Title: Master Wall Stucco Cladding Options


1
Master WallStucco Cladding Options
2
About Master Wall
  • Founded in 1987 focused on EIFS
  • Grew rapidly during the early years, mainly
    through customer satisfaction and professional
    staff
  • Developed quality materials based upon 100 pure
    acrylic formulations
  • Expanded national distribution about 60
    locations with outstanding local service
  • Full service Technical and Sales assistance

3
Mission Statement
  • To manufacture the highest quality EIFS and
    related products (coatings, adhesives, etc.)
    available in the market.
  • To be the service leader of our industry in the
    region and areas that we market our products
  • To be respected in our industry because of
    honesty and integrity within our ranks
  • To encourage our employees to set the highest
    standards possible for their careers and their
    personal lives by supporting them through
    education, training and sharing any God given
    wisdom we may obtain. To compensate all
    employees in such a way that they can support
    themselves and their families in a comfortable
    manner.
  • To seek Gods guidance in all decisions, and to
    give Him glory for any results.

4
General Notes
  • Please reference the specific product data sheets
    or contact Master Wall for project-specific
    recommendations
  • This program is published for general
    informational purposes only and is not intended
    to imply that these are the only materials,
    procedures, or methods, which are available or
    suitable. Materials, procedures, or methods may
    vary according to the particular circumstances,
    local building code requirements, design
    conditions, or statutory and regulatory
    requirements. While the information in this
    program is believed to be accurate and reliable,
    it is presented without guarantee or
    responsibility on the part of Master Wall Inc.
  • Photographs may or may not depict the specific
    system but demonstrate the techniques used in the
    proper application of the products

5
Learning Objectives
  • Code Overview
  • Basic System Types
  • Best Uses, Advantages, Disadvantages
  • Specialty Products Best Uses

6
System Types
  • New building codes have separated wall cladding
    according to their respective building types
  • Commercial Systems (IBC)
  • Residential Systems (IRC)

7
International Building Code (IBC, 2000)
  • Chapter 14 Exterior Walls
  • Applies to most Weather Coverings such as
    veneers, hardboard/wood, stone and EIFS
  • Chapter 25 Gypsum Board Plaster
  • Applies to stucco

8
IBC Chapter 14
  • Requires a weather barrier behind ALL claddings
    except
  • Over concrete or masonry walls
  • Over a wall cladding that demonstrates
    wind-driven rain resistance including joints,
    penetrations and intersections

Source IBC 2000, 1403.2
9
IBC Chapter 25
  • Typically references three-coat work over lath
    and two-coat work over masonry/concrete
  • ASTM C926 for stucco
  • ASTM C1063 for lath accessories
  • ASTM Standards also used as a reference in some
    One Coat Stuccos

Source IRC 2000, 2512
10
International Residential Code (IRC 2003)
  • Requires a water barrier under all but a few
    claddings
  • Many states have adapted a requirement for a
    water barrier behind all claddings

11
Basic Commercial Stucco Cladding Types
  • Aggre-flex EIFS
  • Exterior Insulation and Finish Systems
  • Drainage EIFS
  • Aggre-flex Drainage
  • EIFS over a sheet water barrier
  • Aggre-flex Commercial Drainage
  • EIFS over a trowel-applied water barrier
  • Rollershield Drainage
  • EIFS over a roll-applied water barrier
  • One Coat Stucco
  • Cemplaster Stucco
  • Direct Applied
  • Drainage DEFS
  • Stucco Cement Board Coatings
  • Insulated Concrete Forms
  • Uninsulated Finishes

12
Basic Residential Stucco Cladding Types
  • Aggre-flex Drainage EIFS
  • EIFS over a water barrier
  • QRW1 Drainage EIFS
  • Polyisocyanurate insulation boards over a water
    barrier
  • One Coat Stucco
  • Cemplaster Stucco
  • Direct Applied
  • Drainage DEFS
  • Cement Board Coatings
  • Insulated Concrete Forms
  • Uninsulated Finishes

13
Stucco Cladding Uses
  • So many choicesWhat works best?

14
EIFS
  • Exterior Insulation and Finish Systems

15
Aggre-flex EIFS
Framing Sheathing (by others)
  • Barrier Wall System
  • Commercial use only
  • Commonly used in strip malls, office buildings
    and schools
  • Adhesively or mechanically attached to a
    substrate
  • Best for use where aesthetics, style and costs
    are a factor

Adhesive (or mechanical attachment)
Insulation Board
Reinforcing Mesh
Base Coat
Finish Coat
16
Aggre-flex Drainage System
Framing Sheathing (by others)
  • Class PB EIFS flexibility, drainage capability
  • Always applied over a water barrier
  • For residential and commercial use
  • Flat or wavy insulation board are often used
  • Most common installation uses flat insulation
    board over a spacer-type water barrier
  • Suitable for most construction types especially
    strip malls, hotels and light commercial

