Release Consistency

1
Release Consistency

• Slides by Konstantin Shagin, 2002

2
The need for Relaxed Consistency Schemes

• In any implementation of Sequential Consistency
  there should be some global control mechanism.
• Either of writes or reads require memory
  synchronization operations.
• In most implementation writes require some kind
  of memory synchronization

w(x) w(y) w(x)
A
B
3
The Idea of Relaxed Consistency Schemes

• The Relaxed Consistency Schemes are designed to
  allow less memory synchronization operations.
• Writes can be delayed, aggregated, eliminated.
• This results in less communication and therefore
  higher performance.

w(x) w(y) w(x)
A
B
4
Software Distributed Shared Memory
page based, permissions, single system
image, shared virtual address space,
5
False Sharing

• False sharing is a situation in which two or
  more processes access different variables within
  a page and at least one of the accesses is a
  write.
• If only one process is allowed to write to a page
  at a time, false sharing leads to unnecessary
  communication, called the ping-pong effect.

6
Understanding False Sharing
x
w(x) w(x) w(x)
A
y
p
p
p
p
p
p
B
r(y) r(y) r(y)
x
w(x) w(x) w(x)
A
y
page p1
B
page p2
r(y) r(y) r(y)
7
False Sharing in Relaxed Consistency Schemes

• False sharing has much smaller overhead in
  relaxed consistency models.
• The overhead induced by false sharing can be
  further reduced by the the usage of
  multiple-writer protocols.
• Multiple-writer protocols allow multiple
  processes to simultaneously modify their local
  copy of a shared page.
• The modifications are merged at certain points of
  execution.

8
Release ConsistencyGharachorloo et al. 1990,
DASH

• Introduces a special type of variables, called
  synchronization variables or locks.
• Locks cannot be read or written to. They can be
  acquired and released. For a lock L those
  operations are denoted by acquire(L) and
  release(L) respectively
• We will say that a process that acquired a lock L
  but has not released it, holds the lock L.
• No more than one process can hold a lock L. One
  process holds the lock while others wait.

9
Using Release and Acquire to define
execution-flow synchronization primitives

• Let a set of processes release tokens by reaching
  the operation release in their program order.
• Let another set (possibly with overlap) acquire
  those tokens by performing acquire operation,
  where acquire can proceed only when all tokens
  have already arrived from all releasing
  processes.
• 2-way synchronization lock-unlock, 1 release, 1
  acquire
• n-way synchronization barrier, n releases, n
  acquires
• PARCs synch k-way synchronization

10
Model of Atomicity

• A read by Pi is considered performed with respect
  to process Pk at a point in time when the issuing
  of a write to the same address by Pk can not
  affect the value returned by the read.
• A write by Pi is considered performed with
  respect to process Pk at a point in time when an
  issued read to the same address by Pk returns the
  value defined by this write (or a later value).
• An access is performed when it is performed with
  respect to all processes.
• An acquire(L)by Pi is performed when Pi receives
  exclusive ownership of L (before any other
  requester).
• A release(L)by Pi is performed when Pi gives away
  its exclusive ownership of L.

11
Formal Definition of Release Consistency

• Conditions for Release Consistency
• Before a read or write access is allowed to
  perform with respect to any other process, all
  previous acquire accesses must be performed, and
• Before a release access is allowed to perform
  with respect to any other process, all previous
  read or write accesses must be performed, and
• acquire and release accesses are sequentially
  consistent.

12
Understanding RC
From this point all processes must see the value
1 in X
It is undefined what value is read here. It can
be any value written by some process. Here it can
be 0 or 1.
1 must be read according to rule (B), but the
programmer can not be sure of it
Programmer is sure that this will return 1
according to rules (C) and (A)
13
Acquire and Release

• release serves as a memory-synch operation, or a
  flush of the local modifications to the attention
  of all other processes.
• According to the definition, the acquire and
  release operations are not only used for
  synchronization of execution, but also for
  synchronization of memory, i.e. for propagation
  of writes from/to other processes.
• This allows to overlap the two expensive kinds of
  synchronization.
• This turns out also simpler on the programmer
  from semantic point of view.

14
Acquire and Release (cont.)

• A release followed by an acquire of the same lock
  guarantees to the programmer that all writes
  previous to the release will be seen by all reads
  following the acquire.
• The idea is to let the programmer decide which
  blocks of operations need be synchronized, and
  put them between matching pair of acquire-release
  operations.
• In the absence of release/acquire pairs, there is
  no assurance that modifications will ever
  propagate between processes.

