3Com Secure Converged Network ( Wireless LAN )

1
3Com Secure Converged Network ( Wireless LAN )

• December 2005 gtgt Mr. Anusit Ratchadalertnarong
• Anusit_ratchadalertnarong_at_3com.com

2
Technology Forces

• Miniaturization, portability, mobile power
• Increasing bandwidth, wired and wireless
• Convergence data, voice, video,
• Connection and connection-less models
• Virtualization compute, storage, network
• Service oriented architectures integration

3
Broadband Wireless Access Evolution
Mass-production
Production
Pilots
Concept
EDGE
HSUPA
GSM
GPRS
TD-CDMA / UMTS-TDD
UMTS/WCDMA
HSDPA
EDGEPh2
ETSI
CDMA 1x EV-DO
CDMA 1x EV-DV
CDMAIS-95A
CDMA 2000 1xRTT
IEEE
802.16e
802.16a
802.16-2004
802.20
MC-CDMA / Navini
Proprietary
Flash OFDM / Flarion
TDMA/FDMA/SDMA / iBurst
4
What is WiMAX?

• WiMAX Worldwide Interoperability for Microwave
  Access
• Refers to wireless technologies based on 802.16
  standard
• Standard designed to provide cost-effective
  fixed, portable, and eventually mobile broadband
  connectivity at speeds as fast or faster than
  cable/DSL for residential and T1/E1 for
  businesses
• Fixed WiMAX applications
• Residential and business connectivity where
  cable/DSL or fiber not available
• Rural and suburban areas of developed countries
  and developing countries
• Mobile WiMAX applications
• Personal broadband experience for consumer
• Urban areas become MetroZones for broadband
  access everywhere

5
Broadband Wireless Sweet Spot
6
WiMAX Network Models Time Frames
Access 2005
Portable 2006
Mobile 2007/8
Metrozone
Fixed Outdoor
Fixed Indoor
Enterprise Campus Piconet
Backhaul
Wi-Fi Hotspot
Mobile
7
WiMAX Technology Overview
8
Broadband Wireless Access Evolution
Mass-production
Production
Pilots
Concept
EDGE
HSUPA
GSM
GPRS
TD-CDMA / UMTS-TDD
UMTS/WCDMA
HSDPA
EDGEPh2
ETSI
CDMA 1x EV-DO
CDMA 1x EV-DV
CDMAIS-95A
CDMA 2000 1xRTT
IEEE
802.16e
802.16a
802.16-2004
802.20
MC-CDMA / Navini
Proprietary
Flash OFDM / Flarion
TDMA/FDMA/SDMA / iBurst
9
Choose Your 802.11 Flavor with No Limit to Your
Security Preference
802.11a 802.11b 802.11g
Standard Ratified 2002 1999 2003
Radio Band 5GHz 2.4GHz 2.4GHz
Data Rates Up to 54Mbps Up to 11Mbps Up to 54Mbps
Coverage Area Up to 50 Meters Up to 100 Meters Up to 100 Meters
Pros Less potential for interference Good support for multimedia apps and densely populated user environments Large installed base Compatible with 802.11b High data rates and broad coverage area
Cons Requires hardware upgrade Less coverage area Slower data rate Interference in 2.4GHz band Interference in 2.4GHz band
10
More Channels Avoids Interference
802.11a/g
802.11b/g
1
1
Distance to Center Cell
2
2
4
3
3
3
3
7
6
14
1
10
1
1
1
10
2
13
2
2
2
12
3
3
3
3
1
3
7
16
1
1
14
1
11
1
2
2
2
2
4
6
8
13
3
3
3
5
15
10
1
1
1
10
13
1
8
2
2
2
15
3
9
3
3
6
9
1
12

• 16 non-overlapping channels and 408.5MHz of
  spectrum at 2.4 and 5GHz makes it possible to set
  up networks without co-channel interference for
  enterprises, public hot spots, and other large
  installations
• 3 non-overlapping channels and 83.5MHz of
  spectrum at 2.4GHz make co-channel interference
  and performance degradation inevitable

