The Application Layer

1
The Application Layer

• Chapter 7-3

Institute of Information Science and Technology .
Chengdu University YiYong 2008?2?25?
2
Teaching object

• Through this section of the study , student
  should be understand the basic concepts of the
  data link layer, on top of stop waiting for the
  agreement

3
Focus and Difficulties

• Multimedia

4
7.4 Multimedia

• Introduction to Audio
• Audio Compression
• Streaming Audio
• Internet Radio
• Voice over IP
• Introduction to Video
• Video Compression
• Video on Demand
• The MBone The Multicast Backbone

5
7.4.1 Introduction to Audio

• (a) A sine wave. (b) Sampling the sine wave.
  (c) Quantizing the samples to 4 bits.

6
7.4.2 Audio Compression

• (a) The threshold of audibility as a function of
  frequency.
• (b) The masking effect.

7
7.4.3 Streaming Audio

• A straightforward way to implement clickable
  music on a Web page.

8
Streaming Audio (2)
When packets carry alternate samples, the loss of
a packet reduces the temporal resolution rather
than creating a gap in time.
9
Streaming Audio (3)

• The media player buffers input from the media
  server and plays from the buffer rather than
  directly from the network.

10
Streaming Audio (4)

• RTSP commands from the player to the server.

11
7.4.4 Internet Radio

• A student radio station.

12
7.4.5 Voice over IP

• The H323 architectural model for Internet
  telephony.

13
Voice over IP (2)

• The H323 protocol stack.

14
Voice over IP (3)

• Logical channels between the caller and callee
  during a call.

15
SIP The Session Initiation Protocol

• The SIP methods defined in the core specification.

16
SIP (2)

• Use a proxy and redirection servers with SIP.

17
Comparison of H.323 and SIP
18
7.4.6 Video Analog Systems

• The scanning pattern used for NTSC video and
  television.

19
The JPEG Standard

• The operation of JPEG in lossy sequential mode.

20
The JPEG Standard (2)

• (a) RGB input data.
• (b) After block preparation.

21
The JPEG Standard (3)
(b)
(a)

• (a) One block of the Y matrix.
• (b) The DTC coefficients.

22
The JPEG Standard (4)

• Computation of the quantized DTC coefficients.

23
The JPEG Standard (5)

• The order in which the quantized values are
  transmitted.

24
The MPEG Standard

• Synchronization of the audio and video streams in
  MPEG-1.

25
The MPEG Standard (2)

• Three consecutive frames.

26
7.4.8 Video on Demand

• Overview of a video-on-demand system.

27
Video Servers

• A video server storage hierarchy.

28
Video Servers (2)

• The hardware architecture of a typical video
  server.

29
7.4.9 The MBone The Multicast Backbone

• MBone consists of multicast islands connected by
  tunnels.
