Quantitative Risk Assessment Monte Carlo Simulation

1
Quantitative Risk Assessment Monte Carlo
Simulation
2
What is Monte Carlo Analysis?

• It uses random number generation, rather than
  analytic calculations, to combine distributions
• It is increasingly popular due to high speed
  personal computers

3
Risk of infection from drinking water containing
protozoan micro parasites. (e.g. cryptosporidium)
4
The model
Viability I
Water source concentration
Treatment Process DR - effectiveness
Volume consumed V
5
Variables Conc - Concentration of pathogenic
micro-organisms in untreated (surface) water I -
Fraction of the detected pathogens that is
capable of infection (viability) DR - Removal or
inactivation efficiency of the treatment process,
expressed as its Decimal Reduction factor V
Daily individual consumption of unboiled drinking
water
6
Best estimate values
7
Variability Uncertainty
Key Qusetion of QRA How do we model the
variability of a given parameter?
8
Min, Best Guess, Max
How likely is this value?
3 X 3 X 3 X 3 243 combinations
9
How likely is each value?
Probability
What about values in between?
10
4
19
10
Use information from sampled values
Is there a mathematical function which matches
the distribution?
Cryptomontecarlowhatif.xls
11
Probability Density Function (pdf)
0.16
Probability Density Function (PDF) describes the
relative likelihood that a random variable will
assume a particular value
0.12
0.08
Frequency / Probability
Area under a PDF is always unity
The PDF is alternatively referred to in the
literature as the probability function or the
frequency function
0.04
0.00
0.0
20.0
40.0
60.0
80.0
100.0
Parameter Value
12
Cumulative Distribution Function
1.00
0.80
Cumulative Distribution Function (CDF) gives the
probability that the variable will have a value
less than or equal to the selected value
0.60
Probability of Value lt X Axis Value
0.40
CDF is the integral of the corresponding PDF
The CDF is alternatively referred to in the
literature as the distribution function, cumulativ
e frequency function, or the cumulative
probability function.
0.20
0.00
0.0
20.0
40.0
60.0
80.0
100.0
Parameter Value
13
Representing Uncertainty
Risk analysis relies on the appropriate use of
probability distributions to accurately
represent the uncertainties of the problem
14
Probability Distributions

• Risk analysis relies on the appropriate use of
  probability distributions to accurately represent
  the uncertainties of the problem
• Distributions can be
• Discrete or Continuous
• Bounded or Unbounded
• Parametric or Non-parametric
• Inappropriate use of probability distributions
  is a very common failing of risk analysis models

_at_Risk Help file Define Distribution
15
Discrete Distributions
May take one of a set of identifiable values
Each of which has a calculable probability of
occurrence Probability of occurrence sometime
called probability mass
Probability Mass Function
Sum of all these values must add up to 1

• Examples
• Binomial Negative Binomial Distributions
• Poisson Distribution
• Geometric Hypergeometric Distributions
• Generalised Discrete Distribution

16
1.00
e
u
CDF
l
a
0.80
V

s
i
x
A

X

0.60


lt

e
u
l
a
V

0.40
f
o

y
t
i
l
i
b
a
b
0.20
o
r
P
0.00
2
3
4
5
6
7
8
Parameter Value
17
Continuous Distributions
Used to represent a variable that can take any
value within a defined range
Probability Density Function

• Examples
• Normal, Lognormal
• Beta, Triangular
• Weibull

18
CDF
19
Continuous Distributions

• Measurement could be infinitely divisible
• e.g. Time, mass distance
• Also for 'discrete' variables where the gap or
  increment between them is insignificant e.g.
  project costs
• Descriptors
• Mean, variance, standard deviation, coefficient
  of variation, confidence interval

20
Bounded Unbounded Distributions

• A bounded distribution is confined to lie
  between two determined values
• Uniform - bounded between a minimum maximum
• Triangular - bounded between a minimum maximum
• Beta - bounded between 0 1
• Binomial - bounded between 0 n
• An unbounded distribution extends from minus
  infinity to plus infinity
• Truncated Normal Distribution
• Partially bounded
• Removes nonsensical tails

21
_at_Risk probability Distributions

• Excel Demo

22
How do the variables vary?
How can we combine the variations? What is the
value that is not exceeded 95 of the time?
23
Using Excel to model variation
Cryptosporid with excel probs
24
Monte Carlo Simulation

• Each uncertain variable modelled by a probability
  distribution rather than a single value
• Structure of a quantitative risk assessment model
  similar to a deterministic model i.e. with all
  the multiplication's, additions etc.
• Exception is that probability distributions are
  used to describe the variables rather than single
  values
• Objective is to calculate the combined impact of
  the model's various uncertainties in order to
  determine a probability distribution of the
  possible outcomes