Water Barrier (by others)
Mechanical Attachment
Insulation Board
Reinforcing Mesh
Base Coat
Finish Coat
17
Rollershield Drainage SystemRoll-Applied Water
Barrier
Framing Sheathing (by others)
  • Drainage EIFS adhered to a roll-applied water
    barrier
  • Water barriers are often rolled into openings
  • Typically the adhesive grooves provide the
    drainage channel
  • Benefits of an adhesively-applied EIFS but with
    drainage capability
  • Suitable for light to mid-commercial construction

Rollershield
Adhesive Attachment
Insulation Board
Reinforcing Mesh
Base Coat
Finish Coat
18
Commercial Drainage SystemTrowel-Applied Water
Barrier
Framing Sheathing (by others)
  • Drainage EIFS adhered to a trowel-applied water
    barrier
  • Thicker water barrier compared to roll-applied
    products
  • Typically peel and stick type flashings used at
    openings
  • Some systems incorporate channels or
    pressure-equalizing methods
  • Costly suitable for long-term use buildings
    such as government facilities

WeatherStop
Adhesive Attachment
Insulation Board
Reinforcing Mesh
Base Coat
Finish Coat
19
QRW1 Drainage System
Framing Sheathing (by others)
  • Class PI with Polyocyanurate Insulation
  • Always applied over a water barrier- sometimes
    with spacers
  • Larger insulation sheets with fiberglass facing
    are sometimes easier to apply
  • Control joints often required to ease thermal
    movement
  • Suitable for residential and occasional light
    commercial

Water Barrier (by others)
Mechanical Attachment
Insulation Board
Reinforcing Mesh
Base Coat
Finish Coat
20
EIFS Design Basics
  • A secondary water barrier is required for
    residential construction, optional for light
    commercial (depends on codes)
  • System breaks at penetrations
  • ½ to ¾ wide sealant joints are the norm,
    fillet-type sealant joints are allowed in
    residential construction
  • Sealant bridges between the EIFS and wall
    penetrations
  • Plastic trims or backwrapping may be used where
    the system ends
  • Insulation thickness varies from ¾ to 1 minimum
    to a maximum 4 as allowed by code (5/8 to 2
    for Class PI Systems)
  • Insulation Board keeps inside wall temperatures
    more consistent.

21
Stucco
  • One Coat Cemplaster

22
One Coat Stucco (OCS)
Framing Sheathing (by others)
Water Barrier (by others)
  • Like traditional stucco, but with fibers
  • Installed thinner than regular stucco, ½ is
    typical
  • Typically 2-water barriers are required over
    sheathing
  • May be applied directly to masonry or concrete
  • May not be available in all areas (needs a code
    report)
  • Control joints and casing beads are required
    located by A/E
  • Generally limited to relatively flat walls some
    decorative foam trim can be added
  • Acrylic finishes commonly used as a finish coat

Metal Lath mechanically attached to framing
One Coat Stucco
Primer (optional)
Finish Coat
23
Cemplaster Stucco
Framing Sheathing (by others)
Water Barrier (by others)
  • Traditional stucco with a warranty
  • Applied full thickness, nominal 7/8 over
    sheathing, 1/2 over masonry, 3/8 over concrete
  • Like traditional stucco, but with fibers
  • Two water barriers are required over sheathing
  • May be applied directly to masonry or concrete
  • Control joints and casing beads are required
    located by A/E
  • Generally limited to relatively flat walls some
    decorative foam trim can be added
  • Acrylic finishes commonly used as a finish coat

Metal Lath mechanically attached to framing
Stucco
Primer (optional)
Finish Coat
24
Stucco/OCS Design Basics
  • A secondary water barrier is required for
    sheathing applications
  • System breaks at penetrations
  • Very little guidelines are available. Sometimes
    the stucco is run tight to penetrations, other
    times a small sealant joint is used
  • Plastic, galvanized or zinc trims are used, sized
    for the stucco thickness (ground)
  • Control joints are used to help reduce cracking
  • 144 s.f. maximum wall area
  • Length to width ratio no more than 2.51
  • Off corners of windows/doors and at dissimilar
    substrates
  • Avoid layouts that form unusual shapes (L, U, T)

25
DEFS
  • Direct-Applied Exterior Finish System

26
Drainage DEFS
  • Direct-applied Exterior Finish System over an
    approved substrate and a weather-resistive
    barrier in vertical applications
  • Economical, easy to apply
  • Limited to southern use on vertical walls (below
    4000 Heating Degree Days)
  • DEFS typically is suitable for limited vertical
    applications

