Journal reading: Traumatic Rupture of Aorta

1
Journal readingTraumatic Rupture of Aorta

• ???????
• ????? ????
• ????? ????
• 91-11-30

2
Traumatic Rupture of Aorta Should Be Ruled Out in
Severe Injuries from Paragliding Report of Three
Cases

• Navarrete-Navarro, Pedro MD Macias, Ines MD
  Lopez-Mutuberria, Maria Teresa Perez, Jose
  Miguel MD Manzano, Francisco MD Garcia, Manuel
  MD Rodriguez, Aurelio MD
• From the Critical Care and Emergency Department,
  Virgen de las Nieves University Hospital
  (P.N.-N., I.M., M.T.L.-M., J.M.P., F.M., M.G.),
  Granada, Spain, and Division of Trauma Surgery,
  Allegheny General Hospital (A.R.), Pittsburgh,
  Pennsylvania
• J Trauma, Volume 52(3). March 2002.567-570

3
Background

• Granada, Spain
• Paragliding

4
Introduction

• Most frequent injuries related to paragliding
• Bone fx lower limbs, pulvis and spine
• Ruptures of the descending aorta (TRA)
• Very high mortality
• Higher incidence of surviving pt dx with TRA in
  ER then before
• Survival depends on early Dx and Tx.

5
Case 1

• 35 y/o male, crash-landed
• Transported by helicopter and received 2L of
  crystalloid fluids, analgesia, and oxygen.
• Awake and lucid. RR 25, BP 90/45, HR 115
• X-ray
• Bilateral legs T-F fx (Rt tibial open fx)
• Both ankle comminuted fx
• L1 L4 vertebral bodies fx.

6
Case 1 Chest X-ray

• CXR
• Mediastinal widening and loss of contour
• Descending aorta

7
Case 1 Helical chest CT with 3D reconstruction.

• Pseudoaneurysm
• 2cm distal to the origin of the left subclavian
  artery.

8
Case 1 Management

• Lower limb fx external fixation
• ICU 24 hr Labetalol ivf to keep SBP lt 120 mm Hg
• Surgery for repair of the aortic rupture
• CP bypass 56 min, Vacutex-type tube implanted
• Post-OP stable
• 48 hr later, progressive left hemothorax
• Repeat CT large periaortic hematoma
• Immediate exploratory thoracotomy drainage
• No evidence of prosthetic dysfunction.

9
Case 2

• 39 y/o male, crashed into a tree.
• Good consciousness, abundant facial bleeding,
  bilateral otorrhagia, and upper airway
  obstruction.
• Transported by helicopter
• Sedation, tracheal intubation with MV.
• 2.5 L of cry. coll. fluids.
• Could be aroused.
• FiO2 0.5, PaO2 80 mmHg, PaCO2 31.6 mmHg
• BP 100/60, HR 110

10
Case 2 CXR and CT

• CXR
• mediastinal widening with loss of aortic arch and
  contour
• Chest CT
• mediastinal hematoma
• minimal left pleural effusion
• anterior subcutaneous emphysema
• Fracture of the left 6th rib
• Aortogram
• Rupture of the descending aorta 2 cm distal to
  the origin of subclavian artery with formation of
  pseudoaneurym of 4-5 cm.

11
Case 2 Management

• OP CP bypass (29 min), Dacron 7 graft implanted.
• Post-OP hemodynamically stable
• Respiratory failure
• FiO2 0.8, PEEP 15 cm H2O
• 4 weeks later, s/p tracheostomy and
  osteosynthesis for facial bone fx
• Discharged with tracheostomy cannula

12
Alhambra Granada, Spain
13
Case 3

• 29 y/o male, crash-landed
• At the scene
• Both ankle fx with pelvis deformity
• Transported by helicopter
• 3 L of crystolloid fluids
• Analgesia and O2
• Awake and lucid. RR 28, BP 80/40, HR 118
• No evident chest deformity or external injury

14
Case 3 CXR and CT

• X-ray
• Bilateral comminuted fracture of the tibia at the
  ankle
• Open-book complex fracture of pelvis
• CXR
• Mediastinal widening and loss of contour of
  aorta.
• CT
• Pelvis major retroperitoneal hematoma
• Chest mediastinal widening with minimal left
  pleural effusion.

