Elevator

1
Elevator Escalator Products
2
Elevator Escalator Products

• Cab Handrails
• Rope Wear Gauges
• Escalator Step Gap Gauges
• Escalator Anti-Slide Knobs
• Pad Hooks
• Braille Tags and Jamb Plates
• Signage

SETTING THE STANDARD
...
3
ROUND Handrails
Functional designs meet accessibility
requirements.
4
Straight or Curved! Machined precision straight
capped ends or bent ends curving flush to the cab
wall.
An additional option is the bullet ends which
are perfectly symmetrical dome ends.
5
Solid Flat BarHandrails
Heavy duty design for passenger or freight
elevators
6
These handrails come precision-machined straight
capped ends or optional bent (returned) ends
curving flush to the cab wall.
Sizes 1.5, 2, 3, 4 6 widths x 3/8 thick
7
Extruded Handrails
Revolutionary design offers unparalleled
adjustability
8
Using extreme pressure, the 3 wide extrusion is
tightly roll formed and clad with a minimum .024
thick sheet metal in the finish of your choice.
The channeled aluminum extrusion design of these
handrails allows for easily adjustable spacer
locations that can be slid along the length of
the handrail and locked into place.
9
STONEGRIP Handrails
Architectural design with adjustable spacers.
10
These handrails are constructed from Solid
Surface, (mineral-filled acrylic polymer)
materials, in a variety of sandstone colors.
They meet ADA requirements.
The one piece channeled design of these handrails
allows for easily adjustable spacer locations
that can be slid along the length of the handrail
and locked into place.
11
Continuous Handrails
SOLID FLAT BAR
Continuous Handrail Construction.
ROUND
12
Precision Component Machine
Handrail Spacer Assemblies
Standard Spacer Assembly
Ease of Installation
Removable Spacer Assembly
Removable Handrail Spacer Installation
Instructions
13
Pad Hooks
Anti-Slide Knobs
Elevator Escalator
ACCESSORIES
1 / 2 Diameter Pad Hooks are designed to securely
mount and support protective pads.
Escalator Safety Knobs 2.5 diameter x 1
tall solid stainless or cast acrylic.
14
Elevator Rope Wear Gauge
Escalator Step Gap Gauge
This IMPERIAL and METRIC escalator tool was
developed for fast accurate measuring of step to
skirt gaps.
This IMPERIAL and METRIC No-Go gauge confirms
maximum allowable diameter loss.
We can even add your company logo.
15
SIGNAGE
Code Compliant
SIGNAGE
No Smoking
Fire Fighters Signage
Star of Life Medical
16
SIGNAGE
Code Compliant
17
SIGNAGE
Code Compliant

• Tough Sign Construction Perma-bond Layers.
• Easy Mount Signs Peel and Stick no tools or
  hardware required.
• Metal Plates
• Aluminum substraight is highly durable and
  provides a smooth slim profile when installed.
• A thickness of 0.025 with a baked white, brushed
  or polished enamel finish.
• Vandal resistant sub-surface heat baked graphics.
• Plastic Plates
• Durable Lexan Plastic, will not chip, peel or
  flake.
• A thickness of 0.015, flexes easily without
  cracking or breaking.
• Matte finish for reduced reflection and glare.
• Very durable, graffiti and scratch resistant
  surface.
• Vandal resistant sub-surface graphics are
  protected against fading wear.

18
Braille Plates
Plastic

• Economical plastic Braille plates.
• Manufactured from durable solid color laminated
  acrylics,
• there is no painting of characters or background.
• Advantages of Plastic Jamb Plates
• Plastic substrate enables the plates to actually
  flex
• and make full contact with any irregular
• (concave or convex) door jambs.

Code Compliant
19
Exceeding Your Expectations

• Quality Assurance 100 Every Time

• Secure Packaging

• On Time Delivery

CUSTOMER SERVICE ABOVE ALL ELSE
.....
20
Visit our Interactive Website at
www.lustreproducts.com
Visit our Interactive Website at
www.lustreproducts.com
21
Visit our Interactive Website at
www.lustreproducts.com
22
Visit our Interactive Website at
www.lustreproducts.com
23
Visit our Interactive Website at
www.lustreproducts.com
24
Customer Service Toll Free 1-866-823-4160 Email
Sales_at_lustreproducts.com Tel
1-604-823-4160 Fax [phone] Website
www.lustreproducts.com Lustre Products Ltd. 3975
Eckert Street Chilliwack, B.C. V2R 5J6 Canada
.....
CUSTOMER SERVICE ABOVE ALL ELSE
