The Entity-Relationship Model

1
Chapter 3

• The Entity-Relationship Model

2
ER Model

• Conceptual Design answers
• What are the entities and relationships?
• What information about these entities and
  relationships should we store in the database?
• What are the integrity constraints or business
  rules?
• ER Model Concepts
• Entity types
• Relationship types
• Attributes

3
Diagrammatic notation

• Use of UML class diagram for displaying ER
  concepts.
• UML class represents an entity type.
• First section include entity type name.
• Second section lists attributes.
• Third section is not displayed (or used for
  derived attributes).
• Relation types represented as lines connecting
  entity types (classes).
• Some UML terminology differs from ER terminology
  (discussed later).

4
Entity Type

• Entity type
• Define a group of objects with same properties or
  attributes.
• Examples EMPLOYEE, CUSTOMER, SUPPLIER entity
  types.
• Entity occurrence (or entity instance)
• Uniquely identifiable object of an entity type.
• Examples Employee John Doe, Customer Mike
  Jordan, Supplier Office Depot.
• Entity set is the set of entity occurrences.

5
ER diagram of Staff and Branch entity types
An entity type is displayed in a rectangular box.
6
Relationship Types

• Relationship type
• Define a set of meaningful associations among
  entity types.
• Examples A Branch HAS some Staff, An Employee
  WORKS ON a Project.
• Relationship occurrence
• Uniquely identifiable association, which includes
  one occurrence from each participating entity
  type.
• Relationship set is the set of relationship
  occurrences (current state of a relationship).

7
Semantic net of Has relationship type
8
ER diagram of Branch Has Staff relationship
Another notation
Has
Staff
Branch
9
Relationship Types

• Degree of a Relationship
• Number of participating entities in
  relationship.
• Relationship of degree
• two is binary
• three is ternary
• four is quaternary.

10
Binary and ternary relationships
Binary
Ternary
11
Quaternary relationship called Arranges
12
Relationship Types

• Recursive Relationship
• A relationship type where same entity type
  participates more than once in different roles.
• Relationships may be given role names to indicate
  purpose that each participating entity type plays
  in a relationship.

13
Recursive relationship called Supervises with
role names
14
Entities associated through two distinct
relationships with role names
15
Attributes

• Attribute
• Property of an entity or a relationship type.
• Attribute Domain
• Set of allowable values for one or more
  attributes.
• Simple Attribute (or single-valued Attribute)
• An entity has a single atomic value for the
  attribute.
• Example Employee with SSN 123-45-6789
• Composite Attribute
• Attribute composed of multiple components.
• Examples Address, Name.
• It can be nested.

16
Attributes

• Multi-valued Attribute
• Attribute that holds multiple values for each
  occurrence of an entity type.
• Example Previous jobs for an employee.
• Derived Attribute
• Attribute that represents a value that is
  derivable from value of a related attribute, or
  set of attributes, not necessarily in the same
  entity type.
• Example Age derived from DOB and Todays date.

17
Keys

• Candidate Key
• Minimal set of attributes that uniquely
  identifies each occurrence of an entity type.
• Primary Key
• Candidate key selected to uniquely identify each
  occurrence of an entity type.
• Composite Key
• A candidate key that consists of two or more
  attributes.

18
ER diagram of Staff and Branch entities and
their attributes
19
Entity Type

• Strong Entity Type
• Entity type that is not existence-dependent on
  some other entity type.
• Weak Entity Type
• Entity type that is existence-dependent on some
  other entity type.
• It does have a key attribute.
• Identified by a partial key of the weak entity
  type and by the primary of the strong entity type
  they are related to.

20
Strong entity type called Client and weak entity
type called Preference
21
Relationship called Advertises with attributes
22
Structural Constraints

• Main type of constraint on relationships is
  called multiplicity.
• Multiplicity - number (or range) of possible
  occurrences of an entity type that may relate to
  a single occurrence of an associated entity type
  through a particular relationship.
• Represents policies (called business rules)
  established by user or company.

