An Agile Vertical Handoff Scheme for
Heterogeneous Networks

• Hsung-Pin Chang
• Department of Computer Science
• National Chung Hsing University
• Taichung, Taiwan, R.O.C.

2
Outline

• Motivation
• Related work
• How to achieve seamless vertical handoff ?
• Challenge and Contribution
• How to pass NAT gateway ?
• How to adapt TCP behavior ?
• Experiments
• Conclusion

3
Outline

• Motivation
• Related work
• How to achieve seamless vertical handoff ?
• Challenge and Contribution
• How to pass NAT gateway ?
• How to adapt TCP behavior ?
• Experiments
• Conclusion

4
Hierarchical Overlay Network

• Many different communications systems coexist
  around us
• Ethernet, Wireless LAN, GPRS, 3G
• Each owns different characteristics
• Bandwidth, delay, cost
• Hierarchical overlay network
• The combination of these heterogeneous networks

5
Example An Overlay Networks
Campus-wide (3G, GPRS)
6
Horizontal versus Vertical Handoff

• Problem handoffs
• Horizontal handoff
• The same kind of network technology
• Ex BSS to BSS
• Vertical handoff
• Different kinds of network technologies
• Ex Wireless LAN to 3G

lt what we are addressed
7
Horizontal Handoff
BSS
BSS
AP
AP
Internet
8
Vertical Handoff
WCDMA
WLAN
AP
BS
Internet
9
Outline

• Motivation
• Related work how to achieve seamless vertical
  handoff ?
• Challenge and Contribution
• How to pass NAT gateway ?
• How to adapt TCP behavior ?
• Experiments
• Conclusion

10
Previous Approaches to Vertical Handoff 1/2

• Mobile IP/Infrastructure Based
• Approaches
• Mobile IP with multicast
• Care-of-address is changed to a multicast address
• Integration of WLAN and GPRS
• Integration of WLAN and 3G
• Problem
• Require modification of network infrastructure
• Hindrance to deployment
• Need to be keep up to data
• New technologies are always introduced

11
Previous Approaches to Vertical Handoff 2/2

• End-to-end based
• Application layer
• SIP (Session Initiation Protocol)
• Transport layer enable TCP connection alive even
  the underlying IP address is changed
• TCP-R
• TCP Migrate
• Between transport layer and network layer
• C. Guo, et. al., A Seamless and Proactive
  End-to-End Mobility Solution for Roaming Across
  Heterogeneous Wireless Networks, IEEE JSAC,
  22(5), pp.834-848. Jun. 2004

12
A Seamless and Proactive End-to-End Solutions for
Roaming Across Heterogeneous Wireless Networks
(1/4)
Network Applications
User
Kernel
Socket Interface
BSD Sockets
TCP
UDP
Transport Layer
LCT Table Translation
IP
Network Layer
PPP
SLIP
Ethernet
Network Devices
13
A Seamless and Proactive End-to-End Solutions for
Roaming Across Heterogeneous Wireless Networks
(2/4)
L A N
L A N
Original address Original port Mapped address Mapped port
A p1 C p2
Original address Original port Mapped address Mapped port
A p1 A p1
Original address Original port Mapped address Mapped port
A p1 C p2
Original address Original port Mapped address Mapped port
A p1 A p1

W L A N
Mobile Client
Fixed Host
14
A Seamless and Proactive End-to-End Solutions for
Roaming Across Heterogeneous Wireless Networks
(3/4)
Application
Application
A B
A B
Kernel
Kernel
Handoff Layer
Handoff Layer
Table Lookup
Table Lookup
C B
?3 ????????
15
A Seamless and Proactive End-to-End Solutions for
Roaming Across Heterogeneous Wireless Networks
(4/4)

• Problems
• NAT issue
• Require an S/N (Subscription/Notification) Server
• Modify the infrastructure
• TCP performance
• Do not consider

16
Outline

• Motivation
• Related work how to achieve seamless vertical
  handoff ?
• Challenge and Contribution
• How to pass NAT gateway ?
• How to adapt TCP behavior ?
• Experiments
• Conclusion

17
How to pass NAT gateway ?

• Problem
• Communication must always be initiated by the
  private network
• Solution
• Use the previous IP address as the source IP
  address

18
Problem
Fixed Host
New IP address
NAT
Switch
Ethernet
Update
WLAN
AP
19
Solution
Fixed Host
Old IP address
NAT
Switch
Ethernet
Update
WLAN
AP
20
Outline

• Motivation
• Related work how to achieve seamless vertical
  handoff ?
• Challenge and Contribution
• How to pass NAT gateway ?
• How to adapt TCP behavior ? gt CWND-Restore
• Experiments
• Conclusion