15
Consistency of synchronization operations

• Note the relations of the release/acquire
  operations to themselves also define an
  independent memory consistency scheme.
• The rule (C) defined it to be Sequential
  Consistency.
• There are other flavors of RC in which the
  consistency of synchronization operations defined
  to be some consistency x (e.g., Coherence). Such
  a memory model is denoted by RCx.
• RCx is weaker than RCy if x is weaker than y.
• For simplicity, we deal only with RCsc.

16
Happened-Before relation induced by
acquire/release

• Redefine the happened-before relation using
  acquire and release instead of receive and send
  respectively.
• We say that event e happened before event e (and
  denote it by e ? e or e lt e) if one of the
  following properties holds

Processor Order e precedes e in the same
process Release-Acquire e is a release and e is
the following acquire of the same
lock Transitivity exists e s.t. e lt e and
elt e
17
Happened-Before relation induced by
acquire/release (cont.)
A
B
acq(L1)
C
rel(L2)
acq(L2)
18
Competing Accesses

• Two memory accesses are not synchronized if they
  are independent events according to the
  previously defined happened-before relationship.
• Two memory accesses are conflicting if they are
  accesses to the same memory location, and at
  least one of them is a write.
• Conflicting accesses are said to be competing if
  there exists an execution in which they are not
  synchronized.
• Competing accesses form a race condition as they
  may be executed concurrently.

19
Data Races in RC

• Release Consistency does not guarantee anything
  about propagation of updates without
  synchronization. Example

Initially grades oldDatabase updated false

Thread T.A.
grades newDatabase updated true
Thread Lecturer
while (updated false) Xgrades.gradeOf(lectu
rersSon)

• If the modification of variable updated is passed
  to Lecturer, while the modification of grades is
  not, then Lecturer looks at the old database!
• This is possible in Release Consistency, but not
  in Sequential Consistency.

20
Expressiveness of Release ConsistencyGharachorlo
o et.al 1990

• Let a properly-labeled (PL) program be such that
  has no
• competing accesses.
• Theorem RCsc SC for PL programs.
• Should make sure there are no data-races.

21
Implementing RC

• The first implementation was proposed by the
  inventors of RC and is called DASH.
• DASH combats memory latency by pipelining writes
  to shared memory.

• The processor is stalled only when executing a
  release, at which time it must wait for all its
  previous writes to perform.

22
Implementing RC (cont.)

• It is important to reduce the number of messages
  exchanges, because every message has additional
  fixed overhead, independent of its size.
• Another implementation of RC, called Munin
  reduces the number of messages by buffering
  writes until a release.

23
Eager Release ConsistencyCarter et al. 1991,
Munin

• Implementation of Release Consistency (not a new
  memory model).
• Postpone sending modifications to the next
  release.
• Upon a release send all accumulated modifications
  to all caching processes.
• No memory-synchronization operations on an
  acquire.
• Upon a miss (no local caching of the variable)
  get latest modification from latest modifier
  (need some more control to store its identity, no
  big deal).

24
Understanding ERC
apply changes
apply changes
r(z)1
r(y)1
A
acq(L1)
z
x,y
apply changes
w(x)1
w(y)1
r(z)1
B
rel(L1)
x,y
z
w(z)1
acq(L2)
C
rel(L2)
apply changes

• Release operation does not complete (is not
  performed) until the acknowledgements from all
  the processes are received.

25
Supporting Multiple Writers in ERC

• Modifications are detected by twinning.
• When writing to unmodified page, its twin is
  created.
• When releasing, the final copy of a page is
  compared to its twin.
• The resulting difference is called a diff.
• Twinning and diffing not only allow multiple
  writers, but also reduce communication.
• Sending a diff is cheaper than sending an entire
  page.

26
Twinning and Diffing
27
Update-based vs. Invalidate-based

• In update-based protocols the modifications are
  sent whereas in invalidate-based protocol only
  notifications of modifications are sent.

Update-based
Invalidate-based
rel(L)
rel(L)
P1
P1
x1
I changed x and y
y2
P2
P2
28
Update-Based vs. Invalidate-Based (cont.)

• Invalidations are smaller than the updates.
• The bigger the coherency unit the bigger is the
  difference.
• In invalidation-based schemes there can be
  significant overhead due to access misses.

rel(L)
P1
inv(x)
get(x)
x1
y2
get(y)
inv(y)
acq(L)
P2
r(y)
r(x)
29
Reducing the Number of Messages

• In DASH and Munin systems all processes (or all
  processes that cache the page) see the updates of
  a process.
• Consider the following example of execution in
  Munin

w(x)
rel(L)
P1
w(x)
acq(L)
rel(L)
P2
w(x)
acq(L)
rel(L)
P3
r(x)
acq(L)
P4

• There are many unneeded messages. In DASH even
  more.
• This problem exists in invalidation-based schemes
  as well.

