Introduction to Modern Measurement SEM and IRT

1
Introduction to Modern Measurement SEM and IRT

• Paul Crane, MD MPH
• Rich Jones, ScD
• Friday Harbor 2006

2
Outline

• Intro and definitions
• Factor analysis and link to IRT
• Parametric IRT models
• Information curves and rational test design
• Model assumptions
• Applications in cognition

3
Use of modern measurement tools

• Educational testing since 1968, most
  educational tests built using this framework
• SATs, GREs, high-stakes tests, MCATs, LSATs
• Increasing in psychology in general
• In the medical arena, increasing use in patient
  reported outcomes (health-related quality of
  life, depression, etc.)
• PROMIS
• Most people who have used these tools on
  cognitive functioning tests are in this room

4
Definitions of measurement

• The assignment of numerals to objects or events
  according to some rule (Stevens 1946)
• The numerical estimation and expression of the
  magnitude of one quantity relative to another
  (Michell, 1997)
• These definitions imply different perspectives on
  what we do with test data

5
Purposes of measurement

• (After Kirshner and Guyatt)
• Discriminative purpose
• Evaluative purpose
• Predictive purpose
• Statistical properties desired differ according
  to the purpose of measurement
• Often tests are used for multiple purposes,
  without necessarily documenting appropriateness
  for intended purpose
• Well come back to this

6
Latent traits or abilities

• The underlying thing we are trying to measure
  with a test
• Cant be directly observed (hence latent)
• Cause observable behavior (such as responses on a
  test)
• A task of psychometrics is to try to determine
  levels of latent traits or abilities based on
  responses to test items

7
Factor analysis

• Factor analysis history intimately involved with
  history of psychometrics (Spearman, Thurstone)
• Analyze a covariance (correlation) matrix
• Exploratory factor analysis / principal
  components analysis
• Identify a factor that explains most of the
  variance in the matrix
• Extract the factor and determine whats left
  (residual matrix)
• (Rotate)
• Repeat

8
CFA

• Theory driven
• Some relationships between specific factors and
  indicators are specified to be 0
• Fit always worse than EFA (which can be proven to
  have optimal fit)
• Single factor CFA very useful

9
Picture of single factor CFA
Latent trait
Item 1
Item 4
Item 3
Item 2
Item 6
Item 5
10
Relationship between CFA and IRT

• I have long believed that a very general version
  of the common factor model supplies a rigorous
  and unified treatment of the major concepts and
  techniques of test theory. The implicit unifying
  principle throughout the following pages is a
  general nonlinear common factor model, which
  includes item response models as special cases,
  and includes also the (linear) common factor
  model as an approximation.
• Roderick McDonald, Test Theory A Unified
  Treatment (1999) p. x.

11
Single common factor math

• X1 ?1F E1
• X2 ?2F E2
• X3 ?3F E3
• Item 1 response (X1) is the sum of a common part
  the loading (?1) times the amount of the factor
  (F), plus a unique part (E1)

12
Enhanced picture of single factor CFA
F
?1
?6
?2
?3
?5
?4
X 1
X 4
X 3
X 2
X 6
X 5
E3
E4
E5
E6
E1
E2
13
Dichotomous / categorical items

• Our picture is of continuous predictors X1-X6
• In practice items are not continuous, they are
  categorical or dichotomous
• Has implications for the unique parts (E1-E6)
• A new parameter needed for threshold(s)

14
(Tetrachoric and polychoric)

• Maps a continuous underlying level (Xj) to a
  dichotomous indicator Xj
• Requires a threshold parameter tj
• If Xj gt tj, Xj 1
• If Xj tj, Xj 0
• Observed data for Xj and Xk are used to estimate
  Xj and Xk, and the correlation between Xj and
  Xk is the tetrachoric correlation
• Extension to gt2 categories polychoric correlation

15
(Tetrachoric and polychoric picture)
Thanks Rich!
16
Item response models

• Introduce a new character ? (theta)
• We met ? as F before
• The (level of the) underlying trait (ability)
  measured by the test
• Starts with dichotomous (polytomous) items rather
  than with continuous correlation matrix ends up
  in the same place

17
(Nonparametric IRT)

• Monotonic increasing relationship between theta
  and item responses
• Obtain ordinal relationships among test takers
• Can use software to determine whether shapes of
  curves look parametric
• Sijtsma and Molenaar, Introduction to
  Nonparametric Item Response Theory (2002)
• MSP5 for Windows
• (I am aware of only one non-parametric paper
  published in medical settings Thanks Rich)

18
Parametric IRT

• (Misquoting Box) All parameterizations are
  wrong, but some are useful.
• Cumulative normal vs. logistic (logistic has won
  because of ease of computation no practical
  difference)
• Number of parameters 4PL models (!)
• Extensions to polytomous items vary

19
1PL item characteristic curves
20
1PL (aka Rasch model)

