DNA Structure and Function

1
DNA Structure and Function

• Chapter 13

2
Scientists that Studied DNA(know what they did
in general)

• Miescher
• Griffith
• Hershey and Chase
• Avery and Colleagues
• Pauling
• Chargaff
• Franklin
• Watson and Crick

3
Miescher Discovered DNA

• 1868
• Johann Miescher investigated the chemical
  composition of the nucleus
• Isolated an organic acid that was high in
  phosphorus
• He called it nuclein
• We call it DNA (deoxyribonucleic acid)

4
Mystery of the Hereditary Material

• Originally believed to be an unknown class of
  proteins
• Thinking was
• Heritable traits are diverse
• Molecules encoding traits must be diverse
• Proteins are made of 20 amino acids and are
  structurally diverse

5
Griffith Discovers Transformation

• 1928
• Attempting to develop a vaccine
• Isolated two strains of Streptococcus pneumoniae
• Rough strain was harmless
• Smooth strain was pathogenic

6
Griffith Discovers Transformation
1. Mice injected with live cells of harmless
strain R.
2. Mice injected with live cells of killer strain
S.
3. Mice injected with heat-killed S cells.
4. Mice injected with live R cells plus
heat-killed S cells.
Mice die. Live S cells in their blood.
Mice live. No live R cells in their blood.
Mice die. Live S cells in their blood.
Mice live. No live S cells in their blood.
Figure 13.3Page 218
7
Transformation

• What happened in the fourth experiment?
• The harmless R cells had been transformed by
  material from the dead S cells
• Descendents of the transformed cells were also
  pathogenic

8
Bacteriophages
Protein coat

• Viruses that infect bacteria
• Consist of protein and DNA
• Inject their hereditary material into bacteria

bacterial cell wall
plasma membrane
cytoplasm
DNA
Figure 13.4bPage 219
9
Hershey Chases Experiments (1940s)

• Created labeled bacteriophages
• Radioactive sulfur
• Radioactive phosphorus
• Allowed labeled viruses to infect bacteria
• Asked Where are the radioactive labels after
  infection?

10
Hershey and Chase Results
virus particle labeled with 35S
virus particle labeled with 32P
bacterial cell (cutaway view)
label outside cell
label inside cell
Figure 13.5Page 219
11
Avery and Colleagues (1944)

• What is the transforming material?
• Cell extracts treated with protein-digesting
  enzymes could still transform bacteria
• Cell extracts treated with DNA-digesting enzymes
  lost their transforming ability
• Concluded that DNA, not protein, transforms
  bacteria TRANSFORMING PRINCIPLE

12
Structure of the Hereditary Material

• Experiments in the 1950s showed that DNA is the
  hereditary material
• Scientists raced to determine the structure of
  DNA
• 1951 Linus Pauling discovered the 3D structure
  of the protein collagen

Figure 13.2Page 217
13
Structure of Nucleotides in DNA

• Each nucleotide consists of
• Deoxyribose (5-carbon sugar aka pentose)
• Phosphate group
• A nitrogen-containing base
• Four bases
• Adenine, Guanine, Thymine, Cytosine

14
Nucleotide Bases
ADENINE (A) PURINE
GUANINE (G) PURINE
phosphate group
deoxyribose
THYMINE (T) PYRIMIDINE
CYTOSINE (C) PYRIMIDINE
Figure 13.6Page 220
15
Animation
DNA subunits interaction.
Click to view animation.
16
Composition of DNA

• Chargaff showed
• Amount of adenine relative to guanine differs
  among species
• Amount of adenine always equals amount of thymine
  and amount of guanine always equals amount of
  cytosine
• AT and GC

17
Rosalind Franklins Work

• Was an expert in X-ray crystallography
• Used this technique to examine DNA fibers
• Concluded that DNA was some sort of helix

18
Watson-Crick Model

• DNA consists of two nucleotide strands
• Strands run in opposite directions (5 prime to 3
  prime and 3 to 5)
• Strands are held together by hydrogen bonds
  between bases
• A binds with T and C with G
• Molecule is a double helix

19
Watson-Crick Model
Figure 13.7Page 221
20
Animation
DNA close-up animation.
Click to view animation.
21
Animation
DNA structure animation.
Click to view animation.
22
DNA Structure Helps Explain How It Duplicates

• DNA is two nucleotide strands held together by
  hydrogen bonds
• Hydrogen bonds between two strands are easily
  broken
• Each single strand then serves as template for
  new strand

23
DNA Replication

• Each parent strand remains intact
• Every DNA molecule is half old and half new
  semi-conservative
• 1 strand of the original is 25 of the
  transcribed helix

new
new
old
old
Figure 13.9Page 222
24
Base Pairing during Replication

• Each old strand serves as the template for
  complementary new strand

Figure 13.10Page 223
25
Enzymes in Replication

• DNA polymerase
• Unwind the strands
• attaches complementary nucleotides (replication
  enzyme)
• Proof reads replicated strands
• Repairs DNA
• DNA ligase
• fills in gaps of nucleotides into one continuous
  strand
• Repairs DNA
• Wind the two strands together

26
Replication (hereditary material duplicated)
happens prior to cell division (mitosis)
27
A Closer Look at Strand Assembly

• Energy for strand assembly is provided by
  removal of two phosphate groups from free
  nucleotides

newly forming DNA strand
one parent DNA strand
Figure 13.10Page 223
28
Continuous and Discontinuous Assembly
3
5
Strands can only be assembled in the 5 to 3
direction
Discontinuous
Continuous 5
3
Figure 13.10Page 223
29
Animation
DNA replication animation.
Click to view animation.
30
DNA Repair

• Mistakes can occur during replication
• DNA polymerase can
• Proof read sequence from complementary strand
• Fixes mistakes in strand with DNA ligase
• Genetic disorders if DNA repair skipping the
  wrong sequences (mutations)

31
Cloning

• Making a genetically identical copy of an
  individual
• Researchers have been creating clones for decades
• These clones were created by embryo splitting

32
Dolly Cloned from an Adult Cell

• Showed that differentiated cells could be used to
  create clones
• Sheep udder cell was combined with enucleated
  (nucleus taken out) egg cell
• Dolly is genetically identical to the sheep that
  donated the udder cell

33
Animation
Cloning of Dolly animation.
Click to view animation.
34
More Clones

• Mice
• Cows
• Pigs
• Goats
• Guar (endangered species)
