ROBUST SPEECH RECOGNITION Introduction to Microphone Arrays

1
ROBUST SPEECH RECOGNITIONIntroduction to
Microphone Arrays

• Richard Stern
• (with Mike Seltzer, Tom Sullivan, and
• Evandro Gouvea)
• Robust Speech Recognition Group
• Carnegie Mellon University
• Telephone [phone]
• Fax [phone]
• rms_at_cs.cmu.edu
• http//www.cs.cmu.edu/rms
• Short Course at UNAM
• August 14-17, 2007

2
Introduction

• The use of arrays of microphones can improve
  speech recognition accuracy in noise
• Outline of this talk
• Review classical approaches to microphone array
  processing
• Delay and sum beamforming
• Traditional adaptive filtering
• Physiological-motivated processing
• Describe and discuss selected recent results
• Matched-filter array processing (Rutgers)
• Array processing based on speech features (CMU)

3
OVERVIEW OF SPEECH RECOGNITION
Speech features
Phoneme hypotheses
Decision making procedure
Feature extraction

• Major functional components
• Signal processing to extract features from speech
  waveforms
• Comparison of features to pre-stored templates
• Important design choices
• Choice of features
• Specific method of comparing features to stored
  templates

4
Why use microphone arrays?

• Microphone arrays can provide directional
  response, accepting speech from some directions
  but suppressing others

5
Another reason why microphone arrays

• Microphone arrays can focus attention on the
  direct field in a reverberant environment

6
Three classical types of microphone arrays

• Delay-and-sum beamforming and its many variants
• Adaptive arrays based on mean-square suppression
  of noise
• Physiologically and perceptually motivated
  approaches to multiple microphones

7
Delay-and-sum beamforming

• Simple processing based on equalizing delays to
  sensors
• High directivity can be achieved with many sensors

z-n1
Sensor 1
z-n2
Sensor 2
Output
z-nK
Sensor K
8
The physics of delay-and-sum beamforming
d
q
dsin(q)
9
The physics of delay-and-sum beamforming

• If sensor outputs are added together, the look
  direction is q 0
• Look direction can be steered to other
  directions by inserting electronic delays to
  compensate for physical ones
• For look direction of q 0, net array output is

d
q
dsin(q)
10
Examples of delay-and-sum beams

• d 8.62 cm, N 9, f 500 Hz

11
Examples of delay-and-sum beams

• d 8.62 cm, N 9, f 1000 Hz

12
Examples of delay-and-sum beams

• d 8.62 cm, N 9, f 1500 Hz

13
Examples of delay-and-sum beams

• d 8.62 cm, N 9, f 2000 Hz

14
Examples of delay-and-sum beams

• d 8.62 cm, N 9, f 2500 Hz

15
Examples of delay-and-sum beams

• d 8.62 cm, N 9, f 3000 Hz

16
Examples of delay-and-sum beams

• d 8.62 cm, N 9, f 3500 Hz

17
Examples of delay-and-sum beams

• d 8.62 cm, N 9, f 4000 Hz

18
Nested microphone arrays (Flanagan et al.)

• 5-element low frequency array

19
Nested microphone arrays

• 5-element mid frequency array

20
Nested microphone arrays

• 5-element high frequency array

21
Combined nested array (Flanagan et al.)

• Three-band quasi-constant beamwidth array

Lowpass filter
Bandpass filter
Highpass filter
22
Another delay-and-sum issue spatial aliasing

• d 8.62 cm, N 9, f 4000 Hz

23
Another delay-and-sum issue spatial aliasing

• d 8.62 cm, N 9, f 5000 Hz

24
Another delay-and-sum issue spatial aliasing

• d 8.62 cm, N 9, f 6000 Hz

25
Preventing spatial aliasing

• Spatial aliasing occurs when sensors receive
  input more than half a period from one another
• The spatial Nyquist constraint depends on both
  frequency and arrival angle
• To prevent spatial aliasing we require that the
  maximum frequency be less than

d
q
dsin(q)
26
Filter-and-sum beamforming

• Input filters can (in principle) place delays
  that vary with frequency to ameliorate frequency
  dependencies of beamforming
• Filters can also compensate for channel
  characteristics