30
Reducing the Number of Messages (cont.)

• Logically, however it suffices to update each
  processors copy only when it acquires L.

w(x)
rel(L)
P1
w(x)
acq(L)
rel(L)
P2
w(x)
acq(L)
rel(L)
P3
r(x)
acq(L)
P4

• Therefore, a new algorithm, called Lazy Release
  Consistency (LRC) for implementing RC was
  proposed.
• LRC is aimed at reducing both the number of
  messages and the amount of data exchanged.

31
Lazy Release ConsistencyKeleher et al.,
Treadmarks 1992

• The idea is to postpone sending of modifications
  until a remote processor actually needs them.
• Invalidate-based protocol
• The BIG advantage no need to get modifications
  that are irrelevant, because they are already
  masked by newer ones.
• NOTE implements a slightly more relaxed memory
  model than RC!

32
Formal Definition of Lazy Release Consistency

• Conditions for Lazy Release Consistency
• Before a read or write access is allowed to
  perform with respect to any other process, all
  previous acquire accesses must be performed with
  respect to that other process, and
• Before a release access is allowed to perform
  with respect to any other process, all previous
  read or write accesses must be performed with
  respect to that other process, and
• acquire and release accesses are sequentially
  consistent.

33
Understanding the LRC Memory Model
A
B
C

• It is guaranteed that the acquirer of the same
  lock sees the modification that precede the
  release in program order.

34
Understanding the LRC Memory Model Transitivity

• The process C sees the modification of x by A.

35
Implementation of LRC

• Satisfying the happened-before relationship
  between all operations is enough to satisfy LRC.
• Maintenance and usage of such a detailed ordering
  would be expensive.
• Instead, the ordering is applied to process
  intervals.
• Intervals are segments of time in the execution
  of a single process.
• New interval begins each time a process executes
  a synchronization operation.

36
Intervals
P1
P2
P3
37
Happened-before of Intervals

• A happened before partial order is defined
  between intervals.

• An interval i1 precedes an interval i2 according
  to happened-before of intervals, if all accesses
  in i1 precede accesses in i2 according to the
  happened-before of accesses.

38
Vector Timestamps

• An interval is said to be performed at a process
  if all intervals accesses have been performed at
  that process.
• Each process p has vector timestamp Vp that
  tracks which intervals have been performed at
  that process.
• A vector timestamp consists of a set of interval
  indices, one per process in the system.

39
Management of Vector Timestamps

• Vector timestamps are managed like vector clocks.
• send and receive events are replaced by release
  and acquire (of the same lock) respectively.
• A lock grant message (that is sent from releaser
  to acquirer to give acquire the exclusive
  ownership) contains the current timestamp of the
  releaser

1. Just before executing a release or acquire in p
   Vpq Vpq 1
2. A lock grant message m is time-stamped with
   t(m)Vp.
3. Upon acquire for every q Vpq max Vpq,
   t(m)q

40
Vector Timestamps (cont.)

• A process updates its vector timestamp at the end
  of an interval. Therefore during an interval the
  process timestamp does not change.
• We denote the vector timestamp of process p at
  interval i by Vpi.
• The entry for process q ? p is denoted by Vpiq.

• It specifies the most recent interval of process
  q that has been performed at process p.
• Entry Vpip is always equal to i.
• An interval x of process q is said to be covered
  by Vpi if Vpiq ? x

41
Write Notices

• Write notice is an indication that a given page
  has been modified.
• Each process keeps a table of intervals covered
  by it.
• An entry in this table represents an interval. It
  contains a write notice for every page that was
  modified during the segment of time corresponding
  to the interval.
• Write notices are sent in the lock grant message
  along with the vector timestamp of the releaser.

42
Write Notices (cont.)

• It is not necessary to send to acquirer the write
  notices belonging to intervals covered by its
  vector timestamp.
• In order to let releaser know what intervals are
  covered by the acquirer, the acquirer sends the
  release its timestamp inside a lock request
  message.
• When the releaser sends a lock grant message to
  the acquirer, it sends only the write notices
  belonging to interval covered by itself, but not
  covered by the acquirer.
• When the acquirer receives the lock grant
  message, it invalidates all the pages for which a
  write notice is included in the message.

