Human Genetics

1
Human Genetics

• The Human Genome

2
Genome

• The genome of an organism is the complete set of
  genes specifying how its phenotype will develop
  (under a certain set of environmental
  conditions).
• Diploid organisms (like us) contain two genomes,
  one inherited from our mother, the other from our
  father.
• The total DNA of an organism.
• Nuclear genome refers to the total DNA in the
  nucleus, which is distinguished from organellar
  genomes of the mitochondria and chloroplast.

3
Genome size variation
4
Comparison of genome organization
5
Eukaryotic Genomes are Variable in Size
Marbled lungfish 139,000,000,000
Salamander 50,000,000,000
Homo sapiens 3,000,000,000
Pufferfish 400,000,000
Fruit Fly 165,000,000
Arabidopsis 100,000,000
Bakers yeast 12,067,280
6
Why the big differences?

• Do Marbled Lungfish differ from Pufferfish?
• Are Lilies all that much different than
  Arabidopsis?
• These differences exist because
• Genomes have duplicated (chromosome doubling)
• Individual genes have duplicated.
• DNA exists that has no coding function.

7
Gene structure

• I. Gene definition
• II. Genome organization (eukaryotic)
• 1. Genes and their noncoding regulatory
  sequences
• 2. Nonfunctional DNA
• 3. Duplicated genes
• 4. Repetitive DNA
• III. Mobile DNA
• IV. Gene Regulation

8
Some Terms

• A duplicate of a gene may acquire mutations and
  emerge as a new gene.
• Noncoding DNA a sequence of DNA contained in
  eukaryotic genomes that does not encode any
  genetic information and often consists of
  repetitive sequences.
• Expression DNA transcribed into RNA and RNA
  turned into protein are expressed. The
  regulation of this process is called gene
  expression.

9
Nomenclature on DNA quantity

• bp one base pair within a double-stranded
  DNA
• kb 1,000 base pairs of double-stranded DNA
• mb 1 million base pairs of double-stranded
  DNA
• n number of chromosomes in a haploid genome
• 2n number of chromosomes in a diploid genome

10
Definition(s) of a Gene

• 1. A hereditary unit that is composed of a
  sequence of DNA and occupies a specific position
  or locus.
• 2. Broadly, any genetic determinant of a specific
  functional gene product.
• 3. Molecular definition
• Entire nucleic acid sequence necessary for the
  synthesis of a functional polypeptide (protein
  chain) or functional RNA

11
Genes and Their Products

• The majority of genes are expressed as the
  proteins they encode.
• The process occurs in two steps
• Transcription DNA -gt RNA
• Translation RNA -gt protein
• This is the Central Dogma" of Biology
• DNA makes RNA makes protein.

12
The Central Dogma of Molecular Biology

• WHY?
• The DNA can retain integrity
• The RNA step allows amplification
• Multiple steps allow multiple points of control

Protein
DNA
Translation
RNA
Transcription
13
Most Genes Encode Proteins

• Original Concept of the Gene
• One gene one enzyme
• This concept does not hold for those proteins
  that consist of two or more different subunits.
• Revised Concept
• One gene one messenger RNA one peptide.

14
RNA Genes

• Some RNAs (tRNA, rRNA, snRNA, mtRNA) dont code
  for proteins that are translated.
• However, these are still referred to as
  genes-they are specific functional gene products.

• Other DNA sequences regulate the transcription of
  other genes and can act like genes in some ways.

15
Genes are interspersed along DNA molecules, being
separated by DNA sequence of unknown function
(intergenic regions)
16
Coding region

• Nucleotides (open reading frame) encoding the
  amino acid sequence of a protein

The molecular definition of gene includes more
than just the coding region.
17
Noncoding regions

• Regulatory regions
• RNA polymerase binding site
• Transcription factor binding sites
• Introns
• Polyadenylation poly(A) sites

18
Nonfunctional DNA
80 kb

• Higher eukaryotes have a lot of noncoding DNA
• Some has no known structural or regulatory
  function (no genes)

19
Duplicated genes

• Encode closely related (homologous) proteins
• Clustered together in genome
• Formed by duplication of an ancestral gene
  followed by mutation

Five functional genes and two pseudogenes
20
Mobile DNA

• Moves within genomes
• Most of moderately repeated DNA sequences found
  throughout higher eukaryotic genomes
• L1 LINE is 5 of human DNA (50,000 copies)
• Alu is 5 of human DNA (gt500,000 copies)
• Some encode enzymes that enable movement

21
Transposition

• Movement of mobile DNA
• Involves copying of mobile DNA element and
  insertion into new site in genome

22
Why?

• Molecular parasite selfish DNA
• Probably have significant effect on evolution by
  facilitating gene duplication, which provides the
  fuel for evolution, and exon shuffling

23
RNA or DNA intermediate

• Transposon moves using DNA intermediate
• Retrotransposon moves using RNA intermediate

24
LTR (long terminal repeat)

• Flank viral retrotransposons and retroviruses
• Contain regulatory sequences
• Transcription start site and poly(A) site

25
LINES and SINES

• Nonviral retrotransposons
• RNA intermediate
• Lack LTR
• LINES (long interspersed elements)
• 6000 to 7000 base pairs
• L1 LINE (5 of human DNA)
• Encode enzymes that catalyze movement
• SINES (short interspersed elements)
• 300 base pairs
• Alu (5 of human DNA)

26
Human Disease and Mobile DNA

• Movement (transposition) of LINES and SINES can
  cause mutations and genetic disease by insertion
  into essential genes
• Hemophilia (blood clotting factor VIII gene)
• Muscular dystrophy (DMD)
• Colon cancer (APC)

27
RNA Transcription

• The process of releasing information contained in
  a DNA sequence, because DNA itself is used only
  for storage and transmission.
• The sequence of bases in the DNA template is
  copied into an RNA sequence, which is either used
  directly or translated into a polypeptide.

