Title: LECTURE : REVIEW OF BASIC CIRCUITS CONCEPTS


1
LECTURE REVIEW OF BASIC CIRCUITS CONCEPTS
  • September 28, 2009

2
REVIEW OF BASIC CIRCUITS CONCEPTS ELECTRICAL
QUANTITIS

Charge, Current, and Voltage

3
REVIEW OF BASIC CIRCUITS CONCEPTS ELECTRICAL
QUANTITIS
  • Charge is measured in coulombs .
  • Current is a flow of electrical charge from one
    region to another.
  • Currents not only have magnitude, but also have
    direction.
  • To indicate its direction, a current is described
    by a number with a sign.

4
REVIEW OF BASIC CIRCUITS CONCEPTS ELECTRICAL
QUANTITIS
Current in a wire has its value and the
reference direction (direction of the arrow).
Choice of the reference direction is
arbitrary. By definition, a current is positive
when positive charges move in the reference
direction. If I is a negative number, this
means that current flows in the direction
opposite to the direction of the arrow.
5
REVIEW OF BASIC CIRCUITS CONCEPTS ELECTRICAL
QUANTITIS
  • Electrical Potential and Voltage
  • When electrical forces act on a charged particle,
    it will possess potential energy the value of it
    depends on the particle location.
  • The potential energy can be turn into kinetic
    energy by releasing the particle.
  • After a while the particle will reach a position
    where its potential energy is lower, and the
    potential energy difference will be converted to
    kinetic energy.

6
REVIEW OF BASIC CIRCUITS CONCEPTS ELECTRICAL
QUANTITIS
  • To describe the potential energy that a particle
    with a charge will have at point , the
    electric potential is defined as
  • where is the potential energy of the
    particle with charge at the position .
  • IMPORTANT The zero point of potential energy can
    be arbitrarily chosen. The reason for this is
    that only differences in potential energy have
    practical meaning.

7
REVIEW OF BASIC CIRCUITS CONCEPTS ELECTRICAL
QUANTITIS
  • We can choose any point in a circuit to be the
    point where electrical potential is zero. This
    point is referred as the ground point.
  • Just as with potential energy, it is the
    differences of electrical potential that matter.
  • The term voltage is used for difference in
    electric potential.
  • Voltages can either positive or negative numbers
    and are measured in volts ( ). It is usual to
    express all potentials with respect to the
    ground.
  • The potential difference between any point and
    ground is called the voltage at that point. The
    words voltage at point A always mean the
    potential at point A with respect to ground. The
    symbol for this voltage is .

8
REVIEW OF BASIC CIRCUITS CONCEPTS ELECTRICAL
QUANTITIS

If there is a circuit element with voltage
indication with and signs, that means that
the indicated voltage is equal to the potential
at the sign minus the potential at the sign.
9
REVIEW OF BASIC CIRCUITS CONCEPTS Problem

(the potential at A with respect to the ground)
is 4V. And
?
What is
10
PROBLEM
In Fig. (a), the current I1 is -2mA. Is it
possible to say what I2 is and why?
In Fig. (b), the current I1 is 2mA. Is it
possible to say what I2 is and why?
Is it possible to say what I3 is and why?
11
REVIEW OF BASIC CIRCUITS CONCEPTS
  • Circuit elements Wires, voltage sources, current
    sources, resistors, capacitors, inductors,…
  • We will assume that wires are ideal (perfect
    conductors) and all points along a wire are at
    exactly the same potential.
  • Open circuit exists between two points when they
    are not connected together by any circuit
    element. No current can flow through the open
    circuit.
  • Short circuit exists between two points when they
    are connected together by an ideal wire. Both
    points have the same voltage.
  • Additional terms Nodes and loops.

