Programming Language Concepts

1
Programming Language Concepts

• Dr. Cong Xing
• Dept of Math Computer Science

2

• Ch1 Preliminaries

3
Reasons for Studying Concepts of PL

• To increase capacity to express ideas

Express ideas/alg
Knowing more PL concepts
Enrich thoughts
4

• To improve background for choosing appropriate
  languages

project
programmer
available PLs
his favorable PLs
5

• To increase ability to learn new languages

Java
programmer
Formal concepts of OO
6

• To better understand the significance of
  implementation

implementation
Efficient programming
Lang concepts (eg, recursion, iteration)
7

• To achieve overall advancement of computing

Current situation
Most popular lang
Best lang available
?
Decision maker learning PL concepts
how?
wanted
Best lang available
Most popular lang

8
Programming Domains

• Brief descriptions of CS applications and their
  associated languages.

9
(No Transcript)
10
Language Evaluation Criteria

• Readability
• The ease w/ which programs can be read and
  understood
• Affected by the following
• Simplicity as simple as possible but not simpler
  (in the sense of of instructions wrt CISC and
  RISC)
• Orthogonality algebraic properties (e.g., if int
  int is a type, then so are intbool and
  (intint)int)
• Control structures loops, selections, etc

11

• Data types and structures facility to define new
  data types
• Syntactic form wording
• Writability
• The ease w/ which to create programs
• Affected by the following
• All that affects readability
• Support for abstraction what is an abstraction?
  Ways to define and use complicated structures so
  that details (of these structures) can be ignored
  when used.

12

• Expressivity means to specify computations.
  (tradeoff with readability)
• Reliability
• Whether a program performs to its specifications
  under all circumstances
• Affected by the following
• All that affects writability
• Type checking check for typing errors
• Exception handling detect run-time errors, fix
  them, and keep on going

13

• Aliasing two or more ways to access the same
  memory cell (dangerous or convenient?)

14
Influences on Language Design

• Computer architecture (hardware)

Imperative programming style
15

• Programming Methodologies (software)
• structured programming
• ADT
• Object-Oriented
• Component-based
• Aspect-oriented

Appropriate Language constructs
16
Language Categories
17
Language Design Trade-offs

• Many language features are conflict
• Need some compromises
• Examples
• Reliability vs. speed of execution (e.g. type
  checking)
• Expressivity vs. readability
• Reliability vs. writability (e.g., pointers)

18
Language Implementation

• Compilation
• Source code is translated (eventually) to machine
  code
• Fig in the next page
• Advantage fast, efficient execution
• Disadvantage implementation complexity

19
(No Transcript)
20

• Pure Interpretation
• Programs (statements) are interpreted and
  executed one after another by the interpreter.
  The interpreter serves as a virtual machine.
• Fig in the next page
• Advantage easy implementation
• Disadvantage slow execution bottleneck same
  statement repeatedly decoded

21
(No Transcript)
22

• Hybrid Systems
• Combination of compilation and pure
  interpretation
• Programs are compiled into some intermediate
  codes which are then interpreted
• Fig next page

23
(No Transcript)
24

• Ex Java

Java prog
compiled
Intermediate code
Byte code
Why Java multiplatform?
interpreter
JVM
result
25

• Advantage hybrid advantages from compilation and
  interpretation
• Disadvantage hybrid disadvantages from
  compilation and interpretation

26

• Ch2 Evolution of the Major PLs

27
Overview
28
Plankalkul

• Developed in 1945, known in 1972
• Konrad Zuse
• A calculus, never been implemented
• Could significantly impact PL designs
• Has data types, loop, selection, arrarys, and
  record constructs

29
Pseudocodes

• (machine code)
• Tedious and error-prone
• Difficult to modify b/c absolute addressing
• Short code (to overcome )
• First language beyond machine code
• Representation of math expressions by (fixed)
  numerals
• E.g. 07 -- 01 -- - 06 -- abs val

30

• Speedingcoding
• John Backus
• Pseudoinstructions for IBM 701

31
Fortran (on IBM 704)

• Fortran the 1st compiled high-level PL
• People John Backus
• Timeline
• Fortran 0 1954
• Fortran I 1957
• Fortran II 1958
• Fortran IV 1966
• Fortran 77 1978
• Fortran 90 1992
• Fortran 95 -- 1997

32

• Evaluation
• Success cannot be overstated
• It dramatically changed forever the way computers
  are used
• All subsequent PLs owe a debt to Fortran

33
Functional Programming LISP

• First functional PL
• John McCarthy at MIT in late 1950s
• Some features of LISP
• Everything is in the form of a list. E.g.
• (A B C D)
• Computations carried out by function applications
• Unlike imperative PLs, variables, assignment
  statements, loops are not necessary

34

• Related languages
• Scheme dialect of LISP, 1970s
• COMMON LISP dialect of (pure) LISP, 1980s
• ML functional PL w/ imperative features, static
  type inference, early 1980s
• Haskell pure functional PL, lazy evaluation,
  late 1980s

