More HSR, OpenGL Buffers

1
More HSR,OpenGL Buffers Tests

• Glenn G. ChappellCHAPPELLG_at_member.ams.org
• U. of Alaska Fairbanks
• CS 481/681 Lecture Notes
• Monday, February 2, 2004

2
ReviewAdvanced HSR Methods 1/2

• Most HSR methods fall into one of two categories
  object-space methods and image-space methods.
• Object-Space Methods
• Here, we do HSR before rasterization.
• Often outside the pipeline entirely.
• We deal with scene descriptions (polygons?).
• Image-Space Methods
• Here, we deal with fragments or pixels.
• Thus, if part of a pipeline, image-space methods
  generally come during or after rasterization.
• General advantages of object-space methods
• Not limited by frame-buffer resolution.
• Most can be used as a pre-processing step.
• General advantages of image-space methods
• Fewer requirements usable more often.
• Usually faster, for scenes with high polygon
  count.

3
ReviewAdvanced HSR Methods 2/2

• Last time we looked at four image-space HSR
  methods
• Z-buffering.
• A.K.A. depth buffering.
• Very general.
• A-buffering (not in text)
• Store list of fragments in each pixel of A
  buffer.
• Render final scene as post-processing step.
• Very general, but not used much.
• Ray Casting
• Send a ray through each pixel. See what it hits
  first.
• Requires a scene description.
• Ray tracing is a fancier version of this.
• Scan-Line Method
• Proceed across scan line, keeping list of
  relevant polygons.
• With each new pixel, adjust list depths of
  polygons.
• Requires a scene description.
• An important method, back before
  rendering-pipeline hardware.

4
More HSRIntro. to Object-Space Methods

• Now we look at five object-space HSR methods.
• Here, we deal with objects or polygons before
  rasterization.
• Object-space methods require a scene description,
  so
• Their applicability is not as general as that of,
  say, z-buffering.
• They do not fit well within a rendering pipeline
  however, they can often be done before the
  pipeline.
• Object-space methods generally require
  comparisons between polygons.
• Thus, high polygon count can slow them down.
• Many object-space methods do make good
  pre-processing steps, however.
• First, an exception.

5
More HSR5. Backface Culling

• If a polygon faces away from the viewer, cull it.
• In other words, toss it out do not rasterize it.
• If all objects are closed surfaces bounding
  convex regions, and no object covers another,
  then backface culling does HSR for us.
• We do this after projection.
• Why?
• In OpenGL
• glCullFace(GL_BACK)
• glEnable(GL_CULL_FACE)
• Properties
• Object space.
• Works just fine in a pipeline.
• Not general at all, of course.
• Rarely is backface culling, by itself, enough to
  accomplish HSR for a scene.
• But we can use it with some other method, to
  improve efficiency.

6
More HSR6. Generic Object-Space HSR

• For each polygon, clip it so that only its
  visible region remains.
• Tricky
• No, Im not going to tell you how. ?
• Properties
• Object-space method.
• Main loop runs over polygons.
• Polygon-polygon comparisons required. Can be
  slow.
• Requires a scene description.
• So do it before the pipeline.
• Does not handle translucency.

7
More HSRNote on Painters Algorithm

• A generally useful technique is the Painters
  Algorithm.
• Method
• Draw back-to-front.
• New fragment colors replace old pixel colors.
• This does HSR.
• But we need to figure out how to draw
  back-to-front.
• The P.A. also handles translucency nicely we use
  blending.
• Closely related is the Reverse Painters
  Algorithm.
• Method
• Draw front-to-back.
• Only set a pixels color once.
• We cannot do translucency with the R.P.A.
• Now we look at ways to draw in back-to-front
  order.
• Front-to-back just reverses this, of course.

8
More HSR7. Depth Sort

• Sort polygons by their depth.
• How can this be a problem?
• Some collections of polygonscannot be sorted.
• In such cases we split apolygon.
• No details right now.
• Maybe implement this aspart of a project?
• Properties
• Object-space method.
• Main loop runs over polygons.
• Polygon-polygon comparisons required. Can be
  slow.
• Requires a scene description.
• Works with P.A. R.P.A.

1
4
1
2
3
3
2
9
More HSR8. BSP Trees

• We know how to get a back-to-front order with a
  BSP tree.
• So we do it.
• This is really just a fancy (but relatively easy)
  way to accomplish a depth sort.
• However, we may split polygons more often than we
  need to.
• Properties
• Object-space method.
• Main loop runs over polygons.
• Polygon-polygon comparisons required.
  Construction is slow.
• BSP-tree construction works well as a
  preprocessing step, as long as the scene is
  mostly static.
• Requires a scene description.
• Works with P.A. R.P.A.

10
More HSRTossing Out Polygons

• With a couple of small exceptions, all of the HSR
  methods we have discussed have a big problem
• They require every polygon in the scene to be
  rendered.
• For large, complex scenes, there are often huge
  areas we cannot see.
• For example, wandering around in a building, you
  cannot see most of the rooms.
• We could greatly improve efficiency if we could
  throw out polygons in hidden regions.
• A recent method that addresses this problem is
  portal rendering.