12
REVIEW OF BASIC CIRCUITS CONCEPTS KIRCHHOFFS LAWS
  • KCL The algebraic sum of the currents entering
    and leaving
  • a junction is zero
  • KVL The algebraic sum of the changes in
    potential around a
  • closed loop is zero

I2
I1
I1I2I3
I3
http//www.rfcafe.com/references/electrical/kirchh
offs_law.htm
b
c
0(Vb-Va)(Vc-Vb)(Vd-Vc)(Va-Vd)
a
d
13
REVIEW OF BASIC CIRCUITS CONCEPTS DC CIRCUIT
ANALYSIS
  • The circuit elements Ideal resistors, Ideal
    voltage and current sources.
  • Ideal voltage source
  • Ideal current source
  • Ideal resistor is described by Ohms law
  • The algebraic signs of voltage and current are
    very important.
  • Useful First choose the reference direction for
    current through the resistor. The value of this
    current is the potential at the tail of the arrow
    minus the potential at the head of the arrow,
    divided by R.
  • Try memorizing this rule.

14
REVIEW OF BASIC CIRCUITS CONCEPTS DC CIRCUIT
ANALYSIS
  • How we should choose a sign of each voltage in
    the circuit?
  • KVL

As a result, KVL has the form
15
REVIEW OF BASIC CIRCUITS CONCEPTS RESISTORS IN
SERIES
  • Two resistors in series

II1I2
V0V1V2
Ohms law for each element VIR
V0I1R1I2R2 Ohms law for complete
circuit V0IReq
ReqR1R2
gt
It is the voltage that is divided between
elements in series.
16
REVIEW OF BASIC CIRCUITS CONCEPTS RESISTORS IN
PARALLEL
  • Two resistors in parallel
  • Resistors are connected in such a way that
    they branch out from a single
  • node

VV1V2
II1I2
V/ReqV1/R1V2/R2
gt
1/Req1/R11/R2
It is the current that is divided between the
elements in parallel.
17
POWER IN RESISTORS
  • The power dissipated by a resistor
  • PIV or I2R
  • Circuit is
  • short if R0
  • open if Rinfinity

18
REVIEW OF BASIC CIRCUITS CONCEPTS AC CIRCUIT
ANALYSIS
  • Everything we have learned about DC analysis
    remains true in the AC, or time-varying, case.
  • The circuit elements - ideal voltage sources,
    current sources, and resistances - behave in the
    same way whether or not the voltages vary in
    time.
  • Additional elements that are useful only in AC
    circuits capacitors and inductors.
  • Sometimes interaction of AC signals with
    inductors and capacitors can provide striking
    results How the very large voltages - tens kV -
    can appear in the sparkplug in a car where power
    is supplied by a battery of 12 V?
  • This amazing voltage transformation is usually
    obtained by using a single inductor.

19
REVIEW OF BASIC CIRCUITS CONCEPTS IDEAL CAPACITOR
  • Basic physics of the capacitor lies in the fact
    that the voltage across the capacitor is linearly
    proportional to the charge on its plates.
  • QCV gt IdQ/dtCdV/dt
  • We have to specify algebraic signs. We will adopt
    the same nomenclature used for resistances.

In dc circuits capacitors behave just like an
open circuit.
Just as with Ohms law, the algebraic signs of
the current and voltage are of greatest
importance.
20
CAPACITORS
  • Two capacitors in parallel
  • I C1dV/dt C2dV/dt (C1 C2)dV/dt
  • Cpar C1 C2
  • Two capacitors in series
  • I C1dV1 /dt C2dV2 /dt
  • dV/dt dV1 /dt dV2 /dt dV1 /dt C1/C2 dV1
    /dt (1 C1/C2)dV1 /dt
  • dV1 /dt I/ C1 Cser C1 C2 /(C1 C2)

21
REVIEW OF BASIC CIRCUITS CONCEPTS IDEAL INDUCTOR
  • The I-V relationship

If current through an inductor is constant, the
voltage across the inductor will be zero.
22
RC CIRCUITS, CHARGING CAPACITOR
For tlt0 switch was in position b and at t0 it
moved in position a.
KVL Vb-VR-VC0 VRIR ICdVC/dt
vR
Solution of non-homogeneous diff. eq-n is sum of
general solution of homogeneous equation and
particular solution of non-homogeneous equation.
Since Vbconst, particular solution is VConstVb
23
RC CIRCUITS, CHARGING CAPACITOR
At t0 V0 gt A -Vb
24
RC CIRCUITS, DISCHARGING CAPACITOR
For tlt0 switch was in position a and at t0 it
moved in position b.
KVL
VR
VR IR
At t0 VVbgt AVb
25
SUMMARY CHARGING AND DISCHARCHING A CAPACITOR
