1
Existing and Possible Applications of Artificial
Intelligence in Computer Games
Ori Liel
2
In this lecture
  • A few words about the industry
  • Current AI technologies applied in games
  • Fuzzy logic
  • Soar Quake-bot
  • Interesting projects and possible future
    applications

3
The computer (and console) game industry
  • Multi-Billion industry
  • Growing fast
  • Main trends
  • Increasing of games with multi-player options
  • Movement towards console games
  • Emerging trend - increasing investment in AI
  • Graphics and sound cant make ground-breaking
    leaps
  • More CPU power available
  • Hardware improvements
  • Graphics cards carry the burden

4
Need for AI different game geners
  • Action
  • Quake
  • IGI Covert Strike
  • Need Formidable opponents
  • Need good Support characters
  • Adventure RPG
  • Mist
  • NeverWinter Nights
  • Need Believable NPCs
  • Have beliefs, desires and intentions
  • Are able to formulate and carry out plans
  • New notion plot management

5
Need for AI contd
  • Strategy
  • Civilization 3
  • WarCraft 3
  • Need enemies with ability to plan, react and
    learn
  • God-games
  • SimCity
  • Populous
  • Need Believable environments

6
Need for AI contd
  • Why are agents suitable?
  • For all the reasons which were mentioned before
  • First of all agents as a natural metaphor
  • Modularity
  • Decentralization
  • Changeability
  • Open environments

7
Current State of AI in games
  • AI is not taken very seriously (yet)
  • Budget goes to graphics
  • Usually put off until late in development
  • Not enough expertise in the industry
  • From an industrial point of view AI is a means,
    not an end.

8
Current AI technologies applied in games
9
Current technology - FSM
  • Finite State Machines
  • States transformation rules
  • Agent behavior
  • deterministic
  • reactive
  • Can be improved by adding intelligent-looking
    scripted behavior

10
Current technology Flocking
  • Flocking algorithms
  • Simulate realistic movement in a group
  • Based on studies of flocks of birds, and schools
    of fish
  • Essence of algorithms
  • Maintain a minimum distance from other agents
  • Move towards center of mass
  • Keep your alignment similar to other agents

follow the leader flocking
11
Current technology others
  • Pursuit-evasion algorithms
  • AI character in pursuit
  • AI character escaping
  • Path-finding - A algorithm
  • Used by units to find their way around in the
    environment

12
Fuzzy logic
  • (And its application in game AI)

13
Fuzzy logic
  • Development of fuzzy logic
  • Plato said it first there is something between
    true and false
  • Since then
  • Three-valued logic -1, 0, 1
  • N-valued logic
  • Finally, infinite-valued logic

14
Fuzzy logic contd
  • The idea
  • the universe is made of fuzzy sets.
  • The fuzzy set of old people
  • The fuzzy set of red objects
  • and a membership function m
  • m STATEMENT ? VALUE

15
Fuzzy logic contd
  • An example
  • Jane is 70 years old. Is Jane old? Depends on who
    youre asking.
  • Assume that membership in old is defined as
    follows
  • mOLD(x) 1 (if age(x)gt100)
  • 0.01age(x) otherwise)

16
Fuzzy logic contd
  • According to this definition
  • mOLD(Jane) 0.7
  • Question
  • What does this mean?
  • Answer
  • Janes degree of membership within the set of old
    people is 0.7
  • Not to be confused with probabilistic approach

17
Fuzzy logic contd
  • Basic definitions (A and B are sets)
  • A is EMPTY ?? for all x, mA(x) 0.0
  • A B ?? for all x mA(x) mB(x)
  • A for all x m(x)A' 1 m(x)A
  • A is CONTAINED in B ?? for all x
  • mA(x) lt mB(x)
  • C A ? B ? mC(x) MAX(mA(x), mB(x))
  • C A ? B ? mC(x) MIN(mA(x), mB(x))

18
Fuzzy logic contd
  • Examples of last two definitions
  • mOLD(Jane) 0.7
  • mSMART(Jane) 0.6
  • What is the degree of membership of Jane in the
    old-or-smart set?
  • mOLD ? SMART(Jane) 0.7
  • What is the degree of membership of Jane in the
    old-and-smart set?
  • mOLD ? SMART(Jane) 0.6

19
Fuzzy logic applications
  • Fuzzy-logic introduces a random element into
    decision-making
  • Opponents personalities in Civilization 3 are
    defined in this way
  • maggressive (Japan) 0.7
  • mscientific(Japan) 0.4
  • mexpansionistic(Japan) 0.6
  • A probabilistic function uses these values (among
    others) to determine Japans next move, depending
    on Japans present state.

20
Probabilistic Fuzzy-State machine
goodwill lt 85
ALLIED treaty 0.8 assist 0.8
COOPERATIVE treaty 0.4 assist 0.2
goodwill gt 85
goodwill lt 65
goodwill gt 65
goodwill lt 65
Neutral treaty 0.1 attack 0.1 assist 0.05
goodwill gt 85
30 lt goodwill lt 45 or gain gt 60
goodwill lt 50 and gain gt 90
goodwill gt 45
AGGRESIVE attack 0.6 ceasefire 0.3 peace
0.8
HOSTILE attack 0.95 ceasefire 0.05
goodwill gt 30 or gain gt -50
gain gt10
21
The Soar Quake-bot
22
Quake II
  • Quake II a first person shooter
  • The Quake II environment
  • Levels sets of rooms and passages
  • Weapons from knife to RPG
  • Power-ups
  • Quake II Death-Match

23
Quake II - mods
  • mods are modified versions of existing games
  • New game-play features
  • Altered laws of physics, changes to environment
  • Improved (or at least different) AI
  • Can be created by company or by players.
  • In Quake II, id software released some source
    code, and mods were created by players
  • Favorite use of code
  • The creation of Quake-bots for death-matches.

