HILT IV Pilot Toolkit Demonstration

1
HILT IV Pilot Toolkit Demonstration

• Emma McCulloch
• Centre for Digital Library Research
• CIG 2008, Glasgow

2
Outline

• Background to HILT
• Pilot Toolkit
• various functions
• Value to services
• BUBL Intute
• Future of HILT

3
HILT Background

• HILT began in 2000
• Subject interoperability problem call a spade a
  spade!
• Distributed architecture
• SRU/W
• SKOS
• Pilot toolkit

4
Mapping Approach
Manual vs Automated
SKOS Limitations
LCSH
IPSV
High vs Deep Level Mapping
Local Schemes
MeSH
HASSET
Mapping Types
Folksonomies
5
HILT Toolkit

• http//hilt.cdlr.strath.ac.uk/hilt4/demonstrators.
  html
• http//linuxserv.cdlr.strath.ac.uk/hiltwiki/index.
  php/Web_Services_Links
• SRU Functions
• get_collections
• get_ddc_records
• get_non_ddc_records
• get_all_records
• get_filtered_set
• browse hierarchies
• get spelling / wordnet suggestions

6
(No Transcript)
7

• Result for get_collections (DDC 621.8)
• lt?xml version"1.0" encoding"UTF-8" ?gt
• - ltzssearchRetrieveResponse xmlnszs"http//www.
  loc.gov/zing/srw/"gt
•   ltzsversiongt1.1lt/zsversiongt
•   ltzsnumberOfRecordsgt1lt/zsnumberOfRecordsgt
• - ltzsrecordsgt
• - ltzsrecordgt
•   ltzsrecordPackinggtxmllt/zsrecordPackinggt
• - ltzsrecordDatagt
• - ltdcmitypeCollection xmlnscld"http//purl.org/
  cld/terms/" xmlnsdc"http//purl.org/dc/elements/
  1.1/" xmlnsdcmitype"http//purl.org/dc/dcmitype/
  " xmlnsdcterms"http//purl.org/dc/terms/"
  xmlnsiesr"http//iesr.ac.uk/terms/usesControlle
  dList" xmlnsxsi"http//www.w3.org/2001/XMLSchema
  -instance"gt
•   ltdctitlegtIntute Science, Engineering
  Technology Engineeringlt/dctitlegt
•   ltdcidentifier xsitype"dctermsURI"gthttp//www
  .intute.ac.uk/sciences/engineering/lt/dcidentifier
  gt
•   ltdctermsabstractgtThe Intute Engineering
  Gateway provides free access to high quality
  resources on the Internet. Each resource has been
  evaluated and categorised by subject specialists
  based at UK universities. Our target audience is
  students, staff and researchers in
  highlt/dctermsabstractgt
•   ltdccreatorgtIntutelt/dccreatorgt
•   ltdctype xsitype"dctermsDCMIType"gtCollectionlt
  /dctypegt
•   ltdcsubject xsitype"dctermsDDC"gt620lt/dcsubje
  ctgt
•   ltcldisAccessedViagthttp//www.intute.ac.uk/scien
  ces/cgi-bin/search.pl?gatewayEngineeringlimit0
  term1lt/cldisAccessedViagt
•   lt/dcmitypeCollectiongt

8
get_all_records

• Combines functions of get_ddc_records and
  get_non_ddc records
• Retrieves DDC numbers and captions relating to a
  term AND retrieves terms mapped to retrieved DDC
  numbers from other schemes.
• Accepts a subject term
• 2 stage process
• First retrieves ddc_records with mappings
  denoting IDs
• Then, on selecting get related concepts, IDs
  are supplemented with corresponding terms from
  satellite schemes (the next slide shows the
  latter part of this result)

9
- ltzsrecordgt   ltzsrecordPackinggtxmllt/zsrecordPa
ckinggt - ltzsrecordDatagt - ltskosConcept
xmlnsmap"http//www.w3.org/2004/02/skos/mapping
" xmlnsrdf"http//www.w3.org/1999/02/22-rdf-synt
ax-ns" xmlnsskos"http//www.w3.org/2004/02/skos
/core.rdf" rdfabout"http//hiltm2m.cdlr.strath.
ac.uk/hilt4/schemes/LCSH.rdf26434"gt
ltskosprefLabel xmllang"en"gtWeedslt/skosprefLabe
lgt   ltskosinScheme rdfresource"http//hiltm2m.
cdlr.strath.ac.uk/hilt4/schemes/LCSH.rdf" /gt
lt/skosConceptgt   lt/zsrecordDatagt
ltzsrecordPositiongt2lt/zsrecordPositiongt
lt/zsrecordgt ltzsrecordgt   ltzsrecordPackinggtxmllt/
zsrecordPackinggt - ltzsrecordDatagt -
ltskosConcept xmlnsmap"http//www.w3.org/2004/02
/skos/mapping" xmlnsrdf"http//www.w3.org/1999/
02/22-rdf-syntax-ns" xmlnsskos"http//www.w3.or
g/2004/02/skos/core.rdf" rdfabout"http//hiltm2
m.cdlr.strath.ac.uk/hilt4/schemes/UNESCO.rdf3724"
gt   ltskosprefLabel xmllang"en"gtWEED
CONTROLlt/skosprefLabelgt   ltskosinScheme
rdfresource"http//hiltm2m.cdlr.strath.ac.uk/hil
t4/schemes/UNESCO.rdf" /gt   lt/skosConceptgt
lt/zsrecordDatagt   ltzsrecordPositiongt7lt/zsrecord
Positiongt   lt/zsrecordgt
10
get_filtered_set