35
ALGOL 60

• Team work ACM GAMM (a German group)
• People John Backus, Peter Naur
• Cooperation of American and European computer
  scientists
• Intense arguments (e.g. 56.32 or 56,32)
• (e.g. Var experssion or
• experssion var )

36

• Some Americans welcomed ALGOL, others rejected it
• Limited success
• The dominant language to formally describe
  algorithms
• Difficult to understand and implement
• BNF (Backus-Naur Form) was introduced to describe
  ALGOL

37
(No Transcript)
38
COBOL

• First language design for computerizing business
• People Grace Hopper
• Has been extensively used
• Has little impact on subsequent languages (unlike
  ALGOL)
• Sponsored and pushed by DoD (1960s)

39
BASIC

• Designed by J. Kemeny and T. Kurtz at Dartmouth
  in 1964
• Easy to learn, easy to use, with limited
  capacity, well-suited for beginners
• Influenced QBASIC and Visual BASIC

40
PL/I

• Attempt to design one language that can replace
  all (existing) languages
• Designed at IBM in 1960s
• Ambitious motivation
• Failure (people dont like it, e.g. Dijkstra)

41
SIMULA 67

• Designed by K. Nygaard and O-J. Dahl in 1960s
  (Norwegian)
• Extension of ALGOL 60
• The father of OOPL

42
ALGOL 68

• Extension of ALGOL 60
• Two new features
• Orthogonality introduced in ALGOL 68 design
  (user-defined data type) that has been carried
  over to other languages
• Dynamic arrays (subscript range not determined
  statically)

43
Some Descendants of the ALGOLs

• Pascal
• Designed by Niklaus Wirth in 1970s
• Simple and elegant
• Enjoyed high reputation as a teaching language
• Arguable (not) many new features

44

• C
• Designed by Dennis Ritchie at Bell Labs in 1970s
• A system PL
• Unix
• Wide range of applications

45

• Perl
• Scripting language
• Designed by Larry Wall in 1980
• Similar to an imperative language
• Combination of sh and awk (two other scripting
  languages)
• Was used as a Unix system admin tool
• Found applications in Web programming

46
Prolog

• (The only) logic PL
• Designed by A. Colmerauer, P. Roussel and R.
  Kowalski in 1970s
• Computation is non-procedural dont state how to
  compute the result, rather, state the form of
  result.
• Foundation predicate calculus/logic

47
Ada

• Largest team work in programming history (1980s)
• Sponsored by DoD
• Supports data abstraction, exception handling,
  generic procedure, concurrent programming
• Pros enclosing state-of-the-art SE concepts.
• Cons too large and complex

48
Smalltalk

• Pioneer in OOP
• Most OOP terminologies originate in Smalltalk
• Alan Kay (1960s Ph.D. dissertation)
• Not only a language but also an programming
  environment
• Impacts windowing and OOP

49
C

• Integrating OOP features into C
• Designed by B. Stroustrup at Bell Labs in 1980s
• Enjoyed high popularity in industries and
  academia.
• Downward compatible to C
• Hybrid language (PO and OO)

50
Java

• James Gosling in 1990s
• Initially developed for real-time consumer
  electronic devices
• Lucky to meet the booming of WWW
• Used for Web programming in early phases
• Multiplatform
• rapid growth

51
JavaScript, PHP, and Python

• JavaScript
• Scripting language
• Developed by Netscape Sun in 1990s
• Html-embedded
• Create dynamic html document
• Browser has JavaScript interpreter

52

• lthtmlgt
• ltheadgtlttitlegt ex lt/titlegt
• lt/headgt
• ltbodygt
• ltscript type "text/javascript"gt
• lt!--
• var intList new Array(99)
• var listLen, counter, sum0 result0
• listLen prompt("type the length of the
  list","")
• if ((listLen gt 0) (listLen lt 100))
• for (counter 0 counter lt listLen counter)
• intListcounter prompt("type next
  number", "")
• sum sum parseInt(intListcounter)

53

• average sum/listLen
• for (counter0 counter lt listLen counter)
• if (intListcountergtaverage)
• result
• document.write("number is", result, "ltbr /gt")
• else
• document.write("illege list length ltbr /gt")
• // --gt
• lt/scriptgt
• lt/bodygt
• lt/htmlgt

54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57

• PHP
• Developed by R. Lerdorf in 1990s
• Scripting language
• Html-embedded
• Facilitate form processing
• Server-side
• Web server has PHP interpreter

58

• Python
• Guido van Rossum in 1990s
• Scripting language
• OO
• System admin, CGI, form processing

59
C

• state-of-the-art PL
• Microsoft, A. Heijsberg, 2002
• Based on Java and C
• Part of MS .NET framework
• Support component-based programming
• Success or failure (well see)

60

• Ch15 Functional Programming

61
Introduction

• Imperative programming base von Neumann
  architecture computer
• Functional programming base math functions
• Which one is superior?
• Pure functional programming has no side effects

62

• E.g. imperative

Obj a
a
x1
a.xlt2
X2
Functional
Obj a
Obj b
x2
x1
a.xlt2
63
Functions

• (normal) math notation f(x) x1
• Lambda-notation ?x.x1
• Math notation has gives a name to a function
  whereas lambda notation does not.
• Higher-order functions functions that take a
  function as argument and/or returns a function as
  the result

64

• E.g. function composition
• fcomp(f, g) g f
• Questions how can we do this w/ imperative
  programming?