• Single parameter for the item is item difficulty
  (b)
• P(Y1?,a) exp(?-b)/1exp(?-b)
• Mathematically the same to write as
• 1exp(-1(?-b))-1
• The distance between a subjects latent trait
  level ? and the items difficulty level b
  determines the probability of endorsing the item
  (or getting the item right)
• All of the loadings for all of the items are
  fixed (?1 ?2 ?k)

21
2PL item characteristic curves
22
2PL

• A second parameter is added to account for
  varying strengths of relationship between items
  and ?. Known as discrimination (a).
• P(Y1?,a,b) exp(a(?-b))/1exp(a(?-b))
• Relationship between ? and b still drives item
  responses
• The a parameter allows our loadings to vary
• The constant D (1.702) is often included in
  formulas. This constant makes the logistic
  curves approximate the normal ogive curves
• P(Y1?,a,b) exp(Da(?-b))/1exp(Da(?-b))

23
1PL vs. 2PL

• Vociferous debates in educational testing
  literature, related to specific objectivity
  from the Rasch literature
• (Has not been an issue in medicine)
• The difficulty parameter is MUCH more important
  for subject scores than the discrimination
  parameter
• ? scores estimated from the 1PL and 2PL models
  are incredibly highly correlated
• 2PL model provides additional insight into how
  good the items may be

24
(3PL and 4PL)

• 3PL incorporates a guessing parameter even
  subjects with very low ability will have a
  non-zero probability of picking the correct
  answer at random in a multiple choice test
• P(Y1?,a,b,c)
• c(1-c)exp(Da(?-b))/1exp(Da(?-b))
• 4PL incorporates a attractive distractor
  parameter even subjects with very high ability
  may be distracted by a nearly correct alternative
• Neither model is relevant for tests that do not
  have multiple choice response formats

25
(Polytomous IRT)

• 2PL extension called the Graded Response Model
  (GRM), Samejima (1969) // to proportional odds
  model for ordinal logistic regression
• 1PL extensions Partial Credit Model (PCM),
  Generalized Partial Credit Model (GPCM), Rating
  Scale Model (RSM)

26
Reliability vs. information

• Reliability is a key feature in classical test
  theory
• McDonalds omega, Cronbachs alpha KR-20
  (Kuder-Richardson, formula 20)
• Provides a single number for the proportion of
  the total score that is true
• Assumes measurement error is constant for a test
• IRT focus shifted to information
• Information analogous to measurement precision
• Varies according to item parameters

27
Information - intuitive

• If there are a lot of hard items, there will be
  relatively more measurement precision for
  individuals with large ? scores
• If there are few hard items, there will be less
  measurement precision for individuals with large
  ? scores
• Precision for individuals with large ? scores
  tells us nothing about precision for individuals
  with small ? scores (would need to know about
  easy items rather than hard items)

28
(Information formulas)

• General I(?) P(?)2/P(?)1-P(?)
• P(?) is the first derivative of P(?)
• 2PL model I(?) D2a2P(?)1-P(?)
• P(?)1-P(?) part makes a hill around the point
  where ? b
• P(?) approaches 0 as ?ltltb
• 1-P(?) approaches 0 as ?gtgtb
• D2 is a constant
• a2 is proportional to the height of the
  information curve around the point where ? b

29
Information - test

• Test information is simply the sum of all of the
  item information curves
• (local independence)
• SEM 1/SQRT(I(?))

30
Kirshner and Guyatt revisited
31
SEM for common screening tests
Red MMSE, blue 3MS, black CASI, green CSI
D.
32
Rational test design

• Start with an item bank (items all in the same
  domain whose parameters have been established)
• Select items in order to fill out a specific
  information curve
• Shape of curve may vary based on purpose of
  measurement
• Mungas et al. matched information curves for
  memory, executive functioning, and global
  cognition
• My workgroup replicating this specific aspect of
  the project

33
Parameterization isnt free

• There are assumptions to IRT and to the models we
  use
• Unidimensionality
• Local independence
• Model fits the data well
• Well look at each of these assumptions in turn

34
Unidimensionality

• Intuitively IRT is a single factor model fit to
  the data. If it is a bad idea to use a single
  factor model on the data, then IRT is a bad idea
  too.
• Pure unidimensionality is impossible emphasis
  has shifted to essential or sufficient
  unidimensionality
• Analyses focus on the residual covariance matrix
  from the single common factor model
• A strong factor emerging from the residual
  covariance matrix hints that a single factor may
  not explain the data well

35
Bi-factor model and unidimensionality

• Instead of EFA approach on the residual
  covariance matrix, use a CFA approach
• Suggested by McDonald (1999, 1990) recently have
  seen more of this (Atlanta 2/2006)
• Theory precedes analysis have to have
  pre-specified subdomains

36
Bi-factor model of executive functioning
37
Standardized loadings (gt0.30)
38
Local independence

• Residual correlation should be no larger than
  chance
• Violations several items related to a common
  passage (testlet) trials on a memory test
• Not clear how robust the models are to violations
  of local independence
• (Information curve height may be artificially
  high if there are items with local independence)

39
Model fit

• No established criteria for 2PL and polytomous
  items
• (But Bjorner et al. 2005 poster at ISOQOL)
• ?2 statistics produced by PARSCALE are
  sample-size dependent
• There are fit statistics that have been developed
  for SEM models, and benchmarks have been
  established
• RMSEA, CFI available from MPLUS for categorical
  items (Rich is that right?)

