Web Community Mining and Web log Mining : Commody Cluster based execution

1
Web Community Mining and Web log Mining Commody
Cluster based execution

• Romeo Zitarosa

2
Overview

• Introduction
• Web Community Mining
• Web log mining on MIS
• Parallel Data Mining on Pc Cluster
• Performance Evaluation
• Conclusion

3
Introduction

• Proposed two application of web mining
• 1) Extract web Communities
• 2) Understand Behaviour of Mobile
  Internet Users (Usage Mining)

4
Web Community Mining

• Web Community
• def A web Community is a collection of web
  pages created by individuals or association that
  have common interests on a specific topic.

5
Proposed technique

• Starts from a set o seed
• Based on RPA
• Create a Community Chart

6
Authorities and Hubs

• Authority page with good contents on a topic
  linked by many good hub pages.
• Hub page with a list of hyperlink to valuable
  pages on a topic, that points to good
  authorities.
• Community Core Authority Hubs

7
Web Community Mining

• Algorithm
• 1. Seed set
• 2. Apply RSA to each seed
• Built web subgraph and extract
  (using HITS) hubs and authority.
• 3. Investigate how seed derive other seed
  as related pages.

8
Example

• 1. Consider that s derives t as related
  page and vice versa.
• s and t are pointed to by
  similar set of hubs.
• 2. Consider that s derives t as related
  page and but t doesnt derives s.
• t is pointed to by many different
  hubs so t derives a different set of
  related pages

9
Observation

• In this way we define a symmertic derivation
  relationship for identify Communities.
• Def. Community Set of pages strongly connected
  by s.d.r.
• Two Communities are related if a member of one
  community derives a member of the other
  community.

10
Web Community Chart

• Def. Is a Graph that consist of communities as
  nodes and weighted edges between nodes.
• The weight represents the relevance of the
  community
• We need a tool to browse Communities

11
Web Community Chart(2)

• Label assigned manually
• Box list of URLs sorted by connectivity score.
• Def. Connectivity score
• number of derivation relatioship from the
  node to others node of the community.

12
Example
13
Mobile Info Search (MIS)

• NTT laboratories
• Goal provide location aware information from
  internet collecting, structuring, filtering and
  organizing.
• www.kokono.net

14
kokono

• There is a database-type resource between user
  and information souces (online maps,yellow pages,
  etc.)

15
MIS Functionalities

• User Location Acquisition
• - GPS,PHS,postal number
• Location Oriented Robot-Based Search(kokono)
• - search documents close to a location
• - display documents in order of distance
  written in the doc and user position
• Location Oriented Meta Search
• - backbone database accessed by CGI
  programs.

16
Association Rule Mining

• Support , confidence
• Hierarchy gt Taxonomy
• Hierarchy allow to find not only rules specific
  to a location but also wider area that covers
  that location.
• Identify Acces patterns of MIS users.
• Prefetch information.
• Reduce acces time.
• Spatial information gives valuabel information to
  mobile users.

17
Sequential Rule Mining

• Sequential Patterns
• Derive how different services are used together.
• Example
• Define the plan after checking the weather
• Submit_weather Wether Forecast ?
• subimit_shop Shop Info shop_web townpage
  ?
• Submit_kokono KOKONOSearch ? Submit_map MAP

18
Parallel DM and Pc Cluster

• Parallel Apriori
• - nodes keep all candidate itemsets
• - scan indipendently the dataset
• - comunicate only at the end of the phase
• Problem Too much memory used!!!
• Solution (Partial) Hash Partitioned Apriori
  (HPA).
• - candidates are partitioned using hash
  function
• - each node buils candidate Itemsets
• - a lot of disk I/O when support is small

19
Parallel Algorithm for Association Rule Mining

• Non partitioned generalized (NPGM)
• Hash Partitioned (HPGM)
• - reduce communications
• Hierarchical HPGM (H-HPGM)
• - candidate whoose root is identical allocated
  on the same node
• H-HPGM with Fine Grain Duplicates
• (H-HPGM-FGD)
• - use remaining free space

20
Performance evaluation

• Oss. Time increase when support becomes small

21
Conclusion

• Real web Mining application need high performance
  computing system
• Pc Cluster with his scalable performance (and
  high costs) is a promising platform