65
Features of Functional Programming

• All computations are carried out by function
  applications
• No side effects (for pure functional
  programming)(no need for variables and assignment
  statements)
• Cannot be replaced by functions in imperative
  languages

66
Features of Imperative Programming

• Fine processing. Computation consists of many
  individual movements and computations of small
  items of data
• Programming by side-effect. Computation proceeds
  by continually changing the state of the
  machine the values stored in memory locations
  by assignments.
• Iteration is the predominant control structure.
  Procedures, esp. recursive procedures, take a
  back seat

67

• The language structures, both data and control,
  are fairly close to the underlying (real)
  computer architecture.
• Ex goto --- unconditional jump
• array --- consecutive blocks of memory
• pointer --- memory location address
• assignment --- data movement
• variable --- memory cell

68
Foundations of Functional Programming Lambda
Calculus

• Introduced by Church in the 1930s to study the
  computations w/ functions
• Basis of functional programming
• Syntax
• M x M1M2 ?x.M
• M term, x variable, M1M2 application,
  ?x.M abstraction

69

• Ex1 x, xx, ?x.x, ?x.(?y.xy) (pure)
• Ex2 ?x.(x1), ?y.(yy2) (extended)
• Substitution N/xM means the result of
  replacing all occurrences of x in M by N
• Reductions
• a axiom ?x.M ?z.z/xM (z not in M)
• ß reduction (?x.M)N N/xM

70

• Examples
• M/xx M
• u/xxx uu
• u/xxy uy
• ?x.x ?y.y/xx ?y.y ?z.z
• (?x.x)/xx ?x.x
• M/x y y
• u/x ?y.y ?y.y
• Note application groups from left to right so
• MNP abbreviates (MN)P

71

• u/x(?u.x) u/x(?z.x) ?z.u
• (?x.x1)1 1/x(x1) 11 2
• ?x. ?y. ?z.(xz)(yz)(?x.x)(?x.x)
• (?y.?z.((?x.x)z)(yz))(?x.x)
• (?y.?z.(z)(yz))(?x.x)
• ?z.z((?x.x)z)
• ?z.zz

72

• ?x. ?y. ?z.(xz)(yz)(?x.x)(?x.x)
• (?y.?z.((?x.x)z)(yz))(?x.x)
• ?z. ((?x.x)z) ((?x.x)z)
• ?z. zz
• note two computations have different order but
  have the same result. ltdiamond propertygt

73

• Non-terminating reductions
• ex1 (?x.xx)(?x.xx)
• (?x.xx)(?x.xx)
• .
• Def if f(x)x, then x is called a fix point
  of f
• ex2 let Y ?f. (?x.f(xx)) (?x.f(xx))

74

• then, Yf (?x.f(xx)) (?x.f(xx))
• f((?x.f(xx)) (?x.f(xx)))
• f (Yf)
• so, Yf is a fix point of f. Y is called the
  fix
• point operator of f.

75

• Evaluation strategies
• Call-by-value (eager evaluation) leftmost,
  innermost
• Call-by-name (lazy evaluation) leftmost, outmost
• Ex (?x.xx)((?y.y) (?z.z))
• (?x.xx)(?z.z)
• (?z.z)(?z.z)
• (?z.z) (call-by-value,
  eager eval)

76

• (?x.xx)((?y.y) (?z.z))
• ((?y.y)(?z.z)) ((?y.y)(?z.z))
• (?z.z)((?y.y)(?z.z))
• (?y.y)(?z.z)
• ?z.z (call-by-name, lazy eval)

77

• An applied Lambda Calculus
• M c x M1M2 ?x.M ( c constants)
• c true false if 0 iszero pred
  succ fix
• Ex a term of applied ? calculus is
• ( ( ( if x) y) true )
• which can be abbreviated as
• if x y true

78

• Reduction rules for constants
• if true M N M
• if false M N N
• fix M M(fix M)
• iszero 0 true
• iszero (succk 0) false (k gt1)
• iszero (predk 0) false (k gt 1)

79

• pred(succ M) M
• succ(pred M) M
• Moreover, we can intuitively regard
• 0 ? 0
• succ 0 ? 1
• succ (succ 0) succ2 0 ? 2
• pred 0 ? -1
• pred(pred 0) pred2 0 ? -2

80

• Ex
• (?x. if x 0 (succ 0) ) false
• if false 0 (succ 0)
• succ 0 ( or 1)

81

• Functions with more than one parameters
• Ex f(x,y) x y
• How to code this function in Lambda calculus?
• ?x.?y.(xy) (suppose
  defined)
• f(1,1)2
• ?x.?y.(xy)(1)(1) ?y.(1y)1 112

82

• ML core (ML0) is a syntactically sugared applied
  lambda calculus
• Lambda Cal ML0

83
(No Transcript)
84
Relationship between recursive functions and fix
point

• f(x) .f f recursively defined
• f(x) Mf syntactic hole
• f ?x.Mf writing f in lambda notion
• (?g.?x.g/fM)f
• f Ff f is the fix pt of F,
  where
• F ?g.?x.g/fM

85
f or f(x)

• note f is not the same as f(x)
• what do you mean?
• why?why?why?why?

