RFID

1
RFID

• The EM Spectrum

2
Electromagnetic waves

• formed when an electric field (the blue arrows)
  couples with a magnetic field (the red arrows)
• magnetic and electric fields of an
  electromagnetic wave are perpendicular to each
  other and to the direction of the wave.

3
Properties of EM Waves

• Wavelength - m
• Frequency - Hz
• Energy - eV

Freq cycles per second
4
Properties of the EM Spectrum

• Typical Units Vary with the Spectrum

5
Observing the EM Spectrum?
6
(No Transcript)
