Status Report on Power Plan Development

1
Status Report on Power Plan Development

• Tribal Energy Conference
• March 16, 2009

2
Emergence of Conservation The 1980 Regional
Power Act
3
Some Trends
4
Trends Economic Growth

• Slower both for the nation the region
• PNW grows faster than US
• Mix of economic activity is changing
• Aging population, growth of non-manufacturing
  industries, electronic age
• Changes the way we use electricity

5
Trends Fuel Prices

• Greater Uncertainty
• Wider Jaws than 5th Plan
• Continued High Volatility Gas Oil
• Moderate Prices in Near-Term
• Higher Prices Long Term

6
Historic Mid-C Average Monthly On- and Off-Peak
Prices Source IntercontinentalExchange (ICE)
7
Trends Electricity Prices

• Volatile and Uncertain
• Wholesale prices grow from 45/MWh in 2010 to
  85/MWh in 2030 (2006)
• Sensitive to Natural Gas prices, CO2 penalty,
  Renewable Portfolio Standards, Hydro

8
Trends Demand for Electricity

• Grow at 1.6 percent per year on average
• About 350-400 MWa per year
• Conservation revised electricity prices can
  reduce that growth rate by HALF
• Peak loads are expected to grow faster than
  energy, especially summer peaks
• Growing Residential Commercial
• Industry flat

9
Trends CO2
10
Impact of CO2 Emission Price Scenarios on
Wholesale Prices Emissions
11
New Analytic Tools(In with Uncertainty and Out
with Perfect Foresight)
12
Resource Options

• Conservation
• Generation
• Demand Response

13
Energy resource optionsEarly 2020s
Transmission cost losses to point of LSE
wholesale delivery No federal investment or
production tax credits Baseload operation (CC,
Nuc, SCPC 85 IGCC, Bio - 80) Medium NG and
coal price forecast (Draft 6th Plan) Proposed
Draft 6th Plan CO2 price.
14
Supply-side Capacity Options Early 2020s
No federal investment or production tax
credits Medium NG and coal price forecast (Draft
6th Plan)
15
Hydroelectric Generation

• Assume Biological Opinion operations
• Assume loss of 300 MWa of energy capability over
  the planning period, test max spill, and Lower
  Snake dam removal
• Variability reflected in 70 water years
  simulation (1929-1998)
• Peak capacity based on new Bonneville/Council
  study

16
Conservation Have We Picked the Low-Hanging
Fruit?
17
Conservation Potential

• Potential reduced by achievements since last plan
• Potential increased by technology advances and
  assessment of some new sectors
• Cost-effectiveness targets will be determined
  in portfolio model analysis
• Achievable technical potential is higher than the
  5th Plan
• Residential and commercial sectors hold three
  quarters of the potential
• Increased potential in industrial (800 MWa) and
  CVR (400 MWa)

18
Conservation How Much Remains?
19
Residential Measures

• Space Conditioning
• Thermal Shell Improvements (e.g. insulation, high
  efficiency windows)
• Duct Sealing
• Heating System Conversions to Air-Source Heat
  Pumps, including ductless systems
• Heat Pump System Efficiency Upgrades
• Central Air Conditioning Efficiency Upgrades
• Room/Window Air Conditioning Efficiency Upgrades
• Heating and Air Condition System Commissioning

• Water Heating
• High Efficiency Tanks
• Heat Pump and Solar Water Heaters
• 2.0 GPM Showerheads
• GFX Wastewater Heat Recovery
• Appliances and Lighting
• Clothes Washers
• Clothes Dryers
• Dishwashers
• Refrigerators
• Freezers
• Microwaves Ovens
• Solar Photovoltaic Systems (On site use)
• TVs Monitors

20
Preliminary Draft 6th Plan Residential Water
Heating, Lighting and Appliance Supply Curve
21
Preliminary Draft 6th Plan Residential Space
Conditioning Supply Curve
22
Commercial Lighting

• Lighting Power Density
• Daylighting with Skylights
• Daylighting with Windows
• Lighting Controls Interior
• Exit Signs
• Exterior Building Lighting
• Street and Roadway Lighting
• Parking Lighting
• LED Traffic Lights
• Signage

23
Commercial HVAC

• Premium HVAC Equipment
• Variable Speed Chiller
• Controls Commissioning
• Package Roof Top Optimization Repair
• Low Pressure Distribution
• Demand Control Ventilation
• Electrically Commutated Motors
• Evaporative Assist Cooling
• Glass
• Roof Insulation

24
Commercial Process

• Municipal Sewage Treatment
• Municipal Water Supply
• Network PC Power Management
• Packaged Refrigeration Equipment
• Commercial Clothes Washers
• Cooking Equipment
• Office Equipment
• Computer Servers and IT
• Demand Control Ventilation Restaurant Hood
• Demand Control Ventilation Parking Garage
• Grocery Refrigeration Bundle
• Plug Load Sensor
• Premium Fume Hood
• Pre-Rinse Spray Valve
• Grocery Refrigeration Bundle

25
Preliminary Draft 6th Plan Commercial Supply Curve
26
Industrial Conservation
27
Industrial Conservation Supply Curve
28
Agricultural Conservation
29
Distribution System Retrofit

• Measures
• Line Drop Compensation
• VAR Management. Phase Load Balancing, Feeder
  Load Balancing
• Substation Voltage Regulators Select
  Re-Conductoring
• End-of Line Voltage Control Regulators

30
Demand Response

• 2,900 MW of potential included in analysis (200
  already achieved)
• 2,300 in winter, 2,500 in summer
• 7 separate categories
• Direct control A/C - 200
• Irrigation - 200
• Direct control SH/WH - 200
• Commercial aggregators - 300
• Interruptible contracts - 600
• Demand buyback - 400
• Dispatchable standby generation 1,000 (Treated
  as contingency reserves)

31
Reducing CO2 Footprint

• Resources available in the longer-term in
  quantities sufficient to replace existing coal
• Coal gasification w/ sequestration
• Post-combustion CO2 separation options for
  existing plants
• New nuclear plants
• Enhanced geothermal, deep water (floating) wind,
  and imported concentrating solar power

32
Generating Resources

• Assess Generation in Terms of
• Energy
• Capacity
• Balancing Reserves

Increasing Importance Capacity Balancing
Reserves
33
Climate Policy Analysis

• Discuss sources of carbon emissions
• Describe alternatives for reducing
• Characterize current policies and proposals
• Analysis
• Force RPS resources, show CO2 effects
• Remove RPS, determine CO2 cost for same CO2
  reduction
• Increase CO2 costs in steps, compare to goal

34
Other Potential Topics

• Direct use of natural gas study
• Discussion of smart grid possibilities
• Interactions between power system and FW program
• Description of energy, capacity, and balancing
  reserves requirements
