Dysrhythmias

1
Dysrhythmias

• Stephen W. Smith, MD

2
When in doubt

• Shock a fast rhythm
• Pace a slow rhythm
• But dont shock sinus tachycardia!!
• (though it will turn out alright)

3
Is patient stable or unstable?

• Patient has serious signs or symptoms? Look for
• Chest pain (ischemic? possible ACS?)
• Shortness of breath (lungs wet? possible CHF?)
• Hypotension
• Decreased level of consciousness
• (poor cerebral perfusion?)
• Clinical shock
• (cool and clammy -- peripheral vaso-constriction?)

• Are the signs symptoms due to the rapid heart
  rate?
• Or are S/Sxs rapid HR due to something else?
• I.e., is it sinus tach due to sepsis, hemorrhage,
  PE, tamponade, dehydration, etc.

4
3 types of tachydysrhythmias

• Re-entrant
• Respond well to electricity
• Atrial fib and flutter
• PSVT
• Ventricular tachycardia
• Monomorphic, Polymorphic (non-torsade)
• Some atrial tachycardias
• Automatic
• Sinus, junctional, most atrial tach, MAT, AIVR
• Triggered automaticity
• Some atrial tach, Torsades

5
Re-entry

• Requires 2 functional pathways that differ in
  their refractory periods.
• Triggered by early beat (e.g., PAC)

Atrium
LA
AV node
Sinus node
LV
Ventricle
6
Cardiac Action Potential
Automaticity depends on the slope of phase 4
7
Enhanced Automaticity--Pacemaker cell

• Pacemaker has spontaneous depolarization
• Fires when reaches threshold
• 1) Enhanced Normal automaticity (normal pacer
  cells)
• Steepening of depolarization, usually by
  adrenergic stimulation
• Some Atrial and Junctional tachycardia
• 2) Abnormal automaticity
• Happening in tissues that are not normally
  pacemakers
• Myocardial ischemia or recent cardiac surgery
• Accelerated idioventricular rhythm
• Atrial tachycardia, MAT
• Diagnosis
• Accelerates and decelerates gradually
• Beat to beat variability
• Treatment
• Do not respond well to standard interventions
• May respond to overdrive pacing

8
Triggered Automaticity/Dysrhythmias
Afterdepolarizations

• Early or Late afterdepolarizations
• R on T phenomenon
• Long preceding R-R interval
• Conditions that prolong QT
• Occur in salvos
• More likely to occur when sinus rate is slow
• Torsades de Pointes
• Digoxin toxicity

9
5 Questions

• Wide or Narrow?
• P-waves?
• Regularity?
• Regular
• Regularly irregular
• Irregularly irregular
• Rate?
• Rate change sudden or gradual?

10
Identify dysrhythmia5 specific common
tachycardias

• Sinus Tachycardia
• Atrial fibrillation
• Atrial flutter
• Paroxysmal supraventricular tachycardia (PSVT)
• Ventricular tachycardianon-torsade
• Monomorphic, Polymorphic
• Ventricular tachycardiaTorsade
• Polymorphic, long QT on baseline ECG
• Acquired vs. Congenital

11
Sinus Tachycardia (sinus SVT)

• Automatic
• P-waves
• Narrow, unless aberration
• Regular
• Max rate dependent on age 200 0.5 x age
• Gradual variations
• Treat underlying condition

12
Atrial fibrillation (SVT)

• Multiple re-entrant wavelets
• Irregularly irregular
• No consistent p-waves
• Narrow, unless aberrancy
• Atrium 400-700, Ventricle 100-200
• lt 100 implies AV nodal disease or drugs
• Ashmann phenomenon
• Short RR after Long RR may result in wide complex

