CPE 619 Monitors

1
CPE 619Monitors

• Aleksandar Milenkovic
• The LaCASA Laboratory
• Electrical and Computer Engineering Department
• The University of Alabama in Huntsville
• http//www.ece.uah.edu/milenka
• http//www.ece.uah.edu/lacasa

2
Part II Measurement Techniques and Tools

• Measurements are not to provide numbers but
  insight - Ingrid Bucher
• Measure computer system performance
• Monitor the system that is being subjected to a
  particular workload
• How to select appropriate workload
• In general performance analysis should know
• What are the different types of workloads?
• Which workloads are commonly used by other
  analysts?
• How are the appropriate workload types selected?
• How is the measured workload data summarized?
• How is the system performance monitored?
• How can the desired workload be placed on the
  system in a controlled manner?
• How are the results of the evaluation presented?

3
Outline

• Introduction
• Terminology
• Software Monitors
• Hardware Monitors
• Monitoring Distributed Systems

4
Monitors
That which is monitored improves. Source unknown

• A monitor is a tool used to observe activities on
  a system
• Observe performance
• Collect performance statistics
• May analyze the data
• May display results
• May even suggest remedies

• Monitors are used not only by performance
  analysts
• Systems programmer may profile software
• System manager may measure resource utilization
  to find bottleneck
• System manager may use to tune system
• System analyst may use to characterize workload
• System analyst may use to develop models or
  inputs for models

5
Outline

• Introduction
• Terminology
• Software Monitors
• Hardware Monitors
• Monitoring Distributed Systems

6
Terminology

• Event a change in the system state
• E.g. cache miss, page fault, process context
  switch, beginning of seek on a disk, arrival of a
  packet,
• Trace a log of events, usually including the
  time of the event, and other important parameters
• Overhead most monitors perturb the system
  operation
• Use CPU or storage Sometimes called artifact.
  Goal is to minimize artifact
• Domain the set of activities observable by the
  monitor
• E.g. accounting logs record information about
  CPU time, number of disks, terminals, networks,
  paging I/Os, the number of characters
  transferred among disks, terminals, networks, and
  paging devices

7
Terminology (contd)

• Input rate the maximum frequency of events that
  monitor can correctly observe
• Burst mode the rate at which an event can occur
  for a short period of time
• Sustained mode the rate the monitor can tolerate
  for long durations
• Resolution coarseness of the information
  observed
• Input width the number of bits recorded for
  each event. Input rate x width storage required

8
Monitor Classification

• Implementation level
• Software, Hardware, Firmware, Hybrid
• Trigger mechanism
• Event driven activated only by occurrence of
  certain events
• Low overhead for rare event, but higher if event
  is frequent
• Sampling (timer driven) activated at fixed time
  intervals by clock interrupts
• Ideal for frequent events
• Display
• On-line provide data continuously. E.g.
  tcpdump
• Batch collect data for later analysis. E.g.
  gprof.

9
Outline

• Introduction
• Terminology
• Software Monitors
• Hardware Monitors
• Monitoring Distributed Systems

10
Software Monitors

• Monitor operating systems, and higher level
  software, e.g., networks, databases
• At each activation, several instructions are
  executed
• In general, only suitable for low frequency event
  or overhead becomes too high
• Overhead may be OK if timing does not need to be
  preserved
• Lower input rates, lower resolutions, and higher
  overhead than hardware
• But, they have higher input widths, higher
  recording capacities
• Easier to develop and modify

11
Issues in Software Monitor Design - Activation
Mechanism

• How to trigger the data collection routine?
• 1) Trap instrument the system software with
  trap instructions at appropriate points. Collect
  data. Like a subroutine.
• E.g. to measure I/O service time, trap before
  I/O service routine and record time, trap after,
  take diff
• 2) Trace each instruction is followed by data
  collection routine (trace mode). Enormous
  overhead. Time insensitive.
• E.g., instruction-trace monitor to produce a PC
  histogram
• 3) Timer interrupt a timer interrupt service
  provided by the OS is used to transfer control to
  a data collection routine at fixed intervals.
• Overhead is independent of the event rate
• If sampling counter, beware of overflows

12
Issues in Software Monitor Design Buffer Size

• Store recorded data in buffers in memory, which
  are later written to hard disk
• Buffers should be large
• To minimize the need to write frequently to hard
  disk
• Buffers should be small
• Dont have a lot of overhead when write to disk
• Doesnt impact performance of system (or reduced
  memory availability is not observable)
• Optimal buffer size is a function of the input
  rate, input width, and emptying rate