86

• f is the function (itself)
• f(x) is the element in the codomain to which x is
  mapped under f
• in terms of programming, f(x) is the value
  returned by the function f when x is submitted to
  f

87

• ex A 1,2,3, B 2,3,4
• f is a function from A to B, (and its
  behavior) is specified by
• f(x) x1 x in A
• then,
• f(1) 2, f(2) 3, f(3) 4
• what do they mean?

88

• Can we write out f directly?
• In traditional math?
• In lambda calculus?

89
How to define recursive functions w/o using
function names?

• Fix pt answers the question
• Ex

y if x0
x y
(x-1) (y1) otherwise
is defined recursively (why?) the operation
(recursively) using fix point notation
90

y if iszero x
plus x y
plus (pred x) (succ y) otherwise
Rewriting plus, we have
plus ?xy. if (iszero x) y (plus (pred x) (succ
y)) (?f. ?xy. if (iszero x) y (f (pred
x) (succ y)) ) plus
then plus fix (?f. ?xy. if (iszero x) y (f
(pred x) (succ y)) ) This is the definition of
plus w/o using its name.
91
Introduction to Scheme
Logo of MIT Scheme
http//swiss.csail.mit.edu/projects/scheme/
92

• To start shceme
• Type mzscheme at the Unix prompt.
• (if this does not work, make sure your path
  variable include /usr/local/plt/bin)
• Once scheme is stared, you can load your program
  by typing
• (load filename)

93

• Dialect of Lisp
• Sussman and Steele, 1970s, MIT
• Small size, clean syntax and semantics,
  well-suited for college functional programming
  courses
• Primitive numeric functions
• , -, , /
• ex ( 3 4) ? 7 ( 3 4) ? 12

94

• Define functions
• w/o name ((lambda (x) ( x x)) 4 ) ? 8
• w/ name (define (doubleit x)
• ( x x)
• )
• ( doubleit 4) ? 8
• Boolean values
• t f ( or empty list () )

95

• Selection structures
• (if exp then-exp else-exp )
• Ex (if ( n 0) 1 ( n n) )
• Conditional
• (cond
• (pred1 exp1)
• (pred2 exp2)
• (predn expn)
• (else exp)
• )

96

• (define (f x)
• (cond
• ( ( x 0) (display "zero"))
• ( (lt x 0) (dispaly "neg"))
• ( else (display "pos"))
• )
• )

97

• List manipulations
• car takes a list and returns the head of a list
• cdr takes a list and returns it w/o the head
• Ex (car (a b)) ? a
• (car (a) ) ? a
• ( cdr (a b) ) ? (b)
• cons takes two parameters and returns a list l
  w/ the first parameter being (car l) and the
  second parameter being (cdr l)

98

• Ex ( cons a (a b) ) ? (a a b)
• Some predicates
• eq? checks to see if the two parameters are
  equal
• List? checks to see if the argument is a list
• Null? checks to see if the argument is an empty
  list

99

• Scheme examples
• Given an atom x and a list l, determine if x is
  in l
• (define (member x l)
• (cond
• ( (null? l) f )
• ( (eq? x (car l)) t )
• ( else (member x (cdr l)) )
• ))

100

• Walk it through with
• X1 (1 3 4)
• X1 (a b c)

101

• Determine if l1 and l2 are equal (l1 and l2 do
  not have to be lists)
• (define (equal l1 l2)
• (cond
• ( (not (list? l1)) (eq? l1 l2)
  )
• ( (not (list? l2)) f )
• ( (null? l1) (null? l2) )
• ( (null? l2) f )
• ( (equal (car l1) (car l2))
• (equal (cdr l1) (cdr l2)) )
• ( else f )
• ))

102

• Walk it through with
• L1a, l2 (a b)
• L1 (a b), l2 a
• L1 (), l2 3
• L1 (a b) , l2 ()
• L1 (a b), l2 (a c)
• L1 ((a b), c) , l2 (c d e)
• L1 ((a b) c d), l2 ((a b) c d)

103

• Combine two lists
• (define (app l1 l2)
• (cond
• ( (null? l1) l2)
• ( else (cons (car l1) (app (cdr
  l1) l2)) )
• ))

104

• Walk it through with
• L1 (a) , l2 (b)
• L1 (a), l2 (a b b)
• L1(), l2 (a b)
• L1 (), l2 2 (??)
• L1 1, l2 2 (?????)