43
Write Notices (cont.)
w(y)
w(x)
acq(L)
rel(L)
A
write notices for intervals not covered by VCB
write notices
generate write notices
request diffs
diffs
lock request
B
acq(L)
r(y)
x,y
invalidate according to write notices
44
Access Misses

• When accessing an invalidated page, all the
  modifications made to it in the intervals that
  happened before the current interval must be
  obtained.
• Note that this is true even if the access is a
  write.
• A process can identify those intervals and the
  processes that performed the modification by the
  write notices it has for the page.
• A write notice is saved along with the id of the
  process from which it was received and its vector
  timestamp.
• How do we merge modifications performed by
  concurrent writers to a page?

45
Tracking Modifications with Multiple Writers

• It is possible that several processes make
  modifications to different variables at the same
  page.

• If the intervals in which the modifications are
  performed are independent (according to
  happened-before), we cannot just bring a page
  from one of the processes.
• What should we do? Employ the twinning and
  diffing technique again!

46
Twinning and Diffing (reminder)
47
Tracking Modifications with Multiple Writers
(cont.)
P1
inv(P)
page P
acq(L1)
r(x)
P2
x
y
inv(P)
P3
rel(L2)

• Note that twinning and diffing not only allows
  multiple independent writers but also
  significantly reduces the amount of data sent.

48
Access Misses (cont.)

• Consider the following scenario, in which P3 has
  a miss on a page containing variables x, y and z

w(x)
rel
P1
inv(x)
w(y)
acq
rel
P2
inv(x,y)
r(z)
mod(x,y)
acq
P3

• When accessing z, P3 sees that according to the
  locally stored write notices there has been two
  previous modifications.
• They are ordered by happened before relationship
  therefore P3 can request both modifications from
  P2.

49
Access Misses (cont.)

• More generally, if processor q modified page P at
  its interval x, then q is guaranteed to have any
  diffs of P created intervals that
  happened-before the interval x.
• Therefore even if diffs from multiple writers
  need to be retrieved, it is usually only
  necessary to communicate with very few
  processors.
• How long should a process keep the diffs ?
• How long should a process keep the write notices
  ?
• Clearly, not forever! A garbage collection needs
  to be done

50
Garbage Collection

• A diff needs to be retained until it is clear it
  will never be requested.
• This happens when a diff has already been sent to
  every processor.
• When a process sees it is running out of memory
  it initiates garbage collection, which is invoked
  at the next barrier.
• Garbage collection piggybacks on the barrier to
  stop the world. Each process receives all write
  notices in the system and uses them to validate
  all of its cached pages. As a result, all write
  notices and diffs are discarded.

51
Lazy Diffing

• Dont diff on every release do it only if
  theres communication with another node.
• Delay generation of a diff until somebody asks
  for the lock.
• When passing a lock token, send write notices for
  modified pages, but leave pages write-enabled.
• If somebody asks for diff, diff and mark clean.
• Diff may include updates from later intervals
  (e.g., under the scope of other locks).
• Must also generate diff if a write notice
  arrives.
• Must invalidate the page but keep modifications.

52
LRC with Lazy Diffing
diff
w(x)
P1
make twin
acq(L)
P2
r(x)
53
Benefits of Lazy Diffing

• The gain is considerable.
• The eventual diff may include modifications that
  would have been split over several diffs.
• Lock acquisitions are faster no need to wait
  for diffs.
• Reducing the number of diffs reduces overall
  amount of transmitted data.

54
Drawbacks of Traditional LRC

• At access miss a node may have to obtain the
  diffs from several nodes.
• This happens when there is a substantial
  write-write false sharing.
• The same diff may be applied many times.
• Once at each node that fetches the diff
• The need to save all diffs seen by a node
  significantly increases memory consumption.
• A node that creates a diff needs to store it
  locally.
• A node stores diffs it fetched from other nodes.
• Garbage collection is an expensive global
  operation.

55
Home-based Lazy Release Consistency

• HLRC is a simple home-based multiple-writer
  protocol that implements LRC
• Each page has a designated node, called the home
  node of the page, which contains its master copy.
• Diffs are computed at lock transfer time, sent to
  the home nodes of the corresponding pages, and
  then discarded.
• On access miss (read or write) an entire page is
  fetched from home.
• HLRC solves the mentioned drawbacks of LRC.

56
Understanding HLRC

• Assume x is a variable on a page p whose home is
  P3

diff
w(x)
P1
make twin
acq(L)
r(x)
P2
p
P3

• What happens if P2 tries to fetch p before the
  diff arrives to P3?