11
More HSR9. Portal Rendering 1/3

• A recently introduced method is portal rendering.
• Introduced in 1995 by David P. Luebke and Chris
  Georges.
• Now implemented in many game engines.
• This is not in the text.
• Method
• Divide the scene into cells (a.k.a. sectors or
  rooms).
• A cell is, roughly speaking, a room.
• Cells contain polygons.
• Some of these polygons are portals.
• A portal joins two cells.
• Portal polygons are often completely transparent
  (invisible).
• When rendering, adjoining cells are placed, using
  the proper transformations, behind the
  appropriate portals.
• Or do ray tracing rays that hit a portal go
  through to another cell.
• Cell that do not (potentially) appear are not
  referenced at all.
• This is not a complete HSR method.
• Some other method must be used to do HSR within a
  cell.
• However, portal rendering can dramatically
  improve efficiency of HSR.

12
More HSR9. Portal Rendering 2/3

• Consider the following cell-portal data
  structure.
• Portals are in red.
• This results in the following logical arrangement
  of cells.

To C
Cell 2
Cell 1
Cell 3
A
D
To B
B
To D
C
To A
Cell 2
Cell 3
B
D
C
Cell 1
A
13
More HSR9. Portal Rendering 3/3

• Portal rendering can easily be extended in
  interesting ways.
• Suppose a portal leads from cell 1 into cell 1,
  at the same portal, with a transformation that
  reflects the cell about the plane of the portal.
• Result
• Suppose a portal leads from cell 2 into the
  opposite end of cell 2. We look into cell 1 from
  cell 3.
• Result
• Generally, portals need not join cells in a
  reasonable fashion.
• Also, unlike structures like BSP trees, the
  cell-portal data structure can easily be modified
  on the fly.
• Thus, portal rendering has no problem with
• Elevators.
• Rooms that are bigger than the buildings they lie
  inside.
• Rips in the fabric of space, or whatever
• Is there a project hidden in here somewhere?

14
OpenGL Buffers TestsOverview

• We next look at various tools provided by OpenGL
• Buffers
• Tests
• Blending
• Part of the OpenGL philosophy is to provide tools
  without dictating their use.
• These tools can be used in many ways.
• Often the name (depth buffer) suggests the most
  common use, but there is nothing wrong with
  using a tool quite differently.

15
OpenGL Buffers TestsBuffers

• An OpenGL buffer is (essentially) an array that
  holds one piece of data for each pixel in the
  viewport.
• OpenGL has 4 types of buffers
• Color buffers
• Depth buffer
• Stencil buffer
• Accumulation buffer
• Each buffer has an intended function however,
  you may use the buffers in any way you wish.
• In order to be used, a buffer must be allocated.
• Do this in your glutInitDisplayMode call.

16
OpenGL Buffers TestsTests

• Related to the buffers are the OpenGL tests
• Scissor test
• Alpha test
• Depth test
• Stencil test
• A test is an expression with a boolean value that
  OpenGL evaluates for every fragment.
• If the result is true, then the test passes, and
  the fragment continues down the pipeline.
• Otherwise, the test fails, and fragment is
  discarded.
• All tests are done in the fragment-processing
  part of the pipeline.
• In order to have any effect, a test must be
  enabled.
• Do this with glEnable.

17
OpenGL Buffers TestsBuffers Tests Together

• Buffers and tests are associated.
• We have already seen this with the depth buffer
  test.
• Remember Allocate buffers enable tests!

Buffer Corresponding Test
-- Scissor Test
Color Buffers Alpha Test
Depth Buffer Depth Test
Stencil Buffer Stencil Test
Accumulation Buffer --
18
OpenGL Buffers TestsClearing

• Every OpenGL buffer can be cleared.
• In each case, the command to do this is the same
  glClear.
• The buffers to clear are specified by
  bitwise-oring together the appropriate
  GL__BUFFER_BIT constants. For example,glClear(G
  L_COLOR_BUFFER_BIT GL_DEPTH_BUFFER_BIT
  GL_STENCIL_BUFFER_BIT
  GL_ACCUM_BUFFER_BIT)
• The value to store in each pixel of a buffer is
  set by a separate command for each
  bufferglClearColorglClearDepthglClearStencil
  glClearAccum

19
OpenGL Buffers TestsMasking 1/2

• Most buffers have masks associated with them.
• The mask determines whether a buffer (or part of
  a buffer) is ever written.
• For example, the color-buffer mask is controlled
  by the glColorMask command.
• This command takes 4 parameters, all GLbooleans,
  representing R, G, B, and A, respectively.
• For example,glColorMask(false, true, true,
  true)means that the R portion of the color
  buffer will not be changed.
• Note The mask affects all commands that would
  change the buffer, even glClear.

20
OpenGL Buffers TestsMasking 2/2

• In masking.cpp, I define five bool variables
  redmask, greenmask, bluemask, depthmask,
  clearall.
• Each defaults to true and is toggled by pressing
  the first letter in its name.
• The interesting part of the code is at the start
  of function display
• if (clearall)
• glColorMask(true, true, true, true)
• glDepthMask(true)
• glClear(GL_COLOR_BUFFER_BIT
  GL_DEPTH_BUFFER_BIT)
• glColorMask(redmask, greenmask, bluemask, true)
• glDepthMask(depthmask)
• if (!clearall)
• glClear(GL_COLOR_BUFFER_BIT
  GL_DEPTH_BUFFER_BIT)

21
OpenGL Buffers TestsThe Scissor Test

• The scissor test is by far the simplest of the
  tests.
• It allows you to restrict drawing to a
  rectangular portion of the viewport.
• To enable glEnable(GL_SCISSOR_TEST)
• Then glScissor(x, y, width, height)
• Parameters are as in the glViewport command.
• (x,y) is the lower-left corner of the rectangle.
• The scissor test passes if the pixel is within
  the rectangle otherwise, it fails.
• The scissor test is really just a quick, simple
  version of stenciling.
• We discuss stenciling later this week.