24
Quake II - Quake-bots
Bots simulate human perception
Status of the targets Status of the targets Status of the targets Status of the targets
target In range visible In front
A Yes No Yes
B Yes No No
C Yes Yes Yes
D No N/A N/A
E Yes No No
25
The Soar Quake-Bot
  • The Soar bots decision cycle

26
Soar Quake-Bot contd
  • Evaluation, proposal and operator selection take
    into account
  • Internal state
  • Health level
  • Current weapon
  • Knowledge of map
  • Some pre-defined ordering among operators, which
    is unique to the version of the robot.

27
Soar Quake-Bot contd
  • Operator application
  • Operators can be
  • primitive actions (move, shoot)
  • internal actions (remember location)
  • abstract actions (collect power-ups)
  • If an abstract operator has been selected, it is
    immediately regarded as a goal

28
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
29
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
30
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
31
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
32
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
33
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
34
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
35
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
36
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
37
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
38
Collect-Powerups
Get item
Choose-best-item
Goto next room
Get item in room
Detect item missing
Face item
Move to item
Stop moving to item
Go through door
Go to door
Align with door
Face door
Move to door
Record at door
Slide to door
Stop move to door
Stop slide to door
39
Soar Quake-Bot Anticipation
  • Robot anticipates players moves by
  • Forming an internal model of player
  • Player status
  • Health
  • Weapon level
  • Players beliefs (current perception of the
    world)
  • Projecting its own behavior on player

40
Soar Quake-Bot Anticipation (contd)
  • Why should anticipation be used?
  • Ambush
  • Hunt (pursuit-evasion)
  • Deny power-ups
  • When should anticipation be used?
  • Not all the time
  • Requires lots of CPU for reasoning.
  • May interfere with regular mechanisms
  • Should be used when
  • Sensing enemy (some knowledge of enemy state)
  • Enemy is far away and not facing the bot

41
?
42
(No Transcript)
43
His Distance 1 My Distance 1
44
His Distance 2 My Distance 2
45
His Distance 2 My Distance 2
46
His Distance 3 My Distance 1 (but hall)
47
His Distance 4 My Distance 0 Ambush!
48
(No Transcript)
49
Bot remembers successful sequences
(learning)
50
Other interesting projects
51
Haunt 2 http//winter.eecs.umich.edu/haunt/overv
iew.html
  • Situation player is a ghost-like energy creature
    trapped in a house
  • Goal escape
  • Problem player is severely limited in
    manipulating the environment
  • Game-play get house residents (AI characters) to
    do things for you by
  • frightening
  • enticing
  • cajoling
  • Threatening
  • Game-play entirely based on interaction with AI
    characters!

52
Haunt 2 contd
  • AI characters must have
  • Personality
  • Goals and motivations
  • Very believable reactions to environment
  • Example of AI characters
  • Evil scientist
  • Driven by desire to capture ghost
  • Personality Immune to fear, cant stand cold
  • Lost hitchhiker
  • Driven by curiosity
  • Personality Easily frightened, physically strong

53
Cyphesis http//www.worldforge.org/wf/dev/eng/serv
ers/cyphesis
  • Idea characters in virtual worlds alive, all
    NPCs have ambitions
  • Between multi-player and single-player
  • Scripting and planning in use
  • A thought how to make it computationally
    feasible?

54
Kemal Envers project http//www.multiagent.tk
  • A variation of capture the flag with tank fights
  • A path-finding
  • Reactive behavior
  • Communication between agents

55
Idea for a game
  • Set in a fantasy DD-like environment
  • (As in Cyphesis) World full of self-interested
    NPCs.
  • (As in Haunt 2) AI cooperation is very
    important
  • Achieve cooperation by
  • Negotiation
  • Threats
  • Building trust and friendship

56
Idea for a project
  • Simplified case of last idea
  • Setting a zoo
  • Paths
  • Cages
  • Obstacles
  • Exits
  • Items tranquilizer gun, riding horse, security
    passes
  • Agents
  • Players (BDI, communication skills)
  • Animals (reactive, subsumption architecture or
    FSM)
  • Guards?

57
Idea for a project contd
  • Game-play
  • Zoo is set randomly
  • Missions are assigned randomly
  • Release Tiger into the wild
  • Move animal Bear from cage a to cage b
  • Keep at least n animals in their cages
    (maintenance task)
  • Protect the Monkey at all costs!
  • Agents have goals ? agents have tasks. So game
    can be seen as task-oriented domain
  • Players dont know about each others missions
    (an opportunity to incorporate learning!)
  • Run simulation and see how fast, if at all, human
    player completes task.

58
(No Transcript)
About PowerShow.com