105
(No Transcript)
106
(No Transcript)
107

• Find common part of two lists
• (define (comm l1 l2)
• (cond
• ( (null? l1) () )
• ( (member (car l1) l2)
• (cons (car l1) (comm (cdr l1) l2)
  )
• )
• ( else (comm (cdr l1) l2))
• )
• )

108

• Higher-order functions
• How to code composition function?
• (define (comp f g)
• (lambda (x) (f (g x)) )
• )

109

• Ex in math, f(x) x1, g(x) x2
• (f g)(x) f(g(x))
  f(x2) x3
• in particular, (f g)(1)
  4
• In scheme,
• (define (f x)
• ( x 1))
• (define (g x)
• ( x 2))
• ((comp f g) 1) 4

110

• Map-all
• (define (mapall f l)
• (cond
• ( (null? l) () )
• ( else (cons (f (car l))
• (mapall f
  (cdr l)) )
• )
• ))
• mapall takes a function f and a list (x1,, xn)
  and returns (f(x1), , f(xn))

111

• Ex
• if I is the identity function, then
• (mapall I (a b c)) ? (a b c)
• if g(x) x1, then
• (mapall g (1 2)) ? (2 3)

112
ML Essentials

• Why study ML?
• Scheme is not the only one
• Different style
• Its important features
• How to starts ML?
• At Unix prompt, type
• sml ltentergt, or
• sml lt foo, or
• Under the interactive mode,
• - use foo

113

• Expressions
• 12
• Val it 3 int
• Ground types int, real, bool, string, char
• Arithmetic operators , , /, div, , -
• note / -- real division, div int
  division
• -- negative sign

114

• Ex 34 1 4 3 1
• 43 ? 41 ?
• 4 3.0 ? 43.0 ?
• 4.03.0 7.0 4 mod 2 0
• 4.0 mod 2.0 ?
• 2/4 ? 2 div 4 0
• 2.0 / 4.0 0.5 3.04.0 12.0
• Note ML is (very) strongly typed (as opposed to
  Scheme)
• do not mix different types of operands

115
Typings of Languages

• Strongly typed statically typed manifest
  types (e.g. ML)
• Weakly typed dynamically typed latent types
  (e.g., Scheme)

116

• Relational operators
• , lt, gt, lt, gt
• ex 1lt2 ? true
• 3.0 gt 1.0 ? true
• ab lt abc ? true
• 4 gt 3.0 ?

117

• Logical operator not, andalso, orelse
• ex (1gt2) andalso (2gt1) ? false
• Conditional expression
• if E then F else G ? F when Etrue, G
  otherwise
• ex if (11) then 2 else 3 ? 2

118

• Variable bindings (val-declarations)
• val a 1 val b 2 val c ab
• (note variable binding is not assignment
  statement)

119

• Tuples and Lists
• Tuples ex (1, 2) intint
• (1, 2, 3.0) intintreal
• (1, 2, (1, 2))
  intint(intint)
• 1 (1,2) ? 1 int
• val t (1,2,(1,2))
• 3 t ? (1,2) intint

120

• Lists
• 1,2,3 int list
• 1 int list
• a list
• a, ab string list
• Q do items in lists (or tuples) have to be of
  the same type? How is this issue reflected on
  the types of lists (or tuples)?

121

• Operations on lists
• let l a1,a2,,an
• then hd and tl are defined as follows
• hd l a1 tl l a2,,an
• ex
• hd 1,2,3 1 int
• tl 1,2,3 2,3 int list
• hd 5 5 int tl 5 int
  list

122

• Concatenation of list list1 _at_ list2
• Ex
• a,b _at_ c,d
  a,b,c,d
• Cons ele list
• Ex
• 12,3 1,2,3 int list
• 1 1 int list
• 1 a ?

123

• 1 1, 2 1, 1, 2 int
  list list
• 1 2 3
• 1 (2 (3 ))
• 1 (2 3 )
• 1 2, 3
• 1,2,3 int list
• Note is right-associative

124

• Type constructions in ML (recall the
  orthogonality issue in PL design)
• If T1, T2, , Tn are types, then
• T1T2Tn is also a type
• If T is a type, then T list a also a type
• Ex intint, (intint)int, int list,
  intint list
• (intint)int list list

125

• More ex

126
(No Transcript)
127

• Defining functions
• Ex fun sq (x real) xx
• sq real ? real
• (compare it w/ Scheme counterpart)
• (define (sq x)
• ( x x)
• )
• sq 2.0 4.0 sq 3 ?

128

• Ex fun max (a,b,c)
• if agtb then
• if agtc then a
  else c
• else
• if bgtc then b
  else c
• val max fn intintint ? int
• note ML tries its best to infer types. (type
  inference)

129

• fun id x x
• val id fn a ? a
• (a is the type variable in ML)
• fun id (xint) x
• val id fn int ? int

130

• fun reverse L if Lnil then nil else
• reverse(tl L)
  _at_ hd L
• val reverse fn a list ? a
  list
• ex reverse 1,2,3 3,2,1 int list
• we know the following (or do we?)

