Magnetic Random Access Memory

1
Magnetic Random Access Memory

• Mathilde Brocq
• Axel Hundertmark
• Magzoub Mohammed

2
Introduction
3
magnetic materials

• Advantages of magnetic storage technology

• Nonvoltile

• High density storage

• Low energy consumption

• Defination

ferromagnetic
antiferromagnetic
4
A large ,positive suceptibility

• Other Ferromagnetic materials

• Properities

• Strong attraction to magnetic field

• Retain their magnetic properties

• Why ferromagnetic have strong magnetic properties?

• Domain

5

• Unmagnitized material

• Magnetized material

6
Principle of GMR (giant magnetoresistance)
GMR ratio GMR (RAP-RP)/RP
At room temperature 20 GMR effect
Magnetoresistance curves at 4.2K of (Fe/Cr)
multilayer
7
Principle of GMR
Orbitals of 3d transition metals as Fe, Co, Ni
Conductance ?(spin up) ? ?(spin down)
Schematic picture of the GMR mechanism
RP lt RAP
8
Principle of TMR(tunnel magnetic junction)
Structure 3 thin layers magnetic/insulator/magne
tic
Principle electron tunneling current for spin
up DFermi (up, ferro 1) DFermi (up, ferro 2)
Parallel configuration
Antiparallel configuration
9
Hysteresis
10
Read Write
11
Bit array
12
Conclusion
In January 2006, IBM presented its 16-Mb MRAM

• - Cell size 1.42 µ.m2
• Better density than SRAM
• Access time (read and write) 20ns
• gt Expected to become just a little higher than
  SRAM

References will be in Report
