Media Access Control and Example Wireless Networks

1
Media Access Control and Example Wireless Networks

• Y. Richard Yang
• 09/25/2006

2
Outline

• Admin. and recap
• Basic media access control
• Example networks

3
Admin.

• Questions on hw1
• problem g)
• Change of office hours
• Monday  4-5 pm (Hong)
• Tuesday  930-1030 am (Richard)
• Wednesday 1030-1130 am (Hong)
• Friday Richard 2-3 pm (Richard)
• Project suggestions
• http//zoo.cs.yale.edu/classes/cs434/projects/sugg
  estions.pdf
• please form groups two per group
• after you have formed a group, please make an
  appointment with me to discuss selection of
  project

4
Recap Media Access Control

• Implements resource allocation
• reduce/avoid interference
• efficient utilization of network resources by
  multiplexing transmissions
• Dimension for multiplexing
• space division multiple access
• time division multiple access
• frequency division multiple access
• code division multiple access

5
Recap CDMA

• CDMA (Code Division Multiple Access)
• Unique code assigned to each user i.e., code
  set partitioning
• All transmissions share the same frequency and
  time
• Each transmission uses DSSS, and has its own
  chipping sequence (i.e., code) to encode data
• e.g. code -1 1 1 -1 1 -1 1

6
CDMA Deal with Multiple-User Interference

• Two codes Ci and Cj are orthogonal, if
• , where we use . to denote inner
  product, e.g.
• If codes are orthogonal, multiple users can
  coexist and transmit simultaneously with
  minimal interference

C1 1 1 1 -1 1 -1
-1 -1 C2 1 -1 1 1
1 -1 1 1 ------------------------
-------------------------- C1 . C2 1 (-1)
1 (-1) 1 1 (-1)(-1)0
Analogy Speak in different languages!
7
Example CDMA/DSSS
tb
user data d(t)
1
-1
X
tc
code c(t)
-1
1
1
-1
1
-1
1
-1
1
-1
-1
1
1
1

resulting transmitted signal
-1
1
1
-1
-1
1
-1
1
1
-1
1
-1
-1
1
tb bit period tc chip period
8
Generating Orthogonal Codes

• The most commonly used orthogonal codes in
  current CDMA implementation are the Walsh Codes
• every row is orthogonal to every other row and
  the log NOT of every other row

9
Summary

• SDMA, TDMA, FDMA and CDMA are basic media
  partitioning techniques
• divide wireless channel into smaller pieces
  (cells, time slots, frequencies, codes) for
  multiple transmissions to share
• Question how to divide?

10
Allocation Constraints

• Each transmission i (si-gtdi) is specified by
• transmission power pi
• time ti
• frequency band fi
• code ci
• Given any two transmissions (si-gtdi pi, ti, fi,
  ci) and (sj-gtdj pj, tj, fj, cj), we can
  determine if they conflict
• We want a schedule
• to maximize resource efficiency
• to allocate resource fairly
• to satisfy app requirements
• e.g. real time app (such as VoIP) need access
  with a bounded delay
• e .g. s wants to talk to d, but cannot reach d
  directly

11
MAC

• The general case is challenging and largely still
  open
• We start with the simplest scenario (e.g., 802.11
  or cellular up links) in this class
• time sharing the same frequency and code
• a single receiver (the Access Point)

12
Time Division

• Fixed allocation
• Centralized authority, e.g., polling
• Taking turns, e.g., token passing
• Distributed random access

• discussion compare the schemes in terms of
• efficient utilization of resources
• delay to access channel
• quality of service (e.g., a guaranteed rate)

13
A
Random Access Slotted Aloha
B
Time divided into slots get a packet from
upper layer repeat at each slottransmit
with probability p until no collision
A
B
C
C
S
E
S
S
Used in GSM initial access channel
Question what is the efficiency?
14
A
Random Access Carrier-Sense Multiple
Access/Collision Detection
B
get a packet from upper layer
transmit prob p 1 repeat while (network
busy) wait transmit with probability p if
detect collision abort backoff p p/2
goto repeat else finish
A
B
The algorithm is the foundation of Ethernet
Question is the algorithm effective in wireless?
15
The Hidden Terminal Problem
B
A
C
D
E