131

• fun c (n,m) if m0 then 1
• else if mn then 1
• else c(n-1,m)
  c(n-1,m-1)
• Val c fn intint ? int

132

• study the following codes and compare them
• public class T
• static int x 3
• public static int f(int a)
• return ax
• public static void main(String args)
• x10
• System.out.println(f(2))
•
  result is 12

133

• val x 3
• fun f a ax
• val x10
• f 2 ( value of f(2)? )
• val it 5
• x ( value of x? )
• val it 10
• This ex shows the variable diff between fun
  programming and imperative programming.

134

• Pattern matching in ML
• Ex Reversal of lists
• fun rev (nil) nil
• rev (xxs) rev (xs) _at_ x
• What is the type of this function?

135

• Ex merge sort
• fun merge (nil,M) M
• merge (L,nil) L
• merge (L as xxs, M as yys) if xlty
  then
• x
  merge(xs,M)
• else y
  merge(L,ys)
• (what is the type of merge?)

136

• Local defintions
• fun f x
• let
• val y 1 in
• xy
• end
• type of f ?

137

• fun f x
• let
• fun g x x1
• in
• g x
• end
• f simulates g.

138

• Chapter 16 Logic Programming and Prolog

139
Introduction

• Logic programming is declarative rather than
  procedural. I.e., it only specifies what we
  want, not how to do it.
• Logic programming languages are also called
  declarative languages.
• Basis of logic programming propositional and
  predicate calculus (cmps 220)

140
Propositions and Clausal Form

• Proposition?
• statements that are either true or false.
• Ex
• 112,
• There are two Mondays in a week.
• mom(mary, bob)
• greater(1,2)
• What are you saying?

141

• Negation, and , and or
• Clausal Form (standard form, canonical form)
• Ex greater(a,c) ? greater(a,b) greater(b,c)
• like(bob,trout) ? like(bob,fish)
  fish(trout)
• dad(a,b) v mom(a,b) ? parent(a,b)

142
Resolution (theorem proving)

• Resolution is the foundation on which logic
  programming is based
• Resolution is based on the tautology (on what?)
• (p ? q) (q ? r) ? (p ? r)
• or (really?)
• (not p v q) (not q v r) ? not p v r

143

• i.e. not p v q
• not q v r
• ------------- (q and not q
  canceled)
• not p v r
• Proof?
• (not p v q) (not q v r) ? not p v r
• not(not p v q) v not(not q v r) v (not p v
  r)
• (p not q) v (q not r) v (not p v r)
  --- ()

This is a more accessible form
144

• When pT, () reduces to
• not q v (q not r) v r
• (not q v r) v (q not r)
• not(q not r) v (q not r)
• T
• when pF, () reduces to
• F v (q not r) v T
• T
• Hence, () is a tautology.

145

• ex given
• father(a,b) v mother(a,b) ? parent(a,b)
• gfather(a,c) ? father(a,b) father(b,c)
• By resolution, we have,
• mother(a,b) v gfather(a,c) ? parent(a,b)
  father(b,c)
• Justification?

146
.

• not parent(a,b) v father(a,b) v mother(a,b)
• not father(a,b) v not father(b,c) v gfather(a,c)
• --------------------------------------------------
  -----------
• not parent(a,b) v mother(a,b) v not father(b,c) v
  gfather(a,c)
• not (parent(a,b) father(b,c)) v (mother(a,b)
  v gfather(a,c))
• mother(a,b) v gfather(a,c) ? parent(a,b)
  father(b,c)

147
Prolog

• Developed by Colmerauer, Roussel and Kowalski in
  1970s
• Many dialects exist
• Widely used one Edinburgh Prolog (manual on
  website)
• Limited success and use (now)

148

• Conventions
• Variables strings that begin w/ an uppercase
  letter. ex T, S, X, X1, Y2
• Atom strings that begin w/ a lowercase letter.
  Ex mary, bill, apple, tree, dog.
• Values are bound to variables.

149

• Instantiation (of a variable)
• binding of a a value to a variable.
• Facts
• Propositions that are true to the system.
• headless Horn clauses.
• Ex man(bill).
• like(a,b).
• greater(a, b).

150

• Note
• Facts have no intrinsic meanings. They can be
  whatever you want them to be.
• Ex like(a,b) a likes b or b likes a
• greater(a,b) agt b or b gt a

151

• Rules implications in the form of
• B - A1, A2, , An
• (Headed Horn clause)
• Ex ancestor(mary, al) - mom(mary, al).
• dangerous(X) - bigteeth(X).
• greater(X,Z) - greater(X,Y),
  greater(Y,Z).

152

• Goal query submitted to the system.
• Ex ?- man(bill).
• ?- greater(two, three).

