-Asher, J.Z., Systems Engineering Aspects in
  Theatre Missile Defense-Design Principles and a
  Case Study, Systems Engineering, Vol. 7, No. 2,
  2004. pp186-194.
• Parnell, G.S., Metzger, R.E., Merrick, J.,
  Eilers, R., Multiobjective Decision Analysis of
  Theater Missile Defense Architectures, Systems
  Engineering, Vol. 4, No. 1, 2001, pp24-34.
• Ball, R. E., The Fundamentals of Aircraft Combat
  Survivability Analysis and Design. AIAA, 2003.
• Ender, T.R., A Top-Down, Hierarchical,
  System-of-Systems Approach to the Design of an
  Air Defense Weapon. PhD thesis, Georgia
  Institute of Technology, 2006.
• Bar-Shalom, Y., Li, X.R, and Kirubarajan, T.
  Estimation with Applications to Tracking and
  Navigation, John Wiley and Sons, Inc. New York,
  NY, 2001.
• Bar-Shalom, Y., and Blair, W.D., editors,
  Multitarget-Multisensor Tracking Applications
  and Advances III, Norwood Massachusetts Artech
  House (2000).
• Blair, W.D. Fixed-Gain, Two-Stage Estimators for
  Tracking Manuevering Targets, IEEE Transactions
  On Aerospace and Electronic Systems, July 1993,
  pp. 1004 1014
• Blair, W.D. and Miceli, P.A., Performance
  Prediction of Multisensor Tracking Systems for
  Maneuvering Targets, submitted to the Journal
  for Advances in Information Fusion, April 2008.

32
Presenter Instructions (IEEE)

• Oral presentation consists of 45 minutes for
  presentation of the problem, the background, the
  innovative approach, the new results, the
  comparative evaluation and questions from
  attendees. Acceptable formats for presentations
  are MS PowerPoint 2003.
• To perform the presentation, the following
  equipment will be available in the conference
  room
• Laptop computer (with MS Windows XP-PRO operating
  system and PowerPoint 2003) and LCD projector.
• Please bring your presentation on a memory stick
  to upload on the laptop provided prior to your
  session.
• The presenter should prepare a reasonable number
  of electronic slides, so as not to exceed the 45
  minute time. Typically, 1 slide is presented in 1
  minute. Additional slides could be prepared to
  support possible answers to attendees' questions.

• Each slide should not be overcrowded by text and
  graphics. Too much text should be avoided slides
  should support the presentation, they should not
  be simply read by the presenter.
• Graphics should be designed to help in the
  overall communications, to illustrate key points
  and illucidate the basic ideas. Avoid excess
  graphics as this makes the overall file size
  large and can delay slide loading.
• Use large fonts so as they are readable without
  efforts typically 20 point font is the smallest
  that should be used. Headers within the body are
  typically 24-pt and slide headers are typically
  28 or 32-pt font. Use Arial, Verdana or other
  san-serif font for readability.
