Radiant Heat Panel Discussion

1
Radiant Heat Panel Discussion

• Pat Cahill

2
Radiant Heat Panel DiscussionSubgroup Topics

• Flame Propagation
• Nozzle Angle
• Heat Flux Check
• Post-Calibration
• Additional Round Robins

3
Radiant Heat Panel Discussion

• Foams
• Expand
• Exhibit Intumescence
• As a result of this expansion and/or intumesence,
  these samples tend to
• Extinguish the Pilot Burner Flame
• Redirect the Pilot Burner Flame
• Expand in to the Pilot Burner Flame
• This may also occur with Cloth type Materials

4
Radiant Heat Panel Discussion
5
Radiant Heat Panel Discussion
6
Radiant Heat Panel Discussion
7
Radiant Heat Panel DiscussionAdvisory Circulars
(ACs)

• New Guidance
• Longer Pilot Burner Flame Exposure
• Solution for Rogue Samples
• Elimination of Composite Substrate for Thermal
  Acoustic Insulation Samples
• Length of Ventilation Slit in Samples

8
Radiant Heat Panel DiscussionAdvisory Circulars
(ACs)

• Tapes New Configuration

9
Radiant Heat Panel DiscussionAdvisory Circulars
(ACs)

• Tapes New Configuration

10
Radiant Heat Panel DiscussionAdvisory Circulars
(ACs)

• Tapes New Configuration

11
Radiant Heat Panel DiscussionAdvisory Circulars
(ACs)

• Tapes New Configuration

12
Radiant Heat Panel DiscussionAdvisory Circulars
(ACs)

• Tapes New Configuration

13
Radiant Heat Panel DiscussionAdvisory Circulars
(ACs)

• Tapes New Configuration

14
Radiant Heat Panel DiscussionAdvisory Circulars
(ACs)

• Damping Systems
• Sample Configuration and Placement within Chamber
  for Testing

15
Radiant Heat Panel DiscussionAdvisory Circulars
(ACs)

• Damping Systems
• Sample Configuration and Placement within Chamber
  for Testing

16
Radiant Heat Panel DiscussionCurrent Priority
Testing

• Silicone Impregnated Fiberglass Insulation
• Purpose Evaluate a 60-second pilot burner flame
  impingement versus 15 and 30 seconds.
• Initial testing has shown that a 60-second flame
  exposure results in no after flame time and no
  flame propagation.

17
Radiant Heat Panel DiscussionCurrent Priority
Testing
18
Radiant Heat Panel DiscussionOngoing Work

• Ongoing support with ACOs and Labs for compliance
  checks
• Continued support for Labs experiencing problems
  (a.k.a., Radiant Panel Help Desk)
• Comparison testing with other Labs on specific
  materials
