Motion

1
Unit 4

• Motion

2
Motion

• change in position

3
Speed

• distance traveled per unit of time
• speed distance / time

4
Speed

• Average speed is equal to the total distance
  traveled divided by the total time for the trip
• average speedtotal distance/total time

5
Speed

• Speed at any instant is called instantaneous speed

6
Velocity

• Speed and direction
• Velocity describes the speed and direction of a
  moving object

7
Changes in Speed

• Speeding up and slowing down are changes in speed

8
Changes in Speed

• To find a change in speed, subtract the initial,
  or starting, speed from the final speed
• change in speed
  final speed initial speed

9
Acceleration

• Change in speed or direction
• An object is accelerating when it speeds up,
  slows down, or changes direction

10
Acceleration

• Slowing down is sometimes called deceleration

11
Acceleration

• To find acceleration, you must know the change in
  speed and the time for that change to occur
• acceleration change in speed / time or
• acceleration (final speed
  initial speed) / time

12
Balanced and Unbalanced Forces

• A force is a push or pull
• To describe a force, you must know two things
• Size of the force
• Direction of the force

13
Balanced Forces

• Forces that are equal in size but opposite in
  direction
• Balanced forces do not cause a change in the
  motion of objects

14
Unbalanced Forces

• Forces that cause a change in the motion of an
  object

15
Unbalanced forces

• Unbalanced forces can change the motion of an
  object in two ways
• When unbalanced forces act on an object at rest,
  the object will move
• When unbalanced forces act on a moving object,
  the velocity of the object will change

16
Newtons First Law of Motion

• Newtons First Law of Motion states that an
  object will remain at rest, or move at a constant
  speed in a straight line, unless it is acted on
  by an unbalanced force

17
Newtons First Law of Motion

• inertia tendency of an object to stay at rest
  or in motion
• Newtons First Law of Motion is also called the
  Law of Inertia

18
Newtons Second Law of Motion

• Newtons Second Law of Motion describes the
  relationship among force, mass, and acceleration

19
Newtons Second Law of Motion

• Unbalanced forces cause objects to accelerate
• The amount by which an object accelerates depends
  on two things
• size and direction of the force
• Mass of the object

20
Newtons Second Law of Motion

• If two forces act on the same object, the larger
  force will produce more acceleration than the
  smaller force

21
Newtons Second Law of Motion

• If you apply the same amount of force to two
  objects with different masses, the object with
  the smaller mass will accelerate more than the
  object with the larger mass

22
Newtons Second Law of Motion

• force mass X acceleration
• F m X a
• Force is measured in Newtons (N)
• Newton unit of force equal to one
  kilogram-meter per second per second

23
Newtons Third Law of Motion

• Newtons Third Law of Motion states that for
  every action force, there is an equal and
  opposite reaction force

24
Newtons Third Law of Motion

• Forces always act in pairs
• The two forces act in opposite directions

25
Newtons Third Law of Motion

• action force force acting in one direction
• reaction force force acting in the opposite
  direction