153

• How to start Sussex Prolog
• At Unix prompt, type prolog
• prolog
• user.
• type facts, rules, and goal
• Alternatively, prolog ltfilegt

154

• If command line prolog not working, then type
  the following (under bash-shell or Borne-shell)
• usepop/usr/local/poplog/v15.53
• poplocal/usr/local/poplog
• local/usr/local/poplog/local
• export usepop poplocal local
• . usepop/pop/com/poplog.sh
• And then, prolog

155

• Try the following
• ex
• man(bill).
• ?- man(bill).
• yes
• ?- man(mary).
• no

156
Logical Inference

• Reasoning chain
• Forward chaining (starting w/ facts and ruels)

Facts and rules
goal
157

• backward chaining (starting w/ goal)

Facts and rules
goal
158

• Prolog uses backward chaining.
• ex
• father(bob).
• man(X) - father(X).
• ?- man(bob).
• yes

159

• Prolog searches the facts first. No success.
  Then, it uses the rule. So X is instantiated to
  bob and father(bob) must be satisfied. Happily,
  father(bob) is a fact. So the rule is satisfied
  (with X instantiated to bob)

160

• Satisfaction strategy Depth-first or
  breadth-first.
• Depth-first satisfying the first subgoal before
  satisfying the second
• Breadth-first all subgoals are worked on in
  parallel.
• Depth-first used in Prolog.

161

• Ex
• greater(1,2).
• greater(2,3).
• greater(X,Z) - greater(X,Y), greater(Y,Z).
• ?- greater(1,3)
• yes

162

• Using backward chaining, Prolog takes the goal
  and searches the database trying to satisfy the
  goal. Facts will be searched first, no success.
  Rules will be searched next. X and Z are
  instantiated to 1 and 3. Can Y be instantiated
  to some value so that the rule will be satisfied?
  To do that, we need to satisfy the greater(1,Y)
  and greater(Y,3) (two subgoals). Prolog finds 2
  for Y in satisfying greager(1,Y) and this value
  also satisfies greater(Y,3). So Y2. Hence the
  rule is satisfied. (So are we. ?)

163

• Backtracking
• When a subgoal fails, the previous subgoal needs
  to be re-satisfied (by using different facts and
  rules).
• Ex
• color(john,blue).
• color(john,red).
• color(mary,red).
• color(mary,green).
• ?- color(john,X), color(mary,X).
• Xred yes

164

• Ex
• likes(jake, chocolate).
• likes(jake, apricots).
• likes(darcie, licorice).
• likes(darcie, apricots).
• ?- likes(jake, X), likes(darcie, X).
• X apricots

165
which can be graphically regarded as
Xchocolate Xapricots
-----------------
Xapricots
166

• Prolog is from top to bottom and from left to
  right
• Top to bottom the order in which Prolog searches
  the database
• Left to right depth-first subgoal satisfaction
  strategy.

167

• Lists
• Similar to ML
• Ex a,b,c apple, orange, grape
• Head and tail X Y denotes a list where
• X is head, Y is tail
• ex mylist(a,b,c).
• mylist(john, keith).
• ?- mylist(X Y).
• X a Y b,c yes

168

• Ex append two list
• app(, List, List).
• app( Head L1, L2, Head L3 ) -
• app(L1, L2, L3).
• ?- app(a,b,c, x,y, X).
• X a,b,c,x,y
• yes (as shown
  in the box model)

169
call
a,b,c/HL1, x,y/L2, X/HL3
fail
b,c/HL1, x,y/L2, L3/HL3
call
fail
c/HL1, x,y/L2, L3/HL3
call
fail
/, x,y/List, L3/List
call
fail
redo
exit
L3x,y
exit
redo
L3c,x,y
exit
redo
L3b,c,x,y
redo
exit
Xa,b,c,x,y
170

• Ex
• op(,).
• op( Head Tail, List) - op(Tail,
  Res),
• app(Res, Head,
  List).
• ?- op(a,b,c,X).
• What does op do?

171
Problems of Prolog

• Control order
• Lack of need of programmers concern over control
  order of programs is supposed to be one of the
  advantages of logic programming.
• It is not the case with Prolog.
• Prologs order of evaluation is left-to-right(
  depth-first). Consider the following code

172

• ancestor(X,X).
• ancestor(X,Y) - ancestor(Z,Y), parent(X,Z).
• ?- ancestor(a,b).
• It causes an infinite loop (why?). But switching
  the order of the right side of the rule fixes the
  problem (while the meaning and execution of the
  program not supposed to be changed).

173

• Double negation
• Consider the goal
• member(X,m,f,a) ------------- (a)
• Prolog would yield yes with X instantiated to m.
  Logically,
• not(not (member(X,m,f,a))) --------- (b)
• would do the same thing. However, Prologs
  response to (b) is yes with X uninstantiated.

174

• member(X,m,f,a
• yes (success), X -gt m
• not(member(X,m,f,a))
• no (fail), uninstantiate X -gt m
• Not(not(member(X,m,f,a)))
• yes (success), argument failed, X not
  instantiated

175

• Still need algorithmic details
• Sorting example, consider the following sorting
  Prolog code
• sorted(old-l,new-l) - permute(old-l,new-l),

•
  sorted(new-l).
• sorted().
• sorted(X).
• sorted(X,YList) - X lt Y,
  sorted(YList).