Framing (by others)
Water Barrier (by others)
DEFS Substrate (by others)
Reinforcing Mesh
Base Coat
Finish Coat
27
DEFS Soffit
Framing (by others)
  • Durable, good looking and economical
  • Nice upgrade from vinyl/aluminum of painted
    exterior gypsum board
  • Common applications include schools, office and
    commercial uses

DEFS Substrate (by others)
Reinforcing Mesh
Base Coat
Finish Coat
28
Stucco Cement Board Coatings
Water Barrier (by others)
Framing Sheathing (by others)
  • Durable, good looking alternative to stucco
  • Foam trims can be added to improve aesthetics
  • Cement boards may be placed in areas too small
    for traditional stucco
  • Common applications include schools, office and
    commercial uses

Cement Board Substrate (by others)
Reinforcing Mesh/Base Coat at joints
Reinforcing Mesh
Base Coat
Finish Coat
29
DEFS Design Basics
  • A secondary water barrier is required for DEFS in
    vertical applications
  • System breaks at penetrations
  • Typically a small sealant joint is used
  • Plastic trims are commonly used
  • Control joints are used to minimize possible
    cracking
  • 160 s.f. maximum wall area
  • Placed no more than 20 lineal feet in any
    direction
  • Length to width ratio no more than 2.51
  • Off corners of windows/doors and at dissimilar
    substrates System breaks at penetrations
  • Sealant bridges between the DEFS and wall
    penetration

30
Insulated Concrete Forms
Insulated Concrete Form (by others)
  • Base coat, mesh and finish over the ICF forms
  • Great if ties are buried within the insulation,
    otherwise another layer of insulation board is
    required
  • Economical compared to other ICF finishing options

Reinforcing Mesh
Base Coat
Finish Coat
31
Uninsulated Finishes
Unpainted Masonry/Concrete (by others)
  • Base coat and finish over an approved substrate
  • Unpainted brick/block
  • Unpainted concrete
  • Mesh is optional if needed for some additional
    crack resistance or to help leveling
  • High-build base coats are recommended to help
    minimize wall variations
  • Great for improving the looks of a
    masonry/concrete building or matching a renovation

Reinforcing Mesh
Base Coat
Finish Coat
32
Specialty Products Best Uses
Use em where you need em
33
Elastomeric Textured Finishes
  • Elastomeric finishes use a softer acrylic polymer
  • Designed to bridge minor cracking especially in
    stucco
  • Factory mixed upgrade

34
Silicone Finish Additive
  • Silicone is factory added to a finish
  • Good for high humidity/moisture laden areas
  • Keeps the finish looking cleaner, especially for
    dirty environments
  • Does eventually leach out
  • Not for dark colors

35
Excel Mildew Finish Additive
  • All finishes are tested for minimum mildew
    resistance
  • Excel booster is factory added to exceed these
    requirements
  • Great for areas that receive minimal sunlight or
    air movement

36
Mesh Upgrades for EIFS
  • Many different mesh weights are available
    depending upon the needs
  • Generally, the higher the mesh weight the better
    the impact resistance
  • 2-layer systems offer the best impact resistance
  • Impact resistance varies from Medium to Ultra
    High
  • Detail mesh is soft and pliable for backwrapping
    or special details

37
FM Plus High Build Base Coat
  • High Build base coats help level walls
  • May be used in EIFS
  • Especially useful in DEFS or Uninsulated
    applications where out of plane conditions exist
  • May also be used to level stucco

38
Guardian Waterproof Base Coat
  • Uses waterproof acrylics
  • Good for below grade applications, long sloped
    applications
  • May be used to adhere insulation boards as well

39
Stucco Ad-Liquid
  • Greatly improve the performance of stucco
  • Increased Compressive Strength
  • Increased Tensile Strength
  • Can eliminate fogging if levels are high enough

40
Primecoat Primer
  • Primecoat equalizes finish absorption and evens
    out finish color
  • Suggested over stucco applications where
    absorption varies considerably
  • Useful over EIFS base coats where a very light
    finish color is desired
  • Highly recommended when foam trims are added to
    stucco

41
Roller-flex
  • Typically the same as the finish, minus the
    aggregate
  • Used for color changes or accent banding

42
Stone Finishes
  • Superior Stone and Aggrestone are used to create
    the look of marble or granite
  • Manufacturers offer a variety of colors and
    aggregate sizes
  • Primer required

43
Vintique Antiquing Accent
  • Highly stylized accents
  • Vary texture technique
  • Spray
  • Sponge
  • Light Spray Accent

44
More Information
  • Contact Master Wall
  • Visit our web site
  • Spin the CD

45
Thank You For Your Time
? Questions ?
www.masterwall.com
Write a Comment
User Comments (0)
About PowerShow.com