23
Structural Constraints

• The most common degree for relationships is
  binary.
• Binary relationships are generally referred to as
  being
• one-to-one (11)
• one-to-many (1 or 1M)
• many-to-many ( or MN)

24
Semantic net of Staff Manages Branch relationship
type
One-to-one (11) relationship
25
Multiplicity of Staff Manages Branch (11)
relationship
11
26
Semantic net of Staff Oversees PropertyForRent
relationship type
One-to-many (1) relationship
27
Multiplicity of Staff Oversees PropertyForRent
(1) relationship type
1M
28
Semantic net of Newspaper Advertises
PropertyForRent relationship type
Many-to-many () relationship
29
Multiplicity of Newspaper Advertises
PropertyForRent () relationship
30
Structural Constraints

• Multiplicity for Complex Relationships
• Number (or range) of possible occurrences of an
  entity type in an n-ary relationship when other
  (n-1) values are fixed for the other
  participating entity types.

31
Semantic net of ternary Registers relationship
with values for Staff and Branch entities fixed
32
Multiplicity of ternary Registers relationship
A staff/branch value pair registers zero or more
clients
33
Summary of multiplicity constraints
34
Structural Constraints

• Multiplicity actually consists of two types of
  restrictions on relationships cardinality and
  participation.
• Cardinality
• Describes maximum number of possible relationship
  occurrences for an entity participating in a
  given relationship type.
• Participation
• Determines whether all (total) or only some
  (partial) entity occurrences participate in a
  relationship.

35
Multiplicity as cardinality and participation
constraints
36
Problems with ER Models

• Problems may arise when designing a conceptual
  data model called connection traps.
• Often due to a misinterpretation of the meaning
  of certain relationships.
• Two main types of connection traps are called fan
  traps and chasm traps.

37
Problems with ER Models

• Fan Trap
• Where a model represents a relationship between
  entity types, but pathway between certain entity
  occurrences is ambiguous.
• Chasm Trap
• Where a model suggests the existence of a
  relationship between entity types, but pathway
  does not exist between certain entity
  occurrences.

38
An Example of a Fan Trap

• At which branch office does staff number SG37
  work?

39
Restructuring ER model to remove Fan Trap
SG37 works at branch B003.
40
An Example of a Chasm Trap

• At which branch office is property PA14
  available?

41
ER Model restructured to remove Chasm Trap
42
Semantic Net of Restructured ER Model with Chasm
Trap Removed
43
Entity vs. Attribute

• Should address be an attribute of Employee or an
  entity (connected to Employee by a relationship)?
• Depends upon the use we want to make of address
  information, the physical data model, and the
  semantics of the data
• If we have several addresses per employee,
  address must be an entity (since attributes
  cannot be set-valued).
• If the structure (city, street, etc.) is
  important, e.g., we want to retrieve employees in
  a given city, address must be modeled as an
  entity (since attribute values are atomic).

44
Entity vs. Attribute

• Works_In1 does not allow an employee to
  work in a department for two or more
  periods.
• Similar to the problem of wanting to record
  several addresses for an employee.
• Solution Place periods in a separate entity
  type.

from to
Department did dname budget
0
11
Works_In1
Department did dname budget
0
11
Works_In2
1
Duration from to
45
Entity vs. Relationship

• First ER diagram OK if a manager gets a separate
  budget for each dept.
• What if a manager gets a budget that covers all
  managed depts?
• Redundancy of dbudget, which is stored for each
  dept managed by the manager.
• Misleading suggests dbudget tied to managed
  dept.
• Solution Create a separate entity type Mgr_Appts.

since dbudget
Department did dname budget
11
01
Manages1
Department did dname budget
11
01
Manages2
01
Mgr_Appts apptnum since dbudget
46
Data Modeling Tools

• Several popular tools exist for conceptual design
  and mapping to relational schema.
• Examples ERWin, S-Designer, ER-Studio, MS Visio.
• Good for documenting database design.
• But, it may not follow ER notation.
• Original ER model did not support other concepts
• Such as specializations/generalizations and
  aggregations.
• They are discussed in next chapter.
