Introduction to Ant and XDoclet

1
Introduction to Ant and XDoclet

• Erik Hatcher

2
Who am I?

• Co-author, Java Development with Ant
• jGuru Ant FAQ Maintainer
• Ant Committer
• XDoclet Committer
• Senior Java Architect, Darden
• ltinsert title heregt, eHatcher Solutions, Inc.

3
Overall Agenda

• Part I - Ant
• Part II - XDoclet
• QA
• Demo

4
Part I Ant Agenda

• Introduction to Ant
• Example project overview
• Leveraging Ant
• Properties
• Datatypes
• Site customization

5
Introduction to Ant

• What is Ant?
• Java-based build tool
• Why use Ant?
• Cross-platform
• Java domain smart
• Fast, extensible, integrated
• Alternatives?
• Analogy
• Factory automation

6
Typical Things to Build
JARs
classes
Javadoc
EAR
Documentation HTML/PDF
WAR
7
Designing a Build

• What are you building?
• What does it take to build it?
• How are the steps related?

8
Our Project

• Search engine of static content allowing for
  site-specific user interface customization.

9
High-level Model
HTML / Text files
Source Code
"The Build"
Index
Application (EAR)
10
Technical Architecture
content
Web Tier
Ant build ltindexgt task
EJB Container
index
11
Bonus Requirements

• Report the duration of each web request
• Allow viewing of build information from live
  application
• Build and deploy multiple sites simultaneously,
  each with separate indexes and content

12
Project Structure

• Directory structure
• Simpler is better
• Map to artifacts
• Customizations/personalizations
• IDE issues
• Separate source from artifacts - cleanable

13
Top-level Directory Structure
lib
metadata
src
test
tools
web
14
Java Directory Structure
src test
anttask
org.example.antbook
common
ejb
web
15
Build File

• XML format
• Typically in project root directory
• Default name build.xml
• Declarative - define steps
• Defines a single project
• A project contains targets
• Targets contain tasks

16
Dependencies
ejbdoclet
webdoclet
package-web
package-ejb
package-common
package-anttask
Did someone say container shootout?
build-site-index
package-ear
deploy-jboss
17
build.xml - Targets
lt?xml version"1.0" ?gt ltproject name"antbook"
default"default"gt lttarget
name"init"gtlt/targetgt lttarget name"clean"
description"Removes build artifacts"gt
lt/targetgt lttarget name"package-ear
depends"package-common,package-ejb,package-w
eb description"Package EAR"gt
lt/targetgt lttarget name"deploy-jboss
depends"package-ear,build-site-index
description"Deploy to local
JBoss"gt lt/targetgt lttarget
name"default" depends"package-ear"/gt lt/projectgt

18
Tasks

• Do the work
• Handle dependency checking internally
• Parameterizable
• Commonly used tasks include
• ltmkdirgt
• ltjavacgt
• ltjargt

19
Running Ant targets

• Execute default target ant
• Execute specific target ant deploy-jboss
• Execute multiple targets ant test-common
  generate-test-reports
• IDE just double-click

20
Command-line switches

• -projecthelp
• gt ant -projecthelp
• Buildfile build.xml
• Main targets
• checkstyle Check code style
• clean Removes build artifacts
• compile-anttask Compile anttask module
• compile-common Compile common module
• compile-web Compile web module
• deploy-jboss Deploy to local JBoss
• ejbdoclet Generate EJB code and
  descriptors
• generate-test-reports Generate test reports
• package-ear Package EAR
• package-ejb Package EJB JAR
• package-web Package WAR
• test-anttask Test anttask module
• test-common Test common module
• webdoclet Generate web and Struts
  descriptors

• -verbose
• -debug
• -find ltfilegt
• -diagnostics
• -logfile ltfilegt
• -help
• and others

21
Sample Ant Run
gt ant deploy-jboss -Dsiteantdocs Buildfile
build.xml init echo Building for antdocs
site. deploy-jboss copy Copying 1 file
to /Users/erik/jboss-3.0.0/server/default/deploy
BUILD SUCCESSFUL Total time 18 seconds
22
Properties

• Ants parameterizability
• Immutable
• All JVM system properties available
• Useful Ant built-in properties
• ant.project.name
• basedir
• property.name for property value