13
Atrial fibrillation--Treatment

• Is WPW present?
• Bizarre, Wide complexes, shortest R-R lt 250 ms?
• Is duration lt or gt 48 hours? (Thromboembolic
  risk)
• Is acute atrial fib the etiology of the RVR?
• Chronic atrial fib, now tachycardic?
• Likely sepsis, GI bleed, dehydration, etc.--Treat
• Cardioversion unlikely to succeed in chronic a
  fib
• May improve with AV nodal blockerbut may worsen!
• If gt 48 hours, only convert if unstable
• But this will rarely happen and rarely work

14
Atrial fibrillationTreatmentIf A fib is sole
cause of instability, it will be acute

• Cardioversion (chronic usually will not convert)
• Electricity easiest150-200 joules biphasic
• If Cardioversion fails or if rhythm converts to
  NSR but converts back to fib, then
• Amiodarone (150 mg over 10 min) or Ibutilide (1
  mg over 10 min)
• Avoid with EF lt 20 or QT gt 480 ms
• May repeat electrical cardioversion
• Success rate 72 without and 100 with ibutilide
• New Engl J Med June 17, 1999 340(24)1849-54.

15
Atrial fibrillation--Treatment

• If Cardioversion contraindicated
• (thromboembolic risk)
• AV nodal blocker (Diltiazem bolus and drip)
• Beware hypotensive effects
• Calcium pretreatment not prophylactic
• J Emerg Med 26(4)395, May 2004
• If poor cardiac function
• Digoxin load
• (0.5 mg IV bolus, then 0.25 mg q 6 hours x 2)
• Works well, but has onset in hours, not minutes

16
Atrial Fibrillation

• AV nodal blockers do not convert
• Most paroxysmal atrial fib will convert
  spontaneously within several days
• The longer you wait, the better chance a clot
  will form
• Safe to convert if lt 48 hours
• Patient must be certain of time of onset
• Enoxaparin if not converting
• Delayed cardioversion

17
Electrical Cardioversion of emergency department
patients with atrial fibrillation.Burton JH et
al. Ann Emerg Med 2004 Jul 4420-30

• 4 sites, 388 patients (mean age 61 years range
  20 to 93 years)
• Duration of atrial fibrillation lt 48 hours in 99
• Electrical cardioversion successful in 332 (86)
  patients
• Twenty-eight complications in 25 encounters
• 22 attributed to procedural sedation
• 6 attributed to electrical cardioversion
• 4 hypotensive episodes (all responded to
  intravenous fluid management)
• 2 bradycardic events

18
Burton JH et al. Ann Emerg Med 2004 Jul
4420-30

• 333 (86) patients were discharged to home from
  the ED
• 301 after electrical cardioversion success
• 32 with electrical cardioversion failure.
• 39 patients (10) returned to the ED within 7
  days
• 25 of these patients (6 of successful electrical
  cardioversion patients) returned because of
  relapse of atrial fibrillation.

19
Atrial flutter (SVT)

• Re-entrant loop just above AVN in right atrium
• Atrial rate 240-360 without medications
• 21 block, vent rate 150 most common
• Regular, fixed or regularly irregular
• Narrow if no aberrancy
• Flutter waves, sawtooth pattern--Always visible
  in lead II
• Adenosine can help to diagnose, not treat
• Conversion vs. Ventricular slowing
• 50 Joules, Ibutilide/Amiodarone
• Diltiazem slows at AV node
• Procainamide before Diltiazem is dangerous

20
Atrial Flutterlead II
21
Paroxysmal supraventricular tachycardia (PSVT)

• Re-entrant, gt90 use AV node, lt 10 PAT
• Adenosine almost always works
• Rate 140-280, constant
• Regular, Narrow unless aberrancy
• Sudden onset and offset (paroxysmal)
• Initiated by PAC
• Atrial stretch (ACS, CHF), catecholamines,
  pericarditis
• AVNRTAV nodal re-entrant tachycardia (60)
• Orthodromic reciprocating tachycardia (30)
• P-wave after QRS, (bypass retrograde is slow)

22
Re-entry

• Requires 2 functional pathways that differ in
  their refractory periods.
• Triggered by early beat (e.g., PAC)

