Environmental Impacts and Aspects

1
Environmental Impacts and Aspects

• Section 1

2
Slide Overview

• Environmental Terminology
• Environmental Aspects and Impacts
• Examples
• Sources of Data
• Site Approach

3
Environmental Effects

• Environmental Effect
• Any effect or change that a project may cause
  in/to the environment
• Note Effect is a noun that means a result for
  example, global warming has an effect on sea
  temperatures.
• Affect is a verb and means to change, impact or
  influence, for example, global warming may
  affect our capacity to feed our global
  population.

4
Environmental Aspect

• Environmental Aspect
• The sum of the effects or changes that a project
  may cause in the environment
• It is the element of a facilities/sites
  activities, products or services which can or
  does interact with the environment
• Environmental aspects can be continuous, periodic
  or only associated with certain event and
  conditions (such as an emergency).

5
Significant Environmental Aspect

• A significant environmental aspect is an aspect
  that may produce a significant environmental
  impact
• Something is significant if it important in
  effect, or substantial. In statistical terms,
  significant indicates that it is greater than
  would would be expected by chance.

6
Environmental Impact

• Is any change to the environment (whether adverse
  or beneficial), resulting from a facilities/sites
  activities, products or services.

7
Characteristics of Environmental Impacts

• Magnitude (severe, moderate, minimal)
• Gradual/Immediate
• Direct/In-direct
• Extent (wide area, localised)
• Duration (short or long-term, intermittent,
  continuous)
• Timing (during construction, use phase,
  decommissioning, restoration phases)
• Reversible/Permanent
• Nature (positive or negative, cumulative)

8
Significant Environmental Impact

• There are four perspectives for rating an impact
  as significant
• Statistical
• Ecological/environmental
• Project
• Social/cultural

9
Examples

• In summary, an aspect is the cause and the impact
  is the effect.

10
Container Port (Dockland)
11
Composting of Bio-Active Wastes
12
Landfill Site
13
Uncontrolled Dumping and Burning of Wastes
14
Electric Car
15
Dam
16
Stormwater Drains

17
Transport and Bailing of Plastics
18
Gravel Extraction
19
Construction Beach Front
20
Road Construction
21
Sources of Data to Determine Aspects and Impacts

• Existing Environmental Impact Assessments
• Site Information
• Maps, geology, area, prevailing wind/weather
• Flow process diagrams
• IPPC applications, Licences, Planning Permissions
• Life Cycle Analyses
• Environment Agency, Local Government, etc.
• Risk Assessments
• COSHH forms
• Environmental Management System (EMS)

22
Sources of Data to Determine Aspects and Impacts

• Environmental Compliance Audits
• Pollution Prevention Audits
• Any Previous Legal Actions
• Site Personnel
• Visual Inspections (Walk-Around)
• Existing Documented Procedures (i.e. for
  monitoring emissions)
• Emergency Plans

23
Sources of Data to Determine Aspects and Impacts

• Life-Cycle Analysis
• Process Flow Diagrams
• Emission Inventories
• Process Hazard Analysis
• Project Safety Sheets

24
Site Approach

• For many industrial sites, it is necessary to
  identify and determine the significance of the
  sites environmental aspects and impacts.
• Tables Heading should include
• Aspect Identification
• Corresponding Impacts
• Significance (i.e. based on factors such as legal
  requirements, company policy, community concern,
  health and safety considerations)
• Objectives and responsibility (i.e. improve
  conditions or maintain current operating
  levels/procedures)

25
Overview Environmental Impact Assessment (EIA)

• Section 2

26
Slide Overview

• Engineering and EIA
• Introduction of Environmental Impact Analysis
  (EIA)
• EIA Processes
• EIA Methodologies
• Assessment Methods
• The Future

27
Engineering and EIA

• Why would an engineering project need an EIA?
• Why do engineers need to be familiar with the EIA
  process?
• How will EIA impact your career?
• What is the role of The Engineer in Society?