23
ltpropertygt task

• Name/value ltproperty name"site"
  value"sample"/gt
• Load from properties fileltproperty
  file"sites/site/config.properties
  prefix"site"/gt
• Load environment variablesltproperty
  environment"env"/gt

24
Property for file/directory

• Use the location variant

ltproperty namebuild.dir locationbuild/gt lt
property name"index.dir
location"build.dir/site/index /gt
25
Properties Quiz
build.properties javac.debugoff
ltproperty filebuild.properties/gt ltproperty
namejavac.debug valueon/gt ltecho
messagedebug compilation is turned
javac.debug/gt
echo debug compilation is turned ????
off
26
Other Property setting tasks

• ltavailablegt - sets if resource present
• ltuptodategt - sets if source files older
• ltconditiongt - O/S, checksum, http, socket, files
  match, and more.
• lttstampgt
• ltxmlpropertygt

27
ltjavacgt

• Façade over Java compilers
• Performs .java/.class out-of-date checking
• Example of why the docs are important!

ltjavac srcdir"src/moduleadditional.src.d
irs" destdir"build.dir/module/classes"
debug"javac.debug" classpathref"compile
.classpath" /gt
28
ltjavacgt - A Closer Look
Property reference
ltjavac srcdir"src/moduleadditional.src.d
irs" destdir"build.dir/module/classes"
debug"javac.debug" classpathref"compile
.classpath" /gt
Path
Datatype reference
29
Ant Datatypes

• Provides domain expertise (e.g. paths)
• Reusable
• Commonly used built-in datatypes
• Path
• Fileset
• Patternset
• Filterset
• and others

30
Path

• Ordered list of path elements
• Analogous to Java CLASSPATH
• Cross-platform path syntax
• Contains files and/or directories
• May contain a fileset, individual elements, or
  nested paths.

ltpath id"anttask.compile.classpath"gt
ltpathelement location"lucene.jar"/gt
ltpathelement location"jtidy.jar"/gt lt/pathgt
31
Fileset

• Set of files from a single root directory
• Unordered
• Patternsets / Selectors filter files
• Many special files automatically excluded

ltfileset dir"web" excludes"search.jsp"/gt ltfiles
et dir"build.dir/site" includes".jsp"/gt
32
Patternset

• Collection of file matching patterns
• Relative paths, can apply to any root directory
• Exclusions take precedence
• ltincludegt/ltexcludegt conditional-capable

ltpatternset idjava.files.pattern
includes/.java/gt ltfileset dir"src"gt
ltpatternset refidjava.files.pattern/gt lt/fileset
gt
33
Filterset

• Token replacement

metadata/app/application.xml ltwebgt
ltweb-urigtantbook-_at_SITE_at_.warlt/web-urigt
ltcontext-rootgtantbook-_at_SITE_at_lt/context-rootgt lt/webgt
ltcopy todir"build.dir/site"
overwrite"true"gt ltfileset dir"metadata/app"
includes"application.xml"/gt ltfiltersetgt
ltfilter token"SITE" value"site"/gt
lt/filtersetgt lt/copygt
build.dir/antdocs/application.xml ltwebgt
ltweb-urigtantbook-antdocs.warlt/web-urigt
ltcontext-rootgtantbook-antdocslt/context-rootgt lt/web
gt
34
Other Ant datatypes

• Selector
• FilterChain / FilterReader
• Mapper - map source filename to destination
• Filelist - ordered collection of files
• Dirset
• ZipFileset
• ClassFileset

35
Overriding properties

• Carefully order ltpropertygtltproperty
  file"user.home/.ant.project.name-build.prop
  erties"/gtltproperty file"user.home/.build.prop
  erties"/gtltproperty file"build.properties"/gtltp
  roperty environment"env"/gtltproperty
  name"jboss.home" location"env.JBOSS_HOME"/gtlt
  property name"env.COMPUTERNAME"
  value"env.HOSTNAME"/gtltproperty
  name"lib.dir" location"lib"/gtltproperty
  file"lib.dir/lib.properties"/gtltproperty
  file"common.properties"/gt
• Command-line -D and -propertyfile switchesant
  deploy-jboss -Dsiteantdocsant -propertyfile
  nightly-build.properties

