An Introduction to Pavements

1
An Introduction to Pavements

• Specific Emphasis on WSDOT Pavements

2
Presentation for CEE 421

• Overview of Pavements
• Introduction to WSDOT Pavements
• Evolution and a Little History
• Pavement Design
• Pavement Rehabilitation
• Pavement Management
• Current Pavement Construction Issues

3
Managing PavementsIs It Important?
4
(No Transcript)
5
Early Roads
6
Early Roads

• Roman Roads
• Early Asphalt Paving in Washington State
• Corduroy Road
• Bothell Road1912
• Sam Hill, Maryhill Roads, and Columbia River
  Highway1909 to 1920
• Opening of Pacific Highway1915
• Paving Sunset Highway (SR 2)1925

7
A Really Early Pavement Roman Road in Pompeii
8
Paving Riverside Ave Spokane, Washington in 1898
9
Chehalis, Washington Corduroy Road
Construction 1910-1920
10
Warrenite Bitulithic Paving Project (King
County) Bothell Road (Now SR 522Bothell
Way) May 1912
11
Photograph date is May 14, 1912
12
(No Transcript)
13
Sam Hill, Maryhill Roads, and Columbia River
Highway
14
Biggs, Oregon
15
(No Transcript)
16
(No Transcript)
17
Maryhill Museum
18
(No Transcript)
19
(No Transcript)
20
Upper Loop Road 1909-1913
21
Upper Loop Road (adjacent to US 97)
22
1909-1913
Today
23
Hand placing Macadam aggregate
Maryhill Road Construction 1909-1912
A real steam roller
24
Maryhill Upper Loop RoadMacadam Pavement Core
25
(No Transcript)
26
Blood Hound Guard DogLyle, Washington Convict
Labor Camp (So how did you think SR 14 was
originally built?)
27
Restored Columbia River HighwayHood River, Oregon
28
This section was constructed ? 1920
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
Opening of Pacific Highway January 29, 1915
33
Paving the Sunset Highway
34
Paving the Sunset Highway West of Spokane 1925
35
Paving the Sunset Highway with PCC--1925
36
Completed Segment of Sunset Highway
37
Current Condition of Portion of Sunset Highway
Paved in 1919
38
Date Stamp
39
Road Vehicles and Construction EquipmentPast to
Present
40
(No Transcript)
41

• Logging Truck in Western Washington--1918
• Solid Rubber Tires
• Chair Drive

42
1923 Kenworth with Solid Rubber Tires
43
1926 Kenworth Truck with Pneumatic Tires
44
End Dump
45
Flowboy
46
Belly Dump
47
Steam Roller Pulling Aggregate Carts Seattle
1910-1920
48
(No Transcript)
49
Blaw-Knox MC-30
50
Roadtec Shuttle Buggy
Photo courtesy of Roadtec
51
Pavement Design
52
Flexible Pavements
53
Trinidad Lake Asphalt
54
Asphalt Concrete and Asphalt Binders
55
Bituminous Surface Treatment Flexible Pavement
56
Flexible Pavement Design Procedures

• AASHTO 86/93
• Asphalt Institute
• Mechanistic-Empirical
• Other

57
AASHTO

• Founded 1914
• AASHO became AASHTO in 1973
• Milestones
• Development of national standards and
  specifications
• Nationwide route numbering system
• AASHO Road Test (1955)
• NCHRP (1962)
• SHRP (1987)

58
Empirical Design Approach

• Based on results of experiments or experience
• Scientific basis not established
• AASHTO 86/93 an empirical design method
• Refer to AASHO Road Test

59
Typical Loop Layout--AASHO Road Test Loop 5
Single Axles 22.4 kips, Tandems 40 kips Loop 6
Single Axles 30.0 kips, Tandems 48 kips
60
Empirical ApproachAASHTO Flexible Pavement
Performance Equation

• log10 W18
• (ZR) (S0) (9.36)(log (SN 1)) - 0.20
• ?log10?PSI/(4.2-1.5)/0.40 1.094/(SN
  1)5.19 ?
• (2.32) (log10MR) - 8.07

61
(No Transcript)
62
Mechanistic-Empirical Approach(for design and
analysis)

• Mechanistic Determine stresses, strains, or
  deflections at critical locations in a pavement
  structure.
• Empirical Relates stresses, strains, or
  deflections to pavement performance. Sometimes
  referred to as Failure Criteria or Transfer
  Functions.