13
Issues in Software Monitor Design Number of
Buffers

• Usually organized in a ring
• Allows recording (buffer-emptying) process to
  proceed at a different rate than monitoring
  (buffer-filling) process
• Monitoring may be bursty
• Since cannot read while process is writing, a
  minimum of two buffers required for concurrent
  access
• May be circular for writing so monitor overwrites
  last if recording process too slow
• May compress to reduce space, but adds overhead

14
Issues in Software Monitor Design Buffer
Overflow

• In spite of a ring, all buffers could become full
• Two options (both result in information loss)
• Overwrite a previously written buffer
• Old information is lost
• Stop monitoring until a buffer becomes available
• New information is lost
• Trade-off old vs. new information importance
• Counter overflows

15
Issues in Software Monitor Design Misc

• Data Compression or Analysis
• Online compression/processing before storing to
  reduce storage requirements
• On/Off
• Most hardware monitors have an on/off switch
• Software can have if then but still some
  overhead. Or can compile out
• E.g. remove -pg flag
• E.g. with define and ifdef
• Priority
• Asynchronous, then keep low. If timing matters,
  need it sufficiently high so doesnt caus skew

16
Outline

• Introduction
• Terminology
• Software Monitors
• Hardware Monitors
• Monitoring Distributed Systems

17
Hardware Monitors

• Hardware monitors -- separate pieces of equipment
  attached to the system being monitored via probes
• No system resources are consumed in monitoring
• Generally, lower overhead, higher input rate,
  reduced chance of introducing bugs
• Can increment counters, compare values, employ
  timers, record histograms of observed values
• Range from simple logic elements and counters to
  sophisticated computer systems
• Usually, gone through several generations and
  testing so is robust

18
Software vs. Hardware Monitors

• What level of detail to measure?
• Software more limited to system layer code (OS,
  device driver) or application or above
• Hardware may not be able to get above information
• What is input rate? Hardware tends to be faster
• Expertise?
• Good knowledge of hardware needed for hardware
  monitor
• Good knowledge of software system (programmer)
  needed for software monitor
• Most hardware monitors can work with a variety of
  systems, but software may be system specific
• Most hardware monitors work when there are bugs,
  but software monitors brittle
• Hardware monitors more expensive

19
Firmware and Hybrid Monitors

• Firmware monitors fall between hardware and
  software monitors
• Implemented by modifying the processor microcode
• Hybrid combines hardware, firmware, software
  monitoring
• E.g., use hardware components to capture events
  and software modules to compress/analyze
  collected data

20
Outline

• Introduction
• Terminology
• Software Monitors
• Hardware Monitors
• Monitoring Distributed Systems

21
Monitoring Distributed Systems
Distributed system many hardware and software
components working together separately and
concurrently
Layered view of a distributed-system monitor

• More difficult than single computer system
• Monitor itself must be distributed
• Easiest with layered view of monitors
• May be zero components of each layer
• Many-to-many relationship between layers

• Management
• Console
• Interpretation
• Presentation
• Analysis
• Collection
• Observation

22
Layered View

• Observation gather raw data on individual
  components of the system each component may have
  an observer designed specifically for it
• Collection collects data from various
  observers may have more than one observer on
  large systems
• Analysis Analyzes data gathered at various
  collectors. May include various statistical
  routines to summarize the data characteristics
• Presentation Deals with human user interface
  (reports, displays, alarms)
• Interpretation Intelligent entity (human or
  expert system) that can make meaningful
  interpretations of the data (more sophisticated
  than simple threshold-based rules)
• Console Interface to control the system
  parameters and states (outside monitor)
• Management Entity that makes the decision to
  set or change system parameters or configuration
  (manager). Implements decisions suing consoles.