Atrium
LA
AV node
Sinus node
LV
Ventricle
23
Aberrancy - SVT with wide complex

• Abnormal ventricular conduction
• RBBB
• LBBB
• Nonspecific intraventricular conduction defect
• Rate-related BBB
• Antidromic Reciprocating
• Goes down through bypass tract

24
LBBB
25
RBBB
26
Supraventricular TachycardiaAny can be narrow
except antidromicOr Wide with aberrancy

• Sinus
• Paroxysmal SVT (PSVT)
• Intranodal re-entry (60)
• Orthodromic reciprocating (bypass tract) (30)
• Antidromic reciprocating (bypass tract) (10)
• A fib
• A flutter
• MAT
• Atrial tachycardia
• Junctional tachycardia

27
Ventricular Tachycardia, wide (gt120 ms) the
origin of the arrhythmia is within the ventricles

• Re-entrant
• Classic V tach
• Monomorphic
• Polymorphic
• Triggered
• Torsade de pointe
• Polymorphic
• long QT on baseline EKG
• Automatic
• Accelerated Idioventricular

28
Ventricular tachycardia

• gt 120 ms QRS
• Rate 140-200
• Slow rates due to anti-arrhythmics, e.g. amio
• V1 positive (RBBB config-origin in LV)
• V1 negative (LBBB config-origin in RV)
• V1 indeterminate, Pos and Neg (RS)
• Rate gt200 Ventricular flutter

Fusion beats
29
Wide Complex Tachycardia--Sinus tach with
aberrancy vs.--SVT (PSVT, fib, flutter) with
aberrancy vs. --Ventricular tachycardia

• Pretest probability
• Majority of wide complex tachycardia is
  ventricular tachycardia
• If h/o MI, cardiomyopathy, low EF, V tach more
  likely still
• P-waves in front of QRS?
• Irregularly irregular? A fib V tach is most
  commonly regular
• Regular? (Sinus / flutter / PSVT / v tach)
• Rate gradually changes or always the same?
• Gradual sinus
• Unchanging flutter vs. PSVT vs. v tach
• Rate the faster, the less likely it is sinus
• Look for a true bundle branch block pattern
• Right or left (sinus or SVT with aberrancy)
• Fusion beats (occasional narrow complex fused
  with wide one)

30
Identify ventricular tachycardia
Brugada P. Circulation 1991, 831649

• Regular and wide
• Step 1 Is there absence of RS complex in all
  leads V1-V6? (Concordance)
• If yes, then rhythm is VT
• Step 2 Is interval from onset of R wave to nadir
  of the S gt 100 msec (0.10 sec) in any precordial
  leads?
• If yes, then rhythm is VT. If no, step 3.
• Step 3 Is there AV dissociation?
• If yes, then rhythm is VT. If no, step 4.
• Step 4 Are morphology criteria for VT present
• (see next slide)? If yes, then VT

gt 0.10 sec?
31
Morphology criteria for VT
RBBB
V1
V6
LBBB
V6
V1
32
(No Transcript)
33
Ventricular Tachycardia Concordance
(different from concordance as used for ST-T vs
QRS)Step 1 Absence of RS in all precordial
leads
34
Ventricular Tachycardia
Step 1 there is no absence of RS in all
precordial leads (no concordance) (V5, V6) Step
2 RS in V5 gt 0.10 ms, therefore v tach Step 3
No AV dissociation Step 4 RBBB pattern (tall R
in V1). Notching of this monophasic R indicates
VT
35
V tachRS gt 0.10 sec
36
polymorphic ventricular tachycardia

• Polymorphic VT
• Long QT on baseline ECG--Torsade de pointes
• Normal QT on baseline ECG not Torsade
• treat ischemia, correct electrolytes, amiodarone