36
Controlling with Properties

• Existence of property is IMPORTANTltjunit
  ltbatchtest todir"test.dir/data"
  if"testcase"gt ltfileset
  dir"test.dir/module/classes
  includes"/testcase.class"/gt
  lt/batchtestgt ltbatchtest todir"test.dir/dat
  a" unless"testcase"gt ltfileset
  dir"test.dir/module/classes
  includes"/Test.class"/gt
  lt/batchtestgtlt/junitgt
• Conditional
• lttargetgt
• Patternset ltincludegt/ltexcludegt elements
• ltfailgt

ltfail unless"site.config.present"gt Site
configuration for site not present. lt/failgt
37
Datatype References

• ltpath id"web.compile.classpath"gt
• ltpathelement location"dist.dir/antbook-com
  mon.jar"/gt
• ltpathelement location"dist.dir/antbook-ejb
  .jar"/gt
• ltpathelement location"struts.jar"/gt
• ltpathelement location"oro.jar"/gt
• ltpathelement location"commons-digester.jar
  "/gt
• ltpathelement location"commons-fileupload.ja
  r"/gt
• ltpathelement location"commons-lang.jar"/gt
• ltpathelement location"commons-resources.jar
  "/gt
• ltpathelement location"commons-validator.jar
  "/gt
• ltpathelement location"j2ee.jar"/gt
• lt/pathgt
• ltpath id"web.test.classpath"gt
• ltpathelement location"junit.jar"/gt
• ltpath refid"web.compile.classpath"/gt
• lt/pathgt

38
Site Customization

• Controlled by site property
• Artifacts unique to site
• Index and content (of course)
• application.xml (different WAR file names)
• web.xml (different index directory references)
• jboss.xml (different JNDI names for session bean)
• search.jsp (results presentation differs)

39
Loading site properties
lt!-- Site configuration --gt ltproperty name"site"
value"sample"/gt ltproperty name"site.dir"
location"sites/site"/gt ltproperty
name"index.dir location"build.dir/
site/index"/gt ltproperty file"site.dir/conf
ig.properties prefix"site"/gt
sites/antdocs/config.properties search.linklta
href"file//ltbeanwrite name"item"
property"field(path)"/gt"gt
ltbeanwrite name"item" property"field(title)"/gtlt
/agt
40
Declarative logic

• Per-site customizations happen without any
  explicit logic
• search.jsp customizationltcopy
  todir"build.dir/site" overwrite"true"gt
  ltfileset dir"web" includes"search.jsp"/gt
  ltfiltersetgt ltfilter token"LINK
  value"site.search.link"/gt
  lt/filtersetgtlt/copygt
• WAR and EAR are named by siteltwar
  destfile"dist.dir/antbook-site.wargt

41
What else?

• JUnit / Cactus / HttpUnit
• Running Java / native programs
• Remote deployment
• Native development
• Custom Ant development
• Maven Centipede
• Continuous integration
• Last but not least..XDoclet

42
Part II XDoclet with Ant
43
Part II XDoclet Agenda

• Introduction to XDoclet
• XDoclet architecture
• The many ways XDoclet is leveraged

44
What is XDoclet?

• Javadoc metadata templating engine
• Attribute-oriented programming
• Outgrown its EJBDoclet roots

_at_tags
45
Why XDoclet?

• Avoid code/metadata duplication
• Pragmatic Programming
• DRY - Dont Repeat Yourself
• Program close to the problem domain
• Write code that writes code
• JSRs 175 181

46
JSR 175
A metadata facility for the JavaTM Programming
Language would allow classes, interfaces, fields,
and methods to be marked as having particular
attributes.
47
JSR 181
This JSR defines an annotated JavaTM format that
that uses JavaTM Language Metadata (JSR 175) to
enable easy definition of Java Web Services in a
J2EE container.
48
XDoclet Architecture

• Built upon XJavaDoc
• Separated into modules
• Sophisticated Ant tasks with dynamically loaded
  subtasks
• Embedded templates
• Tag handlers

49
XJavaDoc

• JavaCC-based source code parser
• Builds model of
• Packages
• Classes / inheritance hierarchy
• Methods and parameters
• Member variables
• Constructors
• Custom _at_tags
• oh yeah, and Javadoc comments too