15
Case 3 angiography

• Rupture of the descending aorta
• 2 cm distal to the origin of subclavian artery
• with formation of pseudoaneurym of 4-5 cm

16
Case 3 Management

• Reduction and ext. fixation of pelvis and ankle
  fx.
• Labetalol ivf to keep SBP lt 120 mmHg.
• At 72h after admission
• CP bybass (29 min)
• Resection of injured aorta, Dacron 7 graft
  inplanted.
• Post-OP
• Acute lung injury, with MV for 12 days.
• Extubated after 16 days.
• After 23 days, he was discharged to ortho. dep.

17
Discussion

• Protective measures of paragliding
• Crash helmet
• Dorsal spinal protection
• Improved footwear
• TRA
• 2nd most cause of death in (First place H.I.)
• Traffic accidents
• Falls from a height
• 85 die before arrival
• 50 mortality among who arriving alive

18
Discussion (2)

• TRA is more common in ER, due to
• Improvements in out-of-hospital stabilization
• Speed of transport
• TRA cases alive in ER
• self-selected group
• 80 the injury is produced at the aortic isthmus
• tear is usually limited and contained

19
Discussion (3)

• Diagnostic tools
• Angiography golden standard
• Chest spiral CT
• For dx of TRA. (J Trauma. 1998 45 922-930 )
• Routine use as first line regardless of the CXR
  (Arch Surg. 1998 133 1084-1088 )
• TEE angiography, but less sensitive, being a
  poor first-line exam tool.

20
Discussion (4)

• Pre-OP management
• instituting a hypotensive regimen
• Beta-blockers, vasodilators, sedatives, and
  analgesics
• Control BP before OP and 24-48 h after.
• prioritizing the injuries
• intraabdominal hemorrhage
• Craniotomy for cerebral decompression

21
Discussion (5)

• Operation options
• clamp sew technique
• operative neurologic sequelae due to spinal cord
  ischemia
• doesnt need heparin (suits exsanguinating
  hemorrhage episode)
• Full cardiopulmonary bypass
• bleeding from other sites of injury due to
  heparin
• Passive shunts (Gott shunts, LV/ascending aorta
  to descending aorta )
• Left heart bypass with a centrifugal or roller
  pump

22
Routine CT scanning for primary evaluation of
blunt chest trauma
23
Do We Really Need Routine Computed Tomographic
Scanning in the Primary Evaluation of Blunt Chest
Trauma in Patients with "Normal" Chest Radiograph?

• Exadaktylos, Aristomenis K. MD Sclabas, Guido
  MD Schmid, Stephan W. MD Schaller, Benoir MD
  Zimmermann, Heinz MD
• From the Trauma and Emergency Unit (A.K.E., G.S.,
  B.S., H.Z.) and the Department of Visceral and
  Transplantation Surgery (S.W.S.), Inselspital,
  University of Berne, Berne, Switzerland.
• J Trauma, Volume 51(6), December 2001. 1173-1176
• Blunt chest trauma
• 63 - 78 caused by motor vehicle crashes (MVCs)
• 10 - 17 related to fall from height.
• Study focus
• How many chest injuries remain undetected if
  chest CT is obtained only after pathologic chest
  radiograph finding.

24
Materials and methods

• University Hospital of Berne (Level I accident
  and emergency unit)
• Inclusion
• January 1999 to July 2000, 93 patients
• MVC (10-95 mph)
• Fall from height (5-35 ft)
• Exclusion
• Hemodynamic instability
• Necessity for rapid surgical intervention
• MF 7815, mean age 48 y/o (17-87)

25
Materials and methods (2)

• ER to CT room
• median transportation time 5 min
• Outside of ER 45 to 60 min
• Accompanied by ER physician and anesthesia team
  with full monitoring.
• No complication
• Helical contrast-enhanced CT were obtained in 0.3
  2 hours after arrival in the ER.

26
Results

• MCV fall from height 76.3 23.7
• Isolated chest inj multiple inj 2.2 97.8
• 73.1 has at least 1 pathologic sign on CXR
• 25 patients (26.9), the initially obtained chest
  radiograph was normal
• However, in 13 (52.0) of these 25 patients, the
  CT scan showed multiple injuries
• 12 patients (13 of total) both image were normal

27
Results (2)
28
Plain chest radiographs compared with helical CT
scanning
29
Patients with pathologic signs on the chest
radiograph
30
CT Scan Findings in 13 of 25 Patients with Normal
Chest Radiographs
CXR (compared with CT) PPV (positive predictive
value) 0.86, NPV 0.48 Sensitivity
(true-positive rate) 0.81. Specificity
(true-negative rate) 0.57
??!??CXR???!
31
Discussion