176

• The system does not know how to sort, other than
  producing all possible permutations of the list
  until one list matches the specification (sorted
  then). In this case, the Prolog sorting program
  needs to specify sorting details, as is the case
  in imperative and functional programming.

177

• Chapter 3 Syntax and Semantics

178
Syntax

• BNF Grammar
• Backus-Naur Form (BNF) is the standard formal
  method for describing syntax of PLs.
• ltLHSgt ltRHS1gt ltRHSngt
• --- can be replaced by
• ---- or

179

• Terminals and non-terminals
• Non-terminals can be rewritten terminals cannot.
• Ex S A a, A aA b
• where
• S, A are non-terminals a,b are
  terminals

180

• ex grammar of Lambda Calculus
• M x ?x.M MM (untyped)
• M x ?(xa).M MM (typed,
•
  simplified)
• a int a ? a

181

• Ex a BNF grammar
• ltproggt begin lts_listgt end
• lts_listgt ltstmtgt ltstmtgtlts_listgt
• ltstmtgt ltvargt ltexpgt
• ltvargt ABC
• ltexpgt ltvargtltvargt ltvargt-ltvargt ltvargt

182

• A program written in this language is
• begin
• A B
• end
• with leftmost derivation as

183

• ltproggt gt begin lts_listgt end
• gt begin ltstmtgt end
• gt begin ltvargtltexpgt end
• gt begin A ltexpgt end
• gt begin A ltvargt end
• gt begin A B end

184

• Ex a grammar for assignment statement
• ltassgngt ltidgt ltexpgt
• ltidgt A B C
• ltexpgt ltidgt ltexpgt
• ltidgt ltexpgt
• ( ltexpgt ) ltidgt

185

• A sentence (assignment statement) derived from
  this grammar is
• A B(AC)
• ltassgngt gt ltidgt ltexpgt
• gt A ltexpgt
• gt A ltidgt ltexpgt
• gt A Bltexpgt
• gt .
• gt A B(AC)

186

• Its parse tree

187

• Consider A B C A
• What would be its parse tree?

188

• ltassgngt
• ltidgt ltexpgt
• A ltidgt ltexpgt
• B ltidgt
  ltexpgt
• C
  A

189

• Consider A B C A
• What would be its parse tree?

190

• ltassgngt
• ltidgt ltexpgt
• A ltidgt ltexpgt
• B ltidgt
  ltexpgt
• C
  A

191

• Ambiguous Grammars
• A grammar is called ambiguous if a sentence
  produced by this grammar has more than one parse
  trees.
• Note parse trees, not derivations.
• A sentence may have two different derivations but
  one unique parse tree. Ex?

192

• Consider this grammar
• ltassgngt ltidgt ltexpgt
• ltidgt A B C
• ltexpgt ltexpgt ltexpgt
• ltexpgt ltexpgt
• ( ltexpgt )
• ltidgt

193

• What would be the parse tree for
• A B C A ?

194
(No Transcript)
195

• To fix the problem, we need to rewrite the
  grammar

196

• Parse tree for
• A B C A
• again?

197
(No Transcript)
198

• Summary
• Three kinds of grammars
• good, bad, ugly
• Derivations and parse trees
• Two diff derivations may have one parse tree
• One derivation has one parse tree
• One parse tree may have two derivations
• Tow diff parse trees have diff derivations

199

• More specifically,
• Derivation is concrete
• Parse tree is abstract
• Given a derivation, we can draw its corresponding
  parse tree
• Given a parse tree, we dont know which
  derivation it corresponds to .

200
Semantics

• Operational semantics
• Denotational semantics
• Axiomatic semantics

201

• Operational semantics
• Specifies the meaning of a program in the
  interest of execution.
• Ex the operational semantics of
• if cond A then B endif
• is cond is evaluated first. If the result is
  true, then A is the value of this sentence
  otherwise, B is the value of this sentence.

202

• In terms of evaluation rules
• If cond ? cond , then if cond then A else B
• ? if cond then A else B
• If true then A else B ? A
• If false then A else B ? B

203

• Ex the operational semantics of
• (?x.M)N
• is (?x.M)N reduces to N/xM

204

• Axiomatic semantics
• Semantics specified (indirectly) by inserting
  preconditions and postconditions for statements.
• General form P S Q, where
• P precondition
• Q postcondition
• S sentence

205

• Ex a gt 1
• x a 1
• x gt 2
• xlt2, ylt7
• y 3x 1
• x y 3
• x lt 10

206

• Denotational semantics
• Math meaning/model of PLs.
• Highly sophisticated.
• Involving set theory, domain theory, category
  theory, and overlaps computer science, math, and
  logics.
• Dana Scott

207

• Ex x ?(x) ? environment
• ?(xa).M f where f is a
  function
• from a to ß,
  where ß is the
• type of M
• MN MN