50
Technical Architecture
content
Web Tier
Ant build ltindexgt task
EJB Container
index
51
Bonus Requirements

• Report the duration of each web request
• Allow viewing of build information from live
  application
• Build and deploy multiple sites simultaneously,
  each with separate indexes and content

52
ToDo List
53
_at_todo
/ Index the fileset. _at_exception
IOException if Lucene I/O exception _at_todo
refactor!!!!! / private void indexDocs() throws
IOException // . . .
54
Ant lttaskdefgt
lttaskdef name"todo" classname"xdoclet.m
odules.doc.DocumentDocletTask"
classpathref"xdoclet.classpath" /gt lttarget
name"todo"gt ltmkdir dir"build.dir/todo"/gt
lttodo destdir"build.dir/todo" gt
ltfileset dir"src/anttask"/gt ltfileset
dir"src/common"/gt ltfileset
dir"src/ejb"/gt ltfileset
dir"src/web"/gt ltinfo/gt
lt/todogt lt/targetgt
55
EJB Deployment Descriptor
. .lt!-- ejb-jar.xml --gt . ltenterprise-beansgt
ltsession gt ltejb-namegtorg.example.ant
book.session.SearchSessionlt/ejb-namegt
lthomegtorg.example.antbook.session.SearchSessionHom
elt/homegt ltremotegtorg.example.antbook.sess
ion.SearchSessionlt/remotegt ltejb-classgt
org.example.antbook.session.SearchSessio
nBean lt/ejb-classgt
ltsession-typegtStatelesslt/session-typegt
lttransaction-typegtContainerlt/transaction-typegt
lt/sessiongt . . .
56
Vender-specific Descriptors
ltjbossgt ltenterprise-beansgt ltsessiongt
ltejb-namegtorg.example.antbook.session.Searc
hSessionlt/ejb-namegt ltjndi-namegt
personal/org.example.antbook.session.SearchSessi
on lt/jndi-namegt lt/sessiongt
lt/enterprise-beansgt ltresource-managersgt
lt/resource-managersgt lt/jbossgt
57
Session Bean
/ _at_ejb.bean type"Stateless
jndi-name"site/org.example.antbook.session.Sea
rchSession" _at_ejb.util generate"physical"
/ public class SearchSessionBean implements
SessionBean // /
_at_ejb.interface-method / public
Document search(String indexDir, String query)
throws
SearchQueryException,SystemException
return SearchUtil.findDocuments(indexDir,
query)
58
Ant Property Substitution

