Title: An Introduction to Solid Oxide Fuel Cell Research at CUED


1
An Introduction to Solid Oxide Fuel CellResearch
at CUED
By Ben Haberman
2
Introduction
  • The fuel cell
  • The Rolls-Royce design
  • Results
  • Conclusions
  • Any Questions?

3
The Fuel Cell
Air flow
Fuel flow
Porous Anode
Electr- olyte
Porous Cathode
H2O
O2-
O2-
H2
O
O2
2H
2e-
2e-
Load
4
Reversible Operation
In open circuit conditions
5
Realistic Operation
6
The Rolls Royce Design
Fuel cells
60 mm
Air flow
Ceramic module
150 mm
Fuel flow
7
The Fuel Cell Components
100 H2O
5 Fuel cell bundles
Air flow
810C 700 Nl/min
950C
Fuel flow 865C
7Nl/min of 100 H2
8
A Hybrid System Replacing Combustion Chamber
Load
Combustor
Fuel cells
Fuel inlet
Remaining fuel and air
Pressure vessel
Exhaust
Air inlet
Turbine
Generator
Compressor
9
What Do We Want to Know?
  • Electrical power and heat generation
  • Gas conditions at surfaces of electrolyte
  • Fuel utilisation

10
Code Development
  • Original code
  • 3D Compressible flow solver by Prof. Denton
  • Explicit time-marching method for Transonic flows
  • New gas channel code
  • Include all relevant physical phenomena
  • Very stiff equations - simplified preconditioning
    method
  • Porous code
  • Time marching as before
  • New model Cylindrical Pore Interpolation Model
    (CPIM)

11
Results Model Description
  • Cannot model complete bundle
  • Can look at infinite array
  • Only need 2 modules
  • Appropriate periodic bcs

12
Boundary Conditions
  • Air Inlet
  • Temperature 865C
  • Pressure 7 bar
  • Composition 21O2, 79N2
  • Flow rate 70 Nl/min per air channel
  • Fuel Inlet
  • Variable Temperature 865-900C
  • Composition 45H2, 21H2O, 10CO2, 24CO
  • Flow rate 1 Nl/min per fuel channel
  • Fuel cells
  • Fixed current density 3000Am-2

13
Model Control Volume
Fuel cells
Fuel outlet
Fuel inlet
Surrounding repeating unit
  • Over 3 million grid cells
  • Simulation required 3 months computer time

14
Hydrogen
XH2
z / mm
20
Fuel outlet
16
12
Fuel cells
8
4
0
Fuel inlet
x / mm
0
20
40
60
80
100
120
140
15
Carbon Monoxide
XCO
z / mm
20
16
12
8
4
0
x / mm
0
20
40
60
80
100
120
140
16
Temperature
z / mm
Temperature (C)
893 891 889 887 885 883 881 879 877 875
20
16
12
8
4
0
x / mm
0
20
40
60
80
100
120
140
17
Summary of Results
  • Fuel consumption
  • 12 of H2 and 7 of CO used
  • Without shift reaction 14.5 of H2 used
  • Shift reaction produces
  • 12 of H2 near fuel inlet
  • 20 of H2 near fuel outlet
  • Net temperature rise
  • 40C along air channels
  • 0C along fuel channels

18
Operating Voltage
y / mm
Voltage (V)
6
4
2
0
x / mm
0
30
60
90
120
150
19
Conclusions
  • Each module produces 12.5 W of power
  • Component efficiency 59
  • Rolls-Royce design is very good
  • High gas flow rates
  • Bundle geometry
  • Further simulations required
  • Whole bundle
  • Experimental validation

20
Thank You for Listening
  • Any Questions ?