• Allows specified fields from specific
  terminologies or combinations of terminologies to
  be searched.
• Additional parameters can be selected e.g. NPT,
  RT
• Accepts a subject term

11
(Partial) result for pottery searching AAT
using get_filtered_set. Pref labels for BTs and
NTs can be retrieved by clicking get related
concepts when entering search term. ltzsrecordgt
ltzsrecordPackinggtxmllt/zsrecordPackinggt -
ltzsrecordDatagt - ltskosConcept
xmlnsrdf"http//www.w3.org/1999/02/22-rdf-syntax
-ns" xmlnsskos"http//www.w3.org/2004/02/skos/c
ore.rdf" rdfabout"http//hiltm2m.cdlr.strath.ac
.uk/hilt4/schemes/AAT.rdf300112569"gt
ltskosprefLabel xmllang"en"gtBritish Isles
Medieval pottery styleslt/skosprefLabelgt
ltskosbroader rdfresource"http//hiltm2m.cdlr.st
rath.ac.uk/hilt4/schemes/AAT.rdf300020794" /gt
ltskosnarrower rdfresource"http//hiltm2m.cdlr.s
trath.ac.uk/hilt4/schemes/AAT.rdf300069526" /gt
  ltskosinScheme rdfresource"http//hiltm2m.cdl
r.strath.ac.uk/hilt4/schemes/AAT.rdf" /gt
lt/skosConceptgt   lt/zsrecordDatagt
ltzsrecordPositiongt1lt/zsrecordPositiongt
lt/zsrecordgt - ltzsrecordgt   ltzsrecordPackinggtxml
lt/zsrecordPackinggt - ltzsrecordDatagt -
ltskosConcept xmlnsrdf"http//www.w3.org/1999/02
/22-rdf-syntax-ns" xmlnsskos"http//www.w3.org/
2004/02/skos/core.rdf" rdfabout"http//hiltm2m.
cdlr.strath.ac.uk/hilt4/schemes/AAT.rdf300106969"
gt   ltskosprefLabel xmllang"en"gtItalian
Medieval pottery styleslt/skosprefLabelgt
ltskosbroader rdfresource"http//hiltm2m.cdlr.st
rath.ac.uk/hilt4/schemes/AAT.rdf300106965" /gt
ltskosnarrower rdfresource"http//hiltm2m.cdlr.s
trath.ac.uk/hilt4/schemes/AAT.rdf300021115" /gt
  ltskosinScheme rdfresource"http//hiltm2m.cdl
r.strath.ac.uk/hilt4/schemes/AAT.rdf" /gt
lt/skosConceptgt   lt/zsrecordDatagt
ltzsrecordPositiongt2lt/zsrecordPositiongt
lt/zsrecordgt
12
Intute

• http//www.intute.ac.uk/socialsciences/hilt_search
  .html
• Enter search term
• Users get an option to view suggestions
• No source scheme information available in SKOS
  output

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
BUBL

• http//bubl.ac.uk/hilt4.htm
• Demonstrates
• Retrieval of relevant DDC hierarchies
• Collection retrieval
• Retrieval of scheme information
• Mapped terms
• Dynamic searching of remote service

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
HILT The Future

• JISC Shared Service
• Distributed approach
• Substantial mapping effort
• Link up with other terminology services?

23
Tell us what you think!

• http//linuxserv.cdlr.strath.ac.uk/hiltwiki/index.
  php/Web_Services_Links
• OR
• http//hilt.cdlr.strath.ac.uk/hilt4/demonstrators.
  html
• Emma McCulloch e.mcculloch_at_strath.ac.uk
• Dennis Nicholson d.m.nicholson_at_strath.ac.uk
• Anu Joseph anu.joseph_at_cstrath.ac.uk
• HILT-Collaborators http//www.jiscmail.ac.uk/