28
Environmental Impact Assessment (EIA)

• Process of identifying and evaluating
  environmental, social and other relevant effects
  of a proposed project/development/activity
• Assists decision-makers evaluate options and
  impacts holistically
• European Directive on Environmental Impact
  Assessment (Directive 97/11/EC)

29
Purpose of an EIA

• Inter-disciplinary decision-making tool, designed
  to be transparent and holistic
• Consider potential environmental impacts and
  implications early in the planning process
• Identify potential solutions to mitigate against
  negative environmental and social impacts

30
Purpose of an EIA

• Shape projects/development to suit local
  environments
• An EIA is conducted so that an Environmental
  Statement can be produced which will be presented
  to the planning authority and other key decision
  makers

31
Summary

• The EIA is undertaken by the developer and a
  final Environmental Statement is prepared.
• The Environmental Statement and supporting
  information is then considered by the relevant
  statutory body
• The statutory body are required to refuse
  projects which are detrimental

32
Strategic Environmental Assessment (SEA)

• SEA involves the definition and evaluation of the
  impacts of a strategic action
• For example, a plan, programme or strategy.
• It aims to contribute to the integration of
  environmental considerations into strategic
  decision-making
• EIA based method, applied to plans and programmes
  rather than projects

33
SEA

• Strategic Environmental Assessment (SEA)
  Directive
• Applies to a wide range of plans and programmes
  for instance, town and country planning and land
  use
• Requires an environmental assessment of plans and
  programmes with a view to promote sustainable
  development
• For plans/programmes after 21 July 2004 or those
  not adopted before 21 July 2006

34
Essential Information

• Under Directive 97/11/EC (and now 85/337/EEC),
  Article 5 specifies the minimum amount of
  information which developers have to provide on
  their project/development
• Description of the project (design, size, etc.)
• A description of the aspects of the environment
  likely to be significantly affected by the
  project
• The data required to identify and assess the main
  environmental effects

35
Essential Information (cont)

• A description of any measures for eliminating or
  reducing any significant adverse effects
• An outline of the main alternatives studies by
  the developer and a clear rationale of the
  choices made taking into account the
  environmental effects
• A non-technical summary of all of the
  before-mentioned information
• Any possible difficulties in data collection

36
UK Legislation

• EIA Directive 85/337/EEC
• Most projects will be covered by the Planning
  Regulations, including
• The Environmental Assessment Regulations 1988 (SI
  No. 1207)
• Town and Country Planning (Assessment of
  Environmental Effects) Regulations 1988 (SI No.
  1199) as amended
• Environmental Assessment (Scotland) Regulations
  1988 (SI No 1221)

37
UK Legislation

• Highways (Assessment of Environmental Effects)
  Regulations (SI No. 1241) as amended
• The Electricity and Pipeline Works (Assessment of
  Environmental Effects) Regulations 1990 (SI No.
  1442)

38
EIA Process

• Project preparation
• Notification to Competent Authority
• Screening Is an EIA or SEA required?
• Scoping (includes the EIA process)
• Environmental Studies (including literature
  reviews)
• Preparation of the Environment Impact Statement
  (EIS)
• Review of the EIS by the relevant stakeholders
  (for example, planning authority)
• Decision (Grant or Refuse Application)
• If granted, project gets underway and monitoring
  starts

39
Notification

• In some European Countries it is necessary for
  the developer to notify the Competent Authority
  in advance of the application for development.
• In the UK this is only voluntary and can be done
  informally.
• Some developers choose to inform the Planning
  Authority of their intention as it can help build
  stakeholder relationships
• Adversely, for possibly contentious projects,
  some developers may chose to be discrete until
  the screening process

40
Screening

• Information to determine if an EIA is required,
  is contained within two schedules of the Annexes
  of the Directive.
• Schedule 1 All projects listed within this
  schedule must have an EIA
• Schedule 2 An EIA will only be required for if
  the project is of significant size or nature to
  give rise to significant environmental effects.
• The Competent Authority (CA) is responsible for
  deciding if an EIA is required.

