Optimizing Clarifiers What Have We Learned?

• Presented by
• John K. Esler, P.E.
• CPE Services, Inc.
• Enfield, NH
• www.clarifiers.com

2
(Alternate Title) Optimizing Clarifiers What
Do We Think We Learned?

• Presented by
• John K. Esler, P.E.
• CPE Services, Inc.
• Enfield, NH
• www.clarifiers.com

3
(Alternate Title) Optimizing Clarifiers What
Do We Still Have to Learn?

• Presented by
• John K. Esler, P.E.
• CPE Services, Inc.
• Enfield, NH
• www.clarifiers.com

4
To Learn to gain knowledge or understanding
of .. by study, instruction or experience.
5
A Basic Understanding

• What do their currents look like?

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
with a Stamford/Crosby baffle.
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
More Basics

• How do we analyze clarifiers? . How do we get an
  initial handle on their performance?

15
(No Transcript)
16
Daigger-Roper Curves
17
Focus on field testing!!
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23

24
(No Transcript)
25
(No Transcript)
26
RSR / draft tube Clarifier Currents
RAS box
27
Begin with best shape It all depends on ..

• Your professor circular!
• Your state of mind .. Square?
• Your location
• NYC, LA, DC, Boston .. Rectangular
• The rest of the universe? .. Circular
• Your data ASCE CRTC
• NYC Rockaway Gould Type 2 .. 1800 g/sf/d
• LACSD San Jose Gould Type 1 .. 2200 g/sf/d

28
Typical LA County San. Dist. Clarifier Layout
150 long x 20 wide x 9.5 deep
2 parallel effluent launders
3 opposing jet inlet nozzles
29
150-ft x 20-ft x 9.5-ft SWD
30
3 Opposing Jet Nozzle Inlets
31
Two parallel launders 1/3 clarifier length
32
Circular Clarifier Centerwells

• What diameter?
• How deep?
• Anything else?

33
What diameter?

• No one knows!
• JE Too big (gt 20) reduces mixing
• JE Too small (10 /-) increases turmoil
• Depends on MLSS concentration SVI

34
What centerwell depth?

• No one knows .. With or without EDI?
• JE too deep (gt1/2 center depth)
• LA-Hyp. 0.25 center depth was OK
• LA-Hyp. 0.4 center depth was OK
• Design for downward velocity?
• Depends on blanket depth

35
Any special centerwell details?

• In-turned lip? (NG)
• Baffles?.. With mixers.
• Submerged? .. It depends .
• Structural supports?

36
In-turned Lip
37
Centerwell Scum!!!
38
Flow is inward!
39
Sheet Flow Inward!
40
Submerged Centerwells?
41
Now we have Q R .. R1 .. ..flowing
downward in the centerwell.
.. which leads to faster density currents!
42
(No Transcript)
43
What about the rest of the scum ???
44
(No Transcript)
45
(No Transcript)
46
What about the launders?

• Weir length is not as important as ..
• Location! Location! Location!

47
The absolute WORST configuration .
48
This is what happens !!!!!
49
A simple solution ..
50
MAJOR Causes of failure in circular clarifiers

• poor flocculation
• High SVIs
• High solids loadings
• Solids leaving the central portion!!!! WHY???

51
9/15 _at_ 0700 hrs 3FC _at_ 10 mgd
LOCATION 7 12 15 45 70
-1 .92 .85 .04 .03 .03
-2 .85 .84 .04 .03 .03
-3 .80 .84 .04 .03 .03
-4 .80 .85 .04 .03 .03
-5 .80 .85 .04 .03 .03
-6 .78 .84 .04 .03 .04
-7 .69 .82 .04 .03 .04
-8 .69 .80 .04 .03 .05
-9 .68 .76 .04 .03 .05
-10 .65 .71 .03 .04 .05
-11 .63 .67 .03 .04 .05
-12 .62 .65 .47 1.20 5.10
-13 .61 .55 .58 3.40
-14 .64 .65 .59
-15 .66 .65
TOTALS 12 13 2 5 5 37
?
?
?
52
Not due to the downward velocity.

• Texas Standard not to exceed 9 fpm
• Metro Syracuse .. 4.8 fpm
• Erie Co. Southtowns .. 6 fpm
• Joint Meeting (NJ) .. 4.7 fpm
• Houston 69th Street .. 3.3 fpm
• Manchester (NH) .. 3 fpm
• LA-Hyperion .. 1 fpm!!!

53
(No Transcript)
54
(No Transcript)
55
Eslers Baffle Hypothesis

• One baffle is good (Oak Orchard)
• Two baffles are better (Herkimer)
• Three baffles even better (Branford, CT)
• Four baffles better yet! (Waterford)
• Five baffles ????? Six baffles ?????
• The wrong baffle will mess it up (Moravia, Salt
  Lake City, Edgewood (NJ))

56

57
(No Transcript)
58
(No Transcript)
59
Edmonton Gold Bar WWTP
Baffled Clarifier
60
Crosby Cylindrical Baffle
61
McKinney Baffle

• Crosby Baffle

62
Sludge Collection in circular clarifiers

• Do we suction it .. or scrape it?
• A suction manifold . or draft tubes?
• plow blade scrapers .. or spiral blade?

63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
Sludge Collection in circular clarifiers

• Floor slope? 1 per ft for scrapers
• Tip speed? Very little data ..
• JE 7 to 10 fpm .. Not 15 to 30 fpm

69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
CFD Modeling what do we know?

• Its now used on many major projects.
• Remember G.I.G.O?
• I have had too much negative experience.
• Why has it never shown the excessive turbulence
  in the central area of a circular clarifier??
• We need a concerted effort to demonstrate the
  predicted performance with actual field tests!

77
In summary, what have we learned?

• The right operator can make almost anything work
  !
• Almost every clarifier can be optimized.
• (Occasionally, one should be nuked.)

78
(No Transcript)
79
WWW.CLARIFIERS.COM
