Chapters 6 and 8 selections Virtual Memory and Parallel Processing

1
Chapters 6 and 8 (selections)Virtual Memory and
Parallel Processing

• CS 271 Computer Architecture
• Indiana University Purdue University Fort Wayne

2
The Operating System Machine Level

• This level is also known as the OSM level
• The OSM level consists of . . .
• Conventional ISM level machine language
  instructions
• Additional OSML instructions
• New conventional machine instructions reserved
  for use by the operating system
• Calls to operating system service routines (API
  calls)
• For example call to support reading a file
• We will focus on three areas
• Virtual memory
• Process concept
• Parallel computer architectures

3
Virtual memory

• The traditional solution to the problem of not
  enough memory was overlays
• The programmer would break a program into pieces
  called overlays
• Each overlay was small enough to fit into memory
• The first overlay was brought in
• When done, it was responsible for reading in the
  next overlay
• The programmer was responsible for all the
  details
• Virtual memory allows the operating system to use
  the hard disk to allow whatever RAM memory is
  available to appear to expand to the size of the
  address space allowed by the processor

4
Virtual memory

• The virtual address space of a computer is the
  set of addresses that make sense at the
  conventional machine level
• Typically depends on the number of bits used for
  addresses
• Examples
• The physical address space consists of the RAM
  memory addresses that are actually installed

5
Virtual memory

• Virtual addresses in a program must be mapped to
  physical addresses dynamically
• This means during run-time
• This requires a memory map
• A table relating a virtual address to the
  corresponding physical address
• Two common techniques are used
• Paging
• Segmentation
• We will only consider paging

6
Paged virtual memory

• The virtual address space is divided into 2m
  pages of fixed size 2n
• m n the number of physical address bits
• Virtual address
• Physical memory is logically divided into 2k page
  frames of the same fixed size 2n
• Of course, k lt m
• Any page may be loaded into any available page
  frame

m bits n
bits
page number displacement
within page
7
Pages and page frames
8
Paged virtual memory

• The operating system maintains a page table for
  each process
• The page table consists of page table entries (or
  PTEs)
• Entry n in the table is the PTE of page n
• The PTE of page n gives the page frame number
  where the page is loaded

9
The page table and PTEs

• The present / absent bit indicates if the page
  has been loaded
• 0 not loaded
• 1 loaded
• Sometimes called a residence bit or a valid bit

10
The page table and PTEs

• Pages 2, 4, 7, 9, 10, 12,13, and 15 are not
  presently loaded into memory

11
Address translation

• Address translation refers to mapping virtual
  addresses to physical addresses
• This is done by dynamically by the memory
  management unit (MMU)
• Given a virtual address let . . .
• p be the page number
• d be the displacement within the page

12
Address translation

• The MMU does the following
• Uses p to index into the page table to fetch the
  PTE
• If the residence bit is 1, then extract the frame
  number f
• This is a k-bit number
• The physical address is
• If the residence bit is 0, generate a page fault
• This is another type of internal interrupt
  similar to a trap
• It is not fatal, but just temporarily blocks the
  process

k bits n
bits
frame number f displacement d
within page
13
Diagram from Stallings, Operating Systems,
Internals and Design Principles, 4th ed.,
Prentice-Hall (2001)
14
Page fault handler

• The operating system page fault handler does the
  following
• Locates an empty page frame
• Finds the disk address for the missing page in a
  directory
• Activates the DMA to copy the needed page from
  the disk into the empty page frame
• Calls the operating system dispatcher routine to
  switch to another process
• This allows the processor to do something useful
  while the DMA is working

15
DMA interrupt handler

• When the DMA has completed the transfer, it
  issues an interrupt
• The interrupt handler for the DMA does the
  following
• Changes the residence bit in the PTE for the page
  to 1
• Places the new frame number in the PTE frame
  field
• Schedules the process that caused the page fault
  for later activation
• When the process resumes, it tries address
  translation as before and this time succeeds

16
Paged virtual memory

• Paging is transparent to the OSM level user
• It is implemented at the ISA level
• New ISA hardware must provide an automatic
  mechanism (the MMU hardware) to
• Either translate the mn bit virtual address to a
  kn bit physical address
• Or generate a page fault
• This requires an additional memory cycle for each
  memory reference in order to fetch the needed PTE
• More hardware may also be needed to facilitate
  this

17
Paged virtual memory

• When a page fault occurs, all page frames are
  typically full
• To make room for the needed page, one of the
  currently loaded pages must be sent back to the
  disk
• How the unlucky page is chosen in determined by a
  page replacement policy
• The ideal choice
• Choose the page that will be needed the farthest
  in the future, if at all
• Some page replacement algorithms
• LRU Least Recently Used
• FIFO First In First Out

18
LRU page replacement

• Swap out the Least Recently Used page
• This method performs well
• To implement LRU, time stamp each page frame
  whenever it is referenced
• A practical way to do this is to have a special
  memory cell associated with each page frame
• For every reference, increment a global counter
  and copy it into the special cell of the
  associated frame
• When a page needs to be replaced, the page fault
  handler searches for the frame with the lowest
  counter
• This involves overhead and costly hardware

19
FIFO page replacement

• Swap out the oldest loaded page
• Implement FIFO as follows
• Add a counter field to each PTE
• When a new page is loaded, set the PTE counter to
  0
• Whenever a page fault occurs, the page fault
  handler iterates through the page table and
  increments all of the PTE counters
• While doing this, the handler makes note of the
  page with the highest counter and chooses that
  page for replacement
• Implementation is much simpler than LRU
• But how would FIFO work in a grocery store?

