Generations of wireless networks

1
Generations of wireless networks

• Chapter 1

2
1G wireless standards
3
2G wireless
4
3G wireless
5
4G wireless
6
Where is wireless access going???

• Many (maybe too many) wireless technology choices
  are available today
• Short-range (WLANs, sensor technologies such as
  Bluetooth or Ultra Wideband)
• Long-range (Cellular)
• Broadband (WiMAX/WiBRO, Flash-OFDM, etc.)
• Broadcast (DVB-H, DMB, MediaFLO)
• Device segmentation is not universal
• Can vendors address the needs of the subcontinent
  while still making a global product?
• Democratization of wireless technologies
• Sales channels in the subcontinent are so varied
  do device features have to stop with the
  original manufacturer?

7
Air Interface Technologies
8
So Many Technology Choices
6.
3.9G
5.
3GHSDPA
3GHSUPA
4.
WiBRO
WiMAX (fixed)
WiMAX (mobile)
3.
WLAN Hotspots
2.
Flash-OFDM
802.20
1.
3GPP2 systems (1X, EV-DO, nxDO, Phase II
Evolution)
2009
2005
2006
2007
2008
9

• Cellular technologies
• Mature GSM/EDGE, CDMA
• Voice-only products approaching commodity status
• Ongoing rollout 3G (WCDMA) and 1X-EV-DO (CDMA
  evolution)
• What are the usage scenarios in the subcontinent?
• Bringing the internet to underserved user
  segments?
• Fancy services for a very small, very rich niche?
• Future 3.9 G
• Extending the high throughput capabilities of
  WLAN technologies into cellular
• Short range technologies (WLAN primarily)
• Not much good without an internet backbone goes
  hand-in-hand with broadband penetration

10

• Wireless broadband
• Slowly gaining traction in the West telecom
  operators are cautious because of previous
  overinvestment in other broadband technologies
  (DSL, optical)
• Very clear usage scenario in the subcontinent
• Strong backbone solution can bring internet
  access to remote areas and villages
• Is there enough business to get a major telecom
  vendor excited?
• Broadcast for wireless (DVB-H, DMB, MediaFLO)
• Certainly a proven appetite in Asia for TV
• Hard to say if users in the subcontinent will
  watch TV on small devices

11
Future Wireless System Development

• Increasing penetration
• Lowering costs of devices
• Improving return for operators
• Customizing services for the local population
• There is a quandary with going forward with a
  regional technology
• Will global vendors support it?
• If not, is there a local vendor base?
• Is the scale of the technology large enough to
  drive down cost?

12

• Low penetration provides some opportunity
• Legacy of cellular circuit-switched services
  (particularly voice) not insurmountable
• Rather than develop a new technology for South
  Asia, subcontinent researchers should try to
  drive locally enabling technologies through
  standardization, for example
• Improve cellular technologies for VoIP, enabling
  lower cost backbone
• Advanced cellular receiver design to improve
  voice capacity
• Driving targeted features in global
  standardization would be a win-win scenario for
  South Asia and the global vendor community
• Global technologies mean large scale costs can
  go down
• Opportunity for Asian researchers to influence
  standards that are deployed over the world
• Cellular is the best choice

13
Devices
14
Wireless Access Mapping

• Voice-only
• 2G (GSM, cdma2000 1X)
• Messaging and limited data services
• 2G (GSM, cdma2000 1X)
• Advanced wireless
• 2G (GSM, cdma2000 1X)
• 3G (WCDMA, cdma2000 1X-EV-DO)
• High-end business/multimedia
• 3G (WCDMA, cdma2000 1X-EV-DO)
• Complimentary access (WLAN a definite, maybe
  WiMAX)

15
Democratization of Wireless Technologies

• Example Research conducted in Delhi by Nokia
  Research Centers Usability Group, Tokyo

16
Karol Bagh market area of Delhi, India 200
small indoor shops, and 100 outdoor market stalls
17
this one building, approx. 60 small shops spread
over 4 stories
wholesaling phone accessories and repair equipment
small workshops actively repairing phones, and
offering training
18
minimal street customer care center flat
surface screwdriver new component knowledge
19
What can we take away?