41
Scoping

• Scoping is used to identify key issues the
  content and extent of the environmental
  information to be included
• Scoping methods include
• Stakeholder consultation (legal requirement)
• Environment Agency, Local Authority, Residents,
  National Trust etc.
• Relevant stakeholders must be given opportunity
  to comment
• Scoping is an ongoing exercise
• A poor scoping exercise will negatively influence
  the quality of the final ES
• A developer can ask the CA for a Scoping Opinion
  (i.e. issues to be covered in the environmental
  information)
• Take account of abnormal events

42
Scoping Questions

• Will construction or operation of the project
  cause physical changes in the locality
  (waterways, land-use, run-off)
• Will construction or operation of the project
  require the use of resources (renewable or
  non-renewable, scarce, fuel, aggregates, water,
  land)

43
Scoping Questions

• Will the project produce any waste
  materials/by-products. Also consider the
  decommissioning stage.
• Will the project cause any nuisance (noise, light
  pollution, heat, odour)
• Will there be a risk of accidents or injury
  during the life-cycle of the project
• Will the project impact on social characteristics
  (employment, schooling, housing)

44
Scoping Questions

• Could the project lead to releases of
  contamination/pollution to the environment (air,
  water, land)
• Will the project require the use or supply of any
  toxic or potentially hazardous materials (what
  are the health and safety implications,
  stakeholder concern, perceived risks)

45
Environmental Studies

• The developer must conduct suitable studies to
  gather the information required in Article 5 of
  the Directive and also identified from the
  Scoping exercise.

46
Environmental Impact Statement (EIS)

• An EIS is a report which summarises the
  anticipated environmental impact of a
  project/development.
• The EIS should also include comment on the
  non-project/development scenario (equivalent to
  the current environmental conditions)

47
Environmental Impact Statement (EIS)

• The developer submits all of the environmental
  information gathered in the form of a EIS, along
  with the planning application.
• The CA will consider the accuracy, scope and data
  presented in the EIA in the decision to grant or
  decline planning permission
• If the EIS is inadequate or incomplete, the
  developer will be asked to provide additional
  information
• The decision (and the decision process) of the CA
  must be made available to the public

48
Rules of a Good EIS

• Non-technical summary
• Clear, concise structure, including a table of
  contents, figures etc.
• Good use of diagrams, flow charts, graphics and
  photographs where appropriate
• Reads as one single document with appropriate
  cross-referencing
• Clear description of the development/ project
• Written in an impartial and professional manner
  using appropriate consistent language (including
  a glossary if necessary)

49
Rules of a Good EIS (cont)

• All information is fully referenced and is of the
  correct scientific rigour
• Any complex issues are clearly explained (as if
  to a lay audience)
• Full methodology for all studies
• Provides clear evidence of consultations
• Clear discussions on alternative options
• Presentation of ongoing monitoring techniques and
  any forms of abatement

50
Project Monitoring

• On-going repetitive measurement of environmental
  variables (as specified in the ES) during and
  after project/development

51
EIA Assessment Methods

• Section 3

52
Functions of EIA Methods

• Impact Identification
• Impact Prediction
• Impact Interpretation
• Impact Costing
• Communication of Information
• Devising Monitoring Schemes

53
Various EIA Methods

• Checklists
• Matrices
• Networks
• Professional Judgement
• Weighting/Scaling
• Overlays

54
Checklists

• Annotate environmental factors to be addressed.
• Vary in complexity (simple to complex)
• Can be sector specific or general
• Highly adaptable to individual sites and projects
• Not effective in identifying higher order impacts
  or inter-relationship between impacts

55
Checklist Example Contents

• Sources of Impacts
• Industrial Processes
• Receptors of Impacts
• Location of sensitive receptors
• Environmental Impacts
• Environmental changes
• Risk analysis
• Mitigation Measures
• Additional Comments

56
Matrices

• A Matrix is a grid-like table
• Used to identify interaction between project
  activities and environmental characteristics
• Entries are made in cells to identify impacts and
  their significance/severity
• Can be complex or simply

57
Types of Matrices

• Leopold Interaction Matrix
• Well known system.
• Complicated (88 environmental characteristics by
  100 project actions)
• Simple
• Often base don the Leopold design, but of limited
  or specified scope
• Component Interaction
• Simple tables listing specific factors relevant
  to the project

58
Leopold Matrix

• Each cell shows two values (one to quantify
  magnitude, and one to measure significance/importa
  nce.
• Numerical cell values from 10 to -10 for both,
  to indicate beneficial or detrimental effects.

