Introduction to Chemistry

1
Introduction to Chemistry Background for
Nanoscience and Nanotechnology

• Prof. Petr Vanysek

2
Introduction to ChemistryHow to go about
making nanomaterials?
3
WHAT IS NANO?
4
What is so big about nano?

• Sun cream
• Face cream
• Computers
• Sports equipment
• Anti-microbial
• bandages

1965 30 transistors on a computer chip Today
40,000,000 details 90nm
5
Whats so big about nano?
Nano-scale materials often have very different
properties from bulk materials e.g. color and
reactivity

• 3nm iron particle has 50 of atoms on the
  surface
• 10nm particle has 20 of atoms on the surface
• 30nm particle has 5 of atoms on the surface

6
(No Transcript)
7
SMALL
8
The scale of things
9
Top-down and bottom-up approach
10
The top-down approach
Machining or etching larger blocks and composites
to smaller structures

• Compare to traditional sculpture
• Size of detailed features depends on size of
  tools

11
The bottom-up approach
Small molecules or particles pre-designed to
self assemble into larger, organised structures
e.g. surfactants
Hydrophilic head group Water loving
oil
oil
oil
water
Hydrophobic tail Water hating
oil
oil
Spherical micelle
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
Gold nanoparticles

• Element 79
• Inert
• Need extreme conditions to react (chlorine,
  fluorine, cyanide, aqua regia 13 nitric
  acidHCl)

25
Not so inert

• Masatake Haruka (Japan)
• Gold nanoparticles catalyse carbon monoxide
  oxidation
• Highly active even BELOW ROOM TEMPERATURE

26
Catalysis the golden age

• Most car pollution in first 5 minutes
• Cold Engine
• Pt/Pd catalysts good gt200?C
• Gold nanoparticles (8nm)
• Active below room temperature

(Science, October 2004, Volume 306, pp. 234-235)
27
Emulsions
Add surfactant and mix
OIL
WATER
EMULSION (water in oil)
28
The bottom-up approach
Use emulsion to make nanoparticles
Precipitation inside micelles
29
Gold nanoparticles
Reducing agent KBH4 (potassium borohydride)
Au3 ions (potassium tetrachloroaurate KAuCl4)
30
Gold nanoparticles
oil
oil
oil
oil
oil
oil
oil
oil
oil
oil

• Micelles collide
• Reagents mix inside micelles
• Gold ions reduced to gold metal
• Gold trapped in micelle forms sphere

31
Crystalline in nature
www.drexel.edu/coe/enggeo/minerals.html
32
Crystalline in nature
Calcium carbonate
Calcium phosphate
Image courtesy of Vicky Swinerd
Nature produces very unusual, irregular crystals
33
Changing faces
Calcium carbonate (CaCO3)
Image courtesy of Dr Alex Kulak
34
Changing faces
Calcium carbonate (CaCO3) grown on uneven surface
Image courtesy of Nicola Hetherington
35
Changing faces
Calcium carbonate (CaCO3) Grown from a solution
containing a polymer
Image courtesy of Dr Alex Kulak
36
Changing faces
37
Changing faces
38
Changing faces
Images courtesy of Dr Simon Hall
Crystals of superconductor Grow into needles when
polymer from crab shell added
39
Carbon nanotubes

• Allotrope of carbon
• Graphite sheet rolled into a tube
• 50,000x smaller than human hair
• Members of fullerene family
• (including buckyballs)

40
Carbon nanotubes
http//www.seas.upenn.edu/mse/images/nanotube1.jpg
41
Single-walled nanotubes

• Capped or uncapped
• All covalent sp2 bonding
• Metallic conductors or semiconductors
• Bundles
• Defects points for reaction

42
Multi-walled nanotubes

• 63GPa tensile strength
• (steel 1.2GPa)
• Inner tubes slide without friction

http//www.msm.cam.ac.uk/polymer/research/nanointr
oCNT.html
43
Ancient nanotubes?

• Damascus steel swords extremely strong
• Middle Eastern origin 1100-1700AD
• Manufacturing secret lost
• Thought to be pattern welded
• Recent study showed nanowires
• and carbon nanotubes

Nature, 16th November 2006
44
Nanotubes today
Carbon nanotubes incorporated in bike frame
45
Concerns?
Lots of people suspicious of nanotechnology Worrie
s about nano-robots that could self-replicate

• Not that realistic
• Brownian motion
• Surface forces

BUT body cells are effectively machines, with
working parts on the nano-scale so nature has
done it
46
The real safety issue

• Nanoparticles can be much more reactive than
  bulk material
• Physical shape of material can seriously affect
  its toxicity

e.g. Asbestos
Serpentine flat sheets of atoms,
harmless Chrysotile nano-scale tubes
Should treat these new nano-materials with caution
47
Self-assembly
48
Self-assembly
49
Self-assembly
50
Mesoscopic self-assembly
51
Self-assembly
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
Electrons and dimensions
60
Examples of nanomaterials
61
Nanoparticles and size effects
62
Bottom-up to nano
63
Ways to the nano world
64
Colloids
65
Colloids