20
Dirty pages

• If a page that is to be replaced has not been
  modified (written), it need not be copied back to
  disk
• The disk copy is an identical clean copy
• If the page has been modified, the disk copy is
  dirty
• The page in memory must be copied back to disk
• Bookkeeping
• Include an extra dirty bit in the PTE
• Initialize the dirty bit to 0
• Set the bit to 1 whenever there is a write to the
  page
• This could be implemented by the microcode for
  memory writes
• After a page fault, this bit determines whether
  the page needs to be copied back to disk

21
Parallel processing

• A large problem may sometimes be solved by
  distributing the computations over many CPUs that
  work on the problem simultaneously
• The best way to organize the activity is to
  decompose the activity into separate independent
  processes
• A process can be thought of as a running program
  together with all of its state information
• A process can be interrupted at any point and
  resumed later
• Each process runs on only one processor at a time
• At least in the simple case of a process
  consisting of a single thread
• A process can jump from one processor to another

22
Processes

• Typically, many processes are concurrently active
  on a computer
• Each process gives the illusion of running on a
  separate OSML computer
• OSML instructions allow process . . .
• Creation
• Termination
• Memory sharing and synchronization
• Blockage
• Scheduling
• Etc.

23
Processes

• The operating system needs to maintain state
  information for each process
• PSW
• PC
• Registers
• Stack
• Allocated address space (memory)
• Privilege
• Pending I/O activity
• Device ownership
• etc.

24
Process states

• At a given time, a process may be running, ready,
  or blocked

Running
Ready
dispatch
time out
block (event wait)
wake-up (event completion)
Blocked
25
Process states

• The ready state involves a queue of waiting
  processes
• A process makes a number of state transitions
  whenever there is a . . .
• Page fault
• Time-out
• I/O request
• A transition to the blocked state is the only
  transition that a process itself initiates

26
Concurrent processes

• Asynchronous concurrent processes . . .
• May collaborate on an application
• Need to communicate
• Need to synchronize
• Concurrent processes may run on . . .
• A single shared processor
• Simulated parallel processing
• Separate processors
• True parallel processing

27
Single processor execution

• Simulated parallel processing on a single
  processor is implemented using time slicing
• A time slice is a maximum time increment for a
  process

28
Single processor execution

• Each time slice terminates with a timer interrupt
• The interrupt handler . . .
• Saves the state of the interrupted process
• Enqueues the interrupted process in the ready
  queue
• Dequeues the next process to run from the ready
  queue
• Loads the state of the new process
• Transfers to the new process

29
Multiple processor execution

• Symmetric multiprocessing (SMP)
• Multiple processors share a common memory
• Each processor is equivalent
• If there are more processes than processors, then
  the CPUs must simulate parallelism with time
  slicing

CPU1
CPU2
CPU3
memory
CPU4
30
Parallel computer architectures

• High-level decomposition of parallel architectures

(a) On-chip parallelism (b) A coprocessor (c) A
multiprocessor (d) A multicomputer (e) A grid
31
Homogeneous multiprocessors on a chip

• (a) A dual-pipeline chip (Pentium 4
  hyperthreading)
• Allows resources (functional units) to be shared
• Does not scale up well
• (b) A chip with two cores
• A core is a complete CPU

32
Symmetric multiprocessors (SMP)

• (a) A multiprocessor with 16 CPUs sharing a
  common memory
• (b) An image partitioned into 16 sections, each
  being analyzed by a different CPU

33
Multicomputers

• (a) A multicomputer with 16 CPUs, each with its
  own private memory
• (b) The bit-map image of Fig. 8-17 split up among
  the 16 memories

34
Taxonomy of parallel computers
35
UMA symmetric multiprocessor architectures

• (a) Without caching
• (b) With caching
• (c) With caching and private memories

36
UMA multiprocessors using crossbar switches

• (a) An 8 8 crossbar switch
• (b) An open crosspoint
• (c) A closed crosspoint

37
Message-passing multicomputers

• A generic multicomputer

38
Interconnection network topologies

• The heavy dots represent switches (the CPUs and
  memories are not shown)
• (a) A star
• (b) A complete interconnect
• (c) A tree
• (d) A ring
• (e) A grid
• (f) A double torus
• (g) A cube
• (h) A 4D hypercube

39
Massively parallel processors (MPPs)

• Typical supercomputer
• Use standard CPUs
• Intel Pentium
• Sun UltraSPARC
• IBM PowerPC
• Set apart by a very high-performance proprietary
  interconnection network

40
BlueGene/L MPP

• The BlueGene/L custom processor
  chip
• Design goals
• Worlds fastest MPP
• Most efficient in terms of teraflops/dollar and
  terraflops/watt
• 65,536 dual-processor nodes configured as a 32 x
  32 x 64 3-D torus
• Peak 360 teraflops/sec (sustained 280.6
  teraflops/sec)
• 1.5 megawatts
• 2500 square feet floor space

41
BlueGene/L MPP
42
COWs (Cluster of Workstations)

• A cluster consists of dozens, hundreds, or
  thousands of PCs or workstations connected over a
  commercially-available network
• Two dominant types
• Centralized
• Typically all in one room
• Decentralized
• Connected by a LAN or the internet
• Google

43
Software metrics

• Real programs achieve less than the perfect
  speedup indicated by the dotted line
• Data from a multicomputer consisting of 64
  Pentium Pro CPUs
