AR Field Probes

1
AR Field Probes Laser Powered Battery Powered
ar rf/microwave instrumentation160 School
House Road Souderton, PA 18964-9990
jsmith_at_ar-worldwide.com
2
Covered Objectives

• FL Series Probes
• Key features of FL Series Probes
• FI7000 Laser Interface Unit
• FP and FH Series Probes
• FM7004 Field Monitor
• VM7000 Virtual Field Monitor
• Probe Configurations

J. Smith
3
z
FL Series Probes

• Laser Powered E-field Probes
• FL7030 Starprobe 1
• 5 kHz to 30 MHz
• 1.5 V/m to 300 V/m
• FL7006 Starprobe 2
• 100 kHz to 6 GHz
• 0.5 V/m to 800 V/m
• FL7018 Starprobe 3
• 3 MHz to 18 GHz
• 1 V/m to 1000 V/m

J. Smith
4
Key FL Series Features

• AR Designed and Built
• Small Size (opens up new applications for
  shielded effectiveness testing in small areas and
  has less effect on the RF field)
• Excellent Isotropic Response (electronics housed
  in small sphere)
• Temperature Compensated (no temperature equation
  needed)
• No Batteries (will run for years without stopping
  to charge batteries)
• Excellent Laser Safety

J. Smith
5
Dimensions
2.25
2.52
1.25
2.25
1.15
11.2
J. Smith
6
FI7000 Field Interface for FL Series

• Laser Enable Key
• Push Button Start / Laser Indicator
• Fiber Optic Status Indicator
• System Fault Indicator
• Interfaces
• GPIB (IEEE-488)
• RS-232 (19200 baud)
• USB 2.0 (TMC)
• Fiber optic serial

J. Smith
7
Protection from laser exposure

• Class 1 Laser Product
• Embedded Class 4 Laser (500mW)
• CDRH Report Filed Accepted
• Shuttered Connecters
• Safety Loop-Back
• Probe Communications Monitoring
• Laser enable key

J. Smith
8
FL Series Kits include

• Selected laser probe
• FI7000 Laser probe interface
• FC7010 10 meters of fiber cable
• Pair of duplex glass fibers
• w/safety shutter connectors
• For laser safety
• To protect connection from damaging dust and dirt
• Color coded connectors
• 0.3 m patch cable for use with FM7004
• Orange carrying case
• A2LA Accredited, NIST Traceable Calibration Report

J. Smith
9

• Battery Powered E-Field Probes
• FP7003
• 100 kHz to 3 GHz
• 0.4 V/m to 660 V/m
• FP7018
• 3 MHz to 18 GHz
• 0.6 V/m to 1000 V/m
• FP7050
• 300 MHz to 50 GHz
• 8 V/m to 614 V/m (RMS)
• Composite Only
• FP7060
• 27 MHz to 60 GHz
• 0.7 V/m to 300 V/m
• Composite Only

J. Smith
10

• Battery Powered H-Field Probes
• FH7103
• 300 kHz to 30 MHz
• 0.012 A/m to 17 A/m
• FH7110
• 27 MHz to 1 GHz
• 0.025 A/m to 16 A/m

J. Smith
11
FP FH Series Probes

• Battery powered
• Rechargeable
• Standard AA size
• Batteries are user accessible and changeable
• Durable Rugged Design
• Fiber optic communication
• For RF isolation
• 100kHz 60GHz Coverage

J. Smith
12
FP FH Series Battery Powered Probe Kits

• FP or FH Series Probe
• Battery Charger
• 10 Meter Fiber-Optic Cable
• Black Carrying Case
• NIST Traceable Calibration Report

J. Smith
13
FM7004 Field Monitor

• AR Designed and Built
• 4 Channels for Field Probes
• Color Graphical Display
• Simple Menu Structure
• 4 Communications Port Options
• GPIB (IEEE-488)
• RS-232 (19200 Baud)
• USB 2.0 (Test and Measurement Class)
• Ethernet

J. Smith
14
Key FM7004 Series Features

• Min Max Hold
• Stores Last Configuration
• Axis and Composite Values Displayed
• Auto Recognizes Probes (Correct Units)
• Simple Remote Commands
• Compatible with all 7000 Series Probes
• Software Upgradeable Using USB Port
• Soon to come -storage of correction factors for
  up to 4 probes

J. Smith
15
VM7000 Virtual Field Monitor

• 4 Channels
• Axis and composite values displayed
• Data logging
• Graphical view
• Compatible with all 7000 Series Probes

J. Smith
16
Special Probe Packages

• MP06000 (100kHz to 6 GHz)
• FL7006/Kit (A2LA/NIST Traceable Cal. Report)
• FM7004
• MP18000 (5 kHz to 18 GHz)
• FL7030/Kit (A2LA/NIST Traceable Cal. Report)
• FL7018/Kit (A2LA/NIST Traceable Cal. Report)
• FM7004
• MP60000 (5kHz to 60 GHz)
• FL7030/Kit (A2LA/NIST Traceable Cal. Report)
• FP7060/Kit (NIST Traceable Cal. Report)
• FM7004

J. Smith
17
Trade-in competitive products.

• Limited time trade-up program
• Trade-up your old out dated field probes
• Contact AR for details

J. Smith
18
Thank you for your attention!!!
ar rf/microwave instrumentation160 School House
Road Souderton, PA 18964-9990 www.ar-worldwide.c
om 215-723-8181