• Allows build-time control over values generated

ltproperty file"user.home/.ant.project.name-
build.properties"/gt ltproperty file"user.home/.
build.properties"/gt ltproperty file"build.properti
es"/gt ltproperty name"site" value"sample"/gt
/ _at_ejb.bean type"Stateless
jndi-name"site/org.example.antbook.session.Sea
rchSession" _at_ejb.util generate"physical"
/ public class SearchSessionBean implements
SessionBean . . .
59
Session Bean XDoclet-style
SessionBean
Source Code
Remote interface
Home interface
Generated
Lookup Utilities
jboss.xml
ejb-jar.xml
60
ltejbdocletgt
lttarget name"ejbdoclet" depends"init"gt
lttaskdef name"ejbdoclet"
classname"xdoclet.modules.ejb.EjbDocletTask"
classpathref"xdoclet.classpath"/gt
ltmkdir dir"build.dir/ejb/gen"/gt
ltejbdoclet destdir"build.dir/ejb/gen"
addedtags"_at_xdoclet-generated at
TODAY" ejbspec"1.1"
force"xdoclet.force"
mergedir"metadata/ejb"gt ltfileset
dir"src/ejb"/gt ltremoteinterface/gt
lthomeinterface/gt ltutilobject/gt
ltjboss validatexml"true" destdir"build.dir
/site"/gt ltdeploymentdescriptor
validatexml"true"/gt lt/ejbdocletgt lt/targetgt
61
Servlet Definition
ltservletgt ltservlet-namegtsearch-initlt/servlet-
namegt ltservlet-classgt
org.example.antbook.web.SearchInitServlet
lt/servlet-classgt ltinit-paramgt
ltparam-namegtindex-dirlt/param-namegt
ltparam-valuegt/Users/erik/. . ./personal/indexlt/par
am-valuegt lt/init-paramgt
ltload-on-startupgt1lt/load-on-startupgt lt/servletgt
62
Servlet
/ _at_web.servlet name"search-init"
load-on-startup"1" _at_web.servlet-init-param
name"index-dir" value"index.dir" _at_todo
Refactor to use JNDI for directory lookup.
/ public class SearchInitServlet extends
HttpServlet public void init() throws
ServletException super.init()
ServletConfig config getServletConfig()
getServletContext().setAttribute(Constants.SEARCH
_DIRECTORY, config.getInitParamete
r("index-dir"))
63
Filter Definition
ltfiltergt ltfilter-namegtTimingFilterlt/filter-name
gt ltfilter-classgtorg.example.antbook.web.TimingFi
lterlt/filter-classgt lt/filtergt ltfilter-mappinggt
ltfilter-namegtTimingFilterlt/filter-namegt
lturl-patterngt/lt/url-patterngt lt/filter-mappinggt
64
Filter
/ Logs duration of each request.
_at_web.filter name"TimingFilter"
_at_web.filter-mapping url-pattern"/"
servlet-name"TimingFilter" / public class
TimingFilter implements Filter // . . .
65
Tag Library Descriptor
lttaglibgt lttlib-versiongt1.0lt/tlib-versiongt
ltjsp-versiongt1.2lt/jsp-versiongt
ltshort-namegtantbooklt/short-namegt lttaggt
ltnamegtbuildpropslt/namegt lttag-classgtorg.examp
le.antbook.web.BuildPropertiesTaglt/tag-classgt
lttei-classgtorg.example.antbook.web.BuildProperti
esTeilt/tei-classgt lt/taggt lt/taglibgt
66
Tag Library
/ Iterates build properties and places
name/value into page scope. _at_jsp.tag
name"buildprops" bodycontent"JSP"
tei-class"org.example.antbook.web.Buil
dPropertiesTei" / public class
BuildPropertiesTag extends BodyTagSupport
// . . .
67
Web Deployment Descriptor
SearchInitServlet
TimingFilter
BuildPropertiesTag
merge files
web.xml
68
Merge Points

• Not everything is stored in source code
• Customization entry point to generated artifacts
• Often documented in the generated code
• web.xml, for example
• External servlet mappings
• Tag library mappings
• Welcome file list, error pages, etc

69
Quick Struts Overview
SearchForm
ActionServlet
instantiates, populates, validates
/search.do?querye
SearchAction
executes
search.jsp
String resources
70
Struts Descriptors

• struts-config.xml
• Global form bean definitions
• Action mappings
• validation.xml
• Field-level validations per form or action
• I18N
• Extensible

71
struts-config.xml
ltform-beansgt ltform-bean name"SearchForm"
type"org.example.antbook.struts.Search
Form" /gt lt!-- If you have non
XDoclet forms, define them in a file
called struts-forms.xml and place it in
your merge directory. --gt lt/form-beansgt
72
validation.xml
Form bean name
ltform name"SearchForm"gt ltfield
property"query" depends"required"gt
ltmsg name"required"
key"query.required /gt ltarg0
key"SearchForm.query"/gt lt/fieldgt lt/formgt
Field name
Validation(s)
Message key
Argument for message
query.requiredYou must enter a query
73
Struts ActionForm
/ Search query entry form.
_at_struts.form name"SearchForm" / public
class SearchForm extends ValidatorForm
private String query / Sets the
query attribute of the SearchForm object
_at_struts.validator type"required"
msgkey"query.required" / public void
setQuery(String query) this.query
query public String getQuery()
return query
74
ltwebdocletgt
ltwebdoclet destdir"build.dir/web/WEB-INF"
force"xdoclet.force"
mergedir"metadata/web"gt ltfileset
dir"src/web"/gt ltdeploymentdescriptor
validatexml"true
destdir"build.dir/site /gt
ltjsptaglib validatexml"true
shortName"antbook
filename"antbook.tld /gt
ltstrutsconfigxml validatexml"true"
version"1.1"/gt ltstrutsvalidationxml
omitdtd"true"/gt lt/webdocletgt
75
Custom Generation

• Supply your own templates for the standard
  subtasks
• Use lttemplategt task for ad hoc generation
• Write tag handlers / subtasks