63

• M-E design process requires
• Material properties of each layer (Ei, ?i)
• Thickness of each layer (hi) and load (P, a)

64
Fatigue Cracking and Nfatigue
65
Total Pavement Rut Depth and Nrutting
66
Design Inputs

• Traffic Loading and the Design Period
• Materials Characterization
• Climate Characterization or Conditions
• Life Cycle Cost Analysis

67
Traffic Loading

• Equivalent Axle Loads (18,000 lb (80kN) single
  axles)ESALs or E80s
• Approximate estimate
• Fourth Power Law axle wt/18,0004

68
WSDOT Design Periods

• New Designs/Reconstruction
• National Highway System 40 years
• Non-Federal Aid 40 years unless ESALS less than
  100,000 per year
• Rehabilitation
• AC Overlays 15 years

69
Material Characterization

• Asphalt Concrete
• Marshall Stability
• Hveem Stability
• Elastic Modulus
• Unstabilized Aggregate (Base and Subbase Courses)
• California Bearing Ratio (CBR)
• R-value
• Elastic Modulus
• Subgrade
• CBR
• R-value
• Elastic Modulus

70
Typical Flexible Designs
71
Flexible Pavement Design Procedures
72
COST 333 Participating Countries

• Austria
• Belgium
• Switzerland
• Germany
• Denmark
• Spain
• Finland
• France
• UK
• Greece

• Greece
• Croatia
• Hungary
• Ireland
• Iceland
• Netherlands
• Norway
• Portugal
• Romania
• Sweden
• Slovenia

73
European Standard Axle Loads
74
European Asphalt Concrete Thicknesses (20
Countries)

• Comments
• E80s 10 million
• CBR 5

75
Comparison of Asphalt Concrete Thicknesses (mm)

• Comments
• Minn 75 mm if Deep Strength design
• EU thickness represents the mean of 20 countries
• E80s 10 million
• CBR 5 to 6

76
Asphalt Concrete Thicknesses (mm) for Three
Levels of E80s
Note Various levels of reliability influences
thicknesses.
77
Comparison of Total Pavement Thicknesses (mm)

• Comments
• Tx -200mm if delete lime treated subgrade
• R 85 Wa
• R 95 Tx, RSA
• E80s 10 million
• CBR 5 to 6

78
Rigid Pavements
79
Rigid Pavement Design

• AASHTO 72/81
• AASHTO 86/93
• Portland Cement Association
• Mechanistic-Empirical
• Other

80
Typical Rigid Designs
81
Rigid Pavement Design Features
82
Typical Rigid Pavement Designs
83
15th Avenue NE
84
Jointed Doweled PCC Paving Dowel Bars in Cages
Ready for Placement of PCC US 395
85
PCC Construction US 395
Construction of a Doweled Construction Joint
86
California Profilograph is used to check pavement
smoothness following construction
87
PCC Contraction JointsUS 395
88
Illustration of Contraction Joint Crack and
Aggregate Interlock
89
Tie Bars for Joining to Adjacent Lanes (I-90
Spokane)
90
Pavement Rehabilitation
91
Asphalt Concrete OverlayUS 2
92
1992 Dowel Bar RetrofitI-90
93
Dowel Bars Before Placement of Patch Material
94
Pavement Distress
95
(No Transcript)
96
Longitudinal Cracking
97
Fatigue Cracking (Alligator Cracking)
98
Fatigue Cracking (Alligator Cracking)
99
Pothole
100
Transverse Cracks
101
Rutting
102
Panel Cracks
103
Faulting of Transverse Joints
104
Current Pavement Construction Issues
105
The Problem

• Localized spots of coarse surface texture
• Premature failure due to fatigue cracking,
  raveling, and moisture damage

106
End Dump/No MTV
Route SR-203 Section King/Snohomish Line to
SR-2 Binder PG 64-22 Mix Class A Haul Time
30 minutes Haul Length 18 miles Plant Temp
290F Mat Temp 255F Comments Thermal
differential of 140 degrees between crust and
internal mix.
107
End Dump/No MTV
Route SR-203 Section King/Snohomish Line to
SR-2 Binder PG 64-22 Mix Class A Haul Time
30 minutes Haul Length 18 miles Plant Temp
290F Mat Temp 255F Comments Temperatures
and corresponding densities.
108
Paving Industry
109
Hot Mix Asphalt Industry

• Miscellaneous hot mix facts and figures for the
  US
• 600 million tons of asphalt concrete produced
  during 2006 with a value of 20 billion
• Produced by 1,100 producer firms in 3,600 plants
  and placed by several thousand paving contractors
• 500 million tons of crushed rock, sand, and
  gravel supplied to HMA industry mined and
  processed in 9,000 quarries and sand and gravel
  operations
• More than 36,000 agencies that specify HMA.

110
Hot Mix Asphalt Industry (cont.)

• More than 80 refineries in US and Canada produce
  liquid asphalt cement with additional asphalt
  cement being imported. Total asphalt cement sales
  estimated to be 30 million tons with a value of
  4 billion.
• National Asphalt Pavement Association (NAPA)
  represents the HMA industry at the national
  level. The Asphalt Institute represents the
  liquid asphalt cement suppliers at the national
  and state levels.