• Huge after market service industry has developed
  in South Asia
• Phone repair, re-sale
• Reconditioned phone sales may be the ticket to
  providing new cellular service to customer
  segments, e.g.
• Basic voice to BOP
• Advanced multimedia to existing voice-only users
• Large proliferation of after-market services may
  also be able to provide some limited enhancement
  to cellular devices
• If multinational vendors can tap into this more
  effectively rather than view it as a threat, then
  consumer insight could result
• Are there low-cost innovations that could better
  serve an emerging market?

20
Wide Area Wireless Technology

• What are the next few years going to bring?

21

• From the Seventies through the Nineties, most
  cellular systems were developed through consensus
  and standardization
• AMPS was a technology delayed nearly 20 years due
  to building consensus!
• GSM has proven to be long-lasting and
  widely-supported also developed through
  industry cooperation
• In the Nineties, proprietary technologies emerged
• IS-95 (CDMA), proposed by Qualcomm Inc.
• Followed by 1X-EV-DO in the late Nineties
• Nowadays, several more proprietary alternatives
  to standardized cellular technologies have gained
  notoriety (not necessarily widespread adoption)
• Flarions Flash OFDM
• Other technologies may be nearly proprietary,
  with a small number of companies driving
  development

22

• What makes proprietary technologies attractive?
• Good ideas are sometimes compromised in the
  standardization process
• Standardization process can delay product
  development
• Proprietary route has pitfalls
• Lack of widespread vendor support for a given
  technology
• Intellectual property concentrated in the hands
  of a few players
• Is there a middle ground?
• Yes, when a small group of companies who can
  support a given technology develop it together
  outside of standards
• Standardization can follow, to allow other
  equipment manufacturers exposure to the
  technology and ensure interoperability

23
Where does spectrum come into the picture?

• Spectrum is not as cheap as once thought
• North American example recent consolidation
  among operators has left winners and losers in
  spectrum
• New 3G spectrum auctions (1.7/2.1 GHz) have not
  happened fast enough to address this
• Operators want to evolve existing cellular
  technologies in a manner that continues to
  leverage their huge investment in 3G equipment
• Backwards-compatibility will be a driver
• Makes it difficult to find a disruption point for
  good proprietary technologies
• The overlap period becomes a driver how long
  does the network operator have to support legacy
  subscribers while the new technology is being
  introduced?

24

• These are issues that will influence the
  evolution of cellular technologies
• New cellular systems will leverage as much as
  they can from legacy systems
• For example, reuse of control/overhead mechanisms
  from legacy
• Baggage from the legacy systems can reduce the
  benefits from innovation in evolution systems
• In response, wireless vendors need to get more
  creative as to what defines backwards
  compatibility
• Need to be selective in what is actually
  leveraged from the legacy system
• Also, need to consider how much evolution in the
  air interface technology is necessary for
  improving system performance
• Can improved performance be addressed through
  software/middleware innovation?

25

• Wireless broadband (802.16)
• Slowly gaining traction in the West telecom
  operators are cautious because of previous
  overinvestment in other broadband technologies
  (DSL, optical) Technology positioning is a
  problem for cellular operators already deploying
  3G
• The target customer base overlaps
• Broadcast for wireless (DVB-H, DMB, MediaFLO)
• Certainly a proven appetite in Asia for TV bodes
  well for DMB in East Asia
• European and North American markets unproven yet
  for handheld digital TV

26
What about Voice Services?

• Voice is still the killer app for cellular
• Without a compelling data application for 3G, it
  may be a safe starting point to say that VoIP
  will be the killer app for 3G evolution
• This profoundly affects cellular evolution
• Air interface must be optimized for low rate, low
  delay service such as voice
• This could come in conflict with design goal of
  extending high speed capabilities seen in WLAN to
  cellular
• As long as voice is perceived as a separate
  revenue stream rather than just another IP-based
  service, this could hamper cellular evolution
• In other words, should future cellular systems
  performance be benchmarked primarily by voice
  spectral efficiency?

27
Quality-of-Service for Internet
ApplicationsShould cellular provide the same as
broadband?

• Many internet applications are not designed with
  a cellular link in mind
• Underlying expectation of relatively constant
  quality of service (QoS)
• Throughput is assumed to be known during session
  setup
• Certainly totally different applications can be
  designed for cellular, but some innovation in the
  middleware area may improve application
  performance over cellular without
• Redesigning air interface
• Rewriting application
• Example online multiplayer gaming (First
  person shooter)
• Player actions based on other player actions
• Near real time
