Theoretical distributions Lorenz Wernisch

1
Theoretical distributionsLorenz Wernisch
2
Distributions as compact data descriptions

• 66
• 2463
• 933
• 1287
• 297
• 777
• 1431
• 954
• 588
• 567
• 714
• 591
• .....

List of numbers becomes organized in a
histogram distribution captures statistical esse
ntials
Gamma function with l 2.660301 s 358.4419
3
A scoring scheme

• Compare a new target (keyword, DNA sequence)
• with objects (HTML pages, known DNA sequences)
• in a database to find matching objects.
• Each comparison results in a score

database
scores
comparison
-46
target
-42
-59
-45
330
-53
4
Compare target score with rest of scores
The scores of unrelated (random) database hits
number
Score 330 lies here, way outside the heap
of random scores
scores
5
Fit a Normal (Gaussian) distribution
m -47.1
score s 330
s 20.8
6
Probability for high scores
The red area is the probability that a
random N(-47.1,20.8) distributed variable has
score gt 0 Prs gt 0 0.0117
7
Objectives

• At the end of the day you should be able to
• do some combinatorial counting
• mention one typical example for each of the
  following distributions Binomial, Poisson,
  Normal, Chi-square, t, Gamma, Extreme Value
• plot these distributions in R
• fit one of the above distributions to a set of
  discrete or continuous data using maximum
  likelihood estimates in R

8
How many ways are there to order numbers

• 3 numbers? 123, 213, ...
• 4 numbers using the result for 3 numbers?
• n numbers using the result for (n-1) numbers?

9
The subsets of size k in a set of size n
8
10

• How many subsets of k 3
• in set of n 10 elements?
• Idea
• enumerate all orderings
• take first three
• .......
• 3 7 5 1 10 9 4 2 3 8
• 3 5 7 1 10 9 4 2 3 8
• 5 7 3 9 4 3 1 10 8 2
• .......

9
5
3
4
7
1
2
6
How many orderings give the same result?
10
Binomial coefficient

• Number of choosing subsets of k from set of n
•
  n choose k
• Alternative form

11
Very simple the Bernoulli distribution

• A coin with two sides, side 0 (tail) and side 1
  (head),
• has been tested with thousands of throws
• 60 gives 0 40 gives 1
• P0 0.6 P1 0.4
• The coin is a Bernoulli variable X with p 0.4
• expectation
• variance

12
Flipping a coin

• What is the probability of the following runs?
• P0 1 0 1 1 0 0 0 1 0
• P1 1 0 0 0 0 1 0 0 1
• P0 0 0 1 1 1 0 1 0 0
• How many of such runs with four 1s exist?
• What is the total probability of four 1s in 10
  throws?

13
Binomial distribution
1 Experiment 100 coin tosses with p
Prside 1 0.4 expecting about 40 1s
(but not exactly 40) 1000 experiments (1000 x
100 coin tosses)
number of experiments out of 1000
number of 1s out of 100
14
R program for binomial plot

• generate 1000 simulations
• x lt- rbinom(1000,100,0.4)
• generate vector from 20 to 60
• z lt- 2060
• plot the histogram from 20 to 60
• with no labels
• hist(x,breaksz,xlab"",ylab"",main"",
• xlimc(20,60))
• draw points of binomial distribution
• for 1000 experiments, line width 2
• lines(z,1000dbinom(z,100,0.4),
• type"p",lwd2)

15
Binomial distribution
p 0.82

• Cumulative distribution
• function (cdf)
• probability density
• function (pdf)

binomial n 100 p 0.4
l 44
16
R functions for distributions

• Each distribution comes with a set of R
  functions.
• Binomial distribution with parameters
• n size, p prob
• probability density function, pdf
• dbinom(x,size,prob)
• cumulative distribution function, cdf
• pbinom(x,size,prob)
• generate random examples
• rbinom(number,size,prob)
• More information help(dbinom)