11
802.11X Standards

• WLAN Systems
• 802.11a 5GHz System, 54 Mbps
• 802.11b 2.4GHz System, 11 Mbps
• 802.11g 2.4GHz System, 54 Mbps
• WLAN Enhancements
• 802.11c MAC Routing (moved to 802.1c)
• 802.11d Country compatibility (roaming) for
  802.11b
• 802.11e Enhanced MAC for QoS
• 802.11f Inter Access Point Protocol
• 802.11h Channel Selection and Transmit Power for
  802.11a
• 802.11i Secure MAC
• 802.11j Channel Selection for Japan
• 802.11k Client feedback
• 802.11n High speed
• 802.11r Roaming
• 802.11s Defines a MAC and PHY for meshed networks
• 802.1X Authentication

12
WLAN Deployment Considerations

• Site planning
• Coverage and Capacity
• Mobility
• Roaming User management
• RF Management
• Rogue detection
• Power Channel management
• Security
• Authentication Encryption
• Network Management
• Network Extension

13
3Com Secure Converge Network
3Com Switch 7750/8800
3Com TippingPoint
3Com VCX System
3Com Router
Video Server
3Com SuperStack 3 Switch
3Com AP 8250/7250
3Com AP 3750
3Com AP 2750
3Com AP 2750
Mobile User
Multicast User
Wi-Fi PDA
Mobile User
Wi-Fi Phone
14
Site Planning
15
3Com Secure Converge Network
3Com Switch 7750/8800
3Com TippingPoint
3Com VCX System
3Com Router
3Com Wireless Switch Manager
3Com Wireless Switch
Video Server
3Com SuperStack 3 Switch
3Com AP 8250/7250
3Com AP 3750
3Com AP 2750
3Com AP 2750
Mobile User
Multicast User
Wi-Fi PDA
Mobile User
Wi-Fi Phone
16
Easy and Powerful Site Planning

• Plan and Configure
• Enter building plans, including walls wall
  materials
• Result
• AP location recommendations for coverage pattern
• Predictive modeling capabilities allow user to
  try different scenarios
• Deploy and Manage
• Install APs as described in the deployment plan
• Management software will sweep the environment
  and adjust channel and power settings to optimize
  the network

3Coms Wireless Switch Manager Deployment
Software Tool
17
Mobility
18
3Com Secure Converge Network
3Com Switch 7750/8800
3Com TippingPoint
3Com VCX System
3Com Router
3Com Wireless Switch Manager
3Com Wireless Switch
Video Server
Wireless Roaming Wi-Fi Multimedia ( WMM)
3Com SuperStack 3 Switch
3Com AP 8250/7250
3Com AP 3750
3Com AP 2750
3Com AP 2750
Mobile User
Multicast User
Wi-Fi PDA
Mobile User
19
RF Management
20
RF ManagementCentralized Control of AP
Environment
3Com Wireless Switch

• Dynamic real time control of RF environment
• Centralized control of AP radios, including
• Channel selection and amplification
• Automatic channel assignment
• Load balancing based on of users and traffic to
  optimize throughput
• Adjust radio power to eliminate coverage gaps,
  even on large networks
• Allows direct control of RF optimization
• Control of all radio channels gain

21
3Com Secure Converge Network
3Com Switch 7750/8800
3Com TippingPoint
3Com Router
3Com Wireless Switch Manager
3Com Wireless Switch
Video Server
3Com SuperStack 3 Switch
3Com AP 8250/7250
3Com AP 3750
3Com AP 2750
3Com AP 2750
Mobile User
Multicast User
Wi-Fi PDA
Wi-Fi Phone
Rogue AP
22
Intrusion Detection System ( IDS )