23
Components of a Distributed Systems Monitor

• Subsystem1 Subsystem2 Subsystem3
• Observer1 Observer2 Observer3
• Collector1 Collector 2
• Analyzer1 Analyzer2
• Presenter1 Presenter2
• Interpreter1 Interpreter2
• Console1 Console2
• Manager1 Manger2

Human Beings
24
Observation (1 of 2)

• Concerned with data gathering
• Implicit spying promiscuously observing the
  activity on the bus or network link
• Little impact on existing system
• Accompany with filters that can ignore some
  events
• E.g. tcpdump between two IP address
• Explicit instrumentation incorporating trace
  points, hooks, Adds overhead, but can augment
  implicit data
• E.g. may have application hooks logging when
  data sent

25
Observation (2 of 2)

• Probing making feeler requests to see
  performance
• E.g. packet pair techniques to gauge capacity (a
  special packet sent to a given destination and
  looped back may provide info about queuing at the
  source, intermediate bridges, the destination,
  and back
• There is overlap between the three techniques,
  but they are not totally redundant -- often one
  shows a part of the system that others cannot

26
Collection

• Data gathering component, perhaps from several
  observers
• E.g. I/O and network observer on one host could
  go to one collector for the system
• May have different collectors share same
  observers
• Collectors can poll observers for data
• Or observers can advertise when they have data
• Clock synchronization can be an issue
• Usually aggregate over a large interval to
  account for skew

27
Analysis

• More sophisticated than collector
• Division of labor unclear, but usually, if fast,
  infrequent in observer, but if takes more
  processing time, put in analyzer
• Or, if it requires aggregate data, put in
  analyzer
• Ex if successful transaction rate depends upon
  disk error rate and network error rate then
  analyzer needs data from multiple observers
• General philosophy, simplify observers and push
  complexity to analyzers

28
Presentation (1 of 2)

• User interface, closely tied with monitor
  function
• Three key functions
• 1) Performance monitoring helps quantify if
  service provided is correct
• Throughput, response time, utilization of
  different components
• Summary statistics
• Time stamped traces

29
Presentation (2 of 2)

• 2) Error monitoring incorrect performance
• Error statistics, counts or traces
• Maybe sort to help determine what part of system
  is unreliable
• 3) Configuration monitoring non-performance of
  the system components
• Tell which are up
• Show initial configurations
• May show only incremental configurations
• Scope to allow zoom or whole system

30
Interpretation and Console

• Interpreter uses set of rules to make judgments
  about state of system
• Often need expert system to warn about faults
  before they occur
• May suggest configuration changes
• Console functions allow system manager to
  change system, bring up and down, allow remote
  diagnostics
• Ideally, one console can get feedback and apply
  configuration, but some parts may be vendor
  specific

31
Real-World Examples
32
Performance Tuning

• Performance tuning steps
• 1) Define the performance problem
• 2) Identify the bottlenecks using monitoring and
  measurement tools
• 3) Remove bottlenecks by applying a tuning
  methodology
• 4) Repeat steps 2 and 3 until you find a
  satisfactory resolution

33
Measuring Execution Time

• No changes to the program
• date
• time
• Added to the program code directly
• clock
• gettimeofday
• Program profilers
• gprof

34
Using the date Command
sr4 date dsize 12 date Thu Jan 11
160458 CST 2007 -1473822656 TOT_INS
490005749 Thu Jan 11 160459 CST 2007

• Read /docs/ performance.measurement.txt
• To learn more about the date command type in
  man date.

sr4 date dsize 24 date Thu Jan 11
160816 CST 2007 1529910656 TOT_INS
946006155 Thu Jan 11 160818 CST 2007
sr4 date dsize 36 date Thu Jan 11
160739 CST 2007 1604971008 TOT_INS
1402006388 Thu Jan 11 160742 CST 2007
35
Using the time Command
sr4 time dsize 12 -1473822656 TOT_INS
490005733 real 0m1.217s user 0m1.040s sys
0m0.090s

• Read /docs/ performance.measurement.txt
• To learn more about the date command type in
  man time.

sr4 time dsize 24 1529910656 TOT_INS
946006063 real 0m2.154s user 0m1.980s sys
0m0.070s
sr4 time dsize 36 1604971008 TOT_INS
1402006545 real 0m3.084s user
0m2.930s sys 0m0.090s
36
Using the clock() Function
include lttime.hgt .... int main(void) clock_t
start_time, finish_time ... // determine
overhead start_time clock() finish_time
clock() double delay_time (double)
(finish_time - start_time) ... start_time
clock() ...// code you want to determine the
execution time for finish_time clock() double
elapsed_time finish_time - stat_time -
delay_time double elapsed_time_sec
elapsed_time/CLOCKS_PER_SEC ...

