Title: Chapter 12: ADO'NET and ASP'NET


1
Chapter 12 ADO.NET and ASP.NET
Programming with Microsoft Visual Basic .NET,
Second Edition
2
Database TerminologyLesson A Objectives
  • Define the terms used when talking about
    databases
  • Explain the purpose of the DataAdapter,
    Connection, and DataSet objects
  • Explain the role of the provider
  • Create and configure an OleDbDataAdapter object

3
Database TerminologyLesson A Objectives
(continued)
  • Write SQL SELECT statements
  • Create a dataset
  • Display a dataset in a DataGrid control

4
Database Terminology (continued)
  • Database organized collection of related
    information stored in a file on a disk
  • Relational database database that stores
    information in tables
  • Each column represents a field
  • Each row represents a record

5
Database Terminology (continued)
  • Table a group of related records
  • Each record in a table pertains to the same
    topic, and each contains the same type of
    information
  • Relational database contains one or more tables
  • Primary key a field that uniquely identifies
    each record in a table

6
Database Terminology (continued)
Figure 12-3 Example of a two-table relational
database
7
Database Terminology (continued)
  • In Figure 12-3
  • The first table is called the parent table
  • The second table is called the child table
  • In the parent table, the Number field is the
    primary key
  • In the child table, the Number field is called
    the foreign key

8
ADO.NET
  • To connect an application to a database, Visual
    Basic .NET uses ADO.NET
  • With ADO.NET, the connection between an
    application and a database is a temporary one
  • Use three ADO.NET objects and a provider to
    access a database from a Visual Basic .NET
    application
  • DataAdapter, Connection, and DataSet

9
ADO.NET (continued)
Figure 12-4 Illustration of the relationships
among an application, the ADO.NET objects, a
provider, and a database
10
Creating and Configuring a DataAdapter Object
  • The DataAdapter object is the link between the
    application and the Connection object
  • DataAdapter object contacts the Connection object
    whenever the application needs to read data from
    or write data to a database

11
Creating and Configuring a DataAdapter Object
(continued)
Figure 12-6 Procedure for creating and
configuring a DataAdapter object for a Microsoft
Access database
12
Creating and Configuring a DataAdapter Object
(continued)
Figure 12-6 Procedure for creating and
configuring a DataAdapter object for a Microsoft
Access database (continued)
13
SQL
  • SQL (Structured Query Language) a set of
    commands to access and manipulate the data stored
    in many database management systems
  • SQL commands perform database tasks such as
    storing, retrieving, updating, deleting, and
    sorting

14
SQL (continued)
  • SELECT statement allows you to
  • Specify the fields and records you want to view
  • Control the order in which the fields and records
    appear when displayed

15
SQL (continued)
Figure 12-13 Syntax and examples of the SELECT
statement
16
SQL (continued)
Figure 12-13 Syntax and examples of the SELECT
statement (continued)
17
Using the Query Builder to Enter a SELECT
Statement
  • When you click the Next gt button on the Choose a
    Query Type screen, the Generate the SQL
    statements screen appears
  • You can enter the SELECT statement yourself, or
    you can have the Query Builder enter it for you
  • To use the Query Builder, click the Query Builder
    button
  • The Query Builder and Add Table dialog boxes open

18
Using the Query Builder to Enter a SELECT
Statement (continued)
Figure 12-15 Query Builder and Add Table dialog
boxes
19
Using the Query Builder to Enter a SELECT
Statement (continued)
Figure 12-18 SELECT statement entered in the
Generate the SQL statements screen
20
Creating a Dataset
  • A dataset contains the data you want to access
    from the database, as specified in the SELECT
    statement associated with the DataAdapter object
  • XML (Extensible Markup Language) a text-based
    language used to store and share data between
    applications and across networks and the Internet
  • An XML schema definition file defines the tables
    and fields that make up the dataset

21
Creating a Dataset (continued)
Figure 12-21 Procedure for creating a dataset
22
Using the Fill Method
  • Use the DataAdapter objects Fill method to fill
    a dataset with data while an application is
    running

Figure 12-25 Syntax and an example of the Fill
method
23
Binding the DataSet Object to a DataGrid Control
  • View the data contained in a dataset by
    connecting its DataSet object to one or more
    controls in the interface
  • Binding Connecting a DataSet object to a control
  • Bound controls the connected controls
  • Bind a control using one or more properties
    listed in the Properties window

24
Binding the DataSet Object to a DataGrid Control
(continued)
Figure 12-26 Procedure for binding a DataSet
object to a DataGrid control
25
Binding the DataSet Object to a DataGrid Control
(continued)
  • When bound to a DataSet object, the DataGrid
    control displays the data from the dataset in a
    row and column format
  • Each field in the dataset appears in a column in
    the DataGrid control
  • Each record in the dataset appears in a row in
    the DataGrid control

26
Reconfiguring the DataAdapter Object
Figure 12-30 Procedure for reconfiguring an
existing DataAdapter object
27
More on Binding ControlsLesson B Objectives
  • Display a dataset in various controls in an
    interface
  • Position the record pointer in a dataset