Sensor 1
Filter
Sensor 2
Filter
Output
Sensor K
Filter
27
Compensated delay-and-sum beamforming

• Filter added to compensate for filtering effects
  of delay and sum beamforming

z-n1
Sensor 1
z-n2
Output
Sensor 2
Filter
z-nK
Sensor K
28
Sample recognition results using compensated
delay-and-sum

• The Flanagan array with CDCN does improve
  accuracy

29
Traditional adaptive arrays
30
Traditional adaptive arrays

• Large established literature
• Use MMSE techniques to establish beams in the
  look direction and nulls to additive noise
  sources
• Generally do not perform well in reverberant
  environments
• Signal cancellation
• Effective impulse response longer than length of
  filter
• Techniques to circumvent signal cancellation
• Switching nulling mechanism off and on according
  to presence or absence of speech (Van
  Compernolle)
• Switching off adaptation in reverberant
  environments
• Use of alternate adaptation algorithms

31
Array processing based on human binaural hearing
32
Array processing based on human binaural hearing

• Motivation human binaural system is known to
  have excellent immunity to additive noise and
  reverberation
• Binaural phenomena of interest
• Cocktail party effect
• Precedence effect
• Problems with binaural models
• Correlation produces signal distortion from
  rectification and squaring
• Precedence-effect processing defeats echoes but
  also suppresses desired signals
• Greatest challenge decoding useful information
  from the cross-correlation display

33
Correlation-based system motivated by binaural
hearing
34
Vowel representations using correlation processing

• Reconstructed features of vowel /a/

Two inputs zero delay
Two inputs 120-ms delay
Eight inputs 120-ms delay
35
So what do things sound like on the
cross-correlation display?

• Signals combined with ITDs of 0 and .5 ms
• Individual speech signals
• Combined speech signals
• Separated by delay-and sum beamforming
• Signals separated by cross-correlation display
• Signals separated by additional correlations
  across frequency at a common ITD (straightness
  weighting)

36
Matched-filter beamforming (Rutgers)

• Goal compensation for delay and dispersion
  introduced in reverberant environments

600-ms Room response
Autocorrelation function
37
Matched-filter beamforming procedure

• Measure or estimate sample response from source
  to each sensor
• Convolve input with time-reversed sample function
  (producing autocorrelation function)
• Sum outputs of channels together
• Rationale main lobes of autocorrelation
  functions should reinforce while side lobes cancel

38
Optimizing microphone arrays for speech
recognition features

• The typical microphone array algorithms has been
  signal enhancement rather than speech recognition

MIC1
MIC2
Array Processor
MICN
39
Automatic Speech Recognition (ASR)

• Parameterize speech signal and compare parameter
  sequence to statistical models of speech sound
  units to hypothesize what a user said.
• The objective is accurate recognition, a
  statistical pattern classification problem.

40
ASR feature extraction

• Convert a segment of speech into a compact set of
  descriptive features

FFT
MEL SPECTRUM
LOG
400
512
40
40
speech
DCT
13
features
ASR
41
Speech recognition with microphone arrays

• Recognition with microphone arrays has been
  traditionally been performed by gluing the two
  systems together.

• Systems have different objectives.
• Each system does not exploit information present
  in the other.

42
Array processing based on speech features

• Develop an array processing scheme targeted at
  improved speech recognition performance without
  regard to conventional array processing objective
  criteria.

MIC1
MIC2
ASR
Feature Extraction
Array Proc
MIC3
MIC4
43
Choosing array weights based on speech features

• Want an objective function that uses parameters
  directly related to recognition

Clean Speech Features
x1
h1
t1
MIC1
Ms
x2
h2
t2
My
MIC2
y
FE
e
S
-
xM
hM
tM
MICM
minimize e
44
An objective function for mic arrays based on
speech recognition

• Define Q as the sum of the squared errors of the
  log Mel spectra of clean speech s and noisy
  speech y
• where y is the output of a filter-and-sum
  microphone array and M f, l is the lth log
  Mel spectral value in frame f.
• My f, l is a function of the signals captured
  by the array and the filter parameters associated
  with each microphone.

