Title: ITO etching
1
ITO etching
- Mod3 Day 4
- Tuesday Nov 18th
2
Layers of our ECD
3
Layers of our ECD
- ITO drawbacks
- high cost
- limited supply of iridium
- fragile and inflexible
- costly deposition under vacuum
Carbon nanotubes as possible replacement?
4
Etching the ITO
ITO side is conductivemeasure with multimeter
5
Etching the ITO
ITO side is conductivemeasure with multimeter
Red tape first
6
Etching the ITO
ITO side is conductivemeasure with multimeter
Red tape first Double tape image
7
Etching the ITO
ITO side is conductivemeasure with multimeter
Red tape first Double tape image Cut-away with
knife
8
Please be very careful
