Tolerances in Engineering Design

1
Tolerances in Engineering Design

• STEP Lesson 2
• 2/7/08
• STEP Fellow Mr. Herfat
• STEP Teacher Mrs. Truesdell

2
Tolerances Review

• No two manufactured objects are identical in
  every way. Some degree of variation will exist.
• Engineers apply tolerances to part dimensions to
  reduce the amount of variation that occurs.
• A tolerance is an acceptable amount of
  dimensional variation that will still allow an
  object to function correctly.

3
Medical Devices

• Medical device - covers a wide range of health or
  medical instruments used in the treatment,
  control, diagnosis or prevention of a disease or
  abnormal physical condition.
• Prosthesis - a device, either external or
  implanted, that substitutes for a missing or
  defective part of the body.

4
(No Transcript)
5
Tolerances in the Nati
6
Tolerances in the Nati
7
Tolerances in Medical Design

• Total Knee Reconstruction (DePuy Orthopaedics,
  IN)
• checked with laser scanning
• complex sculptured contours required for proper
  functioning
• Very precise tolerances are needed
• abnormal motion (additional range of motion)
• additional loading on other structures
• wear on the implant
• too little movement will not restore full range
  of motion.