37
Polymorphic VT and prolonged QT (Torsade)

• Usually self terminating, may progress to v fib
• Treatment correct electrolytes (K, Mg)
• At risk of torsade Mg, 2g over 15 min
• Active v tach Mg, 2g over 30-60 sec, max 6g
• Serum K gt 4.5
• Overdrive pacing (100-140)
• Lowest pacing rate that prevents PVBs
• dilantin, lidocaine

38
Isoproterenol or beta blocker?

• Beta blockers long term therapy for familial
  LQTS
• Isoproterenol (beta 1 and 2 agonist)
• Can terminate acquired LQTS
• Isoproterenol only if all of the below
• Torsade is definitely the result of acquired LQTS
• Underlying bradycardia
• Pause dependent
• Pacing cannot be started immediately
• Limited role for acute beta blockade in
  congenital LQTS

39
Other tachydysrhythmias (following 7 slides)

• Junctional tach
• automatic
• Multifocal atrial tachycardia
• automatic
• Atrial tachycardia
• all 3 mechanisms
• Accelerated idioventricular rhythm
• automatic

40
Junctional Tachycardia

• Uncommon SVT
• Enhanced automaticity
• Gradual acceleration and deceleration
• Beat to beat variability
• Narrow (unless aberration)
• Regularly regular
• Rate 70-130
• No p-waves
• Due to MI/ischemia, cardiomyopathy, or Dig
  toxicity

AV node
41
Multifocal atrial tachycardia

• Uncommon SVT
• Enhanced automaticity of multiple atrial foci
• 3 atrial foci (multiform PACs)
• Rate 100-180
• Irreg irreg
• Narrow unless aberration
• Multiform p-waves
• Due to underlying resp disease e.g., COPD
• treat underlying disease

42
MAT
43
Accelerated idioventricular rhythm

• Ventricular (wide)
• Automatic
• Regular
• No p-waves
• 60-100 (ventricular escape is 20-40)
• Reperfusion dysrhythmia

44
Accelerated idioventricular rhythm
45
Atrial Tachycardia-uncommon All 3 types of
dysrhythmia

• Narrow, unless aberration, Regular, Rate 150-250
• Ps before QRS, different morphology from sinus
• Automatic, due to adrenergic stim of normal
  atrial tissue
• Transient suppression by adenosine
• Re-entrant (paroxysmal, PSVT)
• Intra-atrial re-entry
• Abnormal atrium, esp. after atrial surgery
• Not stopped by adenosine (0/13 pts, 8 with
  flutter)
• Electricity works
• Sinus node re-entry--Adenosine works
• Triggered (paroxysmal)
• Cardiomyopathy, on digoxin, usually some AV block
• Prolonged and difficult to treat

46
Atrial Tachycardiarate 140-170, converted with
adenosine
47
5 Questions

• Wide or Narrow?
• P-waves?
• Regularity?
• Regular
• Regularly irregular
• Irregularly irregular
• Rate?
• Rate change sudden or gradual?

48
Wide or Narrow

• Narrow
• Sinus, PSVT, A flutter, A fib
• (All without aberrancy)
• Wide
• SVT with aberrancy
• LBBB, RBBB, IVCD, rate-related BBB, antidromic
• Ventricular tachycardia

49
P waves

• If p waves, and associated with QRS, then sinus
  (or, rarely, atrial tachycardia)
• PSVT generally no p wave visible
• PR short
• P wave hidden in QRS, inverted
• A fib and flutter
• No p waves, but flutter may fool you
• V tach
• May rarely see P waves, but with no association
• (AV dissociation)

50
Regularity in tachycardia

• Regular
• Sinus, PSVT, flutter, V tach
• Regularly irregular
• Atrial flutter
• Irregularly irregular
• Atrial fib, MAT

51
Rate

• Sinus
• 160 - 200 rarely
• 140-160 fast
• Up to 140 common
• PSVT
• 160-190 very common
• A flutter
• 140-200 (ventricle), 260-340 (atrium) common
• A fib
• Any rate, gt 100 unless AV node disease or drugs
• Ventricular tachycardia gt 100
• usually 140-200 (slow is idioventricular rhythm)