40
Why bother?

• Theoretical reasons
• Rational scoring system based on empiric
  relationships rather than unlikely assumptions of
  pre-specified weights and thresholds
• Linearity of IRT scale
• Utility of information (as opposed to alpha)
• Practical reasons we have found stronger
  relationships for IRT scores than for standard
  scores with outcomes of interest (imaging
  dementia status)
• There are a lot more things we can do with IRT
  than with CTT (see next slide)

41
Applications of IRT - cognition

• Co-calibration of scales (FH 2004)
• Generate psychometrically matched scales (same
  information curves) simultaneously in Spanish and
  English (Dans work on the SENAS)
• Determine and account for differential item
  functioning (DIF) (FH 2005)
• Determine and account for varying measurement
  precision (FH 2004)
• A single composite score instead of multiple
  scores for analyses (FH 2006)

42
How to do it?

• Off-the-shelf IRT package, e.g. PARSCALE (FH
  2006)
• Off-the-shelf SEM package, e.g. MPLUS (FH 2006)
• Increasingly common write your own Bayesian code
  using WINBUGS (FH 2008???)
• SAS PROC NLMIXED (Sheu et al. 2005) (FH 2008?)
• STATA user-written code?

43
Practical considerations

• Data requirements
• Large data set (500 or so)
• Long enough scales (5 items an absolute minimum
  more is better)
• Sample with heterogeneous levels of ?
• Software fails with sparse response categories
• We will demonstrate a STATA program that runs
  PARSCALE (runparscale)
• We will also demonstrate a STATA program that
  runs MPLUS (runmplus)

44
New topic DIF

• DIF defined an item has DIF if, when controlling
  for ?, subjects in different groups have
  different probabilities of item responses for
  that item
• Item-level bias
• In math P(Y1 ?,Group) ? P(Y1 ?)
• Group membership interferes with the expected
  tight relationship between ? and item response

45
DIF detection

• Plethora of techniques
• IRT techniques (FH 2005)
• SEM techniques (MIMIC model) (FH 2005)
• (Ordinal) logistic regression techniques
• Hybrid ordinal logistic regression / IRT
  technique (FH 2005)
• Each technique hinges on identifying items with
  no DIF to serve as anchors

46
IRT DIF detection- principles

• Compare IRT curves calibrated separately from the
  group(s)
• In the absence of DIF they will be superimposed
• What is theta?
• Iterative algorithms for identifying items that
  are free of DIF to serve as anchors
• Statistical significance typically used
• Also Raju developed tests based on area between
  curves (mathematically equivalent to statistical
  significance tests)

47
SEM techniques - principles

• Measurement model with covariates
• Initially specify a model with a main effect for
  the covariate, and indirect effects for the
  covariate on each of the items, initially set to
  0 (see next slide)
• Look at Modification Indices, improvements of fit
  for freeing one constraint at a time

48
MIMIC model picture
F
X
0
0
0
0
0
0
X 1
X 4
X 3
X 2
X 6
X 5
49
OLR - principles

• Fit nested (ordinal) logistic regression models
• P(Y1X,g)ß1Xß2gß3(Xg) (model 1)
• P(Y1X,g)ß1Xß2g (model 2)
• P(Y1X,g)ß1X (model 3)
• NUDIF is statistical significance of the
  interaction term (LL difference between models 1
  and 2)
• UDIF
• statistical significance of the group term
  (Hambleton et al, 1991)
• Proportional change in ß1 from models 2 and 3
  (Crane et al. 2004)

50
Hybrid IRT-OLR - principles

• Techniques that rely on standard sum score (X) at
  least theoretically flawed (Millsap and Everson)
• Substitute IRT-derived ? for X (Crane et al.
  2004)
• P(Y1?,g)ß1?ß2gß3(?g) (model 1)
• P(Y1?,g)ß1?ß2g (model 2)
• P(Y1?,g)ß1? (model 3)

51
What to do when we find DIF?

• Ignore
• Omit items found with DIF from the scale
• Account for DIF items by generating and using
  demographic-specific item parameters (Reise et
  al.)

52
Demographic specific item parameters data
structure
53
DIF presence vs. DIF impact

• So far have addressed the question Is it there?
• Have not addressed the question Does it matter?
• We can determine how much individual scores
  change, and display graphically
• Executive functioning items analyzed at FH 2005
  (see next slide)

54
DIF impact
55
Relationships to external criteria

• Concurrent head MRI with volumes of white matter
  hyperintensities and total brain volume
• Amount of variance in scores explained by MRI
  measures
• Total sum score 0.11 IRT score 0.13. IRT
  score accounting for DIF 0.16
• Removing the nuisance of DIF (Shealy and Stout)
• Publicly available STATA code (FH 2006)