• RF Management
• Listen to all communication
• Correlate Data
• Identify
• Rogue APs
• Users of rogue APs
• Ad hoc user groups
• Locate
• Triangulation
• Improves with density
• Active Scan
• Utilization of all radios all the time

RF Management
23
3Com Secure Converge Network
3Com Switch 7750/8800
3Com TippingPoint
3Com Router
3Com Wireless Switch Manager
3Com Wireless Switch
Video Server
Rogue Detection and Containment
3Com SuperStack 3 Switch
3Com AP 8250/7250
3Com AP 3750
3Com AP 2750
3Com AP 2750
Mobile User
Multicast User
Wi-Fi PDA
Wi-Fi Phone
Rogue AP
24
Security
25
Two Key Elements in Security ProtectionAuthentic
ation Encryption
Safeguard Data Broadcast
Valid User???

• Authentication
• Is this a valid user of your network?
• Is this user who you think he is?
• Verify with password control access lists

• Encryption
• Wireless data is by nature broadcast
• Scramble data to safeguard the data network
• Need sophisticated algorithms for best protection

Need both Authentication Encryption for
Protection
26
What Types of Authentication are There?

• Authenticate to prove user identity
• 802.11 Authentication
• Shared key based (password)
• Happens before Access Point association
• Open system (no authentication)
• MAC address filtering (aka local MAC
  authentication)
• Shared key (encrypted challenge with WEP key)
• 802.1X Authentication
• Certificate based
• Happens after Access Point association
• Uses Extended Authentication Protocol (EAP)
• Offers full suite of secure authentication
  protocols
• LEAP, PEAP, EAP-TLS, EAP-TTLS,
• Much better than 802.11 authentication

27
Auto VLAN and QoS Assignment using 802.1X
HR
Red VLAN
Bule VLAN
28
Auto VLAN Assignment using 802.1X with Wireless
Access Points
HR
Red VLAN
Bule VLAN
29
3Com Secure Converge Network
3Com Switch 7750/8800
3Com TippingPoint
3Com VCX System
3Com Router
3Com Wireless Switch Manager
3Com Wireless Switch
Video Server
IEEE 802.1x ( User name Password ) Radius
Authenticated Devices Access ( RADA)
3Com SuperStack 3 Switch
3Com AP 8250/7250
3Com AP 3750
3Com AP 2750
3Com AP 2750
Multicast User
Wi-Fi PDA
Wi-Fi Phone
30
Radius Authenticated Devices Access ( RADA )
HR
Red VLAN
Bule VLAN
31
What Types of Wireless Security Options Do I
Have?

• Remember
• Authenticate
• Message Integrity Check
• Encrypt

• OPEN
• No authentication
• CRC message checking
• No encryption
• WEP/WEP2
• Optional MAC address filtering (aka local MAC
  authentication)
• CRC message checking
• Static shared key encryption (password)
• 40/104-bit RC4 cipher key
• WEP2 adds a rotating key (e.g. DSL or LEAP)
• WPA (ratified July 2003)
• 802.1X authentication (requires EAP)
• MIC/CRC message checking
• TKIP (128-bit RC4 cipher rotating, 128-bit AES
  optional)
• 802.11i (ratified June 2004)
• 802.1X authentication (requires EAP)
• MIC/CRC message checking
• TKIP or AES (256-bit AES is mandatory)

Stronger Security
32
WarChalking
33
Wireless Tools

• Types of Monitoring tools
• Stumbling
• Sniffing
• Handheld
• Hacking tools
• WEP Cracking
• ARP Spoofing

34
Netstumbler

• http//www.netstumbler.com
• Free
• Window based
• Very simple GUI
• GPS capable

35
Wellenreiter

• http//www.remote-exploit.org
• Free
• Linux based
• Supports many
• wireless cards
• GPS capable

36
AirMagnet

• http//www.airmagnet.com/
• Pocket PC based

37
WEP Cracking Tools

• WEPCrack
• http//wepcrack.sourceforge.net/
• AirSnort
• http//sourceforge.net/projects/airsnort/
• BSD-Tools dweputils
• http//www.dachb0den.com/projects/dweputils.html