• A is sending to B, but C cannot detect the
  transmission
• Therefore C sends to B
• In summary, A is hidden from C

Question why is the hidden terminal problem bad?
16
Some Techniques to Address The Hidden-Terminal
Problem

• CSMA/CD -gt CSMA/CA (congestion avoidance)
• default in 802.11
• even if media is not sensed busy, transmits with
  only a probability
• in real implementation, with a random delay
• Busy-tone multiple access
• used in CDPD (cellular digital packet data)
• the base station sends a busy tone on the down
  link when receiving data
• Virtual carrier sense

17
Virtual Carrier Sense RTS/CTS

• Short signaling packets (virtual carrier sense)
• RTS (request to send) and CTS (clear to send)
• contain sender address, receiver address,
  transmission duration, called network allocation
  vector (NAV)
• A node keeps quiet for NAV in CTS

B
A
C
D
18
Comparisons

• Slotted Aloha
• very simple to implement but need clock sync low
  efficiency
• CSMA/CA
• simple to implement
• low efficiency
• Busy tone
• simple to implement but need a channel for busy
  signal may generate exposed terminals (we will
  see it later)
• Virtual carrier sensing (RTS/CTS)
• high efficiency but add control overhead, and
  energy consumption can be high because a node
  needs to monitor the environment all the time
• Idlereceivesend 11.051.4 Stemm and Katz
  1997 Digitan 2 Mbps WLAN 122.5

19
PHY/MAC of Some Wireless Systems

• The Phy/Link layers are also called radio
  interface
• Many deployed systems
• wide-area cellular networks
• 2G (e.g. GSM, CDMA)
• 3G (e.g., W-CDMA, CDMA2000 1X EV-DO)
• WiMAX (802.16)
• WiFi (802.11a, 802.11b, 802.11g)
• Bluetooth
• I will cover a few you will encounter several
  others in homework 2

20
Evolution of Mobile Telecommunication Systems
CT0/1
AMPS
CT2
NMT
IMT-FT DECT
IS-136 TDMA D-AMPS
FDMA
TDMA
EDGE
IMT-SC IS-136HS UWC-136
GSM
GPRS
PDC
IMT-DS UTRA FDD / W-CDMA
IMT-TC UTRA TDD / TD-CDMA
IMT-TC TD-SCDMA
CDMA
IS-95 cdmaOne
IMT-MC cdma2000 1X EV-DO
cdma2000 1X
1X EV-DV (3X)
2G
3G
1G
2.5G
21
GSM Overview

• Formerly Groupe Spéciale Mobile (founded 1982)
• Now Global System for Mobile Communication
• GSM is a PLMN (Public Land Mobile Network)
• several providers setup mobile networks following
  the GSM standard within each country
• Today many providers all over the world use GSM
• by June 2006 2 billion subscribers (78 mil in US)

22
GSM Services

• Telematic services voice communication
• mobile phones (voice)
• fax
• short message service (SMS)
• Bearer services transfer data with access points
• synchronous 2.4, 4.8 or 9.6 kbit/s
• asynchronous 300 - 1200 bit/s
• Supplementary services
• e.g., forwarding of caller number suppression of
  number forwarding, automatic call-back,
  conferencing with up to 7 participants

23
GSM Radio Subsystem (PHY/MAC)

• A GSM operator operates at a given band
• In US, GSM 1900 MHz was initially used, with GSM
  850 being added in 2001
• A US operator obtains a license from FCC

http//wireless.fcc.gov/uls/
24
GSM Radio Subsystem (PHY/MAC)

• A GSM operator uses TDMA and FDMA to divide its
  allocated frequency
• divide allocated spectrum into different physical
  channels each physical channel has a frequency
  band of 200 kHz
• if BPSK, what is the transmission rate supported?