59
Leopold Matrix

• Project
  Features
• Env. Characteristics

Magnitude
Importance
60
Methodology for Completing a Leopold Matrix

• Identify the actions/aspects of the project
  across the top of the table
• For each aspect, all of the potential
  environmental characteristics/impacts should be
  listed down the left side of the table
• For each cell where there is an environmental
  impact, rank its magnitude (top left of the box)

61
Methodology for Completing a Leopold Matrix (2)

• The importance of the impact should then be
  inserted in the bottom right of the box.
• The higher the numbers (1-10 for both scales) the
  grater the magnitude and impact
• A written summary should accompany the table
  identifying the main areas for potential
  environmental harm

62
Benefits of Leopold

• Easy to use
• Minimal personnel training
• Low cost
• Transparent
• Easily understood by a lay audience
• Shows which factors were considered
• Clearly shows where decisions were made

63
Limitations of Leopold

• Subjective
• Ordinal magnitude (importance ranking) can be
  manipulated arithmetically
• The same impact can be recorded in several areas
  and can lead to double-counting
• Some regard the matrix as a comprehensive EIA
  method
• Alternative project designs require separate
  matrices, making it hard for comparison

64
Networks

• Networks are usually displayed pictorially or a s
  a diagram
• Illustrate the cause-effect relationship of
  project activities and environmental
  characteristics.
• Good for identifying second-order environmental
  impacts

65
Sorensen

• Network method
• Cause-condition-effect interactions and linkages
• Pictorial method using a flow/process chart
• Easy to convey information to the reader
• Quality of network is highly dependant on the
  network designer
• Can become too complex and focused on trivial
  matters

66
Advantages of Sorensen

• No numerical (no subjective judgements or
  improper arithmetic operations)
• All project options can be displayed in one
  matrix, making comparisons easier
• Less chance of recording an impact more than once
• Logical arrangement of impacts for ecological
  scoping and baseline study formulation

67
Professional Judgement

• Expert prior knowledge of the EIA process and/or
  the type of project can allow individuals and
  companies to develop data banks, reports, manuals
  and other resources for use on future projects.
• Professional experience and judgement can be
  focused using interactive methods
• Delphi Technique

68
Delphi Technique

• Method for accessing expert opinion by
  systematically soliciting the advice of a
  specified number of experts, and then determining
  a consensus from the advice.
• Establish a monitoring team (2 people) and an
  expert panel (usually 8-10)
• Administer a questionnaire on the issues
• Collate responses and draft a second
  questionnaire based on responses
• Administer the second questionnaire
• Summarise consensus

69
Overlays

• System of representing data is a geographical or
  pictorial form
• Transparent overlays which contain specific
  information are laid over a location map to form
  a comprehensive, aggregate may
• Most common technique was developed by McHarg
  (1969) as a land-use planning tool
• Now typically complimented by GIS

70
Assessment Methods

• Environmental Impacts
• Leopold Matrix
• Sorensen Matrix
• Ecological Impact Assessment (EcIA)
• Cost-Benefit Analysis
• Social Scoping/Stakeholder Dialogue
• Measurement/Prediction of Impact Magnitudes
• Assessment of Impact Significance
• Communication

71
Factors Influencing Methodology

• It is usually best to administer at least two
  different methodologies to ensure reasonable
  coverage of issues as some techniques have
  weaknesses
• The type and size of proposal
• The number (if any) of alternative proposals to
  be considered
• Resources (personnel, capital, time)
• Experience of EIA team
• Ensure the methodology is suitable (for project,
  the environment and is within the capacity of the
  team)

