An International Solution for the United States
ADS-B Program

• Eric Rolfe
• 15 February 2007

Export Control Approval TD-07-0015
2
Raytheon Who We Are

• We are
• A Customer Focused company that places the
  highest value on People, Integrity, Commitment
  and Excellence
• 2005 Sales 21.9 billion
• More than 80,000 employees worldwide
• Headquarters Waltham, Massachusetts
• Our Vision
• Be the most admired defense and aerospace systems
  supplier through world-class people and
  technology.

Working as One Company Focused on Customer Success
3
Raytheon What We Do

• A world leader in technology-driven solutions
  that provide customers with integrated mission
  systems
• Raytheon is an industry leader in
• Defense, government and commercial electronics
• Space
• Information technology
• Technical services
• Business aviation and special mission aircraft
• Raytheon provides integrated mission systems to
  meet the critical defense and non-defense needs
  of its customers

Focused on the Customer
4
Raytheon ATM around the World
Raytheons ATM success and global presence in
over 45 countries is achieved through customer
focus, state-of-the-art technology and total
system solutions capability
5
Raytheon Solid State ATC Radars Around the World
Switzerland
Botswana
China
Oman
Norway - Gullfaks
Heathrow
US
India
6
ADS-B Example International Requirements
also trial systems in China, Tanzania
7
US Requirements
8
History

• Three links considered VDL-M4, 1090ES, UAT
• EUROCONTROL/FAA co-chaired Link Assessment Team
• FAA performed cost/benefit analysis
• Link Decision 2002
• Two links are selected
• 1090ES for high flying aircraft
• UAT for low flying GA aircraft
• Benefits
• Safety (visual acquisition, situational
  awareness, graphical weather)
• Capacity (spacing and separation, surveillance in
  non-radar airspace)
• Underlying Idea was that users would equip to get
  the benefits
• GA Traffic Information Service and Flight
  Information Service
• Air Carrier Terminal/Surface Applications

9
Traffic Information Service Broadcast (TIS-B)

• Uplink broadcast of radar (or other sensor)
  derived nearby aircraft positions
• Broadcast from Ground Stations
• ADS-B Equipped aircraft are filtered out
• Should be available from air-to-air ADS-B link
• Used as an aid to visual acquisition only
• Essential service 99.9 Availability
• Note that FAA distinguishes between TIS-B and
  Rebroadcast function

10
Flight Information Service Broadcast (FIS-B)

• Uplink broadcast of weather and aeronautical
  information
• Broadcast from Ground Stations
• Only provided on UAT Link
• Essential Service 99.9 Availability
• Includes
• Weather radar
• METAR/TAF
• Winds/Temps Aloft
• Temporary Flight Restrictions
• Other information

11
UAT

• UAT is selected to provide ADS-B and associated
  services for the general aviation user because
• Lower cost
• BUTnot borne out by experience to date
• Tradeoff between
• Update/upgrade of transponder
• Newly equipping for UAT
• Greater uplink capacity especially for FIS-B
  service!

12
Multi-link Gateway ServiceADS-Rebroadcast
(ADS-R)

• Ground-based system to interconnect the two
  links 1090ES and UAT
• Allows interoperability between the two links
• Reads messages from one link re-broadcasts on
  the other
• Time-corrects positions to account for slight
  broadcast delay
• Critical service 99.999 availability

13
Service-based procurement

• Not a traditional procurement
• Supplier is to acquire, deploy, and operate two
  services
• Surveillance Service
• ADS-B
• ADS-R
• Broadcast Service
• TIS-B
• FIS-B
• Performance-based specification does not tie
  supplier to specific implementation

14
FAA Desire for Innovation

• Providing maximum flexibility to allow creative
  solutions
• Specifically have asked for innovation to
  achieve
• Earlier/Increased User Benefits
• Reduced Investment
• Encouraging Third Party Data Sales to reduce FAA
  financial burden

15
Challenges and Issues
16
Coverage

• Dual Link Air-to-Air Surveillance depends on
  Ground Infrastructure
• Limits use outside of ground based
  receiver/transmitter coverage
• FIS-B
• Not available on surface at most GA airports
• Reduces utility as a tactical planning tool
• May not be available at low altitude underneath
  ground station coverage
• May not be available in mountainous terrain
  coverage blocked in valleys, etc.

17
Availability/Integrity Air-to-Air

• Dual Link Integrity may be an issue for some
  applications
• Merging/Spacing
• Parallel Approaches
• Failure of Ground Station
• Hard Failure will aircraft detect it quickly
  enough
• Soft Failure will aircraft detect it at all?
• Long term GA pilots dont want a required
  transponder plus UAT
• issues with TCAS?
• SSR/TIS?

18
Security

• Re-broadcast can be exploited

19
Spectrum Utilization

• Dual Link Uses Twice the Spectrum for the Same
  Traffic
• All traffic on 1090ES
• All traffic on UAT
• Co-located Transmitters reduce Probability of
  Detection
• UAT (on 978 MHz) conflicts with other aviation
  uses

20
International Interoperability

• 1090ES is widely accepted standard
• UAT has limited acceptance and deployment
• Some aircraft operate in mixed GA and commercial
  environments
• Might have to equip with both links?
• And VDL M4?
• Light aircraft flying to Canada or Mexico from
  US?
• International sales of light aircraft?
• Commonality of avionics?

21
Proposed Solution
22
Baseline Solution
Un-equipped
1090
UAT
Cross Link
Other A/C Positions (TIS-B)
Weather Service (FIS-B)
Air Traffic Control
23
Proposed Solution
XM
Un-equipped
1090
Other A/C Positions (TIS-B)
Weather Service (FIS-B)
Air Traffic Control
24
What About Frequency Congestion?

• Some concern that having all aircraft on same
  frequency will cause too much congestion
• Rebroadcast results in same effect
• Problem is worst where re-broadcast needed most
  terminal airspace
• Advances in decoding have mitigated congestion
  issues

25
Raytheon Decoder Results

• A recent Eurocontrol funded study by a
  consultancy company produced similar results.
• The results show that for a given Pd, the RSL
  decoder has roughly double the range of the MOPS
  decoder.
• Put another way, the Raytheon decoder can operate
  in significantly denser traffic environments.

26
Coverage Baseline Solution
Floor of Coverage
King Air 1090ES Equipped
Cessna 172 UAT Equipped
Community Airport (e.g., Bar Harbor)
27
Coverage Proposed Solution

• Weather Data Available
• Other Traffic Visible

Floor of Coverage
XM
King Air 1090ES/XM Equipped
Cessna 172 1090ES/XM Equipped
Community Airport (e.g., Bar Harbor)
28
Coverage FIS-B
Planned FIS-B Coverage End of 2010
XM FIS-B Coverage 2007
29
Cost

• Reduces ground infrastructure
• Redundant receivers (1090)
• Single transmitter (1090)
• VS
• Redundant receivers (1090)
• Redundant transmitters (1090)
• Redundant receivers (UAT)
• Redundant transmitters (UAT)
• Eliminates ADS-Rebroadcast development and
  certification

30
Summary

• Proposed solution provides
• International compatibility
• Cost effective solution
• Improved coverage
• Improved safety
• Spectrum savings