• In Europe, in blunt abdominal trauma, US has
  practically replaced DPL for the search of
  hemoperitoneum
• Reliable, if operator has short period of
  experience.
• Primary routine helical CT scan in blunt chest
  trauma under debate
• Even experienced radiologist may mis-read.
• Occult pneumothorax (esp anterior) only
  detectable by CT in 40 of traumatic cases.
• 1990 Woodring, and Woodring and Dillon 7 of
  thoracic aortic injuries have a normal chest
  radiograph.
• Demetriades et al. helical CT scan has a
  sensitivity of 100 in detecting aortic injuries.

32
Discussion (2)

• Angiography
• Brasel et al., in a cost-utility study, suggested
  the routine use of thoracic angiography as a
  screening method in all patients with a
  significant chest trauma, regardless of the
  findings of the plain chest radiograph.
• Demetriades et al. recommend aortography over
  chest CT scan only in patients who need
  angiography for pelvic or hepatic studies anyway.

• clinical outcome also controversial

33
Discussion (3)

• Risk of a thoracic injury in an MVC is 14
• Sternal fractures 8 of patients of above
  population.
• Risk of cardial contusion and other related
  injuries ??
• Risk of aortic rupture not increased
• Viano et al. and Katyal et al.
• intrathoracic damage occurs before the maximum
  compression of the chest wall is reached
• oscillating viscous response of the aorta.
• Demetriades et al. recommend
• that all trauma patients with high-risk
  deceleration injuries
• should undergo primary routine helical CT scan
  evaluation of the mediastinum irrespective of
  chest radiographic findings.

34
Conclusion

• Significant thoracic/intrathoracic injuries found
  on CT scan in more than 50 of patients with
  normal initial chest radiograph.
• Recommend primary routine chest CT scan in all
  patients with history of MVC
• gt 10 mph in unrestrained passengers.
• gt 30 mph in restrained passengers.
• Recommend a CT scan even if the height fallen lt
  15 ft.
• Low falls are as dangerous as falls from higher
  heights
• The height fallen does not predict the risk for
  serious injury.

35
Further reading ATLS
36
ATLS Thoracic trauma - Primary survey

• Airway fx which compromises airway
• Breath
• Tension pneumothorax
• Open pneumothorax
• Flail chest
• Massive hemothorax
• Circulation
• Massive hemothorax (gt 1500 ml)
• Cardiac tamponade

37
ATLS Thoracic trauma - Secondary survey

• Simple pneumothorax
• Hemothorax
• Pulmonary contusion
• Tracheobronchial tree injuries
• Blunt cardiac injury
• Traumatic aortic disruption
• Traumatic diaphragmatic injury
• Mediastinal traversing wounds

38
ATLS Thoracic trauma - Traumatic aortic
disruption

• Common cause of sudden death after automobile
  collision or fall from great height.
• Pt who survived
• Incomplete laceration near the ligamentum
  arteriosum of the aorta
• Intact adventitial layer
• Contained mediastinal hematoma
• Chest x-ray, especially the supine view, are
  unreliable
• Angiography is the golden standard.

39
Radiologic signs suggest major vascular injury of
chest

• Widened mediastinum
• Obliteration of the aortic knob
• Deviation of the trachea to the right
• Obliteration of the space between th pulmonary
  artery and the aorta (AP window)
• Depression of the left main stem bronchus
• Deviation of the esophagus (NG tube ) to the
  right
• Widened paratracheal stripe
• Widened paraspinal interfaces
• Presence of a pleural or apical cap
• Left hemothorax
• Fx of the 1st or 2nd rib or scapula

40
Radiographic features of Traumatic aortic injury

• Hememediastinum
• Widened mediastinum
• gt 8 cm at aortic arch (supine)
• Med.-Chest-width radio gt 14
• Blurring of the aortic contour with indistinct
  margins
• Left apical pleural cap
• Widening of the left paraspinal stripe
• Opacification of the aorticopulmonary window
• Widening of right paratracheal stripe
• Left pleural effusion
• Displacement of adjacent stuctures
• Tracha rightward and anteriorly
• Left mainstem bronchus inferiorly (bronchus and
  spine angle gt 140)
• Esophagus (NG tube) rightward and posteriorly
• Injury to adjacent thoracic structures

41
Thanks for your attention and comments!