72
Ecological Impact Assessment (EcIA)

• Institute of Ecology and Environmental
  Management, UK, has a set of guidelines for EcIA
• These guidelines
• Standardise the approach by providing a common
  framework
• Ensure scientific rigour
• Provide decision-makers with the relevant
  information on the ecological impacts associated
  with a project/development

73
Requirements for an EcIA

• EcIA is required
• At the scoping stage (to determine which
  ecological resources to monitor)
• During the evolution of the project (to ensure
  ecosystems have not been missed, and to take
  account of any new impacts. Also, to identify
  mitigation strategies and opportunities for
  enhancement)
• To determine the success of the mitigation
  strategies
• To determine if ecological compensation is
  required

74
Baseline Study

• The assessment of impacts should be undertaken in
  relation to the baseline conditions (either
  current, or predicted for when the project will
  start)
• Baseline studies provide a quantitative
  description of various environmental conditions
  existing prior to the project/ development,
  against which subsequent changes (both positive
  or negative) can be predicted or measured
  (essentially the cumulative impacts)

75
Considering Baseline Conditions

• Baseline conditions may change naturally over
  time regardless if the project goes ahead or not
• Future conditions will change subject to
• Environmental trends (changes in rainfall, global
  temperatures)
• Neighbouring developments (which may influence
  run-off, migration patterns, levels of air
  pollution)

76
Example Aspects of Ecological Structures

• Ecological Processes - (i.e. nutrient and
  population cycles, seasonal behaviour,
  reproduction rates)
• Human Influences - (i.e. farming practices,
  pollution, transport, public access, weeds and
  GMOs, mowing)
• Available Resources - (i.e. minerals and
  nutrients, food and water)

77
Example Aspects of Ecological Structures

• Natural Processes (i.e. floods cycles, fire
  events, storms, prevailing winds)
• Ecological Relationships - (i.e. food-webs)
• Ecological Roles (i.e. herbivore, predator,
  fungi, decomposer)
• Ecosystem Properties (i.e. carrying capacity,
  bio-assimilative capacity, productivity,
  populations)

78
Cost-Benefit Analysis

• Economic technique for project appraisal
• Can be used to cot both environmental and
  social impacts
• Must take into account the economics of time
  (discounting over a project life-span)
• Viewed by some unfavourably as it assigns
  financial value to environmental resources

79
Impact Analysis/Magnitude Prediction

• This is the process of predicting the magnitude
  of changes (from the proposed project/development)
  from the baseline conditions.
• Three types of predictions
• Quality predictions based on scientific knowledge
  (quantitative analysis, risk assessment)
• Forecasts (i.e. Delphi, modelling)
• Guesstimates (frequently based on the hunches of
  experienced personnel)

80
The Future

• Sustainability Assessment (SA)
• Aims to influence the decision prior to any
  development, shifting the assessment to the front
  of the project
• In some cases EIA is appears too late in the
  decision-making process
• SA is a pro-active assessment
• EIA is a reactive assessment

81
Sustainability Assessment (SA)

• SA will focus on the triple bottom line framework

• Whilst EIA is believed by some to be too
  environment focused at the expense of social and
  economic factors
• Can be applied to everything policies, plans,
  programmes, services, strategies, planning,
  products, parliamentary decisions
• Project Sustainability Management (PSM) is the
  practical implementation tool of SA.

82
PSM Guidelines

• International Federation of Consulting Engineers
  (FIDIC) guidelines can be found at
• http//www1.fidic.org/resources/contracts/describ
  e/FI-EN-T-AA-10.asp?back/bookshop/prod_page.aspP
  roductCodeFI-EN-T-AA-10price20
• FIDIC homepage www.fidic.org/

83
Cromarty Bridge Video

• Part 4

84
Cromarty Bridge Project

• The building of the Cromarty Bridge across the
  Cromarty Firth, Scotland
• Bridge linked the major towns of Inverness to
  Edinburgh via the A9
• The video shows construction processes
• Some limited presentation of the environmental
  aspects associated with the construction phase
