Title: FVC Multimedia Operating System MOS


1
FVCMultimedia Operating System(MOS)
2
The First Virtual VisionDesktop Mulitmedia
Networking
  • DESKTOP Windows PC, Mac, OS/2 y Unix to follow
  • MULTIMEDIA Data, Digital Audio / Video,
    Telephony
  • NETWORKING Affordable ATM LANs

3
FVC Product Concept
Data Servers
Data Clients
Data (LAN) Network
ATM
Multimedia (ATM) Network
ATM
Multimedia Clients
Room Systems
Telephony (PBX) Network
Telephony Call Server, Services
ISDN, POTS
4
FVC Target Market
WAN
Campus Backbone
ISDN, T1/E1
E, F, A
E, F, T
Existing Workgroup
Emerging Workgroups
Remote Workgroup
E
T
F
A
E
F
E
F
A
5
Product Line Strategy
  • Address emerging Desktop MM Application needs...
  • Desktop Multimedia Collaboration
  • High Quality, Interactive
  • Multimedia Information on Demand
  • Simultaneous, High Quality, Real-time/Offline
    Audio/Video
  • High Performance Data Workgroups
  • Bandwidth on Demand, Virtual Workgroups, Realtime
    Data
  • ... In a scaleable, transparent fashion
  • Scaleable Number of Users Simulataneous
    Applications
  • Transparent Preserve existing LAN, Client/Server
    investment

6
Desktop ATM In Perspective
Serial Line
Shared LANs
Segmented LANs
Switched LANs
Desktop ATM
Network Architecture
Terminal- Host 79-84
Text-based Client-Server 86-90
Graphics-based Client-Server 91-95
Desktop Multimedia 95-
  • Desktops have evolved from Terminals to MPCs
  • Networks are evolving from shared to switched

7
Historical Perspective
SERVER
WAN
LAN
Multimedia Server, Service
ATM
USER (CLIENT PCs)
DESKTOP ATM - 1996
8
The Promise of ATM Convergence
TERMINAL-HOST - 1980
PHONE-SERVICE
RESOURCES (Data)
SERVICE
ATM
WAN
WAN
USER (CLIENT PCs)
CLIENT/SERVER - 1990
CLIENT/SERVER-SERVICE - 2000
9
Todays C/S cannot support MM
Legend NOS Network Operating System
LAN
  • LANs have QoS, bandwidth, scaleability issues
  • NOSs are optimized for bursty data transfers
  • Servers have bus, processor, capacity bottlenecks

10
FVCs Solution for Desktop MM
? Desktop ATM network to front-end the LAN ?
Media Operating Software (MOS) to augment the
NOS ? Native ATM Services such as Stored A/V,
Realtime A/V, Video Conferencing
11
Emerging Client-Server Model
Server File, Message, Database Servers manage
(naming, browsing, authentication, billing)
specific multimedia services
LAN, WAN
MM Services Stored A/V Realtime A/V Video
Conferencing Voice
Desktop ATM
MM Client Can simultaneously access Data, A/V,
VideoConferencing and Voice services
12
Why Desktop ATM?
LAN
WAN
Desktop ATM
ATM
ATM
Multimedia Desktop
Telecom
ISDN, POTS
  • Provides more bandwidth, smart bandwidth
  • Allows multiple, simultaneous Classes of Service
  • Allows emulation of LAN, ISDN, POTs services
  • Is affordable, uses existing structured wiring
  • Enables convergence of LAN/MAN/WAN

13
Video Solutions

The 3 Cs
14
Quality of Service

Existing wiring
LAN QoS
Stored Video QoS
Videoconferencing QoS
15
QoS
?

16
MOS(Multimedia Operating Software)

Network QoS
  • ATM
  • ISDN
  • T1/E1
  • Switched
  • Ethernet

17
MOS advantage
  • Current NOSs are optimised to support high
    throughput, burst data client/server applications
  • MOS coexists with the NOS, and enables realtime
    multimedia applications such as stored or live
    Audio/Video and Video Conferencing, to directly
    leverage ATMs sophisticated Classes of Service

18
CMOS SMOS
  • MOS augments the NOS to provide QoS MM
  • Client MOS enables Windows Client to
    transparently access MM Server/Service
  • Server MOS frontends the MM Resource or Service
    and delivers it over the ATM Network

19
MOS Architecture
Server
Legend LEC LAN Emulation Client LES LAN
Emulation Server NOS Network Operating
System MOS Media Operating Software CMOS Client
MOS SMOS Server MOS
LAN, WAN
NOS
File Server Message Server Database
Server Directory Server
LES
MPC
NOS
LEC
Desktop ATM
Server MOS
CMOS
Client MOS
LEC
NOS
SMOS
Multimedia Services
20
MOS Client-Service Architecture
DESKTOP CLIENT
SERVICE-SPECIFIC INTERFACE
Existing C/S Apps
Realtime C/S Apps
Digital Telephony Apps
Application Protocols
LAN Protocols
SERVER MOS
Existing LAN Protocols
CLIENT MOS
MOS, LAN Protocols
LAN Emulation CLIENT
LAN Emulation CLIENT
MOS Network Services
MOS Network Services
ATM Protocol Stack
ATM Protocol Stack
ATM Protocols
MEDIA ADAPTER
SERVICE-SPECIFIC ADAPTER
CLIENT
SERVER
21
MOS for Windows
Data
Audio/Video
DVC
Stored, Realtime Digital A/V Applications
Existing DOS/WIN Applications
Existing Client/Server Applications
Desktop Video Conferencing Applications
Netware Redirector
Windows Redirector
MOS Redirector
CLIENT MOS Storage Services API
NCP
Netbios
WinSock
SPX IPX
SPX IPX
NETBEUI
TCP IP
MOS H.320 Services
MOS Stream Protocol
NDIS
ODI
NETWORK MOS Services
ATM Adapter -BUS Interface
22
www.fvc.com