52
Sudden vs. Gradual changeRe-entry vs.
automaticity

• Sinus gradual
• PSVT sudden
• Atrial flutter sudden
• Atrial fib always changing, but sudden onset
• Ventricular tachycardia Sudden

53
Fast, Narrow, and Irregular

• Atrial Fibrillation
• Irregularly irregular
• Atrial Flutter
• Regularly irregular
• Diagnosis may be aided by adenosine

54
Identify DysrhythmiaFeatures

• P-waves, regular, gradual rate changesinus
• No p-waves, regular, 130-250
• Narrow
• PSVT or flutterintranodal (AVNRT) or orthodromic
  bypass
• Wide
• Ventricular tachycardia
• Most common
• PSVT with aberrancy
• intranodal or bypass tract (orthodromic)
• PSVT due to antidromic reciprocating tachycardia
• Atrial Flutter with aberrancy
• Regularly irregular
• Atrial Flutter
• Irregularly irregular
• Atrial fibrillation, (V tach can be only slightly
  irreg irreg)

55
Very Fast and Irregularthink WPW and atrial fib

• Any R-R interval close to 250 ms?
• Think Atrial Fib with WPW
• Never give AV nodal blocker
• Never give Dig or Calcium channel blocker.
• Even adenosine associated with v fib
• Electrical or chemical conversion
• procainamide, amiodarone, ibutilide
• But NOT chemical AV nodal blocker

• WPW with regular rhythm (orthodromic/antidromic),
  not atrial fib
• AV nodal blockers are OK

56
What is it?
57
What is it?
58
Treatment when in doubtStable or
unstable-Electricity

• If possible, get 12-lead ECG first
• If electricity does not work
• Automatic rhythm
• Sinus, accelerated junctional, accelerated
  idioventricular, automatic atrial, MATtreatment
  of underlying disorder
• Chronic atrial fib
• Be sure it is not physiologic tachycardia
• Amiodarone for conversion
• Diltiazem or Digoxin to control rate
• Refractory ventricular tachycardia
• Amiodarone
• 150 mg, may repeat several times
• Treat underlying ischemia

59
Sinus Rhythm and PACsWith Aberrant Conduction
60
Wide-Complex Tachycardia Followed by
Second-Degree AV Block
61
STEMI Warning Arrhythmias
Antman and Rutherford. Coronary Care Medicine.
Boston, MA Martinus Nijhoff Publishing198681.
Treat resus v fib, and v tach in STEMI, with
amiodarone or lidocaine bolus and drip.
62
Class I for Transvenous Pacing
OR

• Left Bundle Branch Block or RBBB LAFB
  (Bifascicular block
• AND
• 2nd deg Mobitz type 2 block

3rd Degree Block (complete AV dissociation)
OR

• Alternating Left and Right BBB

63
Class IIa for transvenous

• Anterior MI
• and
• New LBBB or new RBBB ant or post FB
• And
• 1st degree AVB or
• 2nd degree AVB, Mobitz I (Wenckebach)

64
Conclusion When in doubt

• Shock a fast rhythm
• Pace a slow rhythm
• In anterior STEMI
• Be certain that transcutaneous pacing will
  capture if there is high grade block
• But dont shock sinus tachycardia!!

65
Questions?
66
Atrial Tachycardia Summary of adenosine

• If PSVT PAT, it will be constant rate and look
  much like AV nodal PSVT
• But should have p-waves
• Adenosine aborts some paroxysmal PAT but not all
• You may not know that the PSVT is PAT
• You might think it is the standard AV nodal
  reentrant PSVT
• If adenosine doesnt work, then it is likely to
  be PAT (if not atrial flutter)
• If adenosine does work, youll think you treated
  PSVT
• If you do diagnose PAT, adenosine is worth a try
