DM221 Build a Productive 24x7 Database Operation Infrastructure

1
DM221Build a Productive 24x7 Database Operation
Infrastructure
George Wang Melinda Meyers Principal
Consultant Senior DBA Sybase Inc. America
Online Inc. zwang_at_sybase.com mmeyersm_at_aol.com
2
Agenda

• AOL Business
• Challenge
• Architecture
• Future Direction
• Q A

3
AOL Business

• Worlds leader in interactive services, Web
  brands, Internet technologies, and e-commerce
  services
• AOL Mission Statement
• To build a global medium as central to peoples
  lives as telephone or televisionand even more
  valuable.
• AOL Vision Statement
• To build an interactive medium that improves the
  lives of people and benefits society as no other
  medium before it.

4
AOL Business
5
AOL Business
Note The number of ASE and RS on the graph
does not indicate production deployment
ASE
RS
6
Challenge

• Explosive growth
• Large-scale distributed deployment
• 24x7 operation
• Heterogeneous environment
• Mixed versions of OS
• Mixed versions of ASE and RS
• Dynamic configuration
• Staff

7
Architecture

• Operation
• System monitoring
• Problem detection
• Maintenance
• Performance analysis
• Repository
• Automation
• Notification

8
Operation Minimize Down Time

• Standardization
• Installation
• Configuration
• Procedures
• High-availability
• Fast response
• History analysis
• Proactive action

9
Operation
Chain of Escalation
10
System Monitoring
Ping
ASE
ASE
RS
BAK
BAK
11
System Monitoring
Data and Log Space
0
100
12
Problem Detection

• LogChecker
• Rule-based
• Check ASE errorlog
• Detect error messages
• Filter out informational messages
• Check RS errorlog
• Capture message tags

13
Problem Detection

• RS Heartbeat Latency
• Program flow
• Alarm if latency gt threshold
• Detect health of RS
• Latency analysis

ASE
ASE
RS
Detect the row at Time Alatency
Insert a row at Time A
14
Maintenance

• Database Transaction Dump
• Dump to file system
• Copy system tables
• Unix backup
• Monitor capacity

15
Maintenance

• Miscellaneous
• Threshold of transaction log
• 50, 75 and 90
• Update statistics
• Rotate errorlogs
• Database consistency check

16
Performance Analysis

• Performance Data Collection
• ASE Monitor Historical Server
• CPU utilization
• Store procedure execution
• IO activity
• Cache activity
• Object activity
• Server status
• Locking

17
Performance Analysis

• Performance Data Analysis
• Exception
• Trend
• Capacity
• Load
• Benchmark

18
Operation
19
Repository

• Server inventory
• Maintenance log
• Problem history
• Performance warehouse

20
Server Inventory

• Server characteristics
• name hostname SA CPU
• version OS PM memory
• type subsystem POC connection
• Manual update via web pages
• Automatic update via collection agents

21
Maintenance Log

• Maintenance history
• Installation Upgrade Bounce
• OS maintenance Configuration Space allocation
• Update query via web pages
• Help diagnose problems

22
Problem History

• Problem history
• Symptom Diagnostics Solution
• Case tracking Workaround
• Update query via web pages
• Benefits
• Diagnose similar problems
• Share knowledge and skills

23
Performance Warehouse

• Automatic data collection
• Automatic data summary
• Analysis model
• Dynamic On-demand analysis on the Web
• Static Pre-defined and complex data model
• Delivery via the Web

24
Operation Repository
SI Server Inventory ML Maintenance Log PH
Problem History PW Performance Warehouse
25
Job Scheduling

• Unix Cron
• Benefits
• Simple
• Drawbacks
• Failure detection
• Job stream dependency
• Standalone vs. Distributed environment

26
Job Scheduling

• Autosys
• Scheduling and operations automation for
  distribution environment
• Benefits
• Centralized job scheduling management
• Flexible job scheduling and dependency
• Uninterrupted job processing
• Failure detection
• Fault tolerance

27
Autosys
Ethernet
Client
Server
Remote Agent
Remote Agent
Polls
Autosys Database
Event Processor

• Remote Agent
• start up
• run job
• return job status
• exit

• event found
• starting conditions met
• start up remote agent

28
Job _at_ Autosys

• Job location

29
Job _at_ Autosys

• Start condition
• Min max run time
• Automatic restart
• Grouping
• Dependency
• Standard input output redirection

30
Email Notification
ASE
ASE
RS
Monitoring Host
Autosys
NOC
SA On-call
Designated SA
Group
31
Email Notification

• Benefits
• Easy to configure
• Drawbacks
• Large volume
• Duplicate
• Hard to prioritize
• Broken escalation chain
• Difficult to identify problem

32
Netcool/OMNIbus
ASE
ASE
RS
Monitoring Host
Autosys
NOC
SA On-call
Designated SA
Group
33
Netcool/Omnibus

• Real-time event monitoring management
• Consolidates
• Integrates
• Configurable
• Meaningful

34
Infrastructure
Component
Web-enabled
Operation
Repository
Automation
Notification
35
Infrastructure

• Productivity
• Availability
• Reliability
• Scalability

36
Business Impact

• Improved quality of online services
• Overall system availability 99.6 in 1999
• Strong subscriber growth (10M to 20M in 2 years)
• Strong revenue growth (500M to 1.3B in 2 years)

37
Future Direction

• Web-based infrastructure
• Knowledge-centric event analysis
• Performance-based early detection
• Automated agent
• Problem auto-correction
• Enterprise management integration

38
Conclusion

• Contact Information
• George Wang ltzwang_at_sybase.comgt
• Mendy Meyers ltmmeyersm_at_aol.comgt
• Questions Answers

Thank You