76
Ant Task Library

• Declare multiple Ant tasks using a properties
  filelttaskdef resource"taskdef.properties
  classpath"lucene.jardist.dir/antbook-antta
  sk.jarjtidy.jar"
• /gt
• Name/classname pairsindexorg.example.antbook.a
  nt.lucene.IndexTask
• Task(s) availableltindex index"index.dir
  overwrite"falsegtlt/indexgt

77
Custom Ant Task Metadata
/ Ant task to index files with Lucene
_at_ant.task name"index" / public class IndexTask
extends Task // . . .
78
lttemplategt subtask
ltxdoclet destdir"build.dir/anttask/classes"gt
ltfileset dir"src/anttask"gt ltinclude
name"/.java" /gt lt/filesetgt lttemplate
templatefile"metadata/anttask/taskdef.xdt"
destinationfile"taskdef.properties"gt
ltconfigParam name"date" value"DSTAMP _at_
TSTAMP"/gt lt/templategt lt/xdocletgt
79
XDoclet template
Created ltXDtConfigconfigParameterValue
paramName"date"/gt ltXDtClassforAllClassesgt
ltXDtClassifHasClassTag tagName"anttask"
paramName"name"gt ltXDtClassclassTagValue
tagName"anttask" paramName"name"/gt
ltXDtClassfullClassName/gt lt/XDtClassifHasClas
sTaggt lt/XDtClassforAllClassesgt
/ _at_ant.task name"index" / public class
IndexTask extends Task
Java source
Result
Created 20020903 _at_ 2133 indexorg.example.antbo
ok.ant.lucene.IndexTask
80
Passive Generators

• Based on metadata from XDoclet
• One-time generation
• Results customized
• Regeneration painful after customizing
• Great for rapid development
• Example
• Starter Struts JSP pages
• String resources

81
Starter Struts Pieces
SearchForm
JSP
Localized resources
SearchForm.queryQuery
lttablegt lttrgt ltthgtltbeanmessage
key"SearchForm.query"/gtlt/thgt lttdgtlthtmltext
property"query"/gtlt/tdgt lt/trgt lt/tablegt
82
Per-class template generation
ltxdoclet destdir"build.dir
excludedtags"_at_version,_at_author"
force"xdoclet.force"gt ltfileset
dir"struts.src.dir"
includes"/form.name.java" /gt
lttemplate templateFile"src/FormKeys.xdt"
ofType"org.apache.struts.validator.Valida
torForm" acceptAbstractClasses"fa
lse" prefixWithPackageStructure"f
alse" destinationFile"0.propert
ies" /gt lttemplate templateFile"src/St
rutsForm_jsp.xdt"
ofType"org.apache.struts.validator.ValidatorForm"
acceptAbstractClasses"false"
prefixWithPackageStructure"false"
destinationFile"0.jsp"
/gt lt/xdocletgt
83
Template w/ Custom Tag
ltXDtTagDeftagDef namespace"Struts
handler"org.example.antbook.xdoclet.FormTags
Handler"/gt ltXDtStrutsforAllFieldsgt ltXDtClass
classTagValue tagName"struts.form"
paramName"name"/gt. ltXDtStrutsfieldName/
gtltXDtStrutsfieldDescription/gt
lt/XDtStrutsforAllFieldsgt
84
Custom Tag Handler
public void forAllFields(String template,
Properties attributes)
throws XDocletException
XClass clazz getCurrentClass() TreeMap
setters new TreeMap(getFields(clazz)) for
(Iterator iterator setters.keySet().iterator()

iterator.hasNext()) curFieldName
(String) iterator.next() XMethod field
(XMethod) setters.get(curFieldName)
setCurrentMethod(field)
generate(template) public String
fieldName(Properties props) return
curFieldName
85
Future of XDoclet

• Velocity templating
• Jakarta project?
• Support for metadata JSRs

86
References

• Java Development with Ant
• http//www.amazon.com/exec/obidos/ASIN/1930110588
• http//www.manning.com/antbook/
• XDoclet
• http//xdoclet.sourceforge.net
• Pragmatic Programmer
• http//www.pragmaticprogrammer.com/
• Agile development
• eXtreme Programming Explained, Kent Beck
• Agile Modeling, Scott Ambler

87
The End

• Q A
• Demos
• Thank You!