28
Noncoding DNA can be Part of Transcribed Genes

• Regulatory regions (Promoters)
• Introns
• Poly A Addition sites
• 5 untranslated regions
• 3 untranslated regions.

29
Basic Gene Structure
-35
-10
Prokaryotes like E. coli
CAAT
TATA
GC
Humans and other Eukaryotes
30
Bacterial Gene

31
Human Genes

• Most have introns
• Produce monocistronic mRNA only one encoded
  protein
• Large ( 1000-gt1,000,000 base pairs)

32
Gene Transcription and Regulation
33
A Puzzle about Cells

• Each Cell has a complete copy of all the DNA.
  And yet, cells are different.
• This is the theoretical basis of organism
  cloning.
• So cells are only using some of the DNA to make
  RNA to make proteins at any time.
• How does the cell know which DNA to chose to
  transcribe?
• External environment sends signals that are
  recognized, and transcription is turned on or off
  in response to the signals.

34
Transcription

• Transcription is the synthesis of RNA from a DNA
  template.
• Main Types of RNA each have different roles in
  the cell
• mRNA Messenger RNA
• tRNA Transfer RNA
• rRNA Ribosomal RNA
• mtRNA Mitochondrial RNA
• snRNA Small nuclear RNA

35
rRNA and tRNA are Cogs in the Machinery

• rRNA is a structural part of the ribosome
• tRNA helps the protein machinery to read the mRNA
• Neither of these types of RNAs actually carries
  any information

36
Messenger RNA

• Messenger RNA carries the information in the DNA
  to the protein translation machinery (ribosomes)
• Serves as the template for protein synthesis
• Which mRNAs are transcribed in a cell decide the
  fate of that cell since they dictate which
  information in the DNA is read by the protein
  translation machinery

37
RNA molecules

• Synthesized by RNA polymerases using DNA as a
  template.
• Polymer of ribonucleotides, where each consists
  of a phosphate group (PO4), ribose sugar, and a
  base (adenine, guanine, cytosine, or uracil).
• Following synthesis of an RNA strand, it remains
  single-stranded.

38
Gene Regulation can occur at any of these steps

• Initiation- highly regulated step
• Elongation- the rate at which the mRNA is made
  can control how quickly its made
• Termination- premature termination can mean that
  the whole mRNA never gets made and neither does
  what it codes for
• Like receiving only part of the instructions on
  how to put together your easy to assemble
  bookcase/desk/whatever

39
Steps of RNA Transcription

• Initiation
• Elongation
• Termination
• All RNA transcription is performed by enzymes
  called RNA polymerases.
• RNA transcription starts at a Promoter sequence
  (analogous to ORI for DNA replication).

40
Transcription of mRNA in Humans

• Steps involved are the same as in prokaryotes
• Initiation
• Elongation
• Termination
• Mediated by RNA polymerase II
• Very complex enzyme with many subunits

41
Human Transcription

• Has to be more control of how more complex
  genetic material is read to create more variety
  (multicellular)
• RNA has to be transcribed in the nucleus and then
  transported to the protein translation machinery
  in the cytoplasm before it can be read.

DNA
Nucleus
42
Human genes

• Most have introns
• Produce monocistronic mRNA only one encoded
  protein
• Large genes

43
Initiation

• Initiation occurs at promoters as in prokaryotes-
  eukaryotic promoters are not well-characterized
  but have some well conserved elements- including
  the TATA box and CAAT box (both have AT pairs)
• In addition to the promoters there are region in
  the DNA called enhancers to which transcription
  factors bind and regulate which DNA is read and
  encoded in mRNA

44
Transcription Factor Function
Pol
45
Transcription Factors

• Although transcription is performed by RNA
  Polymerase, it needs other proteins to produce
  the transcript.
• These proteins are either associated directly
  with RNA Polymerase or help it bind to the DNA
  sequences upstream of the initiation of
  translation..
• These associated proteins are called
  transcription factors.

46
RNA transcription begins by the assembly of the
RNA polymerase on a promoter region.
47
Orientation of promoter elements specifies the
direction of transcription
-35
-10
prokaryote
CAAT
TATA
GC
eukaryote
48
Transfer of Information
Gene
mRNA
exon intron exon intron
exon
Exon - portion of the gene that contains DNA
sequences that will be translated into protein.
Intron - portion of the gene that will be cut out
before translation
49
Transfer of Information
50
Reading the Genes in the Genome
Signal recognizing
Transcribing
Processing
mRNA
AAA