17
R program for two binomial plots

• make space for two plots
• par(mfrowc(2,1))
• z lt- 2060
• cdf first, s for cdf plot
• plot(z,pbinom(z,100,0.4),type"s")
• pdf next, h for vertical lines
• plot(z,dbinom(z,100,0.4),type"h")
• add some points, p for points
• lines(z,dbinom(z,100,0.4),type"p")
• one plot only in future
• par(mfrowc(1,1))

18
Binomial for large n and small p

• Number n of throws very large
• Tiny probability p for throwing a 1
• Expected number of 1s constant l np

n 50 p 0.06 l 3
0
1
n 100 p 0.03 l 3
0
1
19
Poisson distribution

• If, on average, one sees l heads between 0 and 1
  what is the probability of seeing k heads?
• Make grid between 0 and 1 finer and finer,
  keeping l np constant
• For example

requires some calculation with limit
20
Poisson distribution

• cdf
• pdf
• expectation
• variance
• ppois(x,lambda)
• dpois(x,lambda)
• rpois(n,x,lambda)

Poisson l 2.7
21
Application of Poisson database search

• Query sequence against database of
• random (that is, nonrelated) sequences
• p Prdatabase sequence looks significant,
  hit
• n number of sequences in database
• n is large and p is small, E-value l np
• Chance to get at least one wrong (random) hit

22
Normal distribution N(m,s)
PXlt7 0.841
Cumulative distribution function
Normal m 5, s 2
Probability density function
Expectation Variance
23
R program for two normal plots of N(5,2)

• par(mfrowc(2,1))
• z lt- seq(-2,12,0.01)
• plot(z,pnorm(z,5,2),type"l",frame.plotF,
• xlab"",ylab"",lwd2)
• plot(z,dnorm(z,5,2),type"l",frame.plotF,
• xlab"",ylab"",lwd2)
• plot the hashing of the pdf
• z lt- seq(-2,7,0.1)
• lines(z,dnorm(z,5,2),type"h")

• par(mfrowc(1,1))

24
Normal distribution as limit of Binomial

• increase n
• constant p
• Binomial
• Normal
• (less and less
• skewed)

25
Central limit theorem

• Independent random variables Xi all with the same
  distribution X EX m and VX s 2
• The sum
• is normal N(0,1) in the limit
• or equivalently density

26
Fitting a distribution

• 200 data points in histogram
• seem to come from
• normal distribution
• To fit a normal distribution
• N(m,s), we need to know
• two parameters m and s
• How to find them?

27
Maximum likelihood estimators (MLE)

• Density function f(x m,s)
• Sample x x1, x2, ..., xn from pdf f(x m,s)
• Likelihood for fixed sample depends on parameters
  m and s
• Log-likelihood
• We now try to find the m and s that maximize the
• likelihood or log-likelihood

28
MLE for normal distribution

29
MLE for normal distribution is simple

• For normal distribution the MLE of m and s is
• straightforward its just the mean and standard
• deviation of the data
• stepsize stsz of histogram, datavector x
• z lt- seq(min(x)-stsz,max(x)stsz,0.01)
• lines(z,
• length(x)stszdnorm(z,mean(x),sd(x)) )

30
Fitting a distribution by MLE in R

• Data points xi x lt- scan(numbers.dat)
• For each data point xi a density value f(xi m,s)
• We are looking for m and s that make all these
  density values as large as possible together
• Parameters m and s should maximize
• sum(log(dens(x,mu,sigma)))
• or minimize -sum(log(dens(x,mu,sigma)))

31
MLE for normal distribution in R

• define the function to minimize
• it takes a vector p of 2 parameters
• f.neglog lt- function(p)
• -sum(log(dnorm(x,p1,p2)))
• starting values for the 2 parameters
• start.params lt- c(0,1)
• minimize the target function
• mle.fit lt- nlm(f.neglog,start.params)
• get the estimates for the parameters
• mle.fitestimate

32
Points to notice about MLE in R

• The nlm algorithm is an iterative heuristic
  minimization algorithm and can fail!
• Choice of the right starting values for the
  parameters is crucial an initial guess from the
  histogram can help
• For location and scale parameters mean(x) and
  sd(x) is often a good guess
• Check the result by fitting the density function
  with the calculated parameters to the histogram