38
New 802.11i Security

• Addresses the main problems of WEP and Shared-Key
  Authentication
• Temporal Key Integrity Protocol (TKIP)
• Message Integrity Control Michael
• AES Encryption replacement for RC4
• Robust Security Network (RSN)
• Require new wireless hardware
• Ratification YE 2004

39
Information Security Hype Cycle
Visibility
Key Time to Plateau
Less than two years Two to five years Five to 10
years More than 10 years Obsolete before Plateau
Instant Messaging Security
Deep Packet Inspection Firewalls
Spam Filtering
All-in-One Security Appliances
Patch Management
Secure Sockets Layer VPNs
Personal Intrusion Prevention
Web Services Security Standards
Vulnerability Management
Hardware Tokens
Federated Identity
Security Smart Cards
Scan and Block
Biometrics
Secure Sockets Layer/Trusted Link Security
Reduced Sign-On
Trusted Computing Group
Managed Security Service Providers
Identity Management
Security Platforms
Data-at-Rest Encryption Appliances
Public Key Operations/ Soft Tokens
Digital Rights Management (enterprise)
Intrusion Detection Systems
WPA Security
Compliance Tools
As of June 2004
Technology Trigger
Peak of Inflated Expectations
Trough of Disillusionment
Slope of Enlightenment
Plateau of Productivity
Maturity
Acronym Key VPN virtual private network WPA Wi-Fi
Protected Access
40
3Com Secure Converge Network
3Com Switch 7750/8800
3Com TippingPoint
3Com VCX System
3Com Router
3Com Wireless Switch Manager
3Com Wireless Switch
Video Server
3Com SuperStack 3 Switch
3Com AP 8250/7250
3Com AP 3750
3Com AP 2750
3Com AP 2750
Mobile User
Multicast User
Wi-Fi PDA
Mobile User
Wi-Fi Phone
41
3Com IPS Primary Function Block Malicious
Traffic

• External Attackers
• Industrial Spies
• Govt Spies
• Terrorists
• Cyber Thieves
• Pranksters

TippingPoint blocks malicious traffic in the
network before it damages your companys
information assets

• Internal Attackers
• Disgruntled Employees
• Dishonest Employees

Good traffic passes through
The IPS blocks malicious traffic based on filters
settings.
Valid User Application Traffic
Cisco IOS
42
3Com TippingPoint Quarantine ServiceSecure
Converged Networks

• TippingPoint Intrusion Protection Systems works
  with 3Com switches for Quarantine Protection
• Quarantine protects endpoints and enforces policy
• Requires no software client or agent
• Protection is flexible, automatic and fast

Switch 7750/5500
43
3Com Wireless Enterprise Solution
44
3Com Wireless Switch Solution
3Com Wireless LAN Controller WX4400

• Enterprise WLAN controller
• 4 Gigabit-port switch
• 3.6Gbps throughput
• 24-96 MAPs

Access Point 2750/3750
Access Point 7250 Access Point 8250
3Com Wireless LAN Switch WX1200
3Com Wireless Switch Manger 3CWXM

• Enterprise/SMB WLAN Switch
• 2-port 10/100Mbps x 6-port 10/100Mbps PoE switch
• 200Mbps throughput
• 12 MAPs

3Com Wireless LAN Switch WXR100

• Remote Office WLAN Switch
• 2-port 10/100Mbps
• 3 MAPs

45
TippingPoint Product Line
Security Management System
Wire Speed IPS
46
3Com 802.11 Client

• 802.11 a/b/g PC Card PCI
• XJACK dual band antenna (PC Card)
• Power management build into XJACK
• USB Adapter
• Wireless 11g Travel Router
• Wireless Print Server

PCI Card
PC Card
USB Adapter
OC 11g Travel Router
OC 11g Print server