• how about QPSK?
• partition the time of each physical channel into
  frames each frame has a duration of 4.615 ms
• divides each frame into 8 time slots (also called
  a burst)
• each slot is a logical channel
• user data is transmitted through a logical channel

25
GSM - TDMA/FDMA
26
Backup Slides
27
Many Types of Logical Channels

• Control channels
• Broadcast control channel (BCCH)
• from base station, announces cell identifier,
  synchronization
• Common control channels (CCCH)
• paging channel (PCH) base transceiver station
  (BTS) pages a mobile host (MS)
• random access channel (RACH) MSs for initial
  access, slotted Aloha
• access grant channel (AGCH) BTS informs an MS
  its allocation
• Dedicated control channels
• standalone dedicated control channel (SDCCH)
  signaling and short message between MS and an MS
• Traffic channels (TCH)

• Example call setup from an MS

BTS
MS
SDCCH message exchange
Communication
28
GSM Coding and Modulation Speech
Viterbis alg
Use GMSK, a variant of binary frequency shift
keying
See A brief Overview of the GSM Radio Interface
by Thierry Turlettihttp//citeseer.ist.psu.edu/5
15017.html
29
GSM Coding and Modulation Speech

• Source speech coding
• one sample (260 bits) per 20 ms

Audio sample (20ms)
30
Channel Coding

• Encode the audio sample using convolutional coding

Decoding using Vibertis algorithm, again !
31
Interleaving

• Spread a single audio sample (20 ms) into 8 bursts

32
GSM Data Services

• An MS can reserve a (logical) traffic channel
  (slot) to send data
• data rate standardized at 9.6 kbps
• Use High Speed Circuit Switched Data (HSCSD) to
  improve data rate
• allocate multiple traffic channels
• higher bandwidth
• different amount of bandwidth
• Problem of HSCSD
• data traffic is bursty reserving multiple slots
  is not efficient
• Solution General Packet Radio Service (GPRS)
• allocate multiple slots from the same frame
• only request slots when needed

33
GPRS
PRACH Pkt. Random Access Channel PAGCH Pkt.
Access Grant Channel PTCH Pkt. Traffic Channel
34
GPRS User Data Rates in kbps
35
W-CDMA

• Spectrum
• 1920-1980 MHz uplink
• 2110-2170 MHz downlink
• Modulation QPSK
• CDMA coding
• CDMA with chipping rate fixed at 3.840 Mchip/s

Question how to allocate codes?
36
Orthognal Variable Spreading Factor (OSVF)
1,1,1,1,1,1,1,1
...
1,1,1,1
1,1,1,1,-1,-1,-1,-1
1,1
1,1,-1,-1,1,1,-1,-1
...
1,1,-1,-1
X,X
1,1,-1,-1,-1,-1,1,1
1
X
1,-1,1,-1,1,-1,1,-1
X,-X
...
1,-1,1,-1
1,-1,1,-1,-1,1,-1,1
1,-1
SFn
SF2n
1,-1,-1,1,1,-1,-1,1
...
1,-1,-1,1
1,-1,-1,1,-1,1,1,-1
SF1
SF2
SF4
SF8
37
GPRS Coding
g(1)(D) 1 D3 D4 g(2)(D) 1 D D3 D4
,
1000 ms / 240 ms/frame 48frame 114
bytes/frame 181/456 9.05kbps
38
Random Access Ethernet
get a packet from upper layer K 0 cw
0 // K random wait time cw congestion
window repeat wait for K unit of transmission
time while (network busy) wait wait for
clearance time after the previous signal stops
transmit and detect collision if detect
collision stop and transmit a jam signal
double cw choose K randomly from 0,
1, 2, , cw. goto repeat
Question are there any things questions in
wireless networks?
39
CSMA Exponential Backoff RTS/CTS/DATA/ACK

• Protocol
• begin
• while (channel busy) wait
• if channel idle
• send RTS
• if receive CTS
• send DATA
• wait for ACK
• if ACK
• return
• exponential backoff
• wait for the backoff period
• goto begin

• Summary
• Use RTS/CTS for virtual carrier sense
• Use ACK to improve reliability
• Missing CTS/ACK triggers exponential backoff

40
GSM Elements
MS (mobile station) BSC (base station
controller) BTS (base transceiver station) MSC
(mobile switching center) GMSC (gateway MSC) HLR
(home location register) VLR (visiting location
register