• The clock() function allows you to measure the
  time spent in a section of a program
• To learn more about the clock() function type
  in man clock
• A typical program template for using the
  clock() function

37
Using the gettimeofday() function
include ltstdio.hgt include ltsys/time.hgt struct
timeval start, finish int msec int main ()
gettimeofday (start, NULL) sleep (200) /
wait 100 seconds / gettimeofday (finish,
NULL) msec finish.tv_sec 1000
finish.tv_usec / 1000 msec - start.tv_sec
1000 start.tv_usec / 1000 printf("Time d
milliseconds\n", msec)

• To learn more about this function type in man
  gettimeofday
• The function gettimeofday returns two integers
• The first one indicates the number of seconds
  from January 1, 1970
• and the second returns the number of microseconds
  since the most recent second boundary.
• A sample program that uses gettimeofday().

38
Program Profiling

• Profilers are utility programs used to determine
  execution profiles,in other words they tell us
  how much time is spent in each subroutine or
  function
• 10-90 rule of thumb states that 10 of your code
  is responsible for 90 of the program execution
  time
• Tuning the most time-consuming subroutines that
  dominate execution time can be very rewarding
  (assuming that we do this right)
• The profiler collects the data during the
  program's execution
• Typical steps in profiling are as follows
• enable it when compiling and linking programs
• a profiling data file are generated when the
  program is executed
• profiling data are analyzed using gprof

39
Example gprof
An excerpt from testsort.report _at__at__at__at__at__at__at__at__at__at__at__at__at__at_
_at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at_
_at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at__at_ .... granularity each sample
hit covers 4 byte(s) for 0.05 of 21.18 seconds
cumulative self self
total time seconds seconds calls ms/call
ms/call name 47.2 9.99 9.99
internal_mcount 5 36.0
17.61 7.62 5894908 0.00 0.00
partition 4 11.7 20.08 2.47 70536890
0.00 0.00 swap 6 2.1 20.52
0.44 1 440.00 10530.00 quicksort 3
1.6 20.86 0.34 10000000 0.00
0.00 rand 8 0.8 21.02 0.16 1
160.00 500.00 fillArray 7 0.8 21.18
0.16 _mcount
(665) 0.0 21.18 0.00 24 0.00
0.00 _return_zero 329 0.0 21.18
0.00 12 0.00 0.00 _mutex_unlock
330 0.0 21.18 0.00 12 0.00
0.00 mutex_lock 9 0.0 21.18
0.00 3 0.00 0.00 atexit 10
0.0 21.18 0.00 3 0.00
0.00 get_mem 11 0.0 21.18 0.00
2 0.00 0.00 free_mem 12 0.0
21.18 0.00 1 0.00 0.00
_atexit_init 331
40
PAPI Interface

• Read PAPI documentation athttp//www.ece.uah.edu/
  milenka/cpe619-08S/docs/papi.README.ver2.s07.txt

41
Tuning Example
include ltstdlib.hgt include ltstdio.hgt int
prime (int num) int main() int i int
colcnt 0 for (i2 i lt 50000 i) if
(prime(i)) colcnt if (colcnt9
0) printf("5d\n",i) colcnt 0
else printf("5d ", i)
putchar('\n') return 0 int prime (int
num) / check to see if the number is a
prime? / int i for (i2 i lt num
i) if (num i 0) return 0
return 1

• sample1.c prints the prime numbers up to 50,000
• Optimize it using gprof

42
Tuning Example (contd)
include ltstdlib.hgt include ltstdio.hgt int
prime (int num) int main() int i int
colcnt 0 for (i2 i lt 50000 i) if
(prime(i)) colcnt if (colcnt9
0) printf("5d\n",i) colcnt 0
else printf("5d ", i)
putchar('\n') return 0 int prime (int
num) / check to see if the number is a
prime? / int i for (i2 i lt num
i) if (num i 0) return 0
return 1

• Compile it using pg option
• gprof b ./sample1
• Analyze output gt almost all time is spent in the
  prime routine
• Use gcov to look at the actual number of times
  each line of the program was executed (hot spots)

43
Tuning Example (contd)
include ltstdlib.hgt include ltstdio.hgt include
ltmath.hgt int prime (int num) int faster (int
num) int main() int i int colcnt 0
for (i2 i lt 50000 i) if (prime(i))
colcnt if (colcnt9 0)
printf("5d\n",i) colcnt 0 else
printf("5d ", i) putchar('\n')
return 0 int prime (int num) /
check to see if the number is a prime? / int
i for (i2 i lt faster(num) i) if
(num i 0) return 0 return
1 int faster (int num) return (int) sqrt(
(float) num)

• sample2.c use sqrt to reduce the number of
  operations in the hot sport
• Repeat steps, measure performance