33
Exponential distributionExp(l)

• cdf
• pdf
• Expectation
• Variance
• pexp(x,lambda)
• dexp(x,lambda)
• rexp(n,x,lambda)

Exponential l 4
34
Exponential distribution and Poisson process

• The exponential distribution as limiting process,
  tiny probability p, many trials n for throwing a
  1 in the unit interval 0,1 l np
• How long does it take until the first 1?
• 18.1 chance of seeing a 1 in the indicated
  region

0
1
35
MLE estimate for exponential function

• Maximum likelihood estimate for l in
• 1)
• 2)
• 3) l

36
The Gamma function

• is the continuation of the factorial n! to real
  numbers
• and is used in many distribution functions
• Moreover,

37
Gamma distribution

• density function, pdf
• expectation
• variance
• pgamma(x,alpha,lambda)
• dgamma(x,alpha,lambda)
• rgamma(n,x,alpha,lambda)

Gamma a 3, l 4
38
Shape parameter of Gamma distribution
39
Gamma distribution and Poisson process

• The gamma distribution as limiting process tiny
  probability p, many trials n for throwing a 1 in
  the unit interval 0,1 l np
• How long does it take until the third 1?
• 0.11 chance of seeing three 1s in the indicated
  region

0
1
40
Example waiting times in a queue

• Time to service a person at the desk
• exponential with le 1/(average waiting
  time)
• If there are n persons in front of you, how is
  the time you have to wait distributed?
• It turns out the sum of n exponentially
  distributed
• variables (waiting time for each person) is
• Gamma distributed with a n and l le

41
Extreme value distribution

• cumulative distribution cdf
• probability density pdf
• No simple form for
• expectation and variance

Extreme Value m 3, s 4
42
Examples for Extreme Value Distribution EVD

• 1) An example from meteorology
• Wind speed is measured daily at noon
• Normal distribution around average wind speed
• Monthly maximum wind speed is recorded as well
• The monthly maximum wind speed does not follow a
  normal distribution, it follows an EVD
• 2) Scores of sequence alignments (local
  alignments) often follow an EVD

43
R code for Extreme Value distribution

• No predefined procedures for the EVD in R
• Replace for example
• pexval lt- function(x,mu0,sigma1)
• exp(-exp(-(x-mu)/sigma))
• dexval lt- function(x,mu0,sigma1)
• 1/sigmaexp((x-mu)/sigma)
• pexval(x,mu,sigma)
• pexval(x,3,4)
• dexval(x,3,4)

44
c2 distribution

• Standard normal random variables Xi, XiN(0,1),
• The variable
• has a cn2 distribution with n degrees of freedom
• density
• expectation
• variance

squared!
pchisq(x,n) dchisq(x,n) rchisq(num,x,n)
45
Shape of c2 distribution
is actually Gamma function with a n/2 and l
1/2

46
t distribution

• Z N(0,1) independent of U cn2
• then
• has a t distribution with n degrees of freedom
• density

pt(x,n) dt(x,n) rt(num,x,n)
47
Shape of t distribution
n 10
N(0,1)

• Approaches
• normal N(0,1)
• distribution
• for large n
• (n gt 20 or 30)

n 3
n 5
n 1
48
Fitting chi-squared ort distribution
w

• Need location parameter
• m and scale parameter s
• the new density is
• mu lt- 3
• sig lt- 2
• 1/sigdt((x-mu)/sig),3)

m
t with n 3
sw
m 3 s 2
49
MLE for t distribution

• function to minimize with 3 parameters
• p1 is m, p2 is s, p3 is n
• f.neglog lt- function(p)
• -sum(log(1/p2dt((x-p1)/p2,p3)))
• starting values for the 2 parameters
• start.params lt- c(0,1,1)
• minimize the target function
• mle.fit lt- nlm(f.neglog,start.params)
• get the estimates for the parameters
• mle.fitestimate