57
Guaranteeing Update Completion Before a Fetch

• There are several techniques to ensure that the
  homes copy of a page contains the required
  updates.
• Write flushing
• Page versions (scalar timestamps)
• Vector timestamps
• All the techniques require that the network
  delivers the messages in the order that they are
  sent.

58
Write Flushing

• The simplest approach.
• Delay the completion of the release events until
  all the updates are propagated to the
  corresponding home are completed
• The completion is ensured by having home
  acknowledge the receipt of diffs.

59
Write Flushing (cont.)
diff
w(x)
P1
make twin
acq(L)
r(x)
P2
p
P3
apply diff

• There are two drawbacks
• Latency increases due to the need to wait for the
  completion of update operation.
• Page prefetching a page fetched from home may
  contain more recent updates than the ones
  required by LRC.

60
Page prefetching
diff
P1
diff
P2
w(y)
rel(L2)
?(x)
?(y)
inv(p)
P3
p
p
apply diff
apply diff
acq(L1)
r(x)
r(y)
P4
inv(p)
inv(p)
acq(L2)
P5
No need to bring p again
61
Page Versions

• A version number is attached to each page.
• Page version number is incremented at home
  whenever the home receives the update performed
  by a non-home writer within an interval.
• The home sends the page version either in reply
  to a diff message, or in reply to a fetch request
  along with the page itself.
• The page version numbers are included in the
  write notices.
• A local page is not invalidated if the local page
  version is greater than or equal to the required
  page version included in the write notice.

62
Page Versions (cont.)
diff
p is not invalidated, because the version of the
local copy is 2
P1
diff
2
P2
w(y)
rel(L2)
?(x)
?(y)
inv(p,2)
1
P3
(p,2)
apply diff
apply diff
acq(L1)
r(x)
r(y)
P4
inv(p,1)
inv(p,1)
acq(L2)
P5

• Using page versions avoid unnecessary
  invalidations, but still require waiting for
  updates to complete at home.

63
Vector Timestamps

• Vector timestamps represent page versions, but
  avoid the need to wait for completion of updates.
• The lock can be transferred immediately, because
  the vector timestamp representing the new page
  version can be calculated without cooperation of
  home.
• The prefetching is detected in same way it is
  detected with scalar page versions.

64
Vector Timestamps (cont.)

• A vector timestamp is attached to a valid page
  and indicates the current version of the page.
• Such timestamp is called flush timestamp.
• At home, flush timestamps are updated each time
  updates corresponding to a remote interval are
  performed.
• At non-home node, flush timestamp are updated
  either
• at the end of intervals during which the page was
  written, or
• when the page is fetched from home.

65
Vector Timestamps (cont.)

• A vector timestamp is attached to an invalid page
  and indicates the page version that the node has
  to fetch from home.
• Such timestamp is called lock timestamp.
• Lock timestamp is updated at acquire time as a
  result of applying the write notices received
  from the last releaser.
• The lock timestamp is presented to the home as a
  part of a fetch request.
• The home delays answering a fetch request if the
  required version is not available (because the
  corresponding updates are not completed).

66
Vector Timestamps (cont.)
p is not invalidated
diff
P1
?(x)
diff
inv(p,)
P2
w(y)
rel(L2)
?(y)
apply diff
P3
(p,)
apply diff
acq(L1)
r(x)
r(y)
P4
inv(p,)
inv(p,)
acq(L2)
P5
read is delayed until the home node P3 applies
the diff from P1
67
Invalidation of a modified page

• There are situations that require that a modified
  page is invalidated. Example

A and B write to two different locations of the
page P (no data race)
w(P)
acq(L)
rel(L)
A
inv(P)
B
acq(L)
w(P)

• After invalidating P at acquire, B cannot discard
  the local copy of P, because it contains Bs
  recent modifications.

68
Invalidation of a modified page (2)

• What happens when B fetches P from its home? (Let
  C be the home of P)

How do we merge Bs local copy with the fetched
one?
acq(L)
rel(L)
w(P)
A
inv(P)
diff(P)
r(P)
B
acq(L)
w(P)
P
C

• Bs local copy is combined with the new one by
  two-way diffing.

69
Two-way diffing

• Let Pold be the modified invalidated copy and let
  Told be its twin.
• Let Pfetched be the fetched copy.
• The new local copy Pnew is calculated by applying
  modification in Pold to Pnew
• Pnew Pfetched Pold ? Told
• In addition, the twin of P is replaced by
  Pfetched
• Tnew Pfetched
• Therefore, the next time the diff of P is
  calculated, both old and new modifications are
  detected.
