Session-Independent Policies draft-ietf-sipping-session-indep-policy-01

1
Session-Independent Policiesdraft-ietf-sipping-se
ssion-indep-policy-01

• Volker Hilt
• volkerh_at_bell-labs.com
• Gonzalo Camarillo
• Gonzalo.Camarillo_at_ericsson.com
• Jonathan Rosenberg
• jdrosen_at_dynamicsoft.com

2
Session-Independent Policies

• Major revision since 00.
• Session-independent policy delivery mechanism.
• Based on the config-framework.
• UAs subscribe to policy servers using the
  following profiles.
• user profile retrieve policies of the users AoR
  domain.
• local profile retrieve policies of the access
  network.
• Rules when to sent a subscribe.

3
Policy Schema

• Generic policy schema defines common elements and
  attributes.
• XML schemas for specific policies.
• Media policies
• Protocol policies
• Media routing policies

4
Policy Schema Structure

• Specifying constraints in policy schemas.
• Simple restrictions.
• Example maximum bandwidth (mandatory).
• UA needs to select multiple values.
• Multiple instances can be present in a session.
• Example audio (mandatory), video (allowed),
  application (denied).
• UA needs to select a single value.
• One instance needs to be selected for a session.
• Example codec PCMU (allowed), PCMA (allowed),
  G729 (denied).
• Constraints
• Mandatory, allowed, denied.

5
XML Containers

• Container-based approach
• Containers define the constraining properties of
  a policy elements.
• Policy elements modify the working profile
  (settings used by a UA).
• ltforbidgt element values must be removed.
• ltset_allgt element values must be added.
• ltset_onegt one of the values must be added.
• ltset_anygt element values may be added.
• Characteristic/Issues
• Well aligned with the data set framework.
• Based on concept of working profile.
• Flexible and complex.

ltforbidgt ltmediagt lttype /gt
ltcodecgtPCMUlt/codecgt lt/mediagt lt/forbidgt ltset_allgt
ltmediagt ltmaxnoStreamsgt4
lt/maxnoStreamsgt lttypegtaudiolt/typegt
lt/mediagt lt/set_allgt ltset_anygt ltmediagt
lttypegtvideolt/typegt lt/mediagt lt/set_anygt
6
XML Attributes

• Attribute-based approach
• "Policy" attribute defines constraining
  properties of elements.
• "Mandatory" - must be used in sessions.
• "Allow" - may be used in sessions.
• "Deny" - can not be used in sessions.
• Policy schemas specify the use of this attribute
  for elements.
• Default policies for an element require a
  separate element.
• Example ltdefault-codecgt defines policy for
  codecs not listed.
• Characteristic
• Session-based.
• Required semantics.
• Simple.

ltmediagt ltmaxnoStreamsgt4lt/maxnoStreamsgt
ltdefault-type policy"disallow" /gt lttype
policy"mandatory"gtaudiolt/typegt lttype
policy"allow"gtvideolt/typegt ltdefault-codec
policy"allow" /gt ltcodec policy"deny"gtPCMUlt/cod
ecgt lt/mediagt
7
Conflict Resolution

• Session policies from different sources may be in
  conflict.
• General conflict resolution mechanisms are very
  complex.
• Out of scope for this draft!!
• Proposal
• Specific rules for merging policies in a policy
  schema.
• Default behavior for conflicts that cant be
  resolved (e.g. alert user).
• Special treatment for emergency calls?

8
Session-Specific Policiesdraft-hilt-sipping-sessi
on-spec-policy-01

• Volker Hilt
• volkerh_at_bell-labs.com
• Gonzalo Camarillo
• Gonzalo.Camarillo_at_ericsson.com
• Jonathan Rosenberg
• jdrosen_at_dynamicsoft.com

9
Session-Specific Policies

• Major revision since 00.
• Mechanism based on the separate channel model.
• Architecture
• Proxy provides the URI of the local policy
  server to UA.
• Policy server receives session information from
  UA and returns session policies.
• Policy enforcement point may be present to
  enforce policies. Out of scope for this draft.

Proxy
Proxy
UA A
Policy Server PS A
Policy Server PS B
UA B
Router w/ Policy Enforcmnt
Router w/ Policy Enforcmnt
10
Distributing PS URIs

• Two new header fields
• Policy-contact header
• Convey the policy server URI from proxy to UAs.
• Policy-Id header
• Used by UAC to identify the policy servers used.

11
Contacting the Policy Server

• When / with which information does a UA contact
  the PS?
• Offer generally needed for session-specific
  policies.
• Answer needed if policies apply to
  answer-specific information (e.g., IP address and
  port).
• BYE needed by PS to free resources (e.g. close
  firewall pinholes, terminate asynchronous policy
  updates).
• Proposal PS provides indication on policy
  channel.
• Offer cycle is mandatory.
• Flag for answer required in offer cycle.
• PS closes policy channel when done.

12
Policy Channel

• Proposal SUBSCRIBE/NOTIFY-based mechanism.
• Same mechanism as session-independent policies.
• Use of SIP authentication and authorization
  mechanisms.
• Allows asynchronous policy updates.
• Content indirection for policy delivery.
• Subscription terminated when session ends or
  policy server has no policy updates.
• Issue
• Offers and answers need to be carried in
  SUBSCRIBE bodies.

13
Policy Channel - Flow
UA
PS
SUBSCRIBE PS ltoffergt

• UA subscribes to policies at PS.
• Offer in SUBSCRIBE body.
• UA refreshes subscription.
• Offer and answer in SUBSCRIBE body.
• Alternative separate subscription for answer.
• PS notifies UA about policy updates.
• UA terminates subscription when session ends.

NOTIFY ltpolicyOffergt answer"yes"
SUBSCRIBE PS ltoffergt ltanswergt
NOTIFY ltpolicyOffergt ltpolicyAnswergt
NOTIFY ltpolicyOffergt ltpolicyAnswergt
SUBSCRIBE PS Expires0
NOTIFY
