ION ACCUMULATION IN LEIR

1
ION ACCUMULATION IN LEIR
Presented by M. CHANEL
ECOOL2001-Bad Honef
2
CONTENTS

• LEAD on LEAD
• General view
• Linac3
• Injection
• Cooling
• Lattice and machine elements
• Vacuum
• PS and further
• Other ions
• Planning
• Summary

3
GENERAL SCHEME
4
Performance needed

• 7 107 Lead ions/bunch in LHC at 2.7 TeV/n in a
  normalised emittance of 1.5 mm(bg s2/b). ( quench
  limit and central detector limit)
• Overall transfer efficiency of 30,
• elt1.2 mm at the exit of SPS,
• elt1 mm at the entrance of SPS after final
  stripping,
• elt0.7 mm at the entrance of PS.
• This means 4 bunches in Leir with 2.3 108
  ions/bunch. Or a total of 0.9 109 ions in 1, 2
  or 4 bunches?

5
(No Transcript)
6
Stacking tests of lead ions
requested
Sourceefficiency
Lossescharge state
7
LINAC3

• Improved afterglow pulsed ECR source (450ms pulse
  length but increased current from 100mA to 300mA
  Lead 27 Leir uses 200 ms max).
• Accelerate to 4.2 MeV/n, b0.0945
• Add a cavity to ramp momentum by 1
• Stripping afterwards and use of Lead 54 (main
  contents Lead53 but too much recombination rate
  with electrons of e-cooler )
• Pulsing from up to 10Hz.

Collaboration Catania, Grenobles, Cern, GSI
8
LEIR

• Combined H/V/P multiturn injection inclined
  septum momentum variation of incoming beam such
  the injection orbit (D dp/pbump) remains the
  same during injection. 50 injection efficiency
  reachable.
• Cool and stack the freshly injected beam by
  electron cooling in 400 ms max.
• 4 injection-cooling-stacking cycles should be
  enough.
• Acceleration and ejection (h2) at T71MeV/n
  energy choice is a compromise between the limit
  of incoherent tune shift in PS, the time between
  bunches for ejection kicker and stacking time in
  SPS/LHC.

9
LEIR Injection

• Combined injection gives lower et (better cooling
  time) compared to normal multiturn but increases
  mom. spread (good long. cool.).
• Combined injection implies large D and D/??5
  (D10, b3).

10
X-Y plane105 turns tracked
Cooled beam
E-SEPTUM
New beam from linac D0
11

• X-Y plane after 100 turns
• 75 injected

• x and y and momentum projected distributions

12
Cooling and Stacking

• Electron cooling theory gives

• where q is the relative difference in angle
  between the ions and electrons qi?(?/?)
• the parameter hecool Lcooler/Lmachine
• and Ie is the electron current.
• A and Q atom mass and charge state

• Large b desirable but ion beam size should remain
  smaller then e-beam size mind to e-beam space
  charge.optimum around b5m

13
Lattice

• Good for injection and coolingstill 2 periods
• tune(1.8,2.7)
• longitudinal acceptance reduced to dp/p 1
• 5 quad families, more flexible.

14
Electron cooling
15
(No Transcript)
16
GUN
Dipole
Toroïd
DRIFT
17
(No Transcript)
18
(No Transcript)
19
LEIR cycle for LEAD ions
20
(No Transcript)
21
OTHERS

• With an electron beam of 200mA, the cooling rate
  is sufficient to counteract the IBS growth rate
  and get the emittances wanted.
• The beam will be maintained stable mainly during
  cooling(coasting beam) by a 100MHz bandwidth
  transverse active feedback.

22
A word on vacuum

• During the tests in 1997, the Lear vacuum was
  good (5E-12T without beam) but the lost lead
  ions (e-ion recombination..lead 54 or res. gas
  charge exchange or..) degas the chamber walls.
  One lead ion releases 105 molecules!!!!
• At end of linac3, tests of different vacuum
  chamber treatment are under way.
• Hope outgassing can be reduced by appropriate
  treatment of the vacuum chamber.
• Already known when ions are lost perpendicularly
  to walls, outgassing is decreased.

23
(No Transcript)
24
PS(preliminary)

• Inject (change/modif. septum-kicker) and
  accelerate on h16 up to T1.5 GeV/n
• h16?14?10 , split 2b. to 4 bunches and finally
  h20 ?17
• h17 is chosen to have 125ns b. separation at
  flatop in LHC and it is compatible at 4.25GeV/n
  with 200MHz RF system in SPS.
• Acceleration to 4.25 GeV/u, cp/Q19.7 GeV/charge.
• Stripping in TT2. Change of TT2 line to have a
  low beta at stripper.

25
TT2(from PS to SPS)

• At stripper bh,v20m?5m, D-1m
• Blow-up reduced by a factor 4 compared to
  old(normal)optic.needs MD for SPS matching.
  De0.2mm after re-matching in SPS?.
• Need of 4 quad, 6 power supplies building?.

26
Other ions
27
Planning
28
Summary

• Accumulation schemes for different kind of ions
  are well advanced
• Electron cooling of heavy ions is defined.
• Space charge limits both in LEAR and PS together
  with cooling/filling time are the main
  limitations especially for light ions.
• Vacuum degradation due to losses is a challenge .
• IBS and conservation of high beam density is
  another challenge.
• Blow-up due to stripping improved in TT2
• Planning established.
• All technical systems are being specified.

29
PSB-PS?

• PSB for light ions(He,O,Ar?) with a source of
  1mAe, cp/Q310 MeV/c/ch ?15, 3-4turns injection
  it could be possible even using the 4 rings(
  change filling scheme in LHC???)