25
Monte Carlo Simulation

• Random sampling of each probability distribution
  within the model
• Produces 1000's or even 10,000's of scenarios
• i.e. Iterations or trials
• Each probability distribution is sampled in a
  manner that reproduces the distribution's shape
• Distribution of the values calculated for the
  model outcome therefore reflects the PROBABILITY
  of the values that could occur
• Developed in World War II from Atomic Bomb
  research
• Monte Carlo or Latin Hypercube Sampling

26
Methodology

• Use data to inform the choice of input
  distributions for model parameters
• The choice of input distribution should always be
  based on all information (both qualitative and
  quantitative) available for a parameter

Data
Expert knowledge
27
Methodology

• In selecting a distributional form, the risk
  assessor should consider the quality of the
  information in the database ask a series of
  questions including (but not limited to)
• Is there any mechanistic basis for choosing a
  distributional family?
• Is the shape of the distribution likely to be
  dictated by physical or biological properties or
  other mechanisms?
• Is the variable discrete or continuous?
• What are the bounds of the variable?
• Is the distribution skewed or symmetric?
• If the distribution is thought to be skewed, in
  which direction?
• What other aspects of the shape of the
  distribution are known?

28
Methodology
Random Number Generated
Process Repeated Many Times
Distributions Sampled
Output Value Calculated
29
Monte Carlo Sampling
1.00
0.80
Random Number Generated
Curve Sampled
0.60
0.40
0.20
Parameter Value
0.00
0.0
20.0
40.0
60.0
80.0
100.0
30
Monte Carlo Sampling
1.00
0.80
0.60
Clustering - unless a large number of samples
taken
0.40
0.20
Parameter Value
0.00
0.0
20.0
40.0
60.0
80.0
100.0
31
Monte Carlo Sampling

• Random sampling from input distribution
• Random number generated between zero one
• Used to sample the probability distribution
• Entirely random sampling technique
• Sample may fall anywhere within the range of the
  input distribution
• Randomness of sampling may mean that it will over
  under sample from various parts of the
  distribution
• Cannot be relied upon to replicate the input
  distribution's shape unless a very large number
  of iterations are performed
• Pure randomness of Monte Carlo sampling not
  really relevant

32
Latin Hypercube Sampling
1.00
Curve stratified into layers
0.80
Each layer only sampled once
0.60
0.40
0.20
Parameter Value
0.00
0.0
20.0
40.0
60.0
80.0
100.0
33
Latin Hypercube Sampling

• Sampling method that appears random
• BUT guarantees to reproduce the input
  distribution with much greater efficiency than
  Monte Carlo sampling
• Uses 'stratified sampling without replacement'
• Sampling is forced to recreate the original input
  probability distribution
• Overcomes clustering problems associated with
  Monte Carlo sampling

34
Random Number Generator Seeds

• Many algorithms developed to generate a random
  number between 0 1 with equal probability
  density for all possible values
• Start or initial seed value
• Possible to select this seed value
• If model is not changed the same simulation
  results can be repeated exactly if same seed
  value set
• Possible to consider the effects of changing a
  distribution on the effects on the model's
  output
• Hence results due to changes in the model not
  as a result of the randomness of the sampling

35
Advantages of Monte Carlo Method

• Complex mathematics can be included with no
  extra difficulty
• Widely accepted technique
• Model behaviour can be investigated with ease
• Changes can be made quickly compared with
  previous models

36
Advantages of Monte Carlo Method

• Distributions of the model's variables can be
  precisely defined
• Sensitivities, Correlations other inter -
  dependencies can be modelled
• Computer does all of the work required
• Commercially available software
• _at_Risk, CrystalBall
• Level of mathematics required to perform a Monte
  Carlo Simulation is quite basic
• Greater levels of precision achieved by
  increasing number of iterations

37
_at_RISK Example
38
References

• Guiding Principles for Monte Carlo Analysis
  (EPA/630/R-97/001)
• http//www.epa.gov/ncea/monteabs.htm
• Guidance on Assigning Values to Uncertain
  Parameters in Subsurface Contaminant Fate and
  Transport ModellingA McMahon, J Heathcote, M
  Carey, A Erskine J Barker June 2001
• www.environment-agency.gov.uk/commondata/105385/nc
  _99_38_3.pdf
• Vose, D. (2000) Risk analysis A Quantitative
  Guide. John Wiley Sons.