21
How to adapt TCP behavior ?

• Problem
• TCP consider packet loss as network congestion
• Slow down
• Butnow packet lose is because handoff
• Solution
• CWND-Restore

22
CWND-Restore
Fixed Host
CWND 20
CWND 2
CWND 50
NAT
Switch
Ethernet
WLAN
AP
23
Outline

• Motivation
• Related work how to achieve seamless vertical
  handoff ?
• Challenge and Contribution
• How to pass NAT gateway ?
• How to adapt TCP behavior ?
• Experiments
• Conclusion

24
System Implementation- Linux Kernel 2.6.11
Applications
User Mode
Kernel Mode
TCP
UDP
CWND-restore
Connection Manager
Handoff Detection
IP
Ethernet Driver
WLAN Driver
3G
25
Experimental Platform
Fixed Host Mobile Host
CPU AMD XP 2600 Intel Pentium M 1.4GHz
RAM 512 MB 256 MB
NIC 1 100Mbps Ethernet 100Mbps Fast Ethernet Ethernet
NIC 2 Philips 802.11g WLAN miniPCI Adapter
NIC 3 Novatel UMTS/WCDMA USB Adapter
26
Experiment 2/2

• Experiments
• TCP handoff verification
• Handoff latency
• TCP handoff performance
• UDP handoff verification

27
Experiment 2/2

• Experiments
• TCP handoff verification
• Handoff latency
• TCP handoff performance
• UDP handoff verification

28
TCP Handoff Verification 1/7
Experiment environment
29
TCP Handoff Verification 2/7

• LAN to WLAN

Handoff
30
TCP Handoff Verification 3/7

• WLAN to LAN

Handoff
31
TCP Handoff Verification 4/7

• LAN to WCDMA

Handoff
32
TCP Handoff Verification 5/7

• WCDMA to LAN

Handoff
33
TCP Handoff Verification 6/7

• WLAN to WCDMA

Handoff
34
TCP Handoff Verification 7/7

• WCDMA to WLAN

Handoff
35
Experiment 2/2

• Experiments
• TCP handoff verification
• Handoff latency
• TCP handoff performance
• UDP handoff verification

36
Handoff Latency 1/2
Experiment environment
37
Handoff Latency 2/2
Handoff Latency (ms)
LAN to WLAN 3
LAN to WCDMA 438
WLAN to LAN 1
WLAN to WCDMA 503
WCDMA to LAN 1
WCDMA to WLAN 3
38
Experiment 2/2

• Experiments
• TCP handoff verification
• Handoff latency
• TCP handoff performance
• UDP handoff verification

39
TCP Handoff Performance 1/8
Experiment environment
40
TCP Handoff Performance 2/8
Original (KB/s) CWND Freeze (KB/s)
WLAN to LAN 6154.8 7690.84
LAN to WLAN 177.58 244.87
WCDMA to LAN 2886.36 5059.62
WCDMA to WLAN 138.34 237.77
LAN to WCDMA 3.64 3.98
WLAN to WCDMA 3.47 4.12
41
TCP handoff performance 3/8

• LAN to WLAN

Handoff
42
TCP handoff performance 4/8

• WLAN to LAN

Handoff
43
TCP handoff performance 5/8

• LAN to WCDMA

Handoff
44
TCP handoff performance 6/8

• WCDMA to LAN

Handoff
45
TCP handoff performance 7/8

• WCDMA to WLAN

Handoff
46
TCP handoff performance 8/8

• WLAN to WCDMA

Handoff
47
Experiment 2/2

• Experiments
• TCP handoff verification
• Handoff latency
• TCP handoff performance
• UDP handoff verification

48
UDP Handoff Verification 1/3

• Experiment environment

Internet
Switch
2. LAN
AP
FH
1. WLAN
MH
49
UDP Handoff Verification 1/3
Internet
Switch
AP
B
Mobile Host
A
WLAN
Fixed Host
Ethernet
WLAN
50
UDP Handoff Verification 2/3

• LAN to WLAN

Handoff
51
UDP Handoff Verification 3/3

• WLAN to LAN

Handoff
52
Outline

• Introduction
• Hierarchy Overlay Network
• Horizontal v.s. Vertical Handoff
• Challenge
• How to achieve seamless vertical handoff ?
• How to pass NAT gateway ?
• How to adapt TCP behavior ?
• How to adapt application behavior ?
• Experiments
• Conclusion

53
Conclusion

• A Vertical Handoff framework
• Support NAT while follows the end-to-end
  discipline
• Without an modification to infrastructure
• Improve TCP performance
• CWND Freeze
• At most 2.3 times the original TCP