45
Calibration of microphone arrays for ASR

• Calibration of filter-and-sum microphone array
• User speaks an utterance with known transcription
• With or without close-talking microphone
• Derive optimal set of filters
• Minimize the objective function with respect to
  the filter coefficients.
• Since objective function is non-linear, use
  iterative gradient-based methods
• Apply to all future speech

46
Calibration Using close-talking recording

• Given a close-talking mic recording for the
  calibration utterance, derive an optimal filter
  for each channel to improve recognition

Ms
FE
OPT
MIC1
ASR
h1(n)
t1
S
sn
FE
My
MICM
hM(n)
tM
47
Multi-microphone data sets

• TMS
• Recorded in CMU auditory lab
• Approx. 5m x 5m x 3m
• Noise from computer fans, blowers ,etc.
• Isolated letters and digits, keywords
• 10 speakers 14 utterances 140 utterances
• Each utterance has close-talking mic control
  waveform

7cm
1m
48
Multi-microphone data sets (2)

• WSJ off-axis noise source
• Room simulation created using the image method
• 5m x 4m x 3m
• 200ms reverberation time
• WGN source _at_ 5dB SNR
• WSJ test set
• 5K word vocabulary
• 10 speakers 65 utterances 650 utterances
• Original recordings used as close-talking control
  waveforms

25cm
2m
15cm
1m
49
Results

• TMS data set, WSJ0 WGN point source simulation
• Constructed 50 point filters from a single
  calibration utterance
• Applied filters to all test utterances

50
Calibration without Close-talking Microphone

• Obtain initial waveform estimate using
  conventional array processing technique (e.g.
  delay and sum).
• Use transcription and the recognizer to estimate
  the sequence of target clean log Mel spectra.
• Optimize filter parameters as before.

51
Calibration w/o Close-talking Microphone (2)

• Force align the delay-and-sum waveform to the
  known transcription to generate an estimated HMM
  state sequence.

BLAH BLAH...
MIC1
t1
S
sn
FALIGN
FE
MICM
tM
HMM
52
Calibration w/o Close-talking Microphone (3)

• Extract the means from the single Gaussian HMMs
  of the estimated state sequence.
• Since the models have been trained from clean
  speech, use these means as the target clean
  speech feature vectors.

HMM
IDCT
53
Calibration w/o Close-talking Microphone (4)

• Use estimated clean speech feature vectors to
  optimize filters as before.

OPT
MIC1
ASR
h1(n)
t1
S
sn
FE
My
MICM
hM(n)
tM
54
Results

• TMS data set, WSJ0 WGN point source simulation
• Constructed 50 point filters from calibration
  utterance
• Applied filters to all utterances

55
Results (2)

• WER vs. SNR for WSJ WGN
• Constructed 50 point filters from calibration
  utterance using transcription only
• Applied filters to all utterances

56
Performance in highly reverberant rooms

• Comparison of single channel and delay-and-sum
  beamforming (WSJ data passed through measured
  impulse responses)

Single channel
Delay and sum
57
Performance in highly reverberant rooms

• Impact of matched filter and feature-based array
  processing
• Matched filter array used 1040 points per channel
  with perfect knowledge of channel characteristics
• Feature-based array used 30 points per channel,
  imperfect channel knowledge

58
Subband processing using optimized features
(Seltzer)

• Subband processing can address some of the
  effects of reverberation. The subband signals
  have more desirable narrowband signal properties.

2. Downsample
4. Upsample
1. Divide into independent subbands
5. Resynthesize full signal from subbands
3. Process subbands independently
L
H1(z)
F1(z)
G1(z)
L
H2(z)
F2(z)
G2(z)
S
yn
xn
L
HL(z)
GL(z)
FL(z)
59
Subband results with reverberated WSJ task

• WER for all speakers, compared to delay-and-sum
  processing

60
Summary

• Microphone array processing is effective although
  not yet in widespread use except for simple
  delay-and-um beamforming
• Despite many developments in signal processing,
  actual applications to speech are based on very
  simple concepts
• Major problems and issues
• Maintaining good performance in reverberation
• Real-time time-varying environments and speakers

61
(No Transcript)