28
Binding the DataSet Object to a Label Control or
a Text Box
Figure 12-33 Procedure for binding a DataSet
object to a label control or text box
29
Coding the Cartwright Industries Application
  • Carl Simons, the sales manager at Cartwright
    Industries, records the item number, name, and
    price of each product the company sells in a
    database named Items.mdb
  • Items.mdb database
  • Contains one table named tblItems
  • The Number and Name fields contain text, and the
    Price field contains numbers

30
Coding the Cartwright Industries Application
(continued)
Figure 12-37 Items.mdb database opened in
Microsoft Access
31
Coding the Cartwright Industries Application
(continued)
Figure 12-39 TOE chart for the Cartwright
Industries application
32
Creating Web Applications Using ASP.NETLesson C
Objectives
  • Define the terms used when talking about the Web
  • Create a Web application
  • Add controls to a Web form
  • Start a Web application

33
Creating Web Applications Using ASP.NET Lesson C
Objectives (continued)
  • Use the validator controls
  • Include a list box on a Web form
  • Determine whether a postback has occurred
  • Include a DataGrid control on a Web form

34
Web Terminology
  • The Internet is the worlds largest computer
    network, connecting millions of computers located
    all around the world
  • World Wide Web (WWW or the Web)
  • Part of the Internet
  • Consists of documents called Web pages that are
    stored on Web servers

35
Web Terminology (continued)
  • Web server computer that contains software that
    serves up Web pages in response to requests
    from clients
  • A client is a computer that requests information
    from a Web server
  • The information is requested and subsequently
    viewed through the use of a program called a Web
    browser (or simply, a browser)

36
Web Terminology (continued)
Figure 12-49 Illustration of the relationship
between a client, a browser, and a Web server
37
Web Terminology (continued)
  • Static Web page document whose purpose is merely
    to display information to the viewer
  • Dynamic Web page is interactive it can accept
    information from the user and also retrieve
    information for the user
  • Every Web page has a unique address called a URL
    (Uniform Resource Locator) that indicates its
    location on the Web

38
Creating Web Applications
  • Use a Web form to create a Web page in Visual
    Basic .NET
  • Create (or design) the Web page in the Web Form
    Designer window

39
Creating Web Applications (continued)
Figure 12-52 Procedure for creating a Web
application
40
Adding Controls to a Web Form
  • Use the tools contained in the Toolbox window to
    add controls to a Web form
  • The tools for a Web form are located on the Web
    Forms tab in the toolbox
  • Can add a control to a Web form by simply
    dragging the corresponding tool from the Web
    Forms tab to the form

41
Using the Web Validator Tools
  • These tools allow you to validate user input

Figure 12-65 The Web validator tools
42
Including a List Box on a Web Form
  • Use the ListBox tool on the Web Forms tab to add
    a list box to a Web form
  • Can use a list box on a Web form to display a
    list of choices from which the user can select
    one or more choices

43
Including a List Box on a Web Form (continued)
  • A postback refers to the client requesting data
    from the server, and the server responding
  • Each time a postback occurs, the Web page is
    redisplayed on the clients screen
  • Can use the Web forms IsPostBack property to
    determine if the Web form is being displayed for
    the first time or as a result of a postback

44
Including a DataGrid Control on a Web Form
  • DataGrid control displays the data from a dataset
    in a row and column format
  • Each field in the dataset appears in a column in
    the DataGrid control, and each record appears in
    a row
  • The DataGrid controls DataBind method is used to
    bind the control to the dataset

45
Including a DataGrid Control on a Web Form
(continued)
Figure 12-72 Web form for the Fairview
application
46
Including a DataGrid Control on a Web Form
(continued)
  • DataGrid control provides many properties to
    control the appearance of its output
  • DataGrid control provides an Auto Format dialog
    box that allows selection from a list of
    predefined formats, or schemes, for displaying
    data

47
Summary
  • To access a database from a Visual Basic .NET
    application, use the DataAdapter, Connection, and
    DataSet objects
  • Use SQL SELECT to specify the fields and records
    to view, and to control the order in which the
    fields and records appear when displayed
  • Use the Fill method to fill a dataset with data
    while an application is running

48
Summary (continued)
  • To bind a DataSet object to a DataGrid control
  • Set DataGrid controls DataSource property to the
    name of the DataSet object
  • Set DataMember property to the name of a table
  • To bind a DataSet object to a list box
  • Set the list boxs DataSource property to the
    name of the DataSet object
  • Set its DisplayMember property to the name of the
    table and field

49
Summary (continued)
  • To add a control to a Web form, use the tools on
    the Web Forms tab in the toolbox
  • To validate user input on a Web page, use one or
    more Web validator tools
  • To determine whether a postback has occurred, use
    the Web forms IsPostBack property
  • To bind a Web DataGrid control to a dataset, use
    the DataBind method
About PowerShow.com
